Experimental Study on Disposal of Chromium-containing Sludge by Sintering
-
摘要:
这是一篇冶金工程领域的论文。钢铁企业在钢板涂镀过程中产生的含铬污泥属于危险废物，其含有一定量的铁和氧化钙，可以通过烧结工艺对其进行资源化利用。本文以含铬污泥为研究对象，通过烧结杯实验探究了含铬污泥在烧结中的应用及影响，并对烧结完成后铬元素的分布情况进行了研究。烧结杯实验结果表明，该方案是可行的。含铬污泥的加入会促进烧结矿中复合铁酸钙相的形成，有利于改善烧结矿的性能。在含铬污泥配比不超过2.5%时，烧结矿的成品率、利用系数和转鼓指数均会有所提高，返矿率和平均粒径会有所降低。在烧结过程中，84%～90%的铬会被固定在烧结矿中，9%～14%会被固定在返矿中，仅不足1%进入烟尘。由此可见，烧结工艺协同处置含铬污泥不会产生二次污染，可以充分发挥钢铁企业的环保效能。
Abstract:This is an article in the field of metallurgical engineering. The chromium-containing sludge produced by iron and steel enterprises in the process of steel plate coating is a hazardous waste. It contains a certain amount of iron and calcium oxide, which can be used as a resource through the sintering process. In this paper, chromium-containing sludge was taken as the research object. The application and influence of chromium-containing sludge in sintering were investigated by sintering cup test, and the distribution of chromium element after sintering was studied.The results of sintering pot tests showed that the scheme was feasible.The addition of chromium-containing sludge could promote the formation of complex calcium ferrite phase and improve the performance of sinter. When the ratio of chromium-containing sludge in sintering mixture was less than 2.5%, the yield and utilization coefficient of sinter increased, the drum index also increased, and the return rate and average particle size decreased. During the sintering process, chromium was rarely diffused, and 84～90%, 9%～14% and less than 1% would be fixed in the sinter, return ore, and into the smoke dust, respectively. Overall, the sintering process synergistic treatment of chromium-containing sludge would not produce secondary pollution, which had promising application as an environmental protection strategy for iron and steel enterprises.
-
-
表 1 含铬污泥化学成分/%
Table 1. Chemical composition of chromium-containing sludge
Cr Cr6+ TFe SiO2 CaO MgO Na2O Cr2O3 Al2O3 FeO S Cl- K2O 水分 3.27 0.000 016 9.49 28.06 26.27 1.57 2.85 4.78 4.15 9.34 2.29 0.42 0.092 43.9
下载: 导出CSV
表 2 国内铬渣主要化学成分/%
Table 2. Main chemical composition of chromium slags in China
Cr2O3 Cr6+ Fe2O3 SiO2 CaO MgO Al2O3 3～8 0.5～1.5 6～15 5～15 25～35 20～35 6～13
下载: 导出CSV
表 3 含铬污泥的破碎后粒度
Table 3. Particle size of crushed chromium-containing sludge
粒径/mm -0.5 -1+0.5 -3+1 -5+3 -8+5 -10+8 +10 粒度分布/% 7.7 2.8 20.0 19.1 37.6 7.6 5.2
下载: 导出CSV
表 4 烧结原料的主要化学成分/%
Table 4. Main chemical composition of sintered raw materials
