Geochemical Characteristics and Genesis of Crystalline Graphite Ore Bed Rocks in Northern Hebei Province
-
摘要: 晶质石墨是一种新兴战略矿产。近年在河北省北部发现了多处大中型晶质石墨矿床, 主要赋矿层位于新太古代崇礼上岩群、古元古代红旗营子岩群等, 具有良好的成矿潜力。通过系统的野外地质调查与采样、分析测试工作, 详细研究了赋矿层位的岩相学、地球化学特征, 并对碳质来源进行了分析。结果表明: 赋矿岩石主要为含石墨黑云斜长变粒岩、片麻岩与透辉岩, 原岩恢复以砂泥质碎屑岩、钙质沉积岩为主。主量元素含量变化较大, SiO2含量为38.90%～80.42%, CaO+MgO 为2.05%～31.93%, Al2O3为1.50%～15.34%; 稀土元素含量为79.1～321.4 μg/g, PAAS 标准化分布模式一般具有右倾或较平坦分布特征, δCe 略具负异常, 部分具有δEu异常。微量元素特征指示沉积环境为滨浅海环境, 部分地区存在富氧条件, 局部为还原环境或存在热液加入。石墨中碳同位素值为–26.0‰ ～ –20.7‰, 主要来源于生物成因有机碳; 大理岩碳同位素值为–3.8‰～1.1‰, 主要来源于碳酸盐岩成因无机碳。区内晶质石墨矿层分布受到地层、岩性、岩相控制, 含矿有利层位为古陆边缘滨浅海相富含有机质的砂泥质碎屑岩、钙质沉积岩。矿床成因为沉积变质型矿床。Abstract: Crystalline graphite is an emerging strategic mineral. In recent years, several large- and medium-sized crystalline graphite deposits have been found in northern Hebei Province, with great mineralization potentiality in this area. The main ore-bearing horizons are Neoarchean Upper Chonglishang Group and Paleoproterozoic Hongqiyingzi Group. Through systematic field geological survey, sampling, analysis and testing, the petrography and geochemical characteristics of the ore-bearing horizon were studied in detail, and the carbon source was analyzed. The results showed that the main host rocks were graphite-bearing biotite plagioclase granulite, graphite-bearing biotite plagioclase gneiss, and graphite-bearing biotite plagioclase diopsides. The proto-rocks restoration are mainly argillaceous clastic and calcareous sedimentary rocks. The contents of main elements in graphite bearing strata vary greatly, with SiO2 content of 38.90%~80.42%, CaO+MgO of 2.05%~31.93%, and Al2O3 of 1.50%~15.34%. The content of rare earth elements is 79.1~321.4 μg/g. PAAS standardized distribution pattern generally has the characteristics of right leaning or relatively flat distribution. Some samples have slightly δCe negative anomaly and δEu anomaly. The characteristics of trace elements indicate that the sedimentary environment is a coastal and shallow sea environment, with oxygen rich conditions in some areas, reduction environment or hydrothermal addition in some areas. The carbon isotope value of graphite is –26.0‰ to –20.7‰, which mainly comes from biogenic organic carbon. The carbon isotope value of marble ranges from –3.8‰ to 1.1‰, mainly derived from inorganic carbon of carbonate origin. The crystalline graphite ore bed in the area is controlled by stratum, lithology and lithofacies. The favorable ore bearing horizon is sandy argillaceous clastic rock and calcareous sedimentary rock rich in organic matter in the coastal shallow sea facies of the ancient continental margin.The deposit is a sedimentary metamorphic deposit.
-
Key words:
- northern margin of North China Plate /
- graphite ore /
- geochemistry /
- trace element /
- isotope of carbon
-
-
陈衍景, 刘丛强, 陈华勇, 等, 2000. 中国北方石墨矿床及赋矿孔达岩系碳同位素特征及有关问题讨论[J]. 岩石学报, 16(2): 233-244.
翟明国, 2019. 华北克拉通构造演化[J]. 地质力学学报, 25(5):722-745.
杜登峰, 宋立方, 李献龙, 等, 2019. 张家口市康保县万隆店金矿区石墨矿床的发现及地质意义[J]. 矿产与地质, 33(4):635-641.
段炳鑫, 陈宏强, 赵华平, 等, 2023. 冀西北地区古元古代含石墨变质地层岩石矿物地球化学特征与成矿机制研究[J]. 岩石矿物学杂志, 42(2): 191-204.
河北省区域地质矿产调查研究所, 2017.中国区域地质志•河北志[M]. 北京: 地质出版社: 1-49.
姜高珍, 李以科, 王安建, 等, 2017. 内蒙古乌拉特中旗大乌淀石墨矿成因特征分析[J]. 地学前缘, 24(5): 306-316.
李超, 王登红, 赵鸿, 等, 2015. 中国石墨矿床成矿规律概要[J].矿床地质, 34(6): 1223-1236.
李曙光, 支霞臣, 陈江峰, 等, 1983. 鞍山前寒武纪条带状含铁建造中石墨的成因[J]. 地球化学, (2): 162-169.
