EXPERIMENTAL STUDY ON DEFORMATION AND FAILURE MECHANISM OF SHALLOW LOESS LANDSLIDE UNDER THE EFFECT OF IRRIGATION
-
摘要:
为有效减少泾阳地区大面积灌溉活动诱发黄土滑坡对社会和经济带来的巨大损失，开展灌溉型滑坡室内实验研究，研究坡度在灌溉条件下对黄土滑坡变形破坏过程影响，具有重大的现实意义。本次实验设计了可用于坡顶和坡面的灌溉装置，同时进行了45°斜坡和60°斜坡的两组室内灌溉模型实验，且每组斜坡内埋设体积含水率传感器、基质吸力传感器和孔隙水压力传感器三种传感器记录其内部变化。通过对两组实验过程及结果进行对比分析，进而得出灌溉条件下浅表层黄土滑坡的变形破坏规律，总结出该类滑坡的破坏模式及其诱发机理。实验结果表明，实验前期随着体积含水率不断增大，基质吸力逐渐减小至基本稳定，土体强度随之减小；实验后期上部土体饱和，斜坡产生的变形和土体排水不畅产生了超孔隙水压力，有效应力随之减小，土体强度减小至最小，导致滑坡产生。同时，坡度越大，滑坡越易发生，滑面深度和滑动距离越小。
Abstract:In order to effectively reduce the enormous losses to society and economy caused by shallow loess landslides triggered by irrigation in large area of Jingyang, it is of great realistic significance to carry out laboratory experimental study on irrigation-induced landslides and to study the effects of slope gradient on deformation and failure process of loess slope under irrigation condition. Irrigation rig used for slope surface and slope top irrigation was designed. In the meanwhile, two groups of indoor physical model experiments respectively with slope of 45 degrees and slope of 60 degrees were conducted, and three kinds of sensors namely volume moisture sensors, matric suction sensors and pore water pressure sensors were buried inside the slopes to record the internal changes. Based on the analysis and the comparison of the experimental procedures and results of two groups, the deformation and failure law of shallow loess landslide under irrigation condition is disclosed, and the failure mode and the triggering mechanism of this kind of landslides are summarized. The experimental results show that, at the early stage of the experiments, with the continuous increases of volume moisture, the matric suction of the loess decreased gradually and maintained stable in the end while the strength reduced accordingly at the later stage, the upper loess of the slope reached the saturation stage, excess pore water pressure was generated by the slope deformation and poor drainage of the loess, which decreased the effective stress and the strength of the loess. As a result, the strength reached the minimum, which resulted in landslides. And meanwhile, the steeper a slope is, the greater probability of landslide occurrence is, and the smaller the depth of sliding surface and sliding distance are.
-
Key words:
- Loess slope /
- irrigation /
- landslide /
- physical model experiment /
- pore water pressure
-
-
表 1 实验黄土的物理参数
Table 1. Physical parameters of the loess used in experiments
天然重度/(kN/m3) 初始体积含水率/% 饱和体积含水率/% 塑限WP/% 液限WP/% 塑性指数IP 14.7 10 43 17.2 28.0 10.9
下载: 导出CSV
表 2 滑坡发展过程和滑动时间
Table 2. Development and sliding times of landslides
斜坡实验 主要破坏类型 现象描述 累计灌溉/L 整体滑动时间/min 60°斜坡 浅层滑动破坏 ①前缘坡脚侵蚀。②距离坡肩约10 cm处产生宽3 mm裂隙。③破坏较快，滑动距离远，最远达19 cm。 124.8 360 45°斜坡 浅层滑动破坏 ①坡脚冲蚀严重，形成临空面。②后缘轻微塌陷，出现1条贯通的拉裂隙距坡肩约13 cm。③滑动2 s完成，最远达到20 cm。 168.5 486