TFe SiO2 Al2O3 CaO MgO 水分 返矿 56.01 4.85 1.61 10.65 2.07 0.00 镁石 - 7.54 0.56 2.02 43.51 5.34 石灰石 - 2.46 0.63 51.97 1.1 1.18 煤焦 - 8.23 4.41 0.81 0.21 4.83 生石灰 - 2.69 0.77 65.35 3.07 0.00 铁精粉1 61.03 4.43 1.72 <0.01 <0.01 8.76 铁精粉2 66.47 5.49 - - - 10.32 尘泥 50.26 4.87 1.16 9.92 1.76 0.22 铁精粉3 59.61 4.45 2.34 <0.1 0.12 0.44
下载: 导出CSV
表 5 烧结燃料的工业分析/%
Table 5. Industrial analysis of sintering fuels
项目 C固 灰分 挥发分 Ig H2O 焦粉 82.12 16.86 0.76 82.88 0.26
下载: 导出CSV
表 6 实验配料方案/%
Table 6. Test proportion scheme
编号 1（基准） 2 3 4 5 6 7 返矿 21.40 21.40 21.40 21.40 21.40 21.40 21.40 镁石 2.76 2.73 2.71 2.69 2.67 2.64 2.62 石灰石 7.04 7.16 7.27 7.36 7.47 7.56 7.67 煤焦 4.20 4.31 4.42 4.42 4.44 4.44 4.47 生石灰 3.44 3.40 3.38 3.36 3.33 3.31 3.27 铁精粉1 15.29 15.16 15.00 14.91 14.78 14.67 14.56 铁精粉2 21.40 21.20 21.02 20.87 20.69 20.53 20.38 尘泥 9.18 9.09 9.00 8.93 8.87 8.80 8.73 铁精粉3 15.29 15.05 14.80 14.56 14.35 14.15 13.90 含铬污泥 0.00 0.50 1.00 1.50 2.00 2.50 3.0 合计 100.00 100.00 100.00 100.00 100.00 100.00 100.00
下载: 导出CSV
表 7 烧结矿粒度组成/%
Table 7. Particle size of sintering
配比 +40 mm -40+25 mm -25+16 mm -16+10 mm -10+5 mm 平均粒径/mm -5 mm返矿率 0% 15.40 23.42 26.24 19.91 15.04 23.2 17.0 0.5% 11.57 25.16 27.18 21.73 14.36 22.9 12.6 1.0% 11.14 25.93 27.80 21.16 13.97 22.9 9.1 1.5% 9.06 28.45 27.53 20.63 14.33 22.7 13.0 2.0% 11.75 23.43 28.37 21.19 15.27 22.6 13.9 2.5% 9.69 25.37 31.50 20.37 13.06 22.7 9.6 3.0% 5.10 21.75 32.85 25.25 15.04 20.5 8.6
下载: 导出CSV
-
[1] 郭宇晨, 刘庆林, 蒋金洋, 等. 含铬污泥资源化方法研究进展[J]. 化工进展, 2023, 42(2):575-584.GUO Y C, LIU Q L, JIANG J Y, et al. Research progress on recycling methods of chromium-containing sludge[J]. Chemical Industry and Engineering Progress, 2023, 42(2):575-584.
GUO Y C, LIU Q L, JIANG J Y, et al. Research progress on recycling methods of chromium-containing sludge[J]. Chemical Industry and Engineering Progress, 2023, 42(2):575-584.
[2] 张垒, 刘尚超, 张道权, 等. 烧结炼铁协同处置含铬污泥的应用研究[J]. 烧结球团, 2018, 43(5):61-64.ZHANG L, LIU S C, ZHANG D Q, et al. Application research on co-disposal of chromium-containing sludge in sintering and ironmaking[J]. Sintering and Pelletizing, 2018, 43(5):61-64.
ZHANG L, LIU S C, ZHANG D Q, et al. Application research on co-disposal of chromium-containing sludge in sintering and ironmaking[J]. Sintering and Pelletizing, 2018, 43(5):61-64.
[3] 邱柏欣, 顾幸勇, 董伟霞, 等. 烧成温度对铬铁渣性能影响与表征[J]. 矿产综合利用, 2020(1):188-193.QIU B X, GU X Y, DONG W X, et al. Effect of firing temperatures on properties of ferrochromium slag and characterization[J]. Multipurpose Utilization of Mineral Resources, 2020(1):188-193.
QIU B X, GU X Y, DONG W X, et al. Effect of firing temperatures on properties of ferrochromium slag and characterization[J]. Multipurpose Utilization of Mineral Resources, 2020(1):188-193.
