Characteristics and Evaluation of Geothermal Resources in the Rongdong Area of Xiongan New Area
-
摘要: 雄安新区容东片区是新区规划建设的第一个安置区, 具有较好的地热资源赋存潜力。查明该地区地热地质条件, 准确评估其地热资源量, 可为雄安新区地热资源的开发利用、能源结构转型提供理论支撑。本文综合分析深部地质结构、断裂分布、地温场与水化学场等, 揭示了容东片区地热资源赋存特征和形成机理, 采用采灌均衡法综合评价了蓟县系碳酸盐岩热储地热资源量。主要结论: (1)本区的主要热储层包括新近系明化镇组孔隙型砂岩热储、蓟县系雾迷山组及高于庄组碳酸盐岩热储、长城系碳酸盐岩热储; 其中, 蓟县系热储为地热勘查开发主要目标层段, 其水温约为 50 ℃, 储厚比为 20%～40%, 储层最大孔隙度为11.3%。(2)西北部太行山地区大气降水是本区地热资源的补给水源, 地下水沿断裂经深循环被深部热源加热, 而后沿导水断裂带运移至凸起处强岩溶裂隙发育区, 形成水热型地热系统。(3)容东片区蓟县系碳酸盐岩热储在采灌均衡条件下热储地热流体可开采量为1.33×104 m3/a, 地热流体可开采热量为0.95×1015 J/a, 折合标准煤3.23万吨/年。以上研究助力构建雄安新区清洁低碳、安全高效的能源体系。Abstract: The Rongdong area is the first resettlement in the planning and construction of Xiongan New Area, which offers good potential for geothermal resources. The identification of its geological conditions and the accurate assessment of its geothermal resources can provide theoretical support for the development and utilization of geothermal resources and the transformation of the energy structure in Xiongan New Area.This study determined the geothermal resource characteristics and formation mechanism of the Rongdong area through analysis of the geological structures, fault distributions, heat flow, and hydrochemical field characteristics. The geothermal resources of the Jixian system carbonate thermal reserve were then evaluated using the equilibrium method of extraction-reinjection. The results showed: (1) The main geothermal reservoirs in the study area include the porosity-type geothermal reservoir of the Neoproterozoic Minghuazhen Formation, the carbonate thermal reservoir of the Jixian System Wuzhishan Formation and Gaoyuzhuang Formation, and the carbonate thermal reservoir of the Changcheng System. The thermal reservoir of the Jixian System is the primary thermal reservoir for geothermal exploration and development, with a water temperature of approximately 50 °C, a reservoir thickness ratio of 20%-40%, and a maximum reservoir porosity of 11.3%. (2) Atmospheric precipitation in the northwestern Taihang Mountains is the recharge source of geothermal resources, groundwater is heated by deep rock along the fractures through deep heat provider, and then transported along the hydraulic fracture zone to the strong karst fissure development area at the bulge, forming a hydro-geothermal systems.(3) The recoverable resources of the geothermal fluids in the carbonate thermal reservoirs of the Jixian system under the balanced extraction and reinjection conditions are 1.33×104 m3/a, and the recoverable heat of geothermal fluid is 0.95×1015 J/a, which is equivalent to 32 300 tons of standard coal pear year. This research will help build a clean, low-carbon, safe and efficient energy system for the Xiongan New Area.
-
-
常健, 邱楠生, 赵贤正, 许威, 徐秋晨, 金凤鸣, 韩春元, 马学峰, 董雄英, 梁小娟. 2016. 渤海湾盆地冀中坳陷现今地热特征[J]. 地球物理学报, 59(3): 1003-1016.
陈墨香, 汪集旸, 汪缉安, 邓孝, 杨淑贞, 熊亮萍, 张菊明. 1990.华北断陷盆地热场特征及其形成机制[J]. 地质学报, (1):80-91.
