Terrestrial Heat Flow in Eastern Sichuan Basin and Its Revelation to Geothermal Resource Evaluation
-
摘要: 大地热流是揭示一个地区的温度空间展布、地热资源形成和赋存条件的综合性评价指标。川东地区大地热流的研究十分薄弱, 制约着对该地区地热资源潜力及展布的认识。本文首先利用4口钻井178个系统稳态测温数据和25口钻井76个试油温度数据, 计算得到了川东地区的地温梯度和大地热流, 再利用一维稳态热传导方程计算得到川东地区下二叠统栖霞—茅口组热储的地温, 最后明确栖霞—茅口组发育的地热资源类型及潜力。结果表明: 川东地区地温梯度在16.0～21.3 °C/km之间, 平均为(18.3±1.59) °C/km; 大地热流值在44.3～67.7 mW/m2之间, 平均为(55.5±6.0) mW/m2, 具有构造稳定区的低温型地温场特征。栖霞—茅口组是川东地区最重要的热储, 主要发育中-低温型地热资源, 其中, 低温型地热资源主要发育在西南构造分区; 中温型地热资源主要发育在东南构造分区、东北构造分区及西北构造分区。结合热储特征, 可以得出川东地区栖霞—茅口组具有形成丰富地热资源的热储和地温条件。该成果可为川东地区的地热资源勘探评价提供重要的地热信息。Abstract: Terrestrial heat flow is a comprehensive index that reveals the spatial distribution of temperature and the formation and occurrence conditions of geothermal resources in a region. The terrestrial heat flow in the Eastern Sichuan Basin has not been extensively studied, which restricts the understanding of the potential and distribution of geothermal resources in this area. In this study, the geothermal gradient and terrestrial heat flow in the Eastern Sichuan Basin are calculated using steady-state temperature measurement data of 178 systems in 4 wells and 76 formation-testing temperature data in 25 wells. Thereafter, the geotemperature of the Lower Permian Qixia-Maokou Formation thermal reservoir in the Eastern Sichuan Basin is calculated using the one-dimensional steady-state heat conduction equation. Finally, the types and potential of geothermal resources developed in the Qixia-Maokou Formation are obtained. The results show that the geothermal gradient in Eastern Sichuan Basin ranges from 16.0 to 21.3 °C/km, with an average value of (18.3±1.59) °C/km, and the terrestrial heat flow ranges from 44.3 to 67.7 mW/m2, with an average value of (55.5±6.0) mW/m2, which has the characteristics of a low-temperature geothermal field in the tectonic stable area. The Qixia-Maokou Formation is the most important thermal reservoirs in Eastern Sichuan Basin. It mainly develops medium-low temperature geothermal resources. Among them, low-temperature geothermal resources are mainly developed in the southwest structural zone, while medium-temperature geothermal resources are mainly distributed in the southeast, northeast, and northwest structural zones. Combined with the characteristics of thermal reservoirs, it can be concluded that the Qixia-Maokou Formation has the thermal reservoir and geothermal temperature conditions necessary to form rich geothermal resources. The results may provide important geothermal information for the exploration and evaluation of geothermal resources in this area.
-
-
蔡希源, 郭旭升, 何治亮, 付孝悦, 刘光祥.2016. 四川盆地天然气动态成藏[M]. 北京: 科学出版社.
曹环宇. 2015. 四川盆地东部地区古生界泥页岩层系热演化研究[D]. 北京: 中国石油大学.
段金宝, 梅庆华, 李毕松, 梁子锐. 2019. 四川盆地震旦纪-早寒武世构造-沉积演化过程[J]. 地球科学, 44(3): 738-755.
高志友, 宁文锋, 李宁. 2018. 莱州市浅层地温能初步评价[J].化工矿产地质, 40(4): 227-234.
郝天珧, 胡卫剑, 邢健, 胡立天, 徐亚, 秦静欣, 刘少华, 雷受旻. 2014. 中国海陆1: 500万莫霍面深度图及其所反映的地质内涵[J]. 地球物理学报, 57(12): 3869-3883.