下载: 导出CSV
-
[1] 朱立峰, 胡炜, 贾俊, 等.甘肃永靖黑方台地区灌溉诱发型滑坡发育特征及力学机制[J].地质通报, 2013, 32(6):840~846. http://d.wanfangdata.com.cn/Periodical/zgqydz201306003
ZHU Lifeng, HU Wei, JIA Jun, et al. Development features and mechanical mechanism of irrigation-induced landslides in Heifangtai, Gansu Province[J]. Geological Bulletin of China, 2013, 32(6):840~846. (in Chinese with English abstract) http://d.wanfangdata.com.cn/Periodical/zgqydz201306003
[2] 徐善常, 梁庆国, 李帅帅, 等.甘肃定西原状Q3黄土各向异性试验研究[J].地质力学学报, 2015, 21(3):378~385. http://journal.geomech.ac.cn/ch/reader/view_abstract.aspx?file_no=20150308&flag=1
XU Shanchang, LIANG Qingguo, LI Shuaishuai, et al. Experimental study on anisotropic characteristics of undisturbed Q3 loess from Dingxi, Gansu[J]. Journal of Geomechanics, 2015, 21(3):378~385. (in Chinese with English abstract) http://journal.geomech.ac.cn/ch/reader/view_abstract.aspx?file_no=20150308&flag=1
[3] 蔺晓燕, 李同录, 赵纪飞, 等.甘肃黑方台黄土固结-渗透特性试验研究[J].水文地质工程地质, 2014, 41(1):41~47. http://d.wanfangdata.com.cn/Periodical/swdzgcdz201401007
LIN Xiaoyan, LI Tonglu, ZHAO Jifei, et al. Permeability characteristics of loess under different consolidation pressures in the Heifangtai platform[J]. Hydrogeology and Engineering Geology, 2014, 41(1):41~47. (in Chinese with English abstract) http://d.wanfangdata.com.cn/Periodical/swdzgcdz201401007
[4] 雷祥义.陕西泾阳南塬黄土滑坡灾害与引水灌溉的关系[J].工程地质学报, 1995, 3(1):56~64. http://www.gcdz.org/CN/abstract/abstract9837.shtml
LEI Xiangyi. The hazards of loess landslides in the southern tableland of Jingyang county, Shaanxi and their relationship with the channel water into fields[J]. Journal of Engineering Geology, 1995, 3(1):56~64. (in Chinese with English abstract) http://www.gcdz.org/CN/abstract/abstract9837.shtml
[5] 田尤, 杨为民, 黄晓, 等.天水市麦积区幅黄土滑坡发育分布特征及其孕灾因素分析[J].地质力学学报, 2016, 22(1):25~38. http://journal.geomech.ac.cn/ch/reader/view_abstract.aspx?file_no=20160103&flag=1
TIAN You, YANG Weimin, HUANG Xiao, et al. Distribution characteristics and inducing factors of loess landslide in Maiji mappable unit, Tianshui[J]. Journal of Geomechanics, 2016, 22(1):25~38. (in Chinese with English abstract) http://journal.geomech.ac.cn/ch/reader/view_abstract.aspx?file_no=20160103&flag=1
[6] 王家鼎, 肖树芳, 张倬元.灌溉诱发高速黄土滑坡的运动机理[J].工程地质学报, 2001, 9(3):241~246. http://d.wanfangdata.com.cn/Periodical/gcdzxb200103003
WANG Jiading, XIAO Shufang, ZHANG Zhuoyuan. The mechanism for movement of irrigation-induced high-speed loess landslide[J]. Journal of Engineering Geology, 2001, 9(3):241~246. (in Chinese with English abstract) http://d.wanfangdata.com.cn/Periodical/gcdzxb200103003
[7] 王家鼎, 惠泱河.黄土地区灌溉水诱发滑坡群的研究[J].地理科学, 2002, 22(3):305~310. http://d.wanfangdata.com.cn/Periodical/dlkx200203009
