摘要:
本文从药剂组合的理念出发，以煤油作为辅助捕收剂部分替代价格昂贵的十二胺，配制不同组成的十二胺-煤油混溶捕收剂，研究了该药剂的对尖山铁矿以及石英纯矿物的分选规律，通过显微图像分析了混溶捕收剂的作用机理，并通过闭路流程实验与传统药剂十二胺进行了对比。结果表明：混溶捕收剂中十二胺的较佳比例为40%，在这个比例下，煤油的增效效果最明显；煤油的加入强化了细粒石英的聚团过程显著提高了细粒级石英的回收率；通过闭路流程实验，以十二胺-煤油作为捕收剂，可以得到TFe品位68.57%，回收率96.72%的铁精矿。与传统阳离子捕收剂十二胺相比，十二胺-煤油选择性更优兼具经济效益，具有良好的应用价值。
Abstract:In this study, a comparison of traditional cationic collector dodecylamine (DDA) and miscible DDA-Kerosene to the flotation performance of Jianshan ore was discussed based on the concept of reagent combination that kerosene was used as the auxiliary collector and partly replaced expensive DDA. To explore the relationship between DDA-Kerosene composition and mineral flotation performance on the reverse flotation of Jianshan ore, the characteristics of the flotation product were analyzed. The results showed that the floatability of the floating material increased with the DDA consumption increased. Specifically, during the flotation process, the fine quartz (-0.074 mm fraction) would selectively float with DDA-Kerosene. The results showed that the optimal ratio of dodecylamine was 40%, and kerosene had the most obvious effect. The addition of kerosene significantly increased the recovery of fine -0.038 mm quartz. Through the closed-circuit process test, using dodecylamine and kerosene as the collector, the iron concentrate with TFe grade of 68.57% recovery rate of 96.72% can be obtained. DDA-Kerosene with the characteristic of better selectivity and economy had a good application value in the future.
-
Key words:
- Kerosene /
- Synergy /
- Agglomeration /
- Separation result
-
-
表 1 尖山铁矿化学多元素分析结果/%
Table 1. Results of multi-elements chemical analysis of Jianshan ore
TFe Fe3O4 SiO2 Al2O3 CaO MgO Na2O P FeO MnO S K2O 63.65 87.65 10.187 0.26 0.31 0.33 0.019 0.015 27.48 0.039 0.026 0.0061
下载: 导出CSV
表 2 尖山铁矿筛析结果
Table 2. Basic properties of Jianshan ore sample
粒级/mm 产率/% 品位/% 分布率 /% Fe SiO2 Fe SiO2 +0.074 3.62 44.35 44.82 2.51 15.72 0.045−0.074 27.95 59.11 16.62 25.89 44.98 0.038−0.045 23.86 65.18 8.02 24.37 18.53 -0.038 44.57 67.61 4.81 47.23 20.78 合计 100.00 63.81 10.33 100.00 100.00
下载: 导出CSV
-
[1] 陈超, 张裕书, 李潇雨, 等. 钛磁铁矿选矿技术研究进展[J]. 矿产综合利用, 2021(3):99-105. CHEN C, ZHANG Y S, LI X Y, et al. Research progress in titanium-magnetite beneficiation technology[J]. Multipurpose Utilization of Mineral Resources, 2021(3):99-105.
[2] 汤优优, 喻连香, 陈雄. 重介质选矿技术在处理有色金属矿和非金属矿的研究现状及展望[J]. 矿产综合利用, 2021(4):118-124. TANG Y Y, YU L X, CHEN X. Research status and prospects of heavy medium beneficiation technology in treating non-ferrous and non-metallic ores[J]. Multipurpose Utilization of Mineral Resources, 2021(4):118-124. doi: 10.3969/j.issn.1000-6532.2021.04.018
[3] 谢广元, 边炳鑫, 张明旭, 等. 选矿学 [M]. 徐州: 中国矿业大学出版社, 2001.
XIE G Y, BIAN B X, ZHANG M X, et al. Mineral processing technology [M]. Xuzhou: China University of Mining and Technology Press, 2001.
[4] 李凤久, 孔亚然, 贾清梅, 等. 磁化处理影响浮选的机理及其在浮选中的应用[J]. 矿产综合利用, 2021(3):120-126. LI F J, KONG Y R, JIA Q M, et al. Mechanism of magnetization effect on flotation and its application in flotation[J]. Multipurpose Utilization of Mineral Resources, 2021(3):120-126. doi: 10.3969/j.issn.1000-6532.2021.03.019
[5] 谢才秀, 张永菊, 龙涛, 等. 不同实验设计方法在高灰分煤泥浮选优化实验中的应用[J]. 矿产综合利用, 2021(1):72-76. XIE C X, ZHANG Y J, LONG T, et al. Application of different experimental design method in the flotation optimization experiments of high ash coal slime[J]. Multipurpose Utilization of Mineral Resources, 2021(1):72-76. doi: 10.3969/j.issn.1000-6532.2021.01.011
[6] Liu An, Fan Minqiang, Li Zhihong, et al. Non-polar oil assisted DDA flotation of quartz I: interfacial interaction between dodecane oil drop and mineral particle[J]. International Journal of Mineral Processing, 2017, 168:1-8. doi: 10.1016/j.minpro.2017.09.004
[7] Liu An, Fan Minqiang, Li Zhihong, et al. Non-polar oil assisted DDA flotation of quartz II: Effect of different polarity oil components on the flotation of quartz[J]. International Journal of Mineral Processing, 2017, 168:25-34. doi: 10.1016/j.minpro.2017.09.003
[8] Liu An, Fan Minqiang, Li Zhihong. Synergistic effect of a mixture of dodecylamine and kerosene on separation of magnetite ore[J]. Physicochemical Problem of Mineral Processing, 2016, 52(2):647-661.
[9] Liu An, Fan Minqiang, Fan Panpan. Interaction mechanism of miscible DDA-Kerosene and fine quartz and its effect on the reverse flotation of magnetic separation concentrate[J]. Minerals Engineering, 2014, 65:41-50. doi: 10.1016/j.mineng.2014.05.008
[10] 刘安. 非极性油辅助十二胺混溶捕收剂提效机理研究[D]. 太原: 太原理工大学, 2015.
LIU A. The synergistic mechanism of non-polar oil assisted DDA miscible collector used in the reverse flotation of magnetite[D]. Taiyuan: Taiyuan University of Technology, 2015.
[11] 李磊, 金建文, 肖仪武, 等. 影响攀西某磁铁矿精矿品质的矿物学因素分析[J]. 矿产综合利用, 2021(4):193-196. LI L, JIN J W, XIAO Y W, et al. Researches of mineralogical factors affecting the quality of a magnetite concentrate in Panxi Area[J]. Multipurpose Utilization of Mineral Resources, 2021(4):193-196. doi: 10.3969/j.issn.1000-6532.2021.04.031
[12] 卢寿慈, 翁达. 矿物分选原理及应用[M]. 北京: 冶金工业出版社, 1992.
LU S C, WENG D. Mechanism and application of interfacial separation of particles[M]. Beijing: Metallurgical Industry Press, 1992.
-
