Machine learning-based inversion of aerosol optical depth inversion from FY-4A data
-
摘要: 我国新一代静止气象卫星FY-4A搭载了先进静止轨道辐射成像仪(advanced geostationary radiation imager, AGRI), 为了针对AGRI数据的特点开发基于机器学习算法的高时空分辨率AGRI气溶胶数据集, 利用2021年中国及周边地区67个全球地基气溶胶自动观测网络系统(aerosol robotic network, AERONET)站点数据, 选取AGRI数据中表观反射率数据、观测角度数据、高程和MODIS的地表反射率等因子, 采用随机森林(random forest, RF)、梯度增强回归(gradient boosting regression tree, GBRT)、极端梯度增强(extrme gradient boosting, XGBoost)和反向传播神经网络(back propagation neural network, BPNN)4种机器学习方法反演气溶胶光学厚度(aerosol optical depth, AOD)。根据模型评价指标选择最优模型, 实现基于FY-4A的AOD反演, 空间分辨率4 km, 并与时刻相近的MODIS气溶胶产品进行对比分析。结果表明: 4种机器学习建立的AOD反演模型相关系数R均在0.90以上, 平均绝对误差(mean absolute error, MAE)和均方根误差(root mean square error, RMSE)均在0.09和0.14以下, 机器学习模型对AOD反演具有一定的可行性; GBRT模型在4种机器学习中反演精度最优, 验证误差中R为0.82, MAE为0.16, RMSE为0.25, 47%的反演结果落在期望误差内, 表明GBRT反演出的FY-4A AOD与站点观测值基本一致; 将GBRT模型反演的AOD结果与MODIS气溶胶产品进行对比验证, 发现FY-4A AOD反演结果与MODIS AOD在空间分布上具有较好的一致性, 83.57%的网格偏差集中在[-1.0, 0)之间, FY-4A AOD反演值相对MODIS AOD略高。
-
关键词:
- 机器学习 /
- 气溶胶光学厚度 /
- FY-4A/AGRI数据 /
- AERONET /
- MODIS AOD产品
Abstract: This study aims to develop a machine learning algorithm based on the characteristics of AGRI data to generate an aerosol dataset with a high spatiotemporal resolution. Using aerosol data from 67 aerosol robotic network (AERONET) sites in China and its surrounding areas in 2021, this study selected data of factors such as apparent reflectance, observation angles, elevation, and MODIS surface reflectance acquired from FY-4A advanced geostationary radiation imager (AGRI)-a new generation geostationary meteorological satellite of China. Then, this study performed the inversion of aerosol optical depth (AOD) using four machine learning methods-random forest (RF), gradient boosting regression tree (GBRT), extreme gradient boosting (XGBoost), and back propagation neural network (BPNN). Using the optimal model determined based on evaluation metrics, this study achieved the AOD inversion with a spatial resolution of 4 km × 4 km based on FY-4A data. Then, this study compared the inversion results with MODIS aerosol products of roughly the same periods. The results indicate that the AOD inversion models based on the four machine learning algorithms yielded correlation coefficients (R) exceeding 0.90, mean absolute errors (MAEs) of less than 0.09, and root mean square errors (RMSE) below 0.14. This indicates that it is feasible to conduct AOD inversion using machine learning-based models. The GBRT-based model exhibited the highest inversion accuracy among the four methods, with a correlation coefficient of 0.82, MAE of 0.16, and RMSE of 0.25, as indicated by the verification results. Additionally, 47% of the inversion results fell within the expected error ranges, indicating that the results of AOD inversion from FY-4A data using the GBRT-based model were generally consistent with observed values. The comparison between the GBRT model-derived AOD inversion results and the results of MODIS aerosol products shows that the former exhibited high consistency with the latter in terms of spatial distribution, with 83.57% of grid deviations falling within the range from -1.0 to 0 and the former slightly higher than the latter.-
Key words:
- machine learning /
- AOD /
- FY-4A/AGRI /
- AERONET /
- MODIS AOD
-
-
[1] Mishra M K, Rathore P S, Misra A, et al.Atmospheric correction of multispectral VNIR remote sensing data:Algorithm and inter-sensor comparison ofAerosol and surface reflectance products[J].Earth and Space Science, 2020, 7(9):e2019EA000710.