梁帅, 2015. 华北典型晶质石墨矿床成因研究[D]. 阜新: 辽宁工程技术大学: 120.
梁钰琦, 赵永, 吴光存, 等, 2020. 山西省大同市新荣区石墨矿岩石矿物地球化学特征与成因[J]. 地球学报, 41(6):827-834.
刘敬党, 肖荣阁, 张艳飞, 等, 2017.华北显晶质石墨矿床[M].北京: 科学出版社: 1-68.
马旭东, 钟焱, 陈雅丽, 等, 2019. 华北克拉通孔兹岩带内孔兹岩系沉积过程对石墨矿床成矿的控制[J]. 大地构造与成矿学, 43(6): 1155-1168.
莫如爵, 刘绍斌, 黄翠蓉, 等, 1989.中国石墨矿床地质[M]. 北京: 中国建筑工业出版社.
齐新国, 谭均, 王志刚, 等, 2017. 张北县义哈德一带石墨成矿地质条件分析[J]. 中国非金属矿工业导刊, 126(2): 33-36, 39.
秦朝建, 裘愉卓, 温汉捷, 等, 2009. 白云鄂博矿床石墨的发现及其地质意义[J]. 矿物学报, 29(S1): 234-235.
谭均, 2019. 蒙西南-冀北石墨矿化带成矿地质特征及矿床成因探讨[J]. 矿产勘查, 10(1): 17-32.
田景春, 张翔, 2016.沉积地球化学[M]. 北京: 地质出版社:21-156.
王时麒, 1989. 内蒙兴和石墨矿含矿建造特征与矿床成因[J]. 矿床地质, 8(1): 85-96.
肖克炎, 孙莉, 李思远, 等, 2016. 我国石墨矿产地质特征及资源潜力分析[J]. 地球学报, 37(5): 607-614.
颜玲亚, 高树学, 陈正国, 等, 2018. 中国石墨矿成矿特征及成矿区带划分[J]. 中国地质, 45(3): 421-440.
张艳飞, 梁帅, 赵青, 等, 2020. 石墨矿床类型及显晶质石墨矿床成矿模式(Ⅱ): 矿石矿物及矿化特征[J]. 化工矿产地质, 42(2): 97-105, 124.
章少华, 1995. 豫西南石墨矿床成因新认识[J]. 建材地质, (1):2-5, 29.
赵宗溥, 1993.中朝准地台前寒武纪地壳演化[M]. 北京: 科学出版社.
中华人民共和国自然资源部, 2022. 中国矿产资源报告(2022)[R]. 北京: 地质出版社: 1-8.
朱建江, 刘福来, 刘福兴, 等, 2021. 胶-辽-吉造山带辽河群石墨矿碳同位素特征及成因分析[J]. 岩石学报, 37(2):599-618.
CHEN Yanjing, LIU Congqiang, CHEN Huayong, et al., 2000.Carbon isotope geochemistry of graphite deposits and ore-bearing khondalite series in North China: implications for several geoscientific problems[J]. Acta Petrologica Sinica, 16(2): 233-244(in Chinese with English abstract).
CRAIG H, 1954. Geochemical implications of the isotopic composition of carbon in ancient rocks[J]. Geochimica et Cosmochimica Acta, 6(4): 186-196.
DU Dengfeng, SONG Lifang, LI Xianlong, et al., 2019. Discovery of graphite deposit in Wanlongdian gold mining area, Kangbao County, Zhangjiakou City and its geological significance[J]. Mineral Resources and Geology, 33(4): 635-641(in Chinese with English abstract).
DUAN Bingxin, CHEN Hongqiang, ZHAO Huaping, et al., 2023.Geochemical characteristics and metallogenic mechanism of the Paleoproterozoic graphite-bearing metamorphic strata in Northwestern Hebei Province[J]. Acta Petrologica et Mineralogica, 42(2): 191-204(in Chinese with English abstract).
FARQUHAR J, ZERKLE A L, BEKKER A, 2014. Geologic and geochemical constraints on Earth’s early Atmosphere[C]//FARQUHAR J. Treatise on geochemistry(Second edition), 6: The atmosphere–History. Oxford: Elsevier Ltd.:91-138.
Hebei Institute for Regional Geology and Mineral Investigation, 2017.Regional geology of China · Hebei Province[M]. Beijing: Geological Publishing House: 1-49(in Chinese).
HOEFS J, 2009.Stable Isotope Geochemistry (6th edition)[M].Berlin: Springer-Verlag Berlin Heidelberg: 20-135.
JIANG Gaozhen, LI Yike, WANG Anjian, et al., 2017. Genetic features of Dawudian graphite deposit in Urad Middle Banner, Inner Mongolia[J]. Earth Science Frontiers, 24(5): 306-316(in Chinese with English abstract).
LI Chao, WANG Denghong, ZHAO Hong, et al., 2015. Minerogenetic regulatity of graphite deposits in China[J]. Mineral Deposits, 34(6): 1223-1236(in Chinese with English abstract).