WANG Jiading, HUI Yanghe. Landslides in crows induced by irrigated water in Loess Area[J]. Scientia Geographica Sinica, 2002, 22(3):305~310. (in Chinese with English abstract) http://d.wanfangdata.com.cn/Periodical/dlkx200203009
[8] Xu L, Dai F C, Gong Q M, et al. Irrigation-induced loess flow failure in Heifangtai Platform, North-West China[J]. Environmental Earth Sciences, 2012, 66(6):1707~1713. doi: 10.1007/s12665-011-0950-y
[9] 朱立峰, 胡炜, 贾俊, 等.甘肃永靖黑方台地区灌溉诱发型滑坡发育特征及力学机制[J].地质通报, 2013, 32(6):840~846. (本条文献与第1条文献重复, 请核对) http://d.wanfangdata.com.cn/Periodical/zgqydz201306003
ZHU Lifeng, HU Wei, JIA Jun, et al. Development features and mechanical mechanism of irrigation-induced landslides in Heifangtai, Gansu Province[J]. Geological Bulletin of China, 2013, 32(6):840~846. (in Chinese with English abstract) http://d.wanfangdata.com.cn/Periodical/zgqydz201306003
[10] 谷天峰, 朱立峰, 胡炜, 等.灌溉引起地下水位上升对斜坡稳定性的影响——以甘肃黑方台为例[J].现代地质, 2015, 29(2):408~413. http://www.cqvip.com/QK/96868X/201502/664388825.html
GU Tianfeng, ZHU Lifeng, HU Wei, et al. Effect on slope stability due to groundwater rising caused by irrigation:A case study of Heifang platform in Gansu, China[J]. Geoscience, 2015, 29(2):408~413. (in Chinese with English abstract) http://www.cqvip.com/QK/96868X/201502/664388825.html
[11] 董英, 贾俊, 张茂省, 等.甘肃永靖黑方台地区灌溉诱发作用与黄土滑坡响应[J].地质通报, 2013, 32(6):893~898. http://d.wanfangdata.com.cn/Periodical/zgqydz201306011
DONG Ying, JIA Jun, ZHANG Maosheng, et al. An analysis of the inducing effects of irrigation and the responses of loess landslides in Heifangtai area[J]. Geological Bulletin of China, 2013, 32(6):893~898. (in Chinese with English abstract) http://d.wanfangdata.com.cn/Periodical/zgqydz201306011
[12] Dong Y, Zhang M S, Liu J, et al. Loess landslides respond to groundwater level change in Heifangtai, Gansu Province[A]. Sassa K, Canuti P, Yin Y P. Landslide Science for a Safer Geoenvironment:Landslide Science for a Safer Geoenvironment[M]. Cham:Springer, 2014, 227~231.
[13] 赵宽耀, 许强, 亓星, 等.甘肃黑方台黄土滑坡类型及其发育特征研究[J].人民长江, 2016, 47(14):46~50, 68. http://d.wanfangdata.com.cn/Periodical/rmcj201614011
ZHAO Kuanyao, XU Qiang, QI Xing, et al. Research on types and characteristics of loess landslides in Gansu Heifangtai[J]. Yangtze River, 2016, 47(14):46~50, 68. (in Chinese with English abstract) http://d.wanfangdata.com.cn/Periodical/rmcj201614011
[14] 慕焕东, 宋登艳, 张茂省, 等.灌溉诱发型黄土滑坡离心模型试验研究[J].岩土工程学报, 2016, 38(S2):172~177. http://d.wanfangdata.com.cn/Periodical/ytgcxb2016z2028
MU Huandong, SONG Dengyan, ZHANG Maosheng, et al. Centrifuge modelling tests on loess landslides induced by irrigation[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(S2):172~177. (in Chinese with English abstract) http://d.wanfangdata.com.cn/Periodical/ytgcxb2016z2028
[15] 宋登艳. 灌溉诱发型黄土滑坡离心模型实验和数值分析[D]. 西安: 长安大学, 2014.