[2] Xie Y, Xue Y, Guang J, et al.Deriving a global and hourly data set of aerosol optical depth over land using data from four geostationary satellites:GOES-16, MSG-1, MSG-4, and himawari-8[J].IEEE Transactions on Geoscience and Remote Sensing, 2020, 58(3):1538-1549.
[3] Sosnowski T R.Aerosols and human health:A multiscale problem[J].Chemical Engineering Science, 2023, 268:118407.
[4] Kaufman Y J, Wald A E, Remer L A, et al.The MODIS 2.1-/ spl mu/m channel-correlation with visible reflectance for use in remote sensing of aerosol[J].IEEE Transactions on Geoscience and Remote Sensing, 1997, 35(5):1286-1298.
[5] Levy R C, Remer L A, Mattoo S, et al.Second-generation operational algorithm:Retrieval of aerosol properties over land from inversion of Moderate Resolution Imaging Spectroradiometer spectral reflectance[J].Journal of Geophysical Research:Atmospheres, 2007, 112(D13):211-231.
[6] Hsu N C, Tsay S C, King M D, et al.Aerosol properties over bright-reflecting source regions[J].IEEE Transactions on Geoscience and Remote Sensing, 2004, 42(3):557-569.
[7] Hsu N C, Tsay S C, King M D, et al.Deep blue retrievals of Asian aerosol properties during ACE-asia[J].IEEE Transactions on Geoscience and Remote Sensing, 2006, 44(11):3180-3195.
[8] Chen Q X, Han X L, Gu Y, et al.Evaluation of MODIS, MISR, and VIIRS daily level-3 aerosol optical depth products over land[J].Atmospheric Research, 2022, 265:105810.
[9] Gao L, Chen L, Li C, et al.Evaluation and possible uncertainty source analysis of JAXA Himawari-8 aerosol optical depth product over China[J].Atmospheric Research, 2021, 248:105248.
[10] 胡秀清, 卢乃锰, 邱红.FY-1C/1D全球海上气溶胶业务反演算法研究[J].海洋学报, 2006, 28(2):56-65.
Hu X Q, Lu N M, Qiu H.Development of aerosol retrieval algorithm over global ocean using FY-1C/1D data[J].Acta Oceanologica Sinica, 2006, 28(2):56-65.
[11] 任通, 高玲, 李成才, 等.利用风云2C静止卫星可见光资料反演气溶胶光学厚度[J].北京大学学报(自然科学版), 2011, 47(4):636-646.
Ren T, Gao L, Li C C, et al.Retrieval of aerosol optical depth from Fengyun-2C geostationary satellite observation:Theory and implementation[J].Acta Scientiarum Naturalium Universitatis Pekinensis, 2011, 47(4):636-646.
[12] 刘智超, 王健, 张鹏, 等.风云三号卫星气溶胶光学厚度产品的适用性验证[J].环境监测管理与技术, 2023, 35(2):18-22.
Liu Z C, Wang J, Zhang P, et al.Verification of aerosol optical depth observed by FY-3 satellite[J].The Administration and Technique of Environmental Monitoring, 2023, 35(2):18-22.
[13] Saide P E, Kim J, Song C H, et al.Assimilation of next generation geostationary aerosol optical depth retrievals to improve air quality simulations[J].Geophysical Research Letters, 2014, 41(24):9188-9196.
[14] 许梦婕.FY-4A气象卫星对京津冀地区AOD的反演方法研究[D].南京:南京信息工程大学, 2021.Xu M J.Study on inversion method of AOD in Beijing-Tianjin-Hebei region by FY-4A meteorological satellite[D].Nanjing:Nanjing University of Information Science & Technology, 2021.
[15] Jiang X, Xue Y, Jin C, et al.A simple band ratio library (BRL) algorithm for retrieval of hourly aerosol optical depth using FY-4A AGRI geostationary satellite data[J].Remote Sensing, 2022, 14(19):4861.