[4] 李玮, 金立宏. 铬渣在济钢120 m2烧结机生产上的应用[J]. 生产实践, 2007(3):21-23.LI W, JIN L H. The application of chromium dregs in production of the 120 m2 sintering machine in jian steel[J]. Metallurgical Information Review, 2007(3):21-23.
LI W, JIN L H. The application of chromium dregs in production of the 120 m2 sintering machine in jian steel[J]. Metallurgical Information Review, 2007(3):21-23.
[5] 武弘毅, 张怡, 刘杨茜雅, 等. 含铬污泥处理及其资源化利用技术研究进展[J]. 应用化工, 2021, 50(5):1395-1402.WU H Y, ZHANG Y, LIU-YANG Q Y, et al. Research progress of chromium-containing sludge treatment and its resource utilization technology[J]. Applied Chemical Industry, 2021, 50(5):1395-1402.
WU H Y, ZHANG Y, LIU-YANG Q Y, et al. Research progress of chromium-containing sludge treatment and its resource utilization technology[J]. Applied Chemical Industry, 2021, 50(5):1395-1402.
[6] SANTOS J A, NUNES L A P L, MELO W J, et al. Tannery sludge compost amendment rates on soil microbial biomass of two different soils[J]. European Journal of Soil Biology, 2011, 47(2):146-151. doi: 10.1016/j.ejsobi.2011.01.002
[7] 王伟杰, 金会心, 张延玲, 等. 含铬固废的资源化处理及循环利用研究进展[J]. 矿产综合利用, 2022(5):64-70.WANG W J, JIN H X, ZHANG Y L, et al. Research progress on resource treatment and recycling of solid waste containing chromium[J]. Multipurpose Utilization of Mineral Resources, 2022(5):64-70.
WANG W J, JIN H X, ZHANG Y L, et al. Research progress on resource treatment and recycling of solid waste containing chromium[J]. Multipurpose Utilization of Mineral Resources, 2022(5):64-70.
[8] LI Z F, DU Y, CHEN Z T, et al. Synthesis and characterization of cobalt doped green ceramic pigment from tannery sludge[J]. Ceramics International, 2015, 41(10):12693-12699. doi: 10.1016/j.ceramint.2015.06.101
[9] 杨秀林. 含铬污泥制砖的实验研究[D]. 武汉: 武汉科技大学, 2015.YANG X L. The experimental research of making bricks by chrome sludge[D]. Wuhan: Wuhan University of Science and Technology, 2015.
YANG X L. The experimental research of making bricks by chrome sludge[D]. Wuhan: Wuhan University of Science and Technology, 2015.
[10] MUKHERJEE D, KAR S, MANDAL A, et al. Immobilization of tannery industrial sludge in ceramic membrane preparation and hydrophobic surface modification for application in atrazine remediation from water[J]. Journal of the European Ceramic Society, 2019, 39(10):3235-3246. doi: 10.1016/j.jeurceramsoc.2019.04.008
[11] MALAIŠKIENĖ J, KIZINIEVIČ O, KIZINIEVIČ V. A study on tannery sludge as a raw material for cement mortar[J]. Materials, 2019, 12(9):E1562. doi: 10.3390/ma12091562
[12] 张焕然, 王俊娥. 电镀污泥资源化利用及处置技术进展[J]. 矿产保护与利用, 2016(3):73-78.ZHANG H R, WANG J E. Progress in resource utilization and disposal technology of electroplating sludge[J]. Mineral Resources Conservation and Utilization, 2016(3):73-78.
ZHANG H R, WANG J E. Progress in resource utilization and disposal technology of electroplating sludge[J]. Mineral Resources Conservation and Utilization, 2016(3):73-78.
