Geothermal Reservoirs Characteristics and Resource Assessment of Jixian System in Gaoyang Geothermal Field, Xiongan New Area
-
摘要: 雄安新区高阳低凸起区钻获华北盆地温度和产能最高的地热井, 揭示雄安新区3000 m以深存在地热开发的第二空间——蓟县系碳酸盐岩热储。高阳低凸起区深部碳酸盐热储规模化开发在服务雄安新区生态文明建设和清洁供暖方面具有重要的意义。本文建立雄安新区范围高阳低凸起热储空间结构, 初步查明了地热田雄安新区范围5000 m深度内的热储分布和性质。结果表明雄安新区高阳地热田深部主要为碳酸盐热储包括蓟县系雾迷山组、高于庄组。蓟县系雾迷山组顶界埋深 3000～3500 m, 厚度 300～1000 m, 热储温度100～120 ℃, 出水量90～170 m3/h, 具有温度高、水量大、热储易于回灌的特点; 高于庄组热储顶深3500～4200 m, 一般厚度不低于800 m, 热储温度一般在110～140 ℃, 出水量50～100 m3/h, 可作为新区的后备资源。文章分析了深部碳酸盐热储空间结构, 整个地热田分为三段, 由西向东分别为西部凹陷区、中央隆起区、东部斜坡区。西部凹陷区西向东逐渐覆盖了寒武系、石炭二叠系; 中央隆起区造上为雁翎潜山; 东部斜坡区雾迷山组上部为古近系地层覆盖。本文通过热储法计算了雄安新区高阳地热田蓟县系热储年地热可采资源量折合标准煤86.72万t; 数值法模拟了水位下降不低于150 m, 开采井温度下降小于2 ℃条件下, 蓟县系热储年地热可采资源量折合标准煤89.86万t 热储法与数值法结果相近, 评价结果可为高阳地热资源规划开发提供参考。Abstract: Geothermal wells with the highest temperature and productivity were drilled in Gaoyang low uplift region of Xiongan New Area in North China basin, revealing the existence of the second space for geothermal exploitation in the deep part of Xiongan New Area, the Jixian carbonate rock geothermal reservoir.The large-scale developent of deep carbonate geothermal reservoir in Gaoyang Low uplift is of great significance in serving the construction of ecological civilization and clean heating in Xiongan New Area. In this paper, the geothermal reservoir space structure of Gaoyang low uplift in Xiongan New Area is established, and the geothermal reservoir distribution and properties within 5000 m depth of the geothermal field in Xiongan New Area are preliminatively identified. The results show that the deep carbonate reservoirs in Gaoyang geothermal field are mainly composed of Wumishan Formation and Gaoyuzhuang Formation of Jixian System. The top boundary of Wumishan Formation in Jixian system has a burial depth of 3000~3500 m, a thickness of 300~1000 m, a geothermal reservoir temperature of 100~120 ℃, and a water yield of 90~170 m3/h. It exhibits characteristics including high temperature, large water volume and easy reservoir recharge. The top boundary of Gaoyuzhuang Formation has a burial depth of 1425~4200 m, and the thickness is generally not less than 800 m.The formation temperature is generally 110~140 ℃, and the water volume is about 50~100 m3/h, which can be used as the reserve resources of the new area. The spatial structure of deep carbonate geothermal reservoir was analyzed. The whole geothermal field is divided into three sections, which are west depression area, central uplift area and east slope area respectively from west to east. The western depression area gradually covers the Cambrian and Carboniferous Permian from west to east. The central uplift area is Yanling buried hill; The upper part of Wumishan Formation in the eastern slope area is covered by Paleogene strata. In this paper, the recoverable geothermal resources of Jixian Systerm in Gaoyang geothermal field are calculated as 867 200 tons of standard coal respectively by geothermal reservoir method. Numerical simulation results show that the annual recoverable geothermal resources of Jixian Systerm are equivalent to 89.86×104 t of standard coal under the condition that the water level drop is no less than 150 m and the temperature drop of mining well is less than 2 ℃.The results of the geothermal reservoir method and the numerical method are similar, and the evaluation results can provide reference for the planning and development of geothermal resources in Gaoyang.
-
-
陈墨香, 黄歌山, 张文仁, 张容燕, 刘炳义. 1982. 冀中牛驼镇凸起地温场的特点及地下热水的开发利用[J]. 地质科学, 25(3): 239-252.
陈墨香, 汪集旸, 汪缉安, 邓孝, 杨淑贞, 熊亮萍, 张菊明. 1990.华北断陷盆地热场特征及其形成机制[J]. 地质学报, 64(1):80-91.
