湖北某磷矿选矿实验研究

王建国; 周丽君; 李宏建

doi:10.3969/j.issn.1000-6532.2023.05.027

湖北某磷矿选矿实验研究

中国瑞林工程技术股份有限公司，江西　南昌　330000

详细信息

作者简介: 王建国（1982-），男，高级工程师，主要从事选矿工艺及药剂研究

中图分类号: TD97

收稿日期: 2022-12-31

刊出日期: 2023-10-25

Research on Beneficiation of a Phosphate Ore in Hubei Province

China Nerin Engineering Co., Ltd, Nanchang, Jiangxi, China

Received Date: 31 December 2022

Publish Date: 25 October 2023

摘要

摘要:
这是一篇矿物加工工程领域的论文。湖北某磷矿中的MgO和倍伴氧化物含量过高，对后续湿法磷酸工艺危害较大。针对该矿石特性，实验开发了“擦洗分级—光电选矿—正反浮选”联合工艺流程，常温条件下，闭路实验可以获得综合精矿P₂O₅品位33.52%、MgO含量0.82%、倍半氧化物(Fe₂O₃+Al₂O₃)含量2.84%、P₂O₅回收率95.69%的良好指标。同时擦洗分级和光电选矿能预先获得产率为72.88%的合格精矿，能够大幅度地减少进入磨浮作业的矿石量和细粒尾矿产生量，经济环境效益显著。
- 矿物加工工程 /
- 磷矿 /
- 擦洗分级 /
- 光电选矿 /
- 浮选
Abstract:
This is an essay in the field of mineral processing engineering. Contamination of MgO and R₂O₃ emanating from dolomite and silicate in phosphate ore from Guizhou province has been a problem in phosphate ore processing. This study explored Scrubbing classification- Optoelectronic beneficiation- froth flotation to remove dolomite and silicate away from this phosphate ore. The phosphate minerals could be concentrated to 33.52% P₂O₅, with a recovery of 95.69%, and the content of MgO reduced to 0.82%, the content of Fe₂O₃+Al₂O₃ reduced to 2.84%. Additionally, scrubbing classification and photoelectric beneficiation can obtain qualified concentrate with a yield of 72.88%, which can greatly reduce the amount of ore entering the flotation operation and reduce the beneficiation cost.
- Mineral processing engineering /
- Phosphate ore /
- Scrubbing classification /
- Optoelectronic beneficiation /
- Flotation

HTML全文

图 1 磷矿样品偏光显微镜照片

Figure 1.

下载: 全尺寸图片幻灯片

图 2 选矿实验流程

Figure 2.

下载: 全尺寸图片幻灯片

图 3 光电分选产品

Figure 3.

下载: 全尺寸图片幻灯片

图 4 磨矿细度与浮选指标关系曲线

Figure 4.

下载: 全尺寸图片幻灯片

图 5 碳酸钠用量实验结果

Figure 5.

下载: 全尺寸图片幻灯片

图 6 硅酸盐抑制剂对比实验结果

Figure 6.

下载: 全尺寸图片幻灯片

图 7 正浮选捕收剂用量实验结果

Figure 7.

下载: 全尺寸图片幻灯片

图 8 浮选矿浆质量浓度实验结果

Figure 8.

下载: 全尺寸图片幻灯片

图 9 反浮选捕收剂QS-29用量实验结果

Figure 9.

下载: 全尺寸图片幻灯片

表 1 原矿化学多元素分析结果/%

Table 1. Chemical multi-element analysis results of the raw ore

P₂O₅	MgO	SiO₂	Fe₂O₃	Al₂O₃	CaO	F	K₂O	NaO	I
30.84	1.24	12.45	1.15	3.12	41.96	2.78	0.55	0.32	0.008