陈墨香.1988. 华北地热[M]. 北京: 科学出版社: 1-214
郭世炎, 李小军. 2013. 河北保定容城凸起地热田储层属性与资源潜力[J]. 地质科学, 48(3): 922-931.
何登发, 崔永谦, 单帅强, 肖阳, 张煜颖, 张传宝. 2018. 渤海湾盆地冀中坳陷古潜山的三维地质结构特征[J]. 地质科学, 53(1): 1-24.
蔺文静, 刘志明, 王婉丽, 王贵玲. 2013. 中国地热资源及其潜力评估[J]. 中国地质, 40(1): 312-321.
刘明亮, 何曈, 吴启帆, 郭清海. 2020. 雄安新区地热水化学特征及其指示意义[J]. 地球科学, 45(6): 2221-2231.
刘志明, 梁继运, 刘春雷. 2016. 地热回灌条件下流体可采量评价方法[J]. 地下水, 38(2): 61-63.
鲁锴, 鲍志东, 季汉成, 刘金侠, 王贵玲, 马峰, 郭瑞婧, 曹瑛倬, 杨飞, 符勇, 李潇博, 华盈鑫, 阙宜娟, 李宗峰, 许西挺, 胡先才. 2019. 雄安新区蓟县系雾迷山组岩溶热储特征、主控因素及有利区预测[J]. 古地理学报, 21(6): 885-900.
马冰, 贾凌霄, 于洋, 王欢, 陈静, 钟帅, 朱吉昌. 2021. 地球科学与碳中和: 现状与发展方向[J]. 中国地质, 48(2):347-358.
马峰, 王贵玲, 张薇, 朱喜, 张汉雄, 岳高凡. 2020. 雄安新区容城地热田热储空间结构及资源潜力[J]. 地质学报, 94(7):1981-1990.
孙明行, 王瑞湖, 梁礼革, 邓宾, 李玉坤, 刘德民, 管彦武. 2022. 广西地热资源特征与潜力评价[J]. 中国地质, https://kns.cnki.net/kcms/detail/11.1167.P.20220316.1348.014.html.
王贵玲, 高俊, 张保建, 邢一飞, 张薇, 马峰. 2020. 雄安新区高阳低凸起区雾迷山组热储特征与高产能地热井参数研究[J].地质学报, 94(7): 1970-1980.
王贵玲, 蔺文静. 2020. 我国主要水热型地热系统形成机制与成因模式[J]. 地质学报, 94(7): 1923-1937.
王贵玲, 张薇, 梁继运, 蔺文静, 刘志明, 王婉丽. 2017. 中国地热资源潜力评价[J]. 地球学报, 38(4): 449-459.
王思琪, 张保建, 李燕燕, 邢一飞, 袁文真, 李郡, 高俊, 赵甜.2021. 雄安新区高阳地热田东北部深部古潜山聚热机制[J].地质科技通报, 40(3): 12-21.
王朱亭, 张超, 姜光政, 胡杰, 唐显春, 胡圣标. 2019. 雄安新区现今地温场特征及成因机制[J]. 地球物理学报, 62(11):4313-4322.
吴爱民, 马峰, 王贵玲, 刘金侠, 胡秋韵, 苗青壮. 2018. 雄安新区深部岩溶热储探测与高产能地热井参数研究[J]. 地球学报, 39(5): 523-532.
杨明慧, 刘池阳, 孙冬胜, 崔永谦. 2002. 冀中坳陷的伸展构造系统及其构造背景[J]. 大地构造与成矿学, 26(2): 113-120.
赵佳怡, 张薇, 马峰, 朱喜, 张汉雄, 王贵玲. 2020. 雄安新区容城热田地热流体化学特征[J]. 地质学报, 94(7): 1991-2001.
朱喜, 王贵玲, 马峰, 蔺文静, 张薇, 张保建, 贾小丰, 张汉雄. 2022.雄安新区地热资源潜力评价[J]. 地球科学, https://kns.cnki.net/kcms/detail/42.1874.p.20220621.1102.008.html.