http://kns.cnki.net/KCMS/detail/detail.aspx?filename=ytgc2016s2028&dbname=CJFD&dbcode=CJFQ SONG Dengyan. The centrifuge modeling test and numerical analysis of irrigation-induced loess landslide[D]. Xi'an:Chang'an University, 2014. (in Chinese with English abstract)
[16] 金艳丽, 戴福初.灌溉诱发黄土滑坡机理研究[J].岩土工程学报, 2007, 29(10):1493~1499. doi: 10.3321/j.issn:1000-4548.2007.10.011
JIN Yanli, DAI Fuchu. The mechanism of irrigation-induced landslides of loess[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(10):1493~1499. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-4548.2007.10.011
[17] Hu W, Zhu L F, Zhang M S, et al. Analyses of the changes of loess engineering properties induced by irrigation[A]. Sassa K, Canuti P, Yin Y P. Landslide Science for a Safer Geoenvironment:Volume 2:Methods of Landslide Studies[M]. Cham:Springer, 2014, 215~220.
[18] 赵纪飞. 灌溉引发的黑方台黄土滑坡-泥流形成机理研究[D]. 西安: 长安大学, 2013.
ZHAO Jifei. The failure mechanism of irrigation-induced slide-flow on Heifangtai loess platform[D]. Xi'an:Chang'an University, 2013. (in Chinese with English abstract)
[19] 杨飞. 黑方台灌溉诱发黄土滑坡变形机理研究[D]. 西安: 长安大学, 2013.
http://cdmd.cnki.com.cn/Article/CDMD-11941-1014023162.htm YANG Fei. Study on the irrigation induced mechanism of loess landslide deformation of Hei Fangtai[D]. Xi'an:Chang'an University, 2013. (in Chinese with English abstract)
[20] 武彩霞, 许领, 戴福初, 等.黑方台黄土泥流滑坡及发生机制研究[J].岩土力学, 2011, 32(6):1767~1773. http://d.wanfangdata.com.cn/Periodical/ytlx201106028
WU Caixia, XU Ling, DAI Fuchu, et al. Topographic features and initiation of earth flows on Heifangtai loess plateau[J]. Rock and Soil Mechanics, 2011, 32(6):1767~1773. (in Chinese with English abstract) http://d.wanfangdata.com.cn/Periodical/ytlx201106028
[21] 朱立峰, 谷天峰, 胡炜, 等.灌溉诱发黄土滑坡的发育机制研究[J].工程地质学报, 2016, 24(4):485~491. http://d.wanfangdata.com.cn/Periodical/gcdzxb201604001
ZHU Lifeng, GU Tianfeng, HU Wei, et al. Developmental mechanism of irrigation-induced loess landslides[J]. Journal of Engineering Geology, 2016, 24(4):485~491. (in Chinese with English abstract) http://d.wanfangdata.com.cn/Periodical/gcdzxb201604001
[22] 胡炜, 张茂省, 朱立峰, 等.黑方台灌溉渗透型黄土滑坡的运动学模拟研究[J].工程地质学报, 2012, 20(2):183~188. http://d.wanfangdata.com.cn/Periodical/gcdzxb201202005
HU Wei, ZHANG Maosheng, ZHU Lifeng, et al. Kinematic simulation of irrigation-induced loess landslide in Heifangtai[J]. Journal of Engineering Geology, 2012, 20(2):183~188. (in Chinese with English abstract) http://d.wanfangdata.com.cn/Periodical/gcdzxb201202005
[23] Li T L, Zhao J F, Li P, et al. Failure and motion mechanisms of a rapid loess flowslide triggered by irrigation in the Guanzhong irrigation area, Shaanxi, China[A]. Wang F W, Miyajima M, Li T L. Progress of Geo-Disaster Mitigation Technology in Asia[M]. Berlin Heidelberg:Springer, 2013, 421~433.
[24] Terzaghi K. Theoretical Soil Mechanics[M]. New York:John Wiley & Sons, 1943.
-
