Analysis of Thermal Storage Characteristics of the Guide Zhacang Geothermal Field in Gonghe Basin Based on Logging Data
-
摘要: 青海共和盆地东部的贵德次盆扎仓地区发育复合型高温地热资源, 先后施工完成的ZR1井3000 m裂隙型热储测温151.34 ℃, ZR2井4600 m干热岩热储测温214 ℃, 展现共和盆地良好的地热资源潜力。本文首次报道ZR2井全井常规与特殊测井数据, 评价了扎仓沟花岗岩热储的孔隙度、体积密度、岩石生热率、岩石力学、地应力等关键参数, 结果显示: ZR2井温测井显示4 092.8 m温度达到180 ℃, 4602 m深度井温214 ℃; 利用电成像测井识别出两段裂缝集中发育带, 分别为4210—4220 m和4310—4320 m, 并对全孔段裂缝的产状进行了统计分析; 利用井壁崩落和三井径法, 计算该钻孔现今最大主应力方向为近南北向; 共解释岩性破碎地层(疑似含水)21.4 m/2层, 岩性较完整地层70.4 m/7层, 岩性完整地层376.1 m/27层, 高放射性地层7.6 m/2层。热储测井解释结果为系统评价热储和开发利用提供参考。Abstract: This study investigated the development of compound high temperature geothermal resources in Zhacang Area, China. Temperature measurement of 3000 m fractured thermal storage in Well ZR1 is 151.34 ℃, and temperature measurement of 4600 m dry hot rock reservoir in Well ZR2 is 214 ℃, showing serviceable geothermal resources potential in Gonghe Basin. Our approach was intented to elucidate potentially serviceable geothermal resources in the Gonghe Basin. Key parameters such as porosity, bulk density, rock heat generation rate, rock mechanics, and ground stress of Zhacanggou granite thermal storage were evaluated. Our results showed that the temperature logging of 4092.8 m was at 180 ℃ and that of 4602 m was at 214 ℃ in Well ZR2.The electrical imaging logging was used to identify two fracture concentrated development zones, which were 4210-4220 m and 4310-4320 m. The occurrence of cracks throughout this section was analyzed statistically.Additionally, using borehole wall caving and the three-bore method, the maximum principal stress direction of the borehole was calculated to be nearly north-south. A total of 21.4 m for 2 lithologic fractured strata (suspected water cut), 70.4 m for 7 lithologic complete strata, 376.1 m for 27 lithologic complete strata, and 7.6 m for 2 highly radioactive strata ware interpreted. Overall, our results show the potential of the geothermal reservoir as an energy source and pave the way for its utilization.
-
Key words:
- Gonghe Basin /
- Guide /
- Zhacang geothermal field /
- dry hot rock /
- geophysical logging /
- high temperature geothermal
-
-
陈作, 许国庆, 蒋漫旗. 2019. 国内外干热岩压裂技术现状及发展建议[J]. 石油钻探技术, 48(6): 1-8.
冯来泉. 2000. 物探测井在地热开发中的应用[J]. 地球学报, 21(2): 212-215.
国家能源局. 2011. 油气储层评价方法: SY/T 6285-2011[S].北京: 石油工业出版社.
国家能源局. 2018. 地热能术语: NB/T 10097-2018[S]. 北京:中国石化出版社: 1-24.
雷玉德, 罗银飞, 许伟林. 2019. 青海省贵德县扎仓沟地热勘查报告[R]. 西宁: 青海省环境地质勘查局.
雷玉德, 童珏, 杨占梅, 杨绍康, 刘毅, 李小林. 2017. 青海省干热岩资源类型及典型地热模式[J]. 南水北调与水利科技, 15(4): 117-122.
李德威, 王焰新. 2015. 干热岩地热能研究与开发的若干重大问题[J]. 地球科学(中国地质大学学报), 40(11): 1858-1869.
李小林, 吴国禄, 雷玉德, 李重阳, 赵继昌, 白银国, 曾昭发, 赵振, 张珊珊, 赵爱军. 2016. 青海省贵德扎仓寺地热成因机理及开发利用建议[J]. 吉林大学学报(地球科学版), 46(1):220-229.
