电感耦合等离子体质谱联用技术在元素形态分析中的应用进展

,  ,  ,

文章导航 > 岩矿测试 > 2021 > 40(3): 327-339

上一篇

下一篇

刘崴, 胡俊栋, 杨红霞, 陈俊良. 电感耦合等离子体质谱联用技术在元素形态分析中的应用进展[J]. 岩矿测试, 2021, 40(3): 327-339. doi: 10.15898/j.cnki.11-2131/td.202006110089
引用本文: 刘崴, 胡俊栋, 杨红霞, 陈俊良. 电感耦合等离子体质谱联用技术在元素形态分析中的应用进展[J]. 岩矿测试, 2021, 40(3): 327-339. doi: 10.15898/j.cnki.11-2131/td.202006110089
shu
LIU Wei, HU Jun-dong, YANG Hong-xia, CHEN Jun-liang. Research Progress on Elemental Speciation Analysis by Inductively Coupled Plasma-Mass Spectrometry Hyphenated Techniques[J]. Rock and Mineral Analysis, 2021, 40(3): 327-339. doi: 10.15898/j.cnki.11-2131/td.202006110089
Citation: LIU Wei, HU Jun-dong, YANG Hong-xia, CHEN Jun-liang. Research Progress on Elemental Speciation Analysis by Inductively Coupled Plasma-Mass Spectrometry Hyphenated Techniques[J]. Rock and Mineral Analysis, 2021, 40(3): 327-339. doi: 10.15898/j.cnki.11-2131/td.202006110089
shu

电感耦合等离子体质谱联用技术在元素形态分析中的应用进展

  • 1.

    国家地质实验测试中心, 中国地质调查局元素微区形态分析重点实验室, 北京 100037

  • 2.

    中国地质调查局, 北京 100037

  • 3.

    中国原子能科学研究院核安全研究所, 北京 102413

  • 基金项目:
    中国地质调查局地质调查项目（DD20190589）；中国地质科学院基本科研业务费项目（CSJ202014）；国家地质实验测试中心大型科研仪器开放共享后补助资金项目（GXBZ-2021-01）
详细信息
    作者简介: 刘崴, 硕士, 副研究员, 主要研究方向为痕量超痕量元素形态分析方法及其应用。E-mail: hattieliu@126.com

  • 中图分类号: O657.63

Research Progress on Elemental Speciation Analysis by Inductively Coupled Plasma-Mass Spectrometry Hyphenated Techniques

  • 1.

    National Research Center for Geoanalysis, Key Laboratory of Element Microareas and Speciation Analysis, China Geological Survey, Beijing 100037, China

  • 2.

    China Geological Survey, Beijing 100037, China

  • 3.

    Institute of Nuclear Safety, China Institute of Atomic Energy, Beijing 102413, China

    摘要

  • 电感耦合等离子体质谱（ICP-MS）作为一种高灵敏度的分析技术在痕量超痕量无机元素分析方面已被广泛应用，其与色谱分离技术相结合为元素形态分析提供了强有力的检测工具。本文阐述了近年来利用不同ICP-MS联用技术进行元素形态分析的研究进展，主要包括：①气相色谱-电感耦合等离子体质谱联用技术（GC-ICP-MS）；②毛细管电泳-电感耦合等离子体质谱联用技术（CE-ICP-MS）；③离子色谱-电感耦合等离子体质谱联用技术（IC-ICP-MS）；④高效液相色谱-电感耦合等离子体质谱联用技术（HPLC-ICP-MS）。在此基础上归纳总结了中国元素形态分析领域的主要研究情况，对元素形态分析发展前景作了展望。这些联用技术中，GC-ICP-MS的灵敏度高，样品传输率接近100%，但其适用于易挥发或中等挥发性样品的分离，应用范围相对较窄；CE-ICP-MS的分离效率高，样品和试剂消耗量少，但受到其进样量限制使得最低检出浓度较大；IC-ICP-MS主要分析阴离子和阳离子及小分子极性化合物，是液相色谱的有益补充，具有分离效果好和快速方便等优点，但离子色谱流动相中的盐类会造成ICP-MS进样管和采样锥的堵塞，使得基体效应严重；HPLC-ICP-MS以其广泛的应用范围、简单的接口技术，成为元素形态分析研究中应用最广泛的联用技术。本文认为，元素形态分析研究中开展复杂基体样品前处理方法研究，研制系列元素形态分析标准物质，建立多元素形态同时分析方法是元素形态分析领域的发展方向。

    BACKGROUND

    As a highly sensitive analytical technique, ICP-MS has been widely used in the analysis of trace inorganic elements. Combined with chromatographic separation technology, it provides a powerful detection tool for elemental speciation analysis.