朱喜, 王贵玲, 马峰, 张薇, 张庆莲, 张汉雄. 2021. 太行山-雄安新区蓟县系含水层水文地球化学特征及意义[J]. 地球科学, 46(7): 2594-2608.
自然资源部. 2020. DZ/T 0331-2020 地热资源评价方法及估算规程[S]. 北京: 自然资源部.
BELHAI M, FUJIMITSU Y, NISHIJIMA J, BERSI M. 2017. Hydrochemistry and gas geochemistry of the northeastern Algerian geothermal waters[J]. Arabian Journal of Geosciences, 10(1): 8.
CHANG Jian, QIU Nan-sheng, ZHAO Xian-zheng, XU Wei, XU Qiu-chen, JIN Feng-ming, HAN Chun-yuan, MA Xue-feng, DONG Xiong-ying, LIANG Xiao-juan. 2016. Present-day geothermal regime of the Jizhong depression in Bohai Bay basin, East China[J]. Chinese Journal of Geophysics, 59(3):1003-1016(in Chinese with English abstract).
CHEN Mo-xiang, WANG Ji-yang, WANG Ji-an, DENG Xiao, YANG Shu-zhen, XIONG Liang-ping, ZHANG Ju-ming.1990. The characteristics of the geothermal field and its formation mechanism in the North China down-faulted basin[J].Acta Geologica Sinica, (1): 80-91(in Chinese with English abstract).
CHEN Mo-xiang.1988. Geothermal in North China[M]. Beijing:Science Press: 1-214(in Chinese).
CRAIG H. 1961. Standard for reporting concentrations of deuterium and oxygen-18 in natural waters[J]. Science, 133(3467):1833-1834.
FOURNIER R O, TRUESDELL A H. 1974. Geochemical indicators of subsurface temperature. Part II. Estimation of temperature and fraction of hot water mixed with cold water[J].Journal of Research of the U.S. Geological Survey, 2(3):263-270.
FOURNIER R O. 1977. Chemical geothermometers and mixing models for geothermal systems[J]. Geothermics, 5(1-4): 41-50.
GIGGENBACH W F. 1988. Geothermal solute equilibria. Derivation of Na-K-Mg-Ca geoindicators[J]. Geochimica et Cosmochimica Acta, 52: 2749-2765.
GUO Shi-yan, LI Xiao-jun. 2013. Reservoir stratum characterstics and geothermal resources potential of Rongcheng uplift geothermal field in Baoding, Hebei[J]. Chinese Journal of Geology, 48(3): 922-931(in Chinese with English abstract).
HE Deng-fa, CUI Yong-qian, SHAN Shuai-qiang, XIAO Yang, ZHANG Yu-ying, ZHANG Chuan-bao. 2018. Characteristics of geologic framework of buried-hill in Jizhong depression, Bohai Bay Basin[J]. Chinese Journal of Geology, 53(1):1-24(in Chinese with English abstract).
KONG Yan-long, PANG Zhong-he, PANG Ju-mei, WANG Ying-chun, YANG Feng-tian. 2017. Stable isotopes of deep groundwater in the Xiongxian Geothermal Field[J]. Procedia Earth & Planetary Science, 17: 512-515.
LIN Wen-jing, LIU Zhi-ming, WANG Wan-li, WANG Gui-ling.2013. The assessment of geothermal resources potential of China[J]. Geology in China, 40(1): 312-321(in Chinese with English abstract).
LIU Ming-liang, HE Tong, WU Qi-fan, GUO Qing-hai. 2020.Hydrogeochemistry of geothermal waters from Xiongan New Area and its indicating significance[J]. Earth Science, 45(6):2221-2231(in Chinese with English abstract).