蔺文静, 刘志明, 马峰, 刘春雷, 王贵玲. 2012. 我国陆区干热岩资源潜力估算[J]. 地球学报, 33(5): 807-811.
蔺文静, 王贵玲, 邵景力, 甘浩男, 谭现锋. 2021. 我国干热岩资源分布及勘探:进展与启示[J]. 地质学报, 95(5):1366-1381.
陆川, 王贵玲. 2015. 干热岩研究现状与展望[J]. 科技导报, 33(19): 13-21.
马峰, 孙红丽, 蔺文静, 甘浩男, 王贵玲. 2015. 中国 EGS示范工程靶区选址与指标矩阵评价[J]. 科技导报, 33(8): 41-47.
马峰, 王贵玲, 孙占学, 张薇, 候贺晟, 郭晓阳. 2019. 利用测井资料获取松辽盆地深部热物性参数[J]. 地球学报, 40(2):350-360.
潘桂堂, 李兴振, 王立全, 丁俊, 陈智粱. 2002. 青藏高原及邻区大地构造单元初步划分[J]. 地质通报, 21(11): 701-707.
青海省地质矿产局.1991. 青海省区域地质志[M]. 北京: 地质出版社.
孙崇仁.1997. 青海省岩石地层[M]. 北京: 中国地质大学出版社.
唐显春, 王贵玲, 马岩, 张代磊, 刘忠, 赵旭, 程天君. 2020. 青海共和盆地地热资源热源机制与聚热模式[J]. 地质学报, 94(7): 2052-2065.
唐显春, 王贵玲, 张代磊, 马岩. 2023. 青藏高原东北缘活动构造与共和盆地高温热异常形成机制[J]. 地球学报, 44(1):7-20.
王贵玲, 张薇, 梁继运, 蔺文静, 刘志明, 王婉丽. 2017. 中国地热资源潜力评价[J]. 地球学报, 38(4): 449-459.
许天福, 胡子旭, 李胜涛, 姜振蛟, 侯兆云, 李凤昱, 梁旭, 冯波. 2018. 增强型地热系统: 国际研究进展与我国研究现状[J]. 地质学报, 92(9): 1936-1947.
雍世和, 张超谟.1996. 测井数据处理与综合解释[M]. 北京: 石油大学出版社.
张超, 胡圣标, 宋荣彩 左银辉, 姜光政, 雷玉德, 张盛生, 王朱亭. 2020. 共和盆地干热岩地热资源的成因机制: 来自岩石放射性生热率的约束[J]. 地球物理学报, 63(7): 2697-2709.
张佳宁. 2018. 青海贵德地热田储层岩石物理力学性质试验及产能评价[D]. 长春: 吉林大学.
张森琦, 吴海东, 张杨, 宋健, 张林友, 许伟林, 黎敦朋, 李胜涛, 贾小丰, 付雷, 李旭峰, 冯庆达. 2020. 青海省贵德县热水泉干热岩体地质-地热地质特征[J]. 地质学报, 94(5):1594-1605.
张雪亭, 杨生德.2007. 青海省板块构造研究[M]. 北京: 地质出版社.
周玲. 2020. 青海省贵德县扎仓沟地热田成因机理及开采潜力研究[D]. 长春: 吉林大学.
ALBERT K, SCHULZE M, FRANZ C, KOENIGSDORFF R, ZOSSEDER K. 2017. Thermal conductivity estimation model considering the effect of water saturation explaining the heterogeneity of rock thermal conductivity[J]. Geothermic, 66:1-12.
BIRCH F, ROY R F, DECKER E R. 1968. Heat flow and thermal history in New York and New England[M]//ZEN E, WHITE W S, HADTEY J B, et al. Studies of Appalachian geology:Northern and Maritime. New York: Interscience Publishers:421-462.
BIRCH F. 1954. Heat from radioactivity[J]. Nuclear Geology, New York: Wiley: 148-174.
