Zircon U- Pb age and geological significance of quartz monzonite from Qingjianpo, Shanxi Province
-
摘要:
通过对华北克拉通北缘青尖坡石英二长岩锆石U-Pb同位素年龄分析, 并结合相关主量和稀土元素数据探讨其地质意义。研究表明, 石英二长岩LA-ICP-MS锆石U-Pb同位素年龄为241.1±1.7Ma, 为早中三叠世岩浆活动的产物。岩石具有富K、Na、Si、Al, 贫Mg、Ca、Ti等特征, 为高钾碱性钾玄岩系列, 属于过铝质花岗岩类；轻稀土元素相对富集, 重稀土元素相对亏损, 具有稳定的弱负Eu异常。总体为I型花岗岩成因, 但兼具S型花岗岩的特征。青尖坡石英二长岩为中下地壳部分熔融成因, 有地幔物质参与, 为华北克拉通北缘三叠纪碱性岩带的组成部分, 形成于晚造山-造山后的伸展构造环境。
Abstract:In this paper, based on the study of Qingjianpo quartz monzonite of zircon U-Pb isotope age, and combine with the major element data and rare earth elementdata, the authors investigated its geological significance. The LA-ICP-MS zircon U-Pb isotopic age of quartz monzonite is 241.1±1.7Ma, revealing that it is a product of the Early-Middle Triassic magmatism. The rock is enriched in K, Na, Si, Al and depleted in Mg, Ca, Ti, belonging to high calc alkaline shoshonite series and peraluminous granitoid. The rock exhibits the enrichment of LREE relative to HREE, and Eu shows weak negative anomaly. The genetic type of Qingjianpo quartz monzonite is I-type granite. with some features of S-type granites. Qingjianpo quartz monzonite characteristics indicate that the rock was formed from partial melting of the mid-lower crust, with the addition of mantle material. Qingjianpo quartz monzonite is a part of the alkaline magmatic belt of Middle Triassic on the northern margin of North China Craton, and it was formed in the extensional tectonic environment of late orogenic-post-orogenic activity.
-
-
表 1 青尖坡石英二长岩LA-ICP-MS锆石U-Th-Pb分析结果
Table 1. The LA-ICP-MS zircon U-Th-Pb result of the Qingjianpo quartz monzonite
测点号 元素含量/10-6 Th/U 同位素比值 年龄/Ma Pb Th U 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ RZ100-1 14.0 331.3 264.1 1.25 0.0513 0.0017 0.271 0.008 0.0384 0.0005 252.2 73.2 243.6 6.0 242.7 3.0 RZ100-2 18.1 597.7 290.7 2.06 0.0511 0.0019 0.268 0.009 0.0380 0.0005 243.7 84.9 241.0 7.2 240.7 3.2 RZ100-3 13.1 313.3 200.6 1.56 0.0511 0.0021 0.277 0.010 0.0393 0.0005 242.9 90.5 248.2 8.1 248.7 3.1 RZ100-4 9.5 230.6 140.6 1.64 0.0513 0.0024 0.270 0.011 0.0381 0.0006 254.9 102.6 242.3 9.1 241.0 3.5 RZ100-5 30.2 1054.4 473.2 2.23 0.0511 0.0018 0.272 0.009 0.0386 0.0005 243.7 80.4 244.0 6.8 244.0 3.0 RZ100-6 32.2 1303.5 466.3 2.8 0.0513 0.0015 0.271 0.007 0.0383 0.0005 251.9 66.9 243.1 5.3 242.2 3.0 RZ100-7 12.2 271.7 237.8 1.14 0.0508 