LIU Zhi-ming, LIANG Ji-yun, LIU Chun-lei. 2016. Assessment method of geothermal fluid exploitable reserve under condition of reinjection[J]. Ground Water, 38(2): 61-63(in Chinese with English abstract).
LONG Xi-ting, ZHANG Ke-neng, YUAN Rui-qiang, ZHANG Liang, LIU Zhen-ling. 2019. Hydrogeochemical and isotopic constraints on the pattern of a deep circulation groundwater flow system[J]. Energies, 12(3): 1-18.
LU Kai, BAO Zhi-dong, JI Han-cheng, LIU Jin-xia, WANG Gui-ling, MA Feng, GUO Rui-jing, CAO Ying-zhuo, YANG Fei, FU Yong, LI Xiao-bo, BI Ying-xin, QUE Yi-juan, LI Zong-feng, XU Xi-ting, HU Xian-cai. 2019. Characteristics, main controlling factors and favorable area prediction of karstic geothermal reservoirs of the Jixianian Wumishan Formation in Xiong’an New Area[J]. Journal of Palaeogeography, 21(6): 885-900(in Chinese with English abstract).
MA Bing, JIA Ling-xiao, YU Yang, WANG Huan, CHEN Jing, ZHONG Shuai, ZHU Ji-chang. 2021. Geoscience and carbon neutralization: Current status and development direction[J].Geology in China, 48(2): 347-358(in Chinese with English abstract).
MA Feng, WANG Gui-ling, ZHANG Wei, ZHU Xi, ZHANG Han-xiong, YUE Gao-fan. 2020. Structure of geothermal reservoirs and resource potential in the Rongcheng geothermal field in Xiong’an New Area[J]. Acta Geologica Sinica, 94(7):1981-1990(in Chinese with English abstract).
Ministry of Natural Resources. 2020. DZ/T 0331-2020 Specification for estimation and evaluation of geothermal recources[S].Beijing: Ministry of Natural Recources(in Chinese).
Our World in Data. 2021a. Installed geothermal energy capacity[EB/OL].[2021-02-10]. https://ourworldindata.org/energy-mix.
SUN Ming-xing, WANG Rui-hu, LIANG Li-ge, DENG Bin, LI Yu-kun, LIU De-min, GUAN Yan-wu. 2022. Characteristics and potential evaluation of geothermal resources in Guangxi[J]. Geology in China, https://kns.cnki.net/kcms/detail/11.1167.P.20220316.1348.014.html(in Chinese with English abstract).
TANG Xian-chun, LIU Sha-sha, ZHANG Dai-lei, WANG Gui-ling, LUO Yin-fei, HU Sheng-biao, XU Qiang. 2022. Geothermal accumulation constrained by the tectonic transformation in the Gonghe Basin, northeastern Tibetan Plateau[J]. Lithosphere, 5:3936881.
WANG Gui-ling, GAO Jun, ZHANG Bao-jian, XING Yi-fei, ZHANG Wei, MA Feng. 2020. Study on the thermal storage characteristics of the Wumishan Formation and huge capacity geothermal well parameters in the Gaoyang low uplift area of Xiong’an New Area[J]. Acta Geologica Sinica, 94(7):1970-1980(in Chinese with English abstract).
WANG Gui-ling, LIN Wen-jing. 2020. Main hydro-geothermal systems and their genetic models in China[J]. Acta Geologica Sinica, 94(7): 1923-1937(in Chinese with English abstract).
WANG Gui-ling, ZHANG Wei, LIANG Ji-yun, LIN Wen-jing, LIU Zhi-ming, WANG Wan-li. 2017. Evaluation of geothermal resources potential in China[J]. Acta Geoscientica Sinica, 38(4): 449-459(in Chinese with English abstract).
WANG Shu-fang, LIU Jiu-rong, SUN Ying, LIU Shi-liang, GAO Xiao-rong, SUN Cai-xia, LI Hai-kui. 2018. Study on the geothermal production and reinjection mode in Xiong County[J].Journal of Groundwater Science and Engineering, 6(3):178-186.