陈墨香.1988. 华北地热[M]. 北京: 科学出版社.
崔悦. 2020. 雄安新区雾迷山组地热资源热源成因机制[D]. 北京: 中国石油大学.
戴明刚, 汪新伟, 刘金侠, 雷海飞, 鲍志东. 2019a. 雄安新区起步区及周边地热资源特征与影响因素[J]. 地质科学, 54(1):176-191.
戴明刚, 雷海飞, 胡甲国, 郭新锋, 马鹏鹏, 张家云. 2019b. 雄安新区顶面埋深在 3500 m以浅的中元古界热储可采地热资源量和开发参数评估[J]. 地质学报, 93(11): 2874-2888.
郭飒飒, 朱传庆, 邱楠生, 唐博宁, 崔悦. 2020. 雄安新区深部地热资源形成条件与有利区预测[J]. 地质学报, 94(7):2026-2035.
何登发, 单帅强, 张煜颖, 鲁人齐, 张锐锋, 崔永谦. 2018. 雄安新区的三维地质结构: 来自反射地震资料的约束[J]. 中国科学: 地球科学, 48(9): 1207-1222.
胡秋韵, 高俊, 马峰, 赵志宏, 刘桂宏, 王贵玲, 张薇, 朱喜, 张保建, 邢一飞. 2020. 雄安新区容城凸起区地热可采资源量动态预测[J]. 地质学报, 94(7): 2013-2025.
刘伟坡, 安永会, 吴玺, 沙娜, 付雷. 2013. 保定市高阳县地热资源开发利用现状[J]. 科技创新导报, 2: 104.
刘现川, 刘仕娟, 杨风良. 2018. 高阳县地热资源评价[J]. 煤炭技术, 37(4): 44-46.
鲁锴, 鲍志东, 季汉成, 刘金侠, 王贵玲, 马峰, 郭瑞婧, 曹瑛倬, 杨飞, 符勇, 李潇博, 华盈鑫, 阙宜娟, 李宗峰, 许西挺, 胡先才. 2019. 雄安新区蓟县系雾迷山组岩溶热储特征, 主控因素及有利区预测[J]. 古地理学报, 21(6): 885-900.
罗宁, 张军, 李健敏, 辛守良. 2021. 雄安新区及其周边古潜山地热资源开发利用前景[J]. 天然气工业, 41(7): 160-171.
马峰, 王贵玲, 张薇, 朱喜, 张汉雄, 岳高凡. 2020. 雄安新区容城地热田热储空间结构及资源潜力[J]. 地质学报, 94(7):1981-1990.
庞忠和, 孔彦龙, 庞菊梅, 胡圣标, 汪集暘. 2017. 雄安新区地热资源与开发利用研究[J]. 中国科学院院刊, 32(11):1224-1230.
庞忠和, 庞菊梅, 孔彦龙, 郭世炎, 王树芳, 黄永辉, 罗霁, 胡圣标. 2020. 大型岩溶热储识别方法与规模化可持续开采技术[J]. 科技促进发展, 16(Z1): 299-306.
唐博宁, 朱传庆, 邱楠生, 崔悦, 郭飒飒, 陈驰. 2020. 雄安新区雾迷山组岩溶裂隙发育特征[J]. 地质学报, 94(7):2002-2012.
王贵玲, 张薇, 梁继运, 蔺文静, 刘志明, 王婉丽. 2017. 中国地热资源潜力评价[J]. 地球学报, 38(4): 449-459.
王贵玲, 高俊, 张保建, 邢一飞, 张薇, 马峰. 2020. 雄安新区高阳低凸起区雾迷山组热储特征与高产能地热井参数研究[J].地质学报, 94(7): 1970-1980.
王思琪, 张保建, 李燕燕, 邢一飞, 袁文真, 李郡, 高俊, 赵甜.2021. 雄安新区高阳地热田东北部深部古潜山聚热机制[J].地质科技通报, 40(3): 12-21.
吴爱民, 马峰, 王贵玲, 刘金侠, 胡秋韵, 苗青壮. 2018. 雄安新区深部岩溶热储探测与高产能地热井参数研究[J]. 地球学报, 39(5): 523-532.
熊亮萍, 张菊明. 1988. 华北平原区地温梯度与基底构造形态的关系[J]. 地球物理学报, 31(2): 146-155.
杨明慧, 刘池阳, 杨斌谊. 2002. 冀中坳陷东部西倾断裂的构造负反转过程[J]. 石油勘探与开发, 29(6): 35-37.
于长春, 乔日新, 张迪硕. 2017. 雄安新区航磁推断的三维基底构造特征[J]. 物探与化探, 41(3): 385-391.