下载: 导出CSV

表 2 原矿石擦洗-分级实验结果

Table 2. Test results of scrubbing-grading of raw ore

粒级/ mm	产率/ %	主要化学成分含量/%					P₂O₅回收率/%
粒级/ mm	产率/ %	P₂O₅	MgO	Al₂O₃	Fe₂O₃	SiO₂	P₂O₅回收率/%
+60	8.35	24.80	0.47	5.93	1.32	23.19	6.72
-60+40	8.20	28.79	0.41	3.78	0.97	17.62	7.65
-40+20	15.85	31.26	1.36	2.19	0.99	11.70	16.07
-20+10	18.95	32.64	0.91	2.32	1.32	9.79	20.05
-10+5	16.06	32.18	1.07	2.45	0.96	10.04	16.76
-5+2	8.33	33.19	1.07	2.13	0.97	9.03	8.96
-2+1	5.85	32.55	1.11	2.10	1.03	8.81	6.17
-1+0.45	3.62	33.87	1.01	2.03	0.99	8.14	3.98
-0.45+0.3	2.16	35.39	0.81	1.64	0.84	6.81	2.47
-0.30+0.15	4.22	35.18	0.69	1.73	0.81	7.04	4.81
-0.15+0.106	1.34	34.97	0.74	2.08	0.91	9.01	1.52
-0.106+0.075	1.05	32.66	0.81	2.33	1.06	10.08	1.11
-0.075+0.038	1.49	29.68	1.25	3.20	1.43	14.03	1.43
-0.038	4.53	15.58	1.47	11.23	1.58	27.98	2.29
合计	100.00	30.84	1.10	3.08	1.10	12.41	100.00

下载: 导出CSV

表 3 原矿擦洗-分级产品归类结果

Table 3. Product classification results of scrubbing-grading test of raw ore

类别	粒级/mm	产率/%	主要化学成分含量/%
类别	粒级/mm	产率/%	P₂O₅	MgO	Al₂O₃	Fe₂O₃	SiO₂
光电选原矿	-60+10	43.00	31.40	0.98	2.55	1.13	11.99
筛分精矿	-10+0.074	42.63	33.13	1.00	1.98	0.95	9.02
筛分尾矿	+60	8.35	24.80	0.47	5.93	1.32	23.19
筛分尾矿	-0.074	6.01	19.06	1.35	9.25	1.54	24.53
合计		100.00	30.84	1.10	3.08	1.10	12.41

下载: 导出CSV

表 4 -60+10 mm粒级矿石光电分选实验结果

Table 4. Test results of photoelectric separation of -60+10 mm size ore

产品名称	作业产率/%	主要化学成分含量/%					P₂O₅作业回收率/%
产品名称	作业产率/%	P₂O₅	MgO	Al₂O₃	Fe₂O₃	SiO₂	P₂O₅作业回收率/%
精矿	70.36	33.70	0.81	1.96	1.00	8.64	75.40
尾矿	29.64	26.10	1.09	5.32	1.41	18.45	24.60
合计	100.00	31.45	0.95	2.98	1.12	11.55	100.00

下载: 导出CSV

表 5 温度对浮选精矿影响实验结果

Table 5. Test results of temperature influence on flotation indexes

温度/ ℃	CB-102用量/ （g/t）	产率/ %	P₂O₅品位/ %	P₂O₅回收率/ %
15	2667	87.15	26.24	94.31
25	1667	86.36	26.14	93.80
35	1000	87.68	25.98	94.49
45	667	89.52	25.86	96.14

下载: 导出CSV

表 6 抑制剂条件实验结果

Table 6. Inhibitor condition test results

抑制剂/ （g/t）	产品名称	作业产率/%	品位/%					P₂O₅作业回收率/%
抑制剂/ （g/t）	产品名称	作业产率/%	P₂O₅	MgO	SiO₂	Fe₂O₃	Al₂O₃	P₂O₅作业回收率/%
硫酸 8056	精矿	93.06	31.47	0.49	6.83	0.85	1.37	99.30
	尾矿	6.94	2.98	15.84				0.70
	合计	100.00	29.49	1.56				100.00
磷酸 6111	精矿	93.01	31.84	0.38	6.31	0.76	1.19	99.33
	尾矿	6.99	2.85	16.86				0.67
	合计	100.00	29.81	1.53				100.00
磷酸 1333 硫酸 6667	精矿	93.50	31.19	0.53	6.58	0.92	1.39	99.34
	尾矿	6.50	3.00	15.80				0.66
	合计	100.00	29.35	1.52				100.00