WANG Si-qi, ZHANG Bao-jian, LI Yan-yan, XING Yi-fei, YUAN Wen-zhen, LI Jun, GAO Jun, ZHAO Tian. 2021. Heat accumulation mechanism of deep ancient buried hill in the northeast of Gaoyang geothermal field, Xiong’an New Area[J].Bulletin of Geological Science and Technology, 40(3):12-21(in Chinese with English abstract).
WANG Yi-bo, WANG Li-juan, BAI Yang, WANG Zhu-ting, HU Jie, HU Di, WANG Ya-qi, HU Sheng-biao. 2021. Assessment of geothermal resources in the North Jiangsu Basin, East China, using Monte Carlo simulation[J]. Energies, 14(2):1-17.
WANG Ying-jin, MA Feng, XIE He-ping, WANG Gui-ling, WANG Zhi-he. 2021. Fracture characteristics and heat accumulation of Jixianian carbonate reservoirs in the Rongcheng Geothermal Field, Xiong'an New Area[J]. Acta Geologica Sinica(English Edition), 95(6): 1902-1914.
WANG Zhu-ting, JIANG Guang-zheng, ZHANG Chao, TANG Xian-chun, HU Sheng-biao. 2019. Estimating geothermal resources in Bohai Bay Basin, eastern China, using Monte Carlo simulation[J]. Environmental Earth Sciences, 78(12): 355.
WANG Zhu-ting, ZHANG Chao, JIANG Guang-zheng, HU Jie, TANG Xian-chun, HU Sheng-biao. 2019. Present-day geothermal field of Xiongan New Area and its heat source mechanism[J]. Chinese Journal of Geophysics, 62(11):4313-4322(in Chinese with English abstract).
WU Ai-min, MA Feng, WANG Gui-ling, LIU Jin-xia, HU Qiu-yun, MIAO Qing-zhuang. 2018. A study of deep-seated karst geothermal reservoir exploration and huge capacity geothermal well parameters in Xiongan New Area[J]. Acta Geoscientica Sinica, 39(5): 523-532(in Chinese with English abstract).
YANG Ming-hui, LIU Chi-yang, SUN Dong-sheng, CUI Yong-qian. 2002. Extensional tectonic system and its deep-seated setting of Jizhong Basin, China[J]. Geotectonic et Metallogenia, 26(2): 113-120(in Chinese with English abstract).
ZHAO Jia-yi, ZHANG Wei, MA Feng, ZHU Xi, ZHANG Han-xiong, WANG Gui-ling. 2020. Geothermal characteristics of the geothermal fluid in the Rongcheng geothermal filed, Xiong'an New Area[J]. Acta Geologica Sinica, 94(7):1991-2001(in Chinese with English abstract).
ZHU Xi, WANG Gui-ling, MA Feng, LIN Wen-jing, ZHANG Wei, ZHANG Bao-jian, JIA Xiao-feng, ZHANG Han-xiong. 2022.Evaluation of the geothermal resource of the Xiong'an New Area[J]. Earth Science, https://kns.cnki.net/kcms/detail/42.1874.p.20220621.1102.008.html(in Chinese with English abstract).
ZHU Xi, WANG Gui-ling, WANG Xiu-yan, QI Shi-hua, MA Feng, ZHANG Wei, ZHANG Han-xiong. 2022. Hydrogeochemical and isotopic analyses of deep geothermal fluids in the Wumishan Formation in Xiong'an New Area, China[J].Lithosphere, 5: 2576752.
ZHU Xi, WANG Gui-ling, MA Feng, ZHANG Wei, ZHANG Qing-lian, ZHANG Han-xiong. 2021. Hydrogeochemistry of geothermal waters from Taihang Mountain-Xiong'an New Area and its indicating significance[J]. Earth Science, 46(7):2594-2608(in Chinese with English abstract).
-