何登发, 李德生, 张国伟, 赵路子, 樊春, 鲁人齐, 文竹. 2011.四川多旋回叠合盆地的形成与演化[J]. 地质科学, 46(3):589-606.
胡东风, 王良军, 黄仁春, 段金宝, 徐祖新, 潘磊. 2019. 四川盆地东部地区中二叠统茅口组白云岩储层特征及其主控因素[J]. 天然气工业, 39(6): 13-21.
胡圣标, 黄少鹏, 何丽娟, 庞忠和, 汪集旸. 2013. 中国大陆地区岩石圈热结构与地热资源潜力[J]. 地质学报, 87(S1): 36.
姜光政, 高堋, 饶松, 张林友, 唐晓音, 黄方, 赵平, 庞忠和, 何丽娟, 胡圣标, 汪集旸. 2016. 中国大陆地区大地热流数据汇编(第四版)[J]. 地球物理学报, 59(8): 2892-2910.
李大军, 陈洪德, 侯明才, 徐胜林, 庞崇友, 郭海洋. 2019. 四川盆地中二叠世栖霞期-茅口期岩相古地理特征及其地球动力学机制探讨[J]. 地质科学, 54(4): 1114-1134.
邱楠生, 胡圣标, 何丽娟.2019. 沉积盆地地热学[M]. 东营: 中国石油大学出版社.
孙自明, 张荣强, 孙炜, 郝运轻, 卞昌蓉. 2021. 四川盆地东部海相下组合油气勘探领域与有利勘探方向[J]. 现代地质, 35(3): 798-806.
田云涛, 朱传庆, 徐明, 饶松, KOHN B P, 胡圣标. 2011. 晚白垩世以来川东北地区的剥蚀历史--多类低温热年代学数据综合剖面的制约[J]. 地球物理学报, 54(3): 807-816.
汪洋, 邓晋福, 汪集旸, 熊亮萍. 2001. 中国大陆热流分布特征及热-构造分区[J]. 中国科学院研究生院学报, 18(1): 51-58.
王贵玲, 张薇, 梁继运, 蔺文静, 刘志明, 王婉丽. 2017. 中国地热资源潜力评价[J]. 地球学报, 38(4): 449-459.
王林琪, 范存辉, 范增辉, 蒋波. 2016. 地震勘探技术对四川盆地构造演化及其区域沉积作用的推定[J]. 天然气工业, 36(7): 18-26.
熊盛青, 杨海, 丁燕云, 李占奎. 2016. 中国陆域居里等温面深度特征[J]. 地球物理学报, 59(10): 3604-3617.
徐明, 朱传庆, 田云涛, 饶松, 胡圣标. 2011. 四川盆地钻孔温度测量及现今地热特征[J]. 地球物理学报, 54(4):1052-1060.
徐秋晨. 2018. 四川盆地中西部海相地层热演化研究[D]. 北京:中国石油大学.
易善锋. 1966. 世界地热测量情况简介[J]. 地质快报, (4): 10-13.
朱传庆, 邱楠生, 曹环宇, 刘一锋, 江强. 2017. 四川盆地东部构造-热演化:来自镜质体反射率和磷灰石裂变径迹的约束[J]. 地学前缘, 24(3): 94-104.
CAI Xi-Yuan, GUO Xu-sheng, HE Zhi-liang, FU Xiao-yue, LIU Guang-xiang.2016. Dynamic accumulation of natural gas in Sichuan Basin[M]. Beijing: Science Press(in Chinese).
CAO Huan-yu. 2015. Study on thermal evolution of Paleozoic shale strata in eastern Sichuan Basin[D]. Beijing: China University of Petroleum(in Chinese with English abstract).
DUAN Jin-bao, MEI Qing-hua, LI Bi-song, LIANG Zi-rui. 2019.Sinian-Early Cambrian tectonic-sedimentary evolution in Sichuan Basin[J]. Earth Science, 44(3): 738-755(in Chinese with English abstract).
GAO Zhi-you, NING Wen-feng, LI Ning. 2018. Preliminary evaluation of shallow ground temperature energy in Laizhou city[J]. Geology of Chemical Minerals, 40(4): 227-234(in Chinese with English abstract).