[13] KIZINIEVIC O, KIZINIEVIC V, MALAISKIENE J. Use of tannery sludge in clay brick manufacturing[J]. Environmental Engineering and Management Journal, 2020, 19(5):839-848. doi: 10.30638/eemj.2020.079
[14] SHEN D S, HUANG M R, FENG H J, et al. Effect of waste addition points on the chromium leachability of cement produced by co-processing of tannery sludge[J]. Waste Management, 2017, 61:345-353. doi: 10.1016/j.wasman.2017.01.039
[15] 石磊, 陈荣欢, 王如意. 含铬污泥球团在钢铁工业中的应用前景[J]. 再生资源研究, 2007(1):33-36.SHI L, CHEN R H, WANG R Y. Application prospect of chromium sludge pellet in iron and steel industry[J]. Recyclable Resources and Circular Economy, 2007(1):33-36.
SHI L, CHEN R H, WANG R Y. Application prospect of chromium sludge pellet in iron and steel industry[J]. Recyclable Resources and Circular Economy, 2007(1):33-36.
[16] 那贤昭, 齐渊洪. 铬渣在钢铁冶金过程中的资源化利用[J]. 钢铁研学报, 2009, 21(4):1-4.NA X Z, QI Y H. Resourceful disposal of chromium-containing residues in ferrous metallurgical process[J]. Journal of Iron and Steel Research, 2009, 21(4):1-4.
NA X Z, QI Y H. Resourceful disposal of chromium-containing residues in ferrous metallurgical process[J]. Journal of Iron and Steel Research, 2009, 21(4):1-4.
[17] 谷孝保, 罗建中, 陈敏. 铬渣应用于烧结炼铁工艺的研究及实践[J]. 环境工程, 2004(4):71-72+5-6.GU X B, LUO J Z, CHEN M. Research and practice of issuing chromic slag for sintering and ironmaking technology[J]. Environmental Engineering, 2004(4):71-72+5-6.
GU X B, LUO J Z, CHEN M. Research and practice of issuing chromic slag for sintering and ironmaking technology[J]. Environmental Engineering, 2004(4):71-72+5-6.
[18] 孟凡俭, 孙长余, 李廷乐, 等. 烧结矿中复合铁酸钙形成影响因素[J]. 钢铁, 2018, 53(7):16-23.MENG F J, SUN C Y, LI T L, et al. Formation and influencing factors of silico-ferrite of calcium and aluminum in sinter[J]. Iron and Steel, 2018, 53(7):16-23.
MENG F J, SUN C Y, LI T L, et al. Formation and influencing factors of silico-ferrite of calcium and aluminum in sinter[J]. Iron and Steel, 2018, 53(7):16-23.
[19] MAO L Q, DENG N, LIU L, et al. Effects of Al2O3, Fe2O3, and SiO2 on Cr(VI) formation during heating of solid waste containing Cr(III)[J]. Chemical Engineering Journal, 2016, 304:216-222. doi: 10.1016/j.cej.2016.06.086
[20] 程扬, 李杰, 朱金伟, 等. 烧结烟气CO 减排研究动态[J]. 矿产综合利用, 2022(2):22-25.CHENG Y, LI J, ZHU J W, et al. Research progress of CO emission reduction in sintering flue gas[J]. Multipurpose Utilization of Mineral Resources, 2022(2):22-25.
CHENG Y, LI J, ZHU J W, et al. Research progress of CO emission reduction in sintering flue gas[J]. Multipurpose Utilization of Mineral Resources, 2022(2):22-25.
[21] 杨光, 张淑会, 杨艳双. 烧结烟气中气态污染物的减排技术现状及展望[J]. 矿产综合利用, 2022(1): 45-56.YANG G, ZHANG S H, YANG Y S. Current status and prospects of emission reduction technology for gaseous pollutants in sintering flue gas[J]. Multipurpose Utilization of Mineral Resources, 2021(1): 45-56.
YANG G, ZHANG S H, YANG Y S. Current status and prospects of emission reduction technology for gaseous pollutants in sintering flue gas[J]. Multipurpose Utilization of Mineral Resources, 2021(1): 45-56.
-