下载: 导出CSV

表 7 全流程实验结果

Table 7. Results of full-process test

产品名称	产率/ %	品位/%					P₂O₅回收率/%
产品名称	产率/ %	P₂O₅	MgO	Al₂O₃	Fe₂O₃	SiO₂	P₂O₅回收率/%
光电选精矿	30.25	33.70	0.81	1.96	1.00	8.64	33.04
筛分精矿	42.63	33.13	1.00	1.98	0.95	9.02	45.76
浮选精矿	15.21	34.28	0.35	1.56	0.80	7.15	16.89
正浮选尾矿	9.75	12.85	0.32				4.06
反浮选尾矿	2.15	3.58	7.58				0.25
合计	100.00	30.86	0.92				100.00
综合精矿	88.09	33.52	0.82	1.90	0.94	8.57	95.69

下载: 导出CSV

参考文献(12)

[1]	张卫峰. 中国、美国、摩洛哥磷矿资源优势及开发战略比较分析[J]. 自然资源学报, 2005(3):378-386. ZHANG W F. Comparative analysis of the superiority of China’s phosphate rock and development strategies with that of the United states and Morocco[J]. Journal of Natural Resources, 2005(3):378-386. ZHANG W F. Comparative analysis of the superiority of China’s phosphate rock and development strategies with that of the United states and Morocco[J]. Journal of Natural Resources, 2005(3): 378-386.
[2]	蔡忠俊, 罗惠华, 吴洁, 等. 晋宁低品位胶磷矿剪切絮凝浮选[J]. 矿产综合利用, 2019(6):49-54. CAI Z J, LUO H H, WU J, et al. Shearing flocculation flotation of low-grade collophanite in Jinning[J]. Multipurpose Utilization of Mineral Resources, 2019(6):49-54. CAI Z J, LUO H H, WU J, et al. Shearing flocculation flotation of low-grade collophanite in Jinning[J]. Multipurpose Utilization of Mineral Resources, 2019(6): 49-54.
[3]	余永富, 葛英勇, 潘昌林. 磷矿选矿进展及存在的问题[J]. 矿冶工程, 2008(1):29-33. YU Y F, GE Y Y, PAN C L. Progress and problem s in beneficiation of phosphorite ores[J]. Mining and Metallurgical Engineering, 2008(1):29-33. YU Y F, GE Y Y, PAN C L. Progress and problem s in beneficiation of phosphorite ores[J]. Mining and Metallurgical Engineering, 2008(1): 29-33.
[4]	王涛, 付磊, 李宁. 某硅钙质胶磷矿正反浮选试验研究[J]. 矿产综合利用, 2020(2):91-95. WANG T, FU L, LI N. Study on direct-reverse flotation of a silica calcinate phosphate ore[J]. Multipurpose Utilization of Mineral Resources, 2020(2):91-95. WANG T, FU L, LI N. Study on direct-reverse flotation of a silica calcinate phosphate ore[J]. Multipurpose Utilization of Mineral Resources, 2020(2): 91-95.
[5]	曾理, 姜小明. Gemini表面活性剂体系下钙质磷矿中白云石的可浮性研究[J]. 矿产综合利用, 2020(1):83-88. ZENG L, JIANG X M. Study on the floatability of dolomite in calcareous phosphate rock under Gemini surfactant system[J]. Multipurpose Utilization of Mineral Resources, 2020(1):83-88. ZENG L, JIANG X M. Study on the floatability of dolomite in calcareous phosphate rock under Gemini surfactant system[J]. Multipurpose Utilization of Mineral Resources, 2020(1): 83-88.
[6]	程亮, 马志军, 邵坤, 等. 辽宁某低品位磷矿选矿实验研究[J]. 矿产综合利用, 2021(1):99-103. CHENG L, MA Z J, SHAO K, et al. Experimental study on beneficiation of a low-grade phosphate ore in Beipiao, Liaoning Province[J]. Multipurpose Utilization of Mineral Resources, 2021(1):99-103. CHENG L, MA Z J, et al. Experimental study on beneficiation of a low-grade phosphate ore in Beipiao, Liaoning Province [J]. Multipurpose Utilization of Mineral Resources, 2021(1): 99-103.