BRIGAUD F, VASSEUR G, CAILLET G. 1992. Thermal state in the North Viking Graben (North Sea) determined from oil exploration well data[J]. Geophysics, 57(1): 69-88.
Bureau of Geological Exploration and Development of Qinghai Province.1991. Qinghai geology minerals bureau[M]. Beijing:Geological Publishing House(in Chinese).
CHEN Zuo, XU Guo-qing, JIANG Man-qi. 2019. The current status and development recommendations for dry hot rock fracturing technologies at home and abroad[J]. Petroleum Drilling Techniques, 47(6): 1-8(in Chinese with English abstract).
FENG Lai-quan. 2000. The application of geophysical logging to geothermal development[J]. Acta Geoscientia Sinica, 21(2):212-215(in Chinese with English abstract).
HARTMANN A, RATH V, CLAUSER C. 2005. Thermal conductivity from core and well log data[J]. International Journal of Rock Mechanics & Mining Sciences, 42(7-8): 1042-1055.
LEI Yu-de, LUO Yin-fei, XU Wei-lin. 2019. Geothermal exploration report of Zhacanggou, Guide County, Qinghai Province[R]. Xining: Environmental Geological Prospecting Bureau of Qinghai Province(in Chinese).
LEI Yu-de, TONG Jue, YANG Zhan-mei, YANG Shao-kang, LIU Yi, LI Xiao-lin. 2017. Research on the typical geothermal models of hot dry rocks in Qinghai[J]. South-to-North Water Transfers and Water Science & Technology, 15(4):117-122(in Chinese with English abstract).
LI De-wei, WANG Yan-xin. 2015. Major issues of research and development of hot dry rock geothermal energy[J]. Earth Science (Journal of China University of Geosiences), 40(11):1858-1869(in Chinese with English abstract).
LI Xiao-lin, WU Guo-lu, LEI Yu-de, LI Chong-yang, ZHAO Ji-chang, BAI Yin-guo, ZENG Zhao-fa, ZHAO Zhen, ZHANG Shan-shan, ZHAO Ai-jun. 2016. Suggestions for geothermal genetic mechanism and exploitation of Zhacang Temple geothermal energy in Guide County, Qinghai Province[J]. Journal of Jilin University (Earth Science Edition), 46(1): 220-229(in Chinese with English abstract).
LIN Wen-jing, LIU Zhi-ming, MA Feng, LIU Chun-lei, WANG Gui-ling. 2012. An estimation of HDR resources in China’s mainland[J]. Acta Geoscientica Sinica, 33(5): 807-811(in Chinese with English abstract).
LIN Wen-jing, WANG Gui-ling, SHAO Jing-li, GAN Hao-nan, TAN Xian-feng. 2021. Distribution and exploration of hot dry rock resources in China: progress and inspiration[J]. Acta Geologica Sinica, 95(5): 1366-1381(in Chinese with English abstract).
MA Feng, GAN Hao-nan. 2016. Research on formation mechanisms of hot dry rock resources in China[J]. Acta Geologica Sinica (English Edition), 90(4): 1418-1433.
MA Feng, SUN Hong-li, LIN Wen-jing, GAN Hao-nan, WANG Gui-ling. 2015. Target site selection and index matrix evaluation of EGS trial project in China[J]. Science & Technology Review, 33(8): 41-47(in Chinese with English abstract).
MA Feng, WANG Gui-ling, SUN Zhan-xue, ZHANG Wei, HOU He-sheng, GUO Xiao-yang. 2019. An analysis of thermal conductivity in Songliao Basin based on logging parameters[J]. Acta Geoscientica Sinica, 40(2): 350-360(in Chinese with English abstract).
NATIONAL ENERGY ADMINISTRATION. 2011. Evaluating methods of oil and gas reservoirs: SY/T 6285-2011[S]. Beijing: Petroleum Industry Press(in Chinese).