     OBJECTIVES

    To summarize the research progress of elemental speciation analysis by inductively coupled plasma mass spectrometry hyphenated techniques.

     METHODS

    The main methods of elemental speciation analysis by ICP-MS hyphenated techniques were summarized and compared. The methods included: (1) Gas chromatography coupled with ICP-MS (GC-ICP-MS). (2) Capillary electrophoresis coupled with ICP-MS (CE-ICP-MS). (3) Ion chromatography coupled with ICP-MS (IC-ICP-MS). (4) High performance liquid chromatography coupled with ICP-MS (HPLC-ICP-MS). The main application fields of elemental speciation analysis in China were biomedical field, food and drug safety monitoring and ecoenvironmental geochemistry.

     RESULTS

    GC-ICP-MS has high sensitivity and is suitable for volatile samples, its application is thus limited. CE-ICP-MS has fast analysis and high separation efficiency, but the limitation of sample injection volume makes the method detection limitation high. IC-ICP-MS mainly analyzes anions, cations and small molecular polar compounds. It is a useful complement to HPLC, but the mobile phase containing inorganic salts may block the sampling cone. HPLC-ICP-MS has been the most widely used technology in speciation analysis because of its wide application fields and simple technology.

     CONCLUSIONS

    Sample preparation research for complex matrices, preparing standard materials, and developing simultaneous multi-element speciation analysis methods are the research direction of elemental speciation analysis.
    • HTML全文
  • 加载中

