Influence of Lead-Zinc Tailing Sand on Acoustic Emission Characteristics of Concrete under Uniaxial Compression Tests
-
摘要:
为了研究尾矿砂骨料混凝土的力学特性，对4种铅锌尾砂含量的混凝土开展单轴压缩实验，同时获取了压缩过程中的声发射信号，基于声发射信号对材料损伤演化特征进行了评价。结果表明：混凝土试件的变形过程分为弹性、塑性、断裂破坏和残余变形4个主要阶段；随着铅锌尾砂取代率增加，抗压强度有增大趋势，并在超过30%后趋于稳定；根据声发射实验得到了损伤因子与应变的关系曲线；普通混凝土结构损伤主要在塑性变形阶段，尾矿砂改性混凝土的结构性损伤集中在塑性和断裂破坏阶段；一定比例的铅锌尾砂有助于加速水化凝胶物的形成，从而增强强度和变形性能。
Abstract:In order to study the mechanical properties of tailings aggregate concrete, uniaxial compression tests were carried out on concrete with four kinds of lead-zinc tailing sand, and the acoustic emission signals during compression were obtained, and the damage evolution characteristics of the material were evaluated based on the acoustic emission signals. The results show that the deformation process of concrete specimens can be divided into four main stages: elastic, plastic, fracture and residual deformation. With the increase of replacement ratio of lead-zinc tailing sand, the compressive strength increases and becomes stable after more than 30%. The relation curve between damage factor and strain was obtained by acoustic emission test. The structural damage of ordinary concrete is mainly in the plastic deformation stage while the structural damage of tailing sand modified concrete is mainly in the plastic and fracture failure stage. A certain proportion of lead-zinc tailing sand helps to accelerate the formation of hydrated gels, thus enhancing the strength and deformation properties.
-
Key words:
- Concrete /
- Lead-Zinc Tailing sand /
- Stress and strain /
- Damage characteristics /
- Acoustic emission
-
-
表 1 粗细骨料的基本物理特性
Table 1. Basic physical index of coarse and fine aggregate
骨料类别 碎石 河砂 尾矿砂 密度 /(g·cm-3) 2.65 2.68 2.80 透水率/% 0.95 1.02 0.75 细度模数 4.60 3.28 2.04
下载: 导出CSV
表 2 混凝土的配合比
Table 2. Mix proportion of concrete
组别 取代率 /% 单位体积的质量 /(kg·m-3) 外加剂/% TS NS G C F AA WA 1# 0 0 780 1285 580 120 0.1 0.4 2# 15 117 663 1285 580 120 0.1 0.4 3# 30 234 546 1285 580 120 0.1 0.4 4# 45 351 429 1285 580 120 0.1 0.4
下载: 导出CSV
-
[1] 李萌, 周庆立, 白丽梅, 等. 机械力化学效应提高铁尾矿活性实验研究[J]. 矿产综合利用, 2021(1):179-185. doi: 10.3969/j.issn.1000-6532.2021.01.030
LI M, ZHOU Q L, BAI L M, et al. Experimental study on improving the activity of iron tailings by mechanochemical effect[J]. Multipurpose Utilization of Mineral Resources, 2021(1):179-185. doi: 10.3969/j.issn.1000-6532.2021.01.030
[2] 吕兴栋, 刘战鳌, 朱志刚, 等. 尾矿作为水泥和混凝土原材料综合利用研究进展[J]. 材料导报, 2018, 32(S2):452-456.
LV X D, LIU Z A, ZHU Z G, et al. Research progress on comprehensive utilization of tailings as raw materials for cement and concrete[J]. Materials Review, 2018, 32(S2):452-456.
[3] 李建涛, 崔杰, 王之宇. 利用商洛钼尾矿制备混凝土保温砌块的试验研究[J]. 新型建筑材料, 2015, 42(3):80-83. doi: 10.3969/j.issn.1001-702X.2015.03.021
LI J T, CUI J, WANG Z Y. Experimental study on preparation of concrete thermal insulation blocks using Shangluo molybdenum tailings[J]. New Building Materials, 2015, 42(3):80-83. doi: 10.3969/j.issn.1001-702X.2015.03.021
[4] 张晋, 贺爱平, 李国栋, 等. 钙镁质磷矿选矿尾矿综合利用技术现状及展望[J]. 矿产综合利用, 2021(2):199-203. doi: 10.3969/j.issn.1000-6532.2021.02.034
ZHANG J, HE A P, LI G D, et al. Status and prospect of comprehensive utilization technology of calcium-magnesium phosphate tailings[J]. Multipurpose Utilization of Mineral Resources, 2021(2):199-203. doi: 10.3969/j.issn.1000-6532.2021.02.034
[5] 郭庆华, 郤保平, 李志伟, 等. 混凝土声发射信号频率特征与强度参数的相关性试验研究[J]. 中南大学学报(自然科学版), 2015, 46(4):1482-1488.
GUO Q H, XI B P, LI Z W, et al. Experimental study on the correlation between frequency characteristics and intensity parameters of concrete acoustic emission signals[J]. Journal of Central South University(Natural Science Edition), 2015, 46(4):1482-1488.
[6] 王笑然, 王恩元, 刘晓斐, 等. 混凝土损伤演化声发射和超声波时-频-空联合响应[J]. 中国矿业大学学报, 2019, 48(2):268-277. doi: 10.13247/j.cnki.jcumt.000981
WANG X R, WANG E Y, LIU X F, et al. Acoustic emission and ultrasonic time-frequency-space joint response of concrete damage evolution[J]. Journal of China University of Mining and Technology, 2019, 48(2):268-277. doi: 10.13247/j.cnki.jcumt.000981
[7] 赖于树, 熊燕, 程龙飞. 受载混凝土破坏全过程声发射信号频带能量特征[J]. 振动与冲击, 2014, 33(10):177-182. doi: 10.13465/j.cnki.jvs.2014.10.034
LAI Y S, XIONG Y, CHENG L F. Energy characteristics of acoustic emission signal bands in the whole process of loaded concrete failure[J]. Vibration and Shock, 2014, 33(10):177-182. doi: 10.13465/j.cnki.jvs.2014.10.034
[8] 于江, 吕旭滨, 秦拥军, 等. 基于声发射技术的再生混凝土梁受弯过程的损伤特性研究[J]. 混凝土, 2020(8):27-31. doi: 10.3969/j.issn.1002-3550.2020.08.007
YU J, LV X B, QIN Y J, et al. Research on damage characteristics of recycled concrete beams during bending process based on acoustic emission technology[J]. Concrete, 2020(8):27-31. doi: 10.3969/j.issn.1002-3550.2020.08.007
-