LI Shuguang, ZHI Xiachen, CHEN Jiangfeng, et al., 1983. Origin of graphites in early Precambrian banded iron formation in Anshan, China[J]. Geochimica, (2): 162-169(in Chinese with English abstract).
LIANG Shuai, 2015. Genisis studies of typical crystalline graphite deposits, in the North China[D]. Fuxin: Liaoning Technical University: 120(in Chinese with English abstract).
LIANG Yuqi, ZHAO Yong, WU Guangcun, et al., 2020. Research on geochemistry characteristics and genesis of the graphite deposit in Xinrong District of Datong City, Shanxi Province[J]. Acta Geoscientica Sinica, 41(6): 827-834(in Chinese with English abstract).
LIU Jingdang, XIAO Rongge, ZHANG Yanfei, et al., 2017. Phanerocrystalline graphite deposit in North China[M]. Beijing:Science Press: 1-68(in Chinese).
MA Xudong, ZHONG Yan, CHEN Yali, et al., 2019. Sedimentary process controls on the graphite mineralized in the Khondalite series, western North China Craton[J]. Geotectonica et Metallogenia, 43(6): 1155-1168(in Chinese with English abstract).
Ministry of Natural Resources of the People’s Republic of China, 2022. China Mineral Resources 2022[R]. Beijing: Geological Publishing House: 1-8(in Chinese).
MO Rujue, LIU Shaobin, HUANG Cuirong, et al., 1989. Geology of graphite deposits in China[M]. Beijing: China Architecture Publishing(in Chinese).
QI Xinguo, TAN Jun, WANG Zhigang, et al., 2017. Analysis on the geological conditions of graphite mineraliztion in Yihade area, Zhangbei County[J]. China Non-metallic Minerals Industry, 126(2): 33-36, 39(in Chinese).
QIN Chaojian, QIU Yuzhuo, WEN Hanjie, et al., 2009. Discovery of graphite in Baiyunebo Deposit and its geological significance[J]. Acta Mineralogica Sinica, 29(S1): 234-235(in Chinese).
SIMONER A, 1953. Stratigraphy and sedimentation of the Svecofennidic, early Archean supracrustal rocks in southwestern Finland[J]. Bulletin of the Geological Society of Finland, 160:1-64.
TAN Jun, 2019. Analysis on metallogenic geologic characteristics and origin of graphite ore in graphite mineralized belt of the Southwest region of Inner Mongolia and northern area of Hebei Province[J]. Mineral Exploration, 10(1): 17-32(in Chinese with English abstract).
TAYLOR S R, MCLENNAN S M, 1985.The continental crust: Its composition and evolution[M]. Oxford: Blackwell Scientific Public: 312.
TIAN Jingchun, ZHANG Xiang, 2016.Sedimentary geochemistry[M]. Beijing: Geological Publishing House: 21-156(in Chinese).
WAN Yusheng, LIU Dunyi, DONG Chunyan, et al., 2015. Formation and evolution of Archean continental crust of the Norh China Craton[C]//ZHAI Mingguo. Precambrian Geology of China. Berlin: Springer-Verlag: 59-136.
WANG Shiqi, 1989. Characteristics of ore-bearing formation and genesis of the Xinche Graphite Deposit in Inner Mongolia[J].Mineral Deposits, 8(1): 85-96(in Chinese with English abstract).
XIAO Keyan, SUN Li, LI Siyuan, et al., 2016. Geological characteristics and mineralization potential of graphite resource in China[J]. Acta Geoscientica Sinica, 37(5): 607-614(in Chinese with English abstract).
YAN Lingya, GAO Shuxue, CHEN Zhengguo, et al., 2018. Metallogenic characteristics and metallogenic zoning of graphite deposits in China[J]. Geology in China, 45(3): 421-440(in Chinese with English abstract).
YANG Qiongyan, SANTOSH M, WADA H, 2014. Graphite mineralization in Paleoproterozoic khondalites of the North China Craton: A carbon isotope study[J]. Precambrian Research, 255(2): 641-652.
ZHAI Mingguo, 2019. Tectonic evolution of the North China Craton[J]. Journal of Geomechanics, 25(5): 722-745(in Chinese with English abstract).
ZHANG Shaohua, 1995. A new understanding of the genesis of graphite deposits in southwestern Henan[J]. Building Materials Geology, (1): 2-5, 29(in Chinese with English abstract).
ZHANG Yanfei, LIANG Shuai, ZHAO Qing, et al., 2020. Types of graphite deposits and metallogenic patterns of phanerocrystalline graphite deposits(Ⅱ): Ore minerals and mineralizing characteristics[J]. Geology of Chemical Minerals, 42(2):97-105, 124(in Chinese with English abstract).
ZHAO Zongpu, 1993.Precambrian crustal evolution of Sino Korean Paraplatform[M]. Beijing: Science Press(in Chinese).
ZHU Jianjiang, LIU Fulai, LIU Fuxing, et al., 2021. Carbon isotope and genesis studies of graphite deposits in the Liaohe Group of the Jiao-Liao-Ji Orogenic Belt[J]. Acta Petrologica Sinica, 37(2): 599-618(in Chinese with English abstract).
-