0.0016 0.266 0.007 0.0381 0.0005 229.5 72.7 239.8 5.8 240.9 3.0 RZ100-8 19.8 575.3 364.3 1.58 0.0541 0.0014 0.268 0.005 0.0360 0.0004 374.1 56.4 241.1 4.1 227.7 2.7 RZ100-9 14.8 423.4 264.9 1.6 0.0509 0.0017 0.268 0.008 0.0382 0.0005 234.2 76.1 241.0 6.2 241.7 3.1 RZ100-10 13.1 329.6 240.8 1.37 0.0510 0.0021 0.268 0.010 0.0381 0.0005 242.7 90.5 241.2 7.8 241.0 3.3 RZ100-11 154.0 140.4 259.3 0.54 0.1635 0.0033 10.642 0.129 0.4721 0.0055 2, 492.0 33.9 2, 492.4 11.3 2, 492.6 24.0 RZ100-12 25.0 755.8 413.6 1.83 0.0508 0.0013 0.266 0.005 0.0380 0.0005 230.9 58.5 239.7 4.2 240.5 2.8 RZ100-13 25.7 979.4 359.6 2.72 0.0511 0.0018 0.273 0.008 0.0387 0.0005 247.0 78.1 245.0 6.6 244.8 2.9 RZ100-14 19.6 523.9 316.2 1.66 0.0513 0.0014 0.272 0.006 0.0385 0.0005 255.2 63.2 244.6 4.9 243.5 2.9 RZ100-15 17.1 523.2 244.2 2.14 0.0514 0.0015 0.270 0.006 0.0381 0.0005 260.1 65.4 242.7 5.1 240.9 2.9 RZ100-16 19.0 642.6 327.0 1.96 0.0510 0.0021 0.264 0.010 0.0375 0.0005 242.4 92.4 238.0 7.9 237.5 3.1 RZ100-17 17.5 488.1 278.8 1.75 0.0509 0.0020 0.264 0.010 0.0376 0.0005 236.9 90.0 237.9 7.7 237.9 3.0 RZ100-18 30.9 1234.3 427.2 2.89 0.0510 0.0013 0.267 0.005 0.0379 0.0005 240.5 59.1 240.1 4.3 240.0 2.8 RZ100-19 17.4 493.6 309.5 1.59 0.0512 0.0016 0.266 0.007 0.0377 0.0005 248.6 71.3 239.6 5.7 238.7 3.0 RZ100-20 22.5 1077.2 357.9 3.01 0.0510 0.0033 0.266 0.017 0.0378 0.0006 240.4 142.8 239.5 13.3 239.4 3.5 RZ100-21 13.7 368.5 199.6 1.85 0.0509 0.0019 0.269 0.009 0.0383 0.0005 234.3 81.7 241.7 6.9 242.5 3.1 RZ100-22 12.8 412.0 183.9 2.24 0.0513 0.0016 0.272 0.007 0.0384 0.0005 254.7 71.0 244.1 5.8 243.0 3.0 RZ100-23 21.5 748.7 319.8 2.34 0.0514 0.0017 0.272 0.007 0.0384 0.0005 259.0 72.3 244.5 5.9 243.0 3.1 RZ100-24 20.0 634.5 311.4 2.04 0.0518 0.0015 0.275 0.006 0.0385 0.0005 275.7 64.4 246.5 5.1 243.4 3.0 RZ100-25 17.0 606.3 319.5 1.90 0.0770 0.0020 0.377 0.007 0.0355 0.0004 1, 120.0 50.5 324.9 5.4 225.1 2.7 RZ100-26 24.1 1361.8 652.1 2.09 0.1470 0.0032 0.427 0.006 0.0210 0.0003 2, 311.1 36.9 360.7 4.3 134.2 1.6 RZ100-27 32.3 1062.5 448.3 2.37 0.0509 0.0018 0.271 0.008 0.0386 0.0005 235.0 77.4 243.1 6.5 243.9 2.9 注：第3、8、11、25、26号测点误差较大，不参加计算
下载: 导出CSV
表 2 青尖坡石英二长岩地球化学数据
Table 2. Whole-rock major, rare-earth elements data of Qingjianpo quartz monzonite