HAO Tian-yao, HU Wei-jian, XING Jian, HU Li-tian, XU Ya, QIN Jing-xin, LIU Shao-hua, LEI Shou-yu. 2014. The Moho depth map (1: 5000000) in the land and seas of China and adjacent areas and its geological implications[J]. Chinese Journal of Geophysics, 57(12): 3869-3883(in Chinese with English abstract).
HE Deng-fa, LI De-sheng, ZHANG Guo-wei, ZHAO Lu-zi, FAN Chun, LU Ren-qi, WEN Zhu. 2011. Formation and evolution of multi-cycle superposed Sichuan Basin, China[J]. Chinese Journal of Geology, 46(3): 589-606(in Chinese with English abstract).
HE Li-juan, XU He-hua, WANG Ji-yang. 2011. Thermal evolution and dynamic mechanism of the Sichuan Basin during the Early Permian-Middle Triassic[J]. Science China Earth Sciences, 54(12): 1948-1954.
HU Dong-feng, WANG Liang-jun, HUANG Ren-chun, DUAN Jin-bao, XU Zu-xin, PAN Lei. 2019. Characteristics and main controlling factors of the Middle Permian Maokou dolomite reservoirs in the eastern Sichuan Basin[J]. Natural Gas Industry, 39(6): 13-21(in Chinese with English abstract).
JIANG Guang-zheng, GAO Peng, RAO Song, ZHANG Lin-you, TANG Xiao-yin, HUANG Fang, ZHAO Ping, PANG Zhong-he, HE Li-juan, HU Sheng-biao, WANG Ji-yang. 2016.Compilation of heat flow data in the continental area of China(4th edition)[J]. Chinese Journal of Geophysics, 59(8):2892-2910(in Chinese with English abstract).
JIANG Guang-zheng, HU Sheng-biao, SHI Yi-zuo, ZHANG Chao, WANG Zhu-ting, HU Di. 2019. Terrestrial heat flow of continental China: Updated dataset and tectonic implications[J].Tectonophysics, 753: 36-48.
LI Da-jun, CHEN Hong-de, HOU Ming-cai, XU Sheng-lin, PANG Chong-you, GUO Hai-yang. 2019. Lithofacies and paleogeographic characteristics of Middle Permian Qixia and Maokou Periods in Sichuan Basin and the geodynamic mecheanism[J]. Chinese Journal of Geology, 54(4): 1114-1134(in Chinese with English abstract).
LIU Shu-gen, DENG Bin, LI Zhi-wu, SUN Wei. 2012. Architecture of basin-mountain systems and their influences on gas distribution: A case study from the Sichuan basin, South China[J]. Journal of Asian Earth Sciences, 47: 204-215.
OSADETZ K G, KOHN B P, FEINSTEIN S, O’SULLIVAN P B.2002. Thermal history of Canadian Williston basin from apatite fission-track thermochronology-implications for petroleum systems and geodynamic history[J]. Tectonophysics, 349(1): 221-249.
QIU Nan-sheng, HU Sheng-biao, HE Li-juan.2019. Sedimentary basin geotherm[M]. Dongying: China University of Petroleum Press(in Chinese).
SOUCHE A, SCHMID D W, RÜPKE L. 2017. Interrelation between surface and basement heat flow in sedimentary basins[J]. AAPG Bulletin, 101(10): 1697-1713.
SPEECE M A, BOWEN T D, FOLCIK J L, POLLACK H N. 1985.Analysis of temperatures in sedimentary basins; the Michigan Basin[J]. Geophysics, 50(8): 1318-1334.
SUN Zi-ming, ZHANG Rong-qiang, SUN Wei, HAO Yun-qing, BIAN Chang-rong. 2021. Petroleum exploration domains and favorable directions of the lower marine assemblage in eastern Sichuan Basin[J]. Geoscience, 35(3): 798-806(in Chinese with English abstract).
TANG Bo-ning, ZHU Chuan-qing, XU Ming, CHEN Tian-ge, HU Sheng-biao. 2019. Thermal conductivity of sedimentary rocks in the Sichuan Basin, Southwest China[J]. Energy Exploration& Exploitation, 37(2): 691-720.