赵佳怡. 2020. 雄安新区深部热储空间结构与水热分异过程研究[D]. 北京: 中国地质科学院.
张保建, 邢一飞, 李燕燕. 2021. 雄安新区地热清洁能源调查评价成果报告[R]. 北京: 中国地质科学院.
中国国家标准化管理委员会. 1985. 中华人民共和国地质矿产部部标准: 地热资源评价方法(DZ40-85)[S]. 北京: 中国标准出版社.
CHEN Mo-xiang, HUANG Ge-shan, ZHANG Wen-ren, ZHANG Rong-yan, LIU Bing-yi. 1982. The temperature distribution pattern and the utilization of geothermal water at Niutuozhen basement protrusion of central Hebei Province[J]. Scientia Geologica Sinica, 25(3): 239-252(in Chinese with English abstract).
CHEN Mo-xiang, WANG Ji-yang, WANG Ji-an, DENG Xiao, YANG Shu-zhen, XIONG Liang-ping, ZHANG Ju-ming.1990. The characteristics of the geothermal field and its formation mechanism in the North China down-faulted basin[J].Acta Geologica Sinica, 64(1): 80-91(in Chinese with English abstract).
CHEN Mo-xiang.1988. Geothermal in North China[M]. Beijing:Science Press(in Chinese).
CIRIACO A E, ZARROUK S J, ZAKERI G. 2020. Geothermal resource and reserve assessment methodology: Overview, analysis and future directions[J]. Renewable and Sustainable Energy Reviews, 119: 109515.
CUI Yue. 2020. The heat source mechanism of Wumishan strata geothermal resources in Xiong’an new area, North China[D].Beijing: China University of Petroleum(in Chinese with English abstract).
DAI Ming-gang, WANG Xin-wei, LIU Jin-xia, LEI Hai-fei, BAO Zhi-dong. 2019a. Characteristics and influence factors of geothermal resources in the starting and adjacent zone of Xiong’an new area[J]. Chinese Journal of Geology, 54(1):176-191(in Chinese with English abstract).
DAI Ming-gang, LEI Hai-fei, HU Jia-guo, GUO Xin-feng, MA Peng-peng, ZHANG Jia-yun. 2019b. Evaluation of recoverable geothermal resources and development parameters of Mesoproterozoic thermal reservoir with the top surface depth of 3500 m and shallow in Xiong’an New Area[J]. Acta Ge-ologica Sinica, 93(11): 2874-2888(in Chinese with English abstract).
GUO Sa-sa, ZHU Chuan-qing, QIU Nan-sheng, TANG Bo-ning, CUI Yue. 2020. Formation conditions and favorable areas for the deep geothermal resources in Xiong’an New Area[J]. Acta Geologica Sinica, 94(7): 2026-2035(in Chinese with English abstract).
HE Deng-fa, SHAN Shuai-qiang, ZHANG Yu-ying, LU Ren-qi, ZHANG Rui-feng, CUI Yong-qian. 2018. 3-D geologic architecture of Xiong’an New Area: Constraints from seismic reflection data[J]. Science China Earth Sciences, 48(9):1207-1222(in Chinese).
HU Qiu-yun, GAO Jun, MA Feng, ZHAO Zhi-hong, LIU Gui-hong, WANG Gui-ling, ZHANG Wei, ZHU Xi, ZHANG Bao-jian, XING Yi-fei. 2020. Dynamic prediction of geothermal recoverable resources in Rongcheng uplift area of the Xiong’an New Area[J]. Acta Geologica Sinica, 94(7): 2013-2025(in Chinese with English abstract).
LIU Wei-po, AN Yong-hui, WU Xi, SHA Na, FU Lei. 2013. Current status of geothermal resources development and utilization in Gaoyang County, Baoding City[J]. Science and Technology Innovation Herald, 2: 104(in Chinese).
LIU Xian-chuan, LIU Shi-juan, YANG Feng-liang. 2018. Evaluation of geothermal resources in Gaoyang County[J]. Coal Technology, 37(4): 44-46(in Chinese with English abstract).
LU Kai, BAO Zhi-dong, JI Han-cheng, LIU Jin-xia, WANG Gui-ling, MA Feng, GUO Rui-jing, CAO Ying-zhuo, YANG Fei, FU Yong, LI Xiao-bo, HUA Ying-xin, QUE Yi-juan, LI Zong-feng, XU Xi-ting, HU Xian-cai. 2019. Characteristics, main controlling factors and favorable area prediction of karstic geothermal reservoirs of the Jixianian Wumishan Formation in Xiong’an New Area[J]. Journal of Palaeogeography(Chinese Edition), 21(6): 885-900(in Chinese with English abstract).