样品编号 岩石名称 采样位置 SiO2 TiO2 Al2O3 Fe2O3 FeO MnO MgO CaO Na2O RZ1100 石英二长岩 青尖坡 69.39 0.28 16.22 1.75 0.38 0.02 0.37 0.61 3.89 Ⅶ1yQ334 石英二长岩 青尖坡 68.06 0.24 16.02 1.71 0.86 0.01 0.96 0.53 4.04 H164 石英二长岩 青尖坡 67.5 0.5 15.93 2.06 1.05 0.08 0.44 0.61 6.08 Gs8138 石英二长岩 青尖坡 65.25 0.24 16.78 1.87 0.96 0.06 0.53 1.52 5.12 Ⅶ1yQ333 石英二长斑岩 青尖坡 71.47 0.22 14.87 0.63 0.9 0.01 0.9 0.29 3.4 HY-01 石英二长岩 胡窑 67.22 0.3 17.09 1.84 0.72 0.03 0.95 0.96 4.6 YQ01 石英二长(斑)岩 青尖坡 - - - - - - - - - YQ03 石英二长(斑)岩 羊爪沟 - - - - - - - - - 样品编号 岩石名称 采样位置 K2O P2O5 烧失量 总计 Na2O+K2O K2O/Na2O A/CNK A/NK RZ1100 石英二长岩 青尖坡 5.22 0.14 1.34 99.61 9.11 1.34 1.23 1.34 Ⅶ1yQ334 石英二长岩 青尖坡 6.14 0.08 1.52 100.17 10.18 1.52 1.12 1.20 H164 石英二长岩 青尖坡 4.1 0.18 2.43 99.66 10.18 0.67 1.02 1.10 Gs8138 石英二长岩 青尖坡 5.61 0.22 1.62 99.78 10.73 1.1 0.97 1.16 Ⅶ1yQ333 石英二长斑岩 青尖坡 5.55 0.08 1.43 99.75 8.95 1.63 1.22 1.28 HY-01 石英二长岩 胡窑 4.15 0.11 0.42 100.55 10.41 1.08 1.24 1.42 YQ01 石英二长(斑)岩 青尖坡 - - - - - - - - - YQ03 石英二长(斑)岩 羊爪沟 - - - - - - - - - 样品编号 岩石名称 采样位置 La Ce Pr Nd Sm Eu Gd Tb Dy RZ1100 石英二长岩 青尖坡 49.9 93 11.2 39.6 6.22 1.52 5.83 0.63 2.49 Ⅶ1yQ334 石英二长岩 青尖坡 - - - - - - - - - H164 石英二长岩 青尖坡 - - - - - - - - - Gs8138 石英二长岩 青尖坡 - - - - - - - - - Ⅶ1yQ333 石英二长斑岩 青尖坡 - - - - - - - - - HY-01 石英二长岩 胡窑 87 142 14.7 51.3 7.73 2.13 5.64 0.712 3.34 YQ01 石英二长(斑)岩 青尖坡 48.4 82.4 8.7 32 5.03 1.16 2.7 0.48 1.89 YQ03 石英二长(斑)岩 羊爪沟 40.2 70.4 6.13 25.7 3.96 0.8 2.09 0.3 1.76 样品编号 岩石名称 采样位置 HO Er Tm Yb Lu Y ΣREE LREE HREE RZ1100 石英二长岩 青尖坡 0.43 1.17 0.15 1.04 0.15 10.9 213.33 201.44 11.89 Ⅶ1yQ334 石英二长岩 青尖坡 - - - - - - - - - H164 石英二长岩 青尖坡 - - - - - - - - - Gs8138 石英二长岩 青尖坡 - - - - - - - - - Ⅶ1yQ333 石英二长斑岩 青尖坡 - - - - - - - - - HY-01 石英二长岩 胡窑 0.573 1.66 0.251 1.53 0.206 18.2 318.77 304.86 13.91 YQ01 石英二长(斑)岩 青尖坡 0.56 0.96 0.14 0.88 0.14 8.73 185.44 177.69 7.75 YQ03 石英二长(斑)岩 羊爪沟 0.35 1.97 0.14 0.98 0.13 9.36 154.91 147.19 7.72 样品编号 岩石名称 采样位置 LREE/HREE (La/Yb)N (La/Sm)N (Gd/Lu)N δEu δCe 数据来源 RZ1100 石英二长岩 青尖坡 16.94 32.35 5.05 4.98 0.77 0.95 本文 Ⅶ1yQ334 石英二长岩 青尖坡 — — — — — — ② H164 石英二长岩 青尖坡 — — — — — — ② Gs8138 石英二长岩 青尖坡 — — — — — — ② Ⅶ1yQ333 石英二长斑岩 青尖坡 — — — — — — ② HY-01 石英二长岩 胡窑 21.92 38.34 7.08 3.51 0.99 0.96 [34] YQ01 石英二长(斑)岩 青尖坡 22.93 37.08 6.05 2.47 0.96 0.97 [35] YQ03 石英二长(斑)岩 羊爪沟 19.07 27.66 6.39 2.06 0.85 1.08 [35] 注：ΣLREE=ΣLREE(La-Eu)，ΣHREE=ΣHREE(Gd-Lu)，—表示未测出。主量元素含量单位为%，稀土元素含量单位为10-6
下载: 导出CSV
-
[1] 莫宣学, 赵志丹, 邓晋福, 等.印度-亚洲大陆主碰撞过程的火山作用响应[J].地学前缘, 2003, 10(3):135-148. doi: 10.3321/j.issn:1005-2321.2003.03.013