[16] 陈兴峰, 郑逢杰, 郭丁, 等.气溶胶定量遥感的机器学习方法综述[J].遥感学报, 2021, 25(11):2220-2233.
Chen X F, Zheng F J, Guo D, et al.Review of machine learning methods for aerosol quantitative remote sensing[J].National Remote Sensing Bulletin, 2021, 25(11):2220-2233.
[17] Ristovski K, Vucetic S, Obradovic Z.Uncertainty analysis of neural-network-based aerosol retrieval[J].IEEE Transactions on Geoscience and Remote Sensing, 2012, 50(2):409-414.
[18] Levy R C, Remer L A, Kleidman R G, et al.Global evaluation of the Collection 5 MODIS dark-target aerosol products over land[J].Atmospheric Chemistry and Physics, 2010, 10(21):10399-10420.
[19] Ding H, Zhao L, Liu S, et al.FY-4A/AGRI aerosol optical depth retrieval capability test and validation based on NNAeroG[J].Remote Sensing, 2022, 14(21):5591.
[20] Yuan Q, Shen H, Li T, et al.Deep learning in environmental remote sensing:Achievements and challenges[J].Remote Sensing of Environment, 2020, 241:111716.
[21] Eck T F, Holben B N, Reid J S, et al.Wavelength dependence of the optical depth of biomass burning, urban, and desert dust aerosols[J].Journal of Geophysical Research:Atmospheres, 1999, 104(D24):31333-31349.
[22] Sun Z, Zhang B, Yao Y.Improving the estimation of weighted mean temperature in China using machine learning methods[J].Remote Sensing, 2021, 13(5):1016.
[23] 高阿芳.基于改进随机森林的耕深预测模型研究[D].长春:长春工业大学, 2022.Gao A F.Research on prediction model of tillage depth based on an improved random forest[D].Changchun:Changchun University of Technology, 2022.
[24] Levy R C, Mattoo S, Munchak L A, et al.The Collection 6 MODIS aerosol products over land and ocean[J].Atmospheric Measurement Techniques, 2013, 6(11):2989-3034.
[25] Levy R C, Munchak L A, Mattoo S, et al.Towards a long-term global aerosol optical depth record:Applying a consistent aerosol retrieval algorithm to MODIS and VIIRS-observed reflectance[J].Atmospheric Measurement Techniques, 2015, 8(10):4083-4110.
[26] Sawyer V, Levy R C, Mattoo S, et al.Continuing the MODIS dark target aerosol time series with VIIRS[J].Remote Sensing, 2020, 12(2):308.
[27] Chen Y, Fan M, Li M, et al.Himawari-8/AHI aerosol optical depth detection based on machine learning algorithm[J].Remote Sensing, 2022, 14(13):2967.
[28] 陈岚琪.基于GWR的郑州市域林地景观格局、气象与气溶胶光学厚度的空间关系研究[D].郑州:河南农业大学, 2020.Chen L Q.Spatial relationship among forest landscape pattern, meteorology and aerosol based on GWR model in Zhengzhou City[D].Zhengzhou:Henan Agricultural University, 2020.
[29] 杨阳, 赵娜, 岳天祥.1980-2018年中国极端高温事件时空格局演变特征[J].地理科学, 2022, 42(3):536-547.
Yang Y, Zhao N, Yue T X.Spatio-temporal variations of extreme high temperature event in China from 1980 to 2018[J].Scientia Geographica Sinica, 2022, 42(3):536-547.
[30] Xue R, Ai B, Lin Y, et al.Spatial and temporal distribution of aerosol optical depth and its relationship with urbanization in Shandong Province[J].Atmosphere, 2019, 10(3):110.
[31] Zhao C, Wang Y, Shi X, et al.Estimating the contribution of local primary emissions to particulate pollution using high-density station observations[J].Journal of Geophysical Research:Atmospheres, 2019, 124(3):1648-1661.
[32] Jin Q, Wei J, Yang Z L, et al.Consistent response of Indian summer monsoon to Middle East dust in observations and simulations[J].Atmospheric Chemistry and Physics, 2015, 15(17):9897-9915.
-
