西藏甲玛铜钼矿浮选产品工艺矿物学

郭谨铭; 杨洪英; 孟晶; 佟琳琳; 金哲男; 陈国宝; 张勤

doi:10.3969/j.issn.1000-6532.2025.02.027

西藏甲玛铜钼矿浮选产品工艺矿物学

东北大学冶金学院，多金属共生矿生态化冶金教育部重点实验室，辽宁　沈阳　110819

基金项目: 国家重点研发项目（2018YFC1902002）；企业项目（2021021800150）

详细信息

作者简介: 郭谨铭（1996-），男，硕士研究生，主要从事重贵金属选矿技术研究

通讯作者: 杨洪英（1960-），女，教授，博士生导师，主要从事重贵金属选冶技术研究

中图分类号: TD952

收稿日期: 2022-04-14

刊出日期: 2025-04-25

Process Mineralogy of Flotation Products of a Copper-molybdenum Ore in Jiama, Xizang

Key Laboratory of Ecological Metallurgy of Polymetallic Symbiotic Ore, Ministry of Education, School of Metallurgy, Northeastern University, Shenyang 110819, Liaoning, China

More Information

Corresponding author: YANG Hongying, yanghy@smm.neu.edu.cn

Received Date: 14 April 2022

Publish Date: 25 April 2025

摘要

摘要:
对西藏甲玛角岩型和矽卡岩型铜钼矿石以及分离浮选得到的铜精矿和钼精矿进行了工艺矿物学研究。研究表明：角岩型铜钼矿含Cu 0.38%、 Mo 0.01%，矽卡岩型铜钼矿含Cu 0.85%、含Mo 0.03%，浮选得到的铜精矿中的Mo主要以与铜矿物连生的形式流失，钼精矿中杂质矿物主要以与辉钼矿连生或细小颗粒的形式进入到钼精矿中。研究结果为充分利用该矿石资源、选别工艺的优化提供理论指导。
- 铜钼矿石 /
- 角岩型 /
- 矽卡岩型 /
- 工艺矿物学 /
- 铜精矿 /
- 钼精矿
Abstract:
The process mineralogy was studied on hornstone and skarn copper-molybdenum ores and the copper and molybdenum concentrates was obtained by separating flotationin Jiama, Xizang. The research shows that the hornstone copper-molybdenum ore contains Cu 0.38% and Mo 0.01%, and the skarn copper-molybdenum ore contains Cu 0.85% and Mo 0.03%. Mo is mainly lost in the form of continuous growth with copper minerals in the copper concentrate. The impurity elements in the molybdenum concentrate mainly enter into the molybdenum concentrate in the form of continuous growth with molybdenite or fine particles. The research results provide theoretical guidance for making full use of the ore resources and optimizing the sorting process.
- Copper-molybdenum ore /
- Hornstone type /
- Skarn type /
- Process mineralogy /
- Copper concentrate /
- Molybdenum concentrate

HTML全文

图 1 黄铁矿颗粒

Figure 1.

下载: 全尺寸图片幻灯片

图 2 黄铜矿颗粒

Figure 2.

下载: 全尺寸图片幻灯片

图 3 斑铜矿颗粒

Figure 3.

下载: 全尺寸图片幻灯片

图 4 铜精矿中的辉钼矿

Figure 4.

下载: 全尺寸图片幻灯片

图 5 黄铁矿颗粒

Figure 5.

下载: 全尺寸图片幻灯片

图 6 黄铜矿颗粒

Figure 6.

下载: 全尺寸图片幻灯片

图 7 钼精矿中的杂质

Figure 7.

下载: 全尺寸图片幻灯片

表 1 角岩型铜钼矿石化学成分分析/%

Table 1. Analysis of chemical composition of hornstone copper-molybdenum ores

Cu	C	Mo	Fe	S	SiO₂	Al₂O₃	CaO	K₂O	MgO	其他
0.38	0.83	0.01	2.55	2.05	68.44	9.46	2.12	5.44	1.06	7.66

下载: 导出CSV

表 2 矽卡岩型铜钼矿石化学成分分析/%

Table 2. Chemical composition analysis of skarn copper-molybdenum ores

Cu	Mo	Fe	S	Bi	Pb	Zn	SiO₂	MgO	Al₂O₃	CaO	C	其他
0.85	0.03	7.13	5.45	0.01	0.12	0.05	35.42	1.39	4.41	26.52	2.22	16.40

下载: 导出CSV

表 3 铜钼分离浮选实验结果

Table 3. Results of copper and molybdenum separation flotation test

产品名称	产率/%	品位/%		回收率/%
产品名称	产率/%	Cu	Mo	Cu	Mo
混合精矿	100.00	19.00	0.38	100.00	100.00
钼精矿	0.66	0.94	46.50	0.03	80.76
铜精矿	99.34	19.12	0.07	99.97	19.24

下载: 导出CSV

表 4 矿物组成及相对含量

Table 4. Mineral composition and relative content

金属矿物	含量/%	非金属矿物	含量/%
黄铁矿	40.79	石英	2.64
黄铜矿	17.71	云母	1.15
斑铜矿	17.38	绿帘石	1.09
铜蓝	3.98	长石	0.98
辉铜矿	3.32	方解石	0.69
方铅矿	2.61	辉石	0.25
黑铜矿	1.65	硅灰石	0.03
闪锌矿	1.10	其他矿物	4.51
辉钼矿	0.12	合计	100.00

下载: 导出CSV

表 5 矿物组成及相对含量

Table 5. Mineral composition and relative content

金属矿物	含量/%	非金属矿物	含量/%
辉钼矿	78.67	石英	1.32
黄铁矿	9.37	方解石	0.89
黄铜矿	2.09	长石	0.46
斑铜矿	1.84	辉石	0.36
方铅矿	0.48	绿帘石	0.11
铜蓝	0.33	硅灰石	0.11
闪锌矿	0.26	其他矿物	3.71
		合计 100.00

下载: 导出CSV