[2] 莫宣学.岩浆作用与青藏高原演化[J].高校地质学报, 2011, 17(3):351-367. doi: 10.3969/j.issn.1006-7493.2011.03.001
[3] 翟明国.克拉通化与华北陆块的形成[J].中国科学(D辑), 2011, 41(8):1037-1046. http://www.cnki.com.cn/Article/CJFDTotal-JDXK201108001.htm
[4] 路凤香, 郑建平, 李伍平, 等.中国东部显生宙地幔演化的主要样式":蘑菇云"模型[J].地学前缘, 2000, 7(1):97-107. doi: 10.3321/j.issn:1005-2321.2000.01.009
[5] Fan W M, Zhang H F, Baker J, et al. On and off the North China Craton:where is the Archean Keel?[J]. Journal of Petrology, 2000, 41:933-950. doi: 10.1093/petrology/41.7.933
[6] Xu Y G. Thermo-tectonic destruction of the Archean lithospheric keel beneath the Sino-Korean craton in China:Evidence, timing and mechanism[J]. Phys. Chem. Earth., 2001, 26:747-757. http://d.old.wanfangdata.com.cn/NSTLQK/10.1016-S1464-1895(01)00124-7/
[7] 翟明国, 朱日祥, 刘建明, 等.华北东部中生代构造体制转折的关键时限[J].中国科学(D辑), 2003, 33(10):913-920. http://d.old.wanfangdata.com.cn/Periodical/zgkx-cd200310001
[8] Deng J F, Mo X X, Zhao H L, et al. A new model for the dynamic evolution of Chinese lithosphere:"Continental roots-plumetectonics"[J]. Earth Sci. Rev., 2004, 65:223-275. doi: 10.1016/j.earscirev.2003.08.001
[9] 赵越, 张拴宏, 徐刚, 等.燕山板内变形带保罗纪主要构造事件[J].地质通报, 2004, 23:854-863. doi: 10.3969/j.issn.1671-2552.2004.09.006
[10] 陈斌, 牛晓露, 王志强, 等.华北克拉通北缘姚家庄过钾质超镁铁岩-正长岩杂岩体的锆石U-Pb年代学、岩石学和地球化学特征[J].中国科学(D辑), 2013, 43(7):1073-1087. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgkx-cd201307001
[11] 华仁民, 毛景文.试论中国东部中生代成矿大爆发[J].矿床地质, 1999, 18(4):300-307. doi: 10.3969/j.issn.0258-7106.1999.04.002
[12] Gao S, Rudnick R L, Carlson R W, et al. Re-Os evidence for replacement of ancient mantle lithosphere beneath the North China Craton[J]. Earth and Planetary Science Letters, 2002, 198(10):307-322. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=429c9ec6e6ee1428288c1bedac6293c3
[13] Wu F Y, Walker R J, Ren X W, et al. Osmium isotopic constraints on the age of lithospheric mantle beneath northeastern China[J]. Chemical Geology, 2003, 196(1):107-129. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=c6705e8db4348a6f14fc9e7a7dcfe6cc
[14] Wu F Y, Walker R J, Yang Y H, et al. The chemical-temporal evolution of lithospheric mantle underlying the North China Craton[J]. Geochimica et Cosmochimica Acta, 2006, 70(19):5013-5034. doi: 10.1016/j.gca.2006.07.014