TIAN Yun-tao, KOHN B P, ZHU Chuan-qing, XU Ming, HU Sheng-biao, GLEADOW A J W. 2012. Post-orogenic evolution of the Mesozoic Micang Shan Foreland Basin system, central China[J]. Basin Research, 24(1): 70-90.
TIAN Yun-tao, ZHU Chuan-qing, XU Ming, RAO Song, KOHN B P, HU Sheng-biao. 2011. Post-Early Cretaceous denudation history of the northeastern Sichuan Basin: constraints from low-temperature thermochronology profiles[J]. Chinese Journal of Geophysics, 54(3): 807-816(in Chinese with English abstract).
TURCOTTE D L, SCHUBERT G. 1983. Geodynamics-Application of Continuum Physics to Geological Problem[J]. Journal of Fluid Mechanics, 134: 461-464.
WANG Gui-ling, ZHANG Wei, LIANG Ji-yun, LIN Wen-jing, LIU Zhi-ming, WANG Wan-li. 2017. Evaluation of geothermal resources potential in China[J]. Acta Geoscientica Sinica, 38(4): 449-459(in Chinese with English abstract).
WANG Lin-qi, FAN Cun-hui, FAN Zeng-hui, JIANG Bo. 2016.Presumption of the tectonic evolution and regional sedimentation of the Sichuan Basin based on seismic exploration technology[J]. Natural Gas Industry, 36(7): 18-26(in Chinese with English abstract).
WANG Yang, DENG Jin-fu, WANG Ji-yang, XIONG Liang-ping.2001. Terrestrial heat flow pattern and thermo tectonic domains in the continental area of China[J]. Journal of the Graduate School Academia Sinica, 18(1): 51-58(in Chinese with English abstract).
XIONG Sheng-qing, YANG Hai, DING Yan-yun, LI Zhan-kui.2016. Characteristics of Chinese continent Curie point isotherm[J]. Chinese Journal of Geophysics, 59(10):3604-3617(in Chinese with English abstract).
XU Ming, ZHU Chuan-qing, TIAN Yun-tao, RAO Song, HU Sheng-biao. 2011. Borehole temperature logging and characteristics of subsurface temperature in the Sichuan Basin[J].Chinese Journal of Geophysics, 54(4): 1052-1060(in Chinese with English abstract).
XU Qiu-chen. 2018. Thermal evolution of marine strata in the central and western Sichuan Basin[D]. Beijing: China University of Petroleum(in Chinese with English abstract).
YI Shan-feng. 1966. Brief introduction of geothermal measurement in the world.[J]. Geology Letters, (4): 10-13(in Chinese).
YU Qiang, REN Zhan-li, LI Rong-xi, WANG Bao-jiang, QIN Xiao-li, TAO Ni. 2018. Paleogeotemperature and maturity evolutionary history of the source rocks in the Ordos Basin[J].Geological Journal, 52(S1): 97-118.
ZHU Chuan-qing, QIU Nan-sheng, CAO Huan-yu, LIU Y-i-feng, JIANG Qiang. 2017. Tectono-thermal evolition of the eastern Sichuan Basin: constraints from the vitrinite reflectance and apatite fission track data[J]. Earth Science Frontiers, 24(3):94-104(in Chinese with English abstract).
ZUO Yin-hui, JIANG Shu, WU Shi-hu, XU Wei, ZHANG Jiong, FENG Ren-peng, YANG Mei-hua, ZHOU Yong-shui, SANTOSH M. 2020. Terrestrial heat flow and lithospheric thermal structure in the Chagan Depression of the Yingen-Ejinaqi Basin, north central China[J]. Basin Research, 32(6): 1328-1346.
ZUO Yin-hui, QIU Nan-sheng, HAO Qing-qing, ZHANG Yun-xian, PANG Xiong-qi, LI Zhong-chao, GAO Xia. 2014.Present geothermal fields of the Dongpu sag in the Bohai Bay Basin[J]. Acta Geologica Sinica (English Edition), 88(3):915-930.
-