[7]	徐伟, 张仁忠, 田言, 等. 贵州某碳酸盐型磷矿反浮选脱镁提磷试验研究[J]. 化工矿物与加工, 2018, 47(4):1-3. XU W, ZHANG R Z, TIAN Y, et al. Experimental study on reverse flotation for removing magnesium and extracting phosphorus from a carbonate phosphate ore in Guizhou[J]. Industrial Minerals & Processing, 2018, 47(4):1-3. XU W, ZHANG R Z, TIAN Y, et al. Experimental study on reverse flotation for removing magnesium and extracting phosphorus from a carbonate phosphate ore in Guizhou[J]. Industrial Minerals & Processing, 2018, 47(4): 1-3.
[8]	吴中贤, 姜效军, 陶东平. 新型胶磷矿反浮选脱硅阳离子捕收剂试验研究[J]. 矿产综合利用, 2020(5):115-119. WU Z X, JIANG X J, TAO D P. Experimental study on a novel cationic collector for reverse flotation of collophane for silica removal[J]. Multipurpose Utilization of Mineral Resources, 2020(5):115-119. WU Z X, JIANG X J, TAO D P. Experimental study on a novel cationic collector for reverse flotation of collophane for silica removal[J]. Multipurpose Utilization of Mineral Resources, 2020(5): 115-119.
[9]	杜令攀, 陈赐云, 钟晋, 等. 浅析磷矿选矿技术进展与问题对策[J]. 化工矿物与加工, 2016, 45(1):57-61. DU L P, CHEN C Y, ZHONG J, et al. Brief analysis of phosphate beneficiation technology progress and problem countermeasures[J]. Industrial Minerals & Processing, 2016, 45(1):57-61. DU L P, CHEN C Y, ZHONG J, et al. Brief analysis of phosphate beneficiation technology progress and problem countermeasures[J]. Industrial Minerals & Processing, 2016, 45(1): 57-61.
[10]	郭文宾. 金属阳离子对磷矿反浮选及泡沫稳定性影响的研究[D]. 武汉: 武汉理工大学, 2017. GUO W B. Effect of Metal cation on reverse flotation and flotation foam of phosphate ore[D]. Wuhan: Wuhan University of Technology, 2017.
[11]	曾小波, 葛英勇. 胶磷矿阳离子反浮选泡沫行为调控研究[J]. 化工矿物与加工, 2008(1):1-3. ZENG X B, GE Y Y. Control of foam behavior in reverse flotation with Cationic collector for phosphate rock[J]. Industrial Minerals & Processing, 2008(1):1-3. ZENG X B, GE Y Y. Control of foam behavior in reverse flotation with Cationic collector for phosphate rock[J]. Industrial Minerals & Processing, 2008(1): 1-3.
[12]	朱一民, 陈通, 闫啸, 等. 新型磷灰石常温捕收剂的浮选试验研究[J]. 矿产综合利用, 2017(6):39-43. ZHU Y M, CHEN T, YAN X, et al. Collecting performance of new collectors on apatite at room temperature[J]. Multipurpose Utilization of Mineral Resources, 2017(6):39-43. doi: 10.3969/j.issn.1000-6532.2017.06.009 ZHU Y M, CHEN T, YAN X, et al. Collecting performance of new collectors on apatite at room temperature[J]. Multipurpose Utilization of Mineral Resources, 2017(6): 39-43. doi: 10.3969/j.issn.1000-6532.2017.06.009