[15] Deng J F, Su S G, Niu Y L, et al. A possible model for the lithospheric thinning of North China Craton:Evidence from the Yanshanian (Jura-Cretaceous) magmatism and tectonism[J]. Lithos, 2007, 96:22-35. doi: 10.1016/j.lithos.2006.09.009
[16] 吴福元, 徐义刚, 高山, 等.华北岩石圈减薄与克拉通破坏研究的主要学术争论[J].岩石学报, 2008, 24(6):1145-1174. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200806001
[17] Xu Y G, Blusztajn J, Ma J L, et al. Late Archean to Early Proterozoic lithospheric mantle beneath the western North China Craton:Sr-Nd-Os isotopes of peridotite xenoliths from Yangyuan and Fansi[J]. Lithos, 2008, 102:25-42. doi: 10.1016/j.lithos.2007.04.005
[18] 高山, 章军锋, 许文良, 等.拆沉作用与华北克拉通破坏[J].科学通报, 2009, 54(1):1962-1973. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=kxtb200914004
[19] 朱日祥, 陈凌, 吴福元, 等.华北克拉通破坏的时间、范围与机制[J].中国科学(D辑), 2011, 41(5):583-592. http://www.cnki.com.cn/Article/CJFDTotal-JDXK201105001.htm
[20] 钟福平, 钟建华, 艾合买提江·阿不都热合曼, 等.华北克拉通破坏时间与破坏范围分布特征——来自银根-额济纳旗盆地苏红图坳陷早白垩世火山岩的启示[J].中国地质, 2015, 42(2):435-456. doi: 10.3969/j.issn.1000-3657.2015.02.006
[21] 吴文彬, 王玉平, 于海峰, 等.华北克拉通北缘八当山火山岩及变质石英闪长岩锆石U-Pb年龄与岩石地球化学特征[J].地质通报, 2019, 38(4):592-602. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20190410&flag=1
[22] Wang Quan, Liu Xueya. Paleoplate tectonics between Cathaysia and Angaraland in Inner Mongolia of China[J]. Tectonics, 1986, 5(7):1073-1088. doi: 10.1029/TC005i007p01073
[23] 王荃, 刘雪亚, 李锦轶.中国华夏与安加拉古陆间的板块构造[M].北京:北京大学出版社, 1991:56-60.
[24] Sengor A M C, Natalin B A, Burtman V S. Evolution of the Altaidtectonic collage and Paleozoic crustal growth in Eurasia[J]. Nature, 1993, 364:299-307. doi: 10.1038/364299a0
[25] Xiao W J, Windley B F, Hao J, et al. Accretion leading to collision and the Permian Solonker suture, Inner Mongolia, China:Termination of the central Asian orogenic belt[J]. Tectonics, 2003, 22(6):1-20. http://cn.bing.com/academic/profile?id=4f70f4625c75e2c67f49e664df0bc8b5&encoded=0&v=paper_preview&mkt=zh-cn
[26] Windley B F, Alexeiev D, Xiao W J, et al. Tectonic models for accretion of the Central Asian Orogenic Belt[J]. Journal of the Geological Society London, 2007, 164:31-48. doi: 10.1144/0016-76492006-022
[27] 李锦轶, 张进, 杨天南, 等.北亚造山区南部及其毗邻地区地壳构造分区与构造演化[J].吉林大学学报(地球科学版), 2009, 39(4):584-605. http://d.old.wanfangdata.com.cn/Periodical/cckjdxxb200904002
[28] 徐备, 陈斌.内蒙古北部华北板块与西伯利亚板块之间中古生代造山带的结构和演化[J].中国科学(D辑), 1997, 27(3):227-232. http://www.cnki.com.cn/Article/CJFDTotal-JDXK199703005.htm