NATIONAL ENERGY ADMINISTRATION. 2018. Terminology of geothermal energy: NB/T 10097-2018[S]. Beijing: China Petrochemical Press: 1-24(in Chinese).
OLASOLO P, JUÁREZ M C, MORALES M P, D’AMICO S, LIARTE I A. 2016. Enhanced geothermal systems (EGS): A review[J]. Renewable and Sustainable Energy Reviews, 56:133-144.
PAN Gui-tang, LI Xing-zhen, WANG Li-quan, DING Jun, CHEN Zhi-liang. 2002. Preliminary division of tectonic units of the Qinghai-Tibet Plateau and its adjacent regions[J]. Geological Bulletin of China, 21(11): 701-707(in Chinese with English abstract).
RYBACH L. 1976. Radioactive heat production in rocks and its relation to other petrophysical parameters. Pure and Applied Geophysics, 114(2): 309-317.
TANG Xian-chun, LIU Sha-sha, ZHANG Dai-lei, WANG Gui-ling, LUO Yin-fei, HU Sheng-biao, XU Qiang. 2022. Geothermal accumulation constrained by the tectonic transformation in the Gonghe Basin, northeastern Tibetan Plateau[J]. Lithosphere, 2021(Special 5): 3936881.
TANG Xian-chun, WANG Gui-ling, MA Yan, ZHANG Dai-lei, LIU Zhong, ZHAO Xu, CHENG Tian-jun. 2020. Geological model of heat source and accumulation for geothermal anomalies in the Gonghe basin, northern Tibetan Plateau[J].Acta Geologica Sinica, 94(7): 2052-2065(in Chinese with English abstract).
TANG Xian-chun, WANG Gui-ling, ZHANG Dai-lei, MA Yan.2023. Coupling Mechanism of Geothermal Accumulation and the Cenozoic Active Tectonics Evolution in Gonghe Basin, Northeastern Margin of the Tibetan Plateau[J]. Acta Geoscientica Sinica, 44(1): 7-20(in Chinese with English abstract).
WOLLENBERG H A, SMITH A R. 1987. Radiogenic heat production of crustal rocks: An assessment based on geochemical data[J]. Geophysical Research Letters, 14(3): 295-298.
XU Tian-fu, HU Zi-xu, LI Sheng-tao, JIANG Zhen-jiao, HOU Zhao-yun, LI Feng-yu, LIANG Xu, FENG Bo. 2018. Enhanced geothermal system: International progresses and research status of China[J]. Acta Geologica Sinica, 92(9):1936-1947(in Chinese with English abstract).
ZHANG Chao, HU Sheng-biao, SONG rong-cai, ZUO Yin-hui, JIANG Guang-zheng, LEI Yu-de, ZHANG Sheng-sheng, WANG Zhu-ting. 2020. Genesis of the hot dry rock geothermal resources in the Gonghe basin: constraints from the radiogenic heat production rate of rocks[J]. Chinese Journal of Geophysics, 63(7): 2697-2709(in Chinese with English abstract).
ZHANG Jia-ning. 2018. Experimental research on physical-mechanical properties and productivity evaluation of geothermal reservoir in Guide, Qinghai[D]. Changchun: Jilin University(in Chinese with English abstract).
ZHANG Sen-qi, WU Hai-dong, ZHANG Yang, SONG Jian, ZHANG Lin-you, XU Wei-lin, LI Dun-peng, LI Sheng-tao, JIA Xiao-feng, FU Lei, LI Xu-feng, FENG Qing-da. 2020.Characteristics of regional and geothermal geology of the Reshuiquan HDR in Guide Country, Qinghai Province[J].Acta Geologica Sinica, 94(5): 1591-1605(in Chinese with English abstract).
ZHANG Xue-ting, YANG Sheng-de.2007. Studies of the tectonic plates of Qinghai Province[M]. Beijing: Geological Publishing House(in Chinese).
ZHOU Ling. 2020. Study on genesis mechanism and exploitation potential of Zhacanggou geothermal field in Guide County, Qinghai Province[D]. Changchun: Jilin University(in Chinese with English abstract).
-
