Research on the Application of a New Low-Temperature Collector DGT-P in Qidashan Iron Ore Reverse Flotation Process
-
摘要:
在实验室自主研发的新型组合型捕收剂DGT-P体系下，针对齐大山铁矿选矿分厂的混合磁选精矿进行了浮选实验研究，确定了较佳的药剂制度，并考查了浮选效率。在矿浆温度20 ℃、pH值=10.0、捕收剂DGT-P用量800 g/t、抑制剂玉米淀粉用量1200 g/t、不添加活化剂的条件下，经过 “一粗一精一扫”的浮选闭路实验，针对铁品位为48.22%的浮选给矿，可获得精矿铁品位69.23%及铁回收率91.52%的良好浮选指标。本研究表明新型低温捕收剂DGT-P是一种高效、选择性高的低温浮选捕收剂，该药剂的推广与应用将会有效解决我国铁矿阴离子反浮选过程中能源浪费问题。
Abstract:With the newly developed compound collector DGT-P, flotation tests were carried out for the mixed magnetic separation concentrates of Qidashan iron ore. The optimum reagent regime was determined and the flotation efficiency was investigated. Under the conditions of pulp temperature 20 ℃, pH value=10.0, collector DGT-P dosage 800 g/t, inhibitor corn starch dosage 1200 g/t and no activator added, good flotation indexes of 69.23% concentrate iron grade and 91.52% iron recovery were obtained through the closed circuit process with "one coarse, one fine and one sweep". This study shows that DGT-P is an efficient and highly selective low-temperature collector, which could effectively solve the problem of energy waste in the anionic reverse flotation of iron ores in China.
-
Key words:
- Flotation /
- Low-temperature collector /
- Compound collector /
- Iron ore
-
-
表 1 齐大山铁矿混合磁选精矿的化学多元素分析/%
Table 1. Chemical analysis of the mixed concentrates from the magnetic separation of Qidashan iron ore
TFe FeO SiO2 Al2O3 MgO CaO 48.22 13.55 30.82 0.16 0.74 0.15
下载: 导出CSV
表 2 齐大山铁矿混合磁选精矿的铁物相分析
Table 2. Iron phase analysis of the mixed concentrates from the magnetic separation of Qidashan iron ore
名称 磁铁矿
中铁赤褐铁
矿中铁碳酸铁
中铁硫化铁
中铁硅酸铁
中铁TFe 含量/% 40.21 6.59 0.78 0.18 0.52 48.22 占有率/% 83.39 13.67 1.62 0.37 1.08 100.00
下载: 导出CSV
表 3 实验中所需的化学试剂
Table 3. Chemical reagents used in the tests
试剂名称 主要成分 试剂纯度 用途 盐酸 HCl 分析纯 pH值调整剂 氢氧化钠 NaOH 分析纯 pH值调整剂 玉米淀粉 (C6H10O5)n 工业纯 抑制剂 氯化钙 CaCl2 化学纯 活化剂
下载: 导出CSV
表 4 浮选开路实验结果
Table 4. Results of the open-circuit flotation test
产品名称 产率/% 铁品位/% 铁回收率/% 精矿 58.30 68.65 83.01 中矿1 6.13 55.86 7.10 中矿2 3.32 53.34 3.67 尾矿 32.25 9.30 6.22 合计 100.00 48.22 100.00
下载: 导出CSV
表 5 浮选闭路实验结果
Table 5. Results of the closed-circuit flotation test
产品名称 产率/% 铁品位/% 铁回收率/% 精矿 63.74 69.23 91.52 尾矿 36.26 11.28 8.48 合计 100.00 48.22 100.00
下载: 导出CSV
-
[1] 林祥辉, 路平, 陈让怀, 等. 高效新品种捕收剂RA-315的制取及应用研究[J]. 矿冶工程, 1993(9):31. LIN X H, LU P, CHEN R H, et al. Study on the preparation and application of a new efficient collector RA-315[J]. Mining and Metallurgical Engineering, 1993(9):31.
[2] 赵立群, 王春女, 张敏, 等. 中国铁矿资源勘查开发现状及供需形势分析[J]. 地质与勘探, 2020, 56(3):635-643. ZHAO L Q, WANG C N, ZHANG M, et al. Analysis on the supply and demand situation and the current situation of exploration and development of China's iron ore resources[J]. Geology and Prospecting, 2020, 56(3):635-643.
[3] 罗光明. 耐低温捕收剂TA-19在李楼铁矿的研究及应用[J]. 矿业工程, 2020, 18(5):41-44. LUO G M. Research and application of a low-temperature collector TA-19 on Lilou iron ore[J]. Mining Engineering, 2020, 18(5):41-44. doi: 10.16672/j.cnki.kygc.2020.05.012
[4] 郭文达, 朱一民, 王鹏, 等. 新型酰胺基羧酸捕收剂DWD-1用于铁矿反浮选试验研究[J]. 矿产保护与利用, 2016 (3): 22-25+39.
GUO W D, ZHUY M, WANG P, et al. Experimental study on the application of a new amide carboxylic acid collector DWD-1 in reverse flotation of iron ore [J] Mineral Protection and Utilization, 2016 (3): 22-25+39.
[5] 任建蕾. DTX体系下东鞍山含碳酸盐铁矿石常温浮选行为研究[D]. 沈阳: 东北大学, 2013.
REN J L. Flotation behavior on carbonate-containing iron ore of Donganshan under the system of DTX at room temperature[D]. Shenyang: Northeastern University, 2013.
[6] 薛敏. 齐大山铁矿开采矿石工艺矿物学及可选性研究[J]. 金属矿山, 2010(5):86-88. XUE M. Study on the mineralogy and beneficiablity of Qidashan iron ore[J]. Metal Mine, 2010(5):86-88.
[7] 周永锋, 罗溪梅, 宋水祥, 等. 四种阳离子捕收剂对赤铁矿和石英浮选行为的影响[J]. 矿产保护与利用, 2020, 40(2):56-61. ZHOU Y F, LUO X M, SONG S X, et al. Effects of four cationic collectors on the flotation behavior of hematite and quartz[J]. Conservation and Utilization of Mineral Resources, 2020, 40(2):56-61. doi: 10.13779/j.cnki.issn1001-0076.2020.02.008
[8] H Sahoo, S S Rath, B Das. Use of the ionic liquid tricapryl methyl ammonium salicylate (TOMAS) as a flotation collector of quartz [J]. Sep. Purif. Technol. 2014, 136: 66-73.
[9] 朱一民, 陈金鑫, 任建蕾, 等. 新型捕收剂DTX-1常温分步浮选东鞍山铁矿混合磁选精矿[J]. 金属矿山, 2014(7):61-64. ZHU Y M, CHEN J X, REN J L, et al. Stepwise flotation with a new collector DTX-1 at room temperature for the mixed magnetic separation concentrates of Donganshan iron ore[J]. Metal Mine, 2014(7):61-64.
[10] 刘宗丰. 赤铁矿反浮选DKZ-1捕收剂的合成及性能研究[D]. 沈阳: 东北大学, 2010.
LIU Z F. Synthesis and collection mechanism of new collector DKZ-1 on reverse floatation of hematite[D]. Shenyang: Northeastern University, 2010.
[11] 梅建庭, 赫荣安, 杨威. KS-Ⅱ捕收剂的设计和合成及应用[J]. 矿业工程, 2009(5):26-28. MEI J T, HE R A, YANG W. Design, synthesis and application of collector KS-Ⅱ[J]. Mining Engineering, 2009(5):26-28. doi: 10.3969/j.issn.1671-8550.2009.05.010
-