[29] 侯万荣, 聂凤军, 徐斌, 等.内蒙古中西部钼多金属矿床地质特征及其动力学背景[J].地质与勘探, 2010, 46(5):751-764. http://d.old.wanfangdata.com.cn/Periodical/dzykt201005001
[30] 张拴宏, 赵越, 刘建民, 等.华北地块北缘晚古生代-早中生代岩浆活动期次、特征及构造背景[J].岩石矿物学杂志, 2010, 29(6):824-842. doi: 10.3969/j.issn.1000-6524.2010.06.017
[31] 赵丽君.华北克拉通北缘早中生代岩体侵位与地壳变形——以盘山岩体周缘变形及年代学分析为例[J].地质与勘探, 2010, 46(1):102-112. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzykt201001013
[32] 赵越, 陈斌, 张拴宏, 等.华北克拉通北缘及邻区前燕山期主要地质事件[J].中国地质, 2010, 37(4):900-915. doi: 10.3969/j.issn.1000-3657.2010.04.007
[33] 程裕淇, 沈永和, 张良臣, 等.中国大陆的地质构造演化[J].中国区域地质, 1995, (4):289-294. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199500835811
[34] 龙灵利, 王玉往, 王京彬, 等.山西堡子湾-九对沟金(钼)矿区岩石地球化学特征及其意义[J].矿床地质, 2012, 31(3):493-505. doi: 10.3969/j.issn.0258-7106.2012.03.008
[35] 曹国雄, 高太忠, 吴有民.堡子湾金矿同位素及稀土元素地球化学研究[J].地质地球化学, 2000, 28(1):10-14. doi: 10.3969/j.issn.1672-9250.2000.01.002
[36] Le Maitre R W, Baterman P, Dudek A, et al. A classification of igneous rocks and glossary of tems[M]. Oxford:Blackwell, 1989:1-200.
[37] Rollinson H. Using Geochemical Data: Evaluation, Presentation, and Interpretation[M]. Longman Scientific & Technical, Harlow, United Kingdom, 1993: 352.
[38] Boynton W V. Geochemistry of the rare earth elements: Meteorite studies[C]//Henderson P. Rare Earth Element Chemistry. Amsterdam: Elsevier; 1984: 63-114.
[39] 张本仁, 傅家谟.地球化学进展[M].北京:化学工业出版社, 2005:200-217.
[40] 牛翠伊, 廖永骨, 卿敏, 等.山西堡子湾金矿成矿时代探讨[J].黄金地质, 2002, 8(1):17-20. http://d.old.wanfangdata.com.cn/Periodical/hjdz200201004
[41] 阎国翰, 牟保垒, 许保良, 等.燕辽-阴山三叠纪碱性侵入岩年代学和Sr, Nd, Pb同位素特征及意义[J].中国科学(D辑), 2000, 30(4):384-387. http://d.old.wanfangdata.com.cn/Periodical/zgkx-cd200004006
[42] 董毅, 刘显凡, 邓江红, 等.中甸弧西斑岩带印支期中酸性侵入岩成因与成矿意义[J].中国地质, 2012, 39(4):887-899. doi: 10.3969/j.issn.1000-3657.2012.04.004
[43] Zorpi M J, Coulon C, Orsini J B. Hybridization between felsic and mafic magmas in calc-alkaline granitoids:A case study in northern Sardinia[J]. Chemical Geology, 1991, 92(1/3):45-86 http://cn.bing.com/academic/profile?id=c946fa34232b39c98d49b406684341ff&encoded=0&v=paper_preview&mkt=zh-cn
[44] 邱家骧.岩浆岩岩石学[M].北京:地质出版社, 1985:37-39.
[45] Li X H, Li W X, Li Z X. On the genetic classification and tectonic implications of the Early Yanshanian granitoids in the Nanling Range, South China[J]. Chinese Science Bulletin, 2007, 52(14):1873-1885. doi: 10.1007/s11434-007-0259-0
[46] 王中刚, 于学元, 赵振华.稀土元素地球化学[M].北京:科学出版社, 1989:222-246.