LUO Ning, ZHANG Jun, LI Jian-min, XIN Shou-liang. 2021.Development and utilization prospect of the geothermal resources in the buried hills of the Xiong’an New Area and its periphery[J]. Natural Gas Industry, 41(7): 160-171(in Chinese with English abstract).
MA Feng, WANG Gui-ling, ZHANG Wei, ZHU Xi, ZHANG Han-xiong, YUE Gao-fan. 2020. Structure of geothermal reservoirs and resource potential in the Rongcheng geothermal field in Xiong’an New Area[J]. Acta Geologica Sinica, 94(7):1981-1990(in Chinese with English abstract).
PANG Zhong-he, KONG Yan-long, PANG Ju-mei, HU Sheng-biao, Wang Ji-yang. 2017. Geothermal resources and development in Xiongan New Area[J]. Bulletin of Chinese Academy of Sciences, 32(11): 1224-1230(in Chinese with English abstract).
PANG Zhong-he, PANG Ju-mei, KONG Yan-long, GUO Shi-yan, WANG Shu-fang, HUANG Yong-hui, LUO Ji, HU Sheng-biao. 2020. Large-scale karst thermal storage identification method and large-scale sustainable mining technology[J]. Science and Technology for Development, 16(Z1):299-306(in Chinese with English abstract).
Standardization Administration of China. 1985. Standard of the Ministry of Geology and Mineral Resources of the People's Republic of China: Evaluation method of geothermal resources(DZ40-85)[S]. Beijing: China Standard Press(in Chinese).
TANG Bo-ning, ZHU Chuan-qing, QIU Nan-sheng, CUI Yue, GUO Sa-sa, CHEN Chi. 2020. Characteristics of the karst thermal reservoir in the Wumishan Formation in the Xiong’an New Area[J]. Acta Geologica Sinica, 94(7): 2002-2012(in Chinese with English abstract).
WANG Gui-ling, ZHANG Wei, LIANG Ji-yun, LIN Wen-jin, LIU Zhi-ming, WANG Wan-li. 2017. Evaluation of geothermal resources potential in China[J]. Acta Geoscientica Sinica, 38(4): 449-459(in Chinese with English abstract).
WANG Gui-ling, GAO Jun, ZHANG Bao-jian, XING Yi-fei, ZHANG Wei, MA Feng. 2020. Study on the thermal storage characteristics of the Wumishan Formation and huge capacity geothermal well parameters in the Gaoyang low uplift area of Xiong’an New Area[J]. Acta Geologica Sinica, 94(7):1970-1980(in Chinese with English abstract).
WANG Si-qi, ZHANG Bao-jian, LI Yan-yan, XING Yi-fei, YUAN Wen-zhen, LI Jun GAO Jun, ZHAO Tian. 2021. Heat accumulation mechanism of deep ancient buried hill in the northeast of Gaoyang geothermal field, Xiong’an New Area[J].Bulletin of Geological Science and Technology, 40(3):12-21(in Chinese with English abstract).
WU Ai-min, MA Feng, WANG Gui-ling, LIU Jin-xia, HU Qiu-yun, MIAO Qing-zhuang. 2018. A Study of deep-seated karst geothermal reservoir exploration and huge capacity geothermal well parameters in Xiongan New Area[J]. Acta Geoscientica Sinica, 39(5): 523-532(in Chinese with English abstract).
XIONG Liang-ping, ZHANG Ju-ming. 1988. Relationship between geothermal gradient and the relief of nasement rock in North China Plain[J]. Chinese Journal of Geophysics, 31(2):146-155(in Chinese with English abstract).
YANG Ming-hui, LIU Chi-yang, YANG Bin-yi. 2002. Negative structure inversion of the west-dipping faults in the eastern Jizhong depression[J]. Petroleum Exploration and Development, 29(6): 35-37(in Chinese with English abstract).
YU Chang-chun, QIAO Ri-xin, ZHANG Di-shuo. 2017. The basement tectonic characteristics from interpretation of aeromagnetic data in Xiong’an region[J]. Geophysical and Geochemical Exploration, 41(3): 385-391(in Chinese with English abstract).
ZHAO Jia-yi. 2020. Study on the spatial structure of deep thermal storage and the process of hydrothermal differentiation in Xiong’an New Area[D]. Beijing: Chinese Academy of Geological Science(in Chinese with English abstract).
ZHANG Bao-jian, XING Yi-fei, LI Yan-yan. 2021. Report on the survey and evaluation of geothermal clean energy in Xiong’an New Area[R]. Beijing: Chinese Academy of Geological Sciences(in Chinese).
-