[47] Schiano P, Monzier M, Eissen J P, et al. Simple mixing as the major control of the evolution of volcanic suites in the Ecuadorian Andes[J]. Contributions to Mineralogy and Petrology, 2010, 160(2):297-312. doi: 10.1007/s00410-009-0478-2
[48] Sylvester P J. Post-collisional peraluminous granites[J]. Lithos, 1998, 45:29-44. doi: 10.1016/S0024-4937(98)00024-3
[49] Bachelor R A, Bowden P. Petrogenetic interpretation of granitoid rock series using multicationic parameters[J]. Chemical Geology, 1985, 48(1):43-55. http://d.old.wanfangdata.com.cn/NSTLQK/10.1016-0009-2541(85)90034-8/
[50] Zhao G C, Cawood P A, Wilde S A, et al. Metamorphism of basement rocks in the Central Zone of the North China Craton:implications for Paleoproterozoic tectonic evolution[J]. Precambrian Research, 2000, 103:55-88. doi: 10.1016/S0301-9268(00)00076-0
[51] 翟明国, 彭澎.华北克拉通元古代构造事件[J].岩石学报, 2007, 23(11):2665-2682. doi: 10.3969/j.issn.1000-0569.2007.11.001
[52] Dobretsov N L, Berzin N A, Buslov M. Opening and tectonic evolution of the Paleo-Asian Ocean[J]. International Geology Review, 1995, 37:335-360. doi: 10.1080/00206819509465407
[53] Windley B F, Kroner A, Guo J H, et al. Neoproterozoic to Paleozoic geology of the Altai orogen, NW China:New zircon age data and tectonic evolution[J]. The Journal of Geology, 2002, 110:719-737. doi: 10.1086/342866
[54] Wu F Y, Zhao G C, Sun D Y, et al. The Hulan Group:Its role in the evolution of the Central Asian Orogenic Belt of NE China[J]. Journal of Asian Earth Sciences, 2007, 30:542-556. doi: 10.1016/j.jseaes.2007.01.003
[55] 阎国翰, 谭林坤, 许保良, 等.阴山地区印支期碱性侵入岩岩石地球化学特征[J].岩石矿物学杂志, 2001, 23(3):281-292. doi: 10.3969/j.issn.1000-6524.2001.03.010
[56] Li J Y. Permian Geodynamic Setting of northeast China and adjacent regions:Closure of the paleo-Asian ocean and subduction of the paleo-Pacific plate[J]. Journal of Asian Earth Sciences, 2006, 26(3/4):207-224. http://cn.bing.com/academic/profile?id=e77fd6a5ce2d0c1b863e92f716eaa12f&encoded=0&v=paper_preview&mkt=zh-cn
[57] 曾庆栋, 刘建明, 张作伦, 等.华北克拉通北缘西拉沐沦钼多金属成矿带钼矿化类型、特征及地球动力学背景[J].岩石学报, 2009, 25(5):1225-1238. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200905015
[58] 汤艳杰, 张宏福, 英基丰.阴山及邻区三叠纪富碱侵入岩的成因意义[J].岩石学报, 2009, 30(7):2031-2040. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201407016
[59] 赵辰, 巩恩普, 刘锦, 等.华北克拉通北缘东段"开原岩群"的解体及重新认识[J].地质与资源, 2018, 27(3):209-217, 256. doi: 10.3969/j.issn.1671-1947.2018.03.001
[60] 牟保磊, 阎国翰.燕辽三叠纪碱性偏碱性杂岩体地球化学特征及意义[J].地质学报, 1992, 66(2):108-121. http://www.cnki.com.cn/Article/CJFDTotal-DZXE199202001.htm
[61] 牛晓露, 杨经绥, 刘飞, 等.华北克拉通北缘包头东正长岩的成因:来自岩石矿物学和地球化学的证据[J].中国科学:地球科学, 2016, 46(3):374-391. http://www.cnki.com.cn/Article/CJFDTotal-JDXK201603008.htm
[62] 任荣, 牟保磊, 韩宝福, 等.河北矾山钾质碱性超镁铁岩-正长岩杂岩体的锆石SHRIMP U-Pb年龄[J].岩石学报, 2009, 25(3):588-594. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200903011
① 山西省地质调查院.1: 25万大同市幅区域地质调查报告.2014.
② 山西省地矿局区调队.1: 5万阳高县幅区域地质调查报告.1995.
③ 山西省地质局区调队.山西省中生代中酸性侵入岩.1982.
-