  • 表 1  砷硒汞铅元素形态分析技术在食品领域的应用研究

    Table 1.  Application of As, Se, Hg and Pb speciation analysis in the food field

    元素 样品 主要色谱条件 分析性能 参考文献
    As 水稻 色谱柱：Hamilton PRP-X100；流动相：20mmol/L磷酸氢二铵和5%甲醇，等度洗脱 可检测As(Ⅲ)、As(Ⅴ)、MMA、DMA、ASA五种砷形态，检出限0.15~0.36μg/L 耿安静等[55]
    鸡肉和鸡肝 色谱柱：Dionex IonPac AS 7；流动相A：3.85mmol/L碳酸铵，流动相B：300mmol/L碳酸铵，梯度洗脱 可检测ROX、ASA、NPAA、CBS、As(Ⅲ)、As(Ⅴ)、MMA、DMA、AsB、AsC十种砷形态，检出限0.3~1.5μg/kg 吴思霖等[56]
    果汁 色谱柱：Prodigy 3 μODS(3)；流动相：5mmol/L丙二酸，3mol/L TBA，5%甲醇，等度洗脱 可检测As(Ⅲ)、DMA、MMA、As(Ⅴ)四种砷形态，检出限0.25、0.33、0.3、0.25μg/L Wang等[57]
    袋泡茶 色谱柱：Dionex IonPac AS19；流动相：30mmol/L碳酸铵，等度洗脱 可检测As(Ⅲ)、As(Ⅴ)、MMA、DMA、AsB五种砷形态，检出限0.04~0.08μg/L 李晓玉等[58]
    植物源保健食品 色谱柱：Thermo SCIENTIFIC AS7；流动相A: 0.35g/L碳酸铵；流动相B: 8g/L碳酸铵，梯度洗脱 可检测As(Ⅲ)、As(Ⅴ)、MMA、DMA、AsB、AsC六种砷形态，检出限0.23~0.54ng/mL 孟珊等[59]
    Se 奶粉 色谱柱：Hamilton PRP-X100；流动相：5mmol/L柠檬酸，10mmol/L乙酸铵，0.1%三氟乙酸，等度洗脱 可检测Se(Ⅳ)、Se(Ⅵ)、SeMet、Se(Cys)2四种硒形态，检出限0.03~0.10μg/L 林立等[60]
    茶叶 色谱柱：Hamilton PRP-X100；流动相A: 10mmol/L柠檬酸，流动相B: 超纯水；梯度洗脱 可检测Se(Ⅳ)、Se(Ⅵ)、SeMet、Se(Cys)2、MeSeCys五种硒形态，检出限0.13~1.09μg/L 陈贵宇等[61]
    苹果 色谱柱：Hamilton PRP-X100；流动相：5mmol/L柠檬酸，等度洗脱 可检测Se(Ⅳ)、Se(Ⅵ)、SeMet、Se(Cys)2、MeSeCys五种硒形态，检出限0.6~1.0μg/L 姚真真等[62]
    小麦 色谱柱：Hamilton PRP-X100；流动相：6mmol/L柠檬酸，等度洗脱 可检测Se(Ⅳ)、Se(Ⅵ)、SeMet、Se(Cys)2四种硒形态，检出限0.15~0.3μg/L 秦冲等[63]
    牛蒡和三七 色谱柱：Hamilton PRP-X100；流动相：8mol/L柠檬酸，等度洗脱 可检测Se(Ⅳ)、Se(Ⅵ)、SeMet、Se(Cys)2四种硒形态，检出限0.033~0.3ng/mL 曹玉嫔等[64]
    Hg 鱼肉 色谱柱：ZORBAX Eclipse Plus C18；流动相A：10mmol/L乙酸铵，0.12%半胱氨酸，流动相B：甲醇，梯度洗脱 可检测Hg(Ⅱ)、MeHg、EtHg三种汞形态，检出限 < 6.2μg/kg 张珂等[65]
    野生菌 色谱柱：Welch Ultimate XB C8；流动相A：甲醇，流动相B：10 mol/L醋酸铵，0.8g/L半胱氨酸，梯度洗脱 可检测Hg(Ⅱ)、MeHg、EtHg、PhHg四种汞形态，检出限0.6~4.5μg/kg Zou等[66]
    海参 色谱柱：Agilent ZORBAX SB-C18；流动相：8%甲醇，92%含0.12%半胱氨酸、0.01 mol/L醋酸铵水溶液，等度洗脱 可检测Hg(Ⅱ)、MeHg、EtHg三种汞形态，检出限分别为0.12、1.6、4.0μg/kg Liu等[67]
    Pb 水产品 色谱柱：Hypersil GLOD C18；流动相：乙二胺四乙酸二钠-乙酸钠溶液+甲醇(75+25，V/V)，等度洗脱 可检测无机铅、三甲基铅、三乙基铅，检出限均为0.01mg/kg 李杰等[68]
    海藻 毛细管柱：未涂层熔融石英毛细管；缓冲溶液：70mmol/L硼酸, 17.5mmol/L硼砂
    (Na2B4O7)    		 可检测无机铅、三甲基铅、三乙基铅，检出限0.091~0.03μg/L 李景喜等[69]
    下载: 导出CSV
    • 参考文献(76)
  • [1]

    李冰, 杨红霞. 电感耦合等离子体质谱原理和应用[M]. 北京: 地质出版社, 2005.

    Li B, Yang H X. Principle and application of inductively coupled plasma mass spectrometry[M]. Beijing: Geological Publishing House, 2005.

    [2]

    Templeton D M, Ariese F, Cornelis R, et al. Guildelines for terms related to chemical speciation and fraction of elements. Definitions, structural aspects, and methodological approaches (IUPAC Recommendations 2000)[J]. Pure and Applied Chemistry, 2000, 72(8): 1453-1470. doi: 10.1351/pac200072081453

    [3]

    李建文, 黄坚. 铬的形态分析研究与展望[J]. 冶金分析, 2006, 26(5): 38-43. doi: 10.3969/j.issn.1000-7571.2006.05.009

    Li J W, Huang J. Studies and prospect on the speciation analysis of chromium[J]. Metallurgical Analysis, 2006, 26(5): 38-43. doi: 10.3969/j.issn.1000-7571.2006.05.009

    [4]

    陈建国, 彭国俊, 朱晓艳, 等. 多元素形态同时分析的研究进展[J]. 理化检验(化学分册), 2015, 51(6): 881-887. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201506043.htm

    Chen J G, Peng G J, Zhu X Y, et al. Research progress in simultaneously speciation analysis of multi-elements[J]. Physical Testing and Chemical Analysis (Part B: Chemical Analysis), 2015, 51(6): 881-887. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201506043.htm

    [5]

    Li Y X, Chen B B, He M, et al. Biomethylation metabolism study of arsenite in SCC-7 cells by reversed phase ion pair high performance liquid chromatography-inductively coupled plasma-mass spectrometry[J]. Talanta, 2018, 188: 210-217. doi: 10.1016/j.talanta.2018.05.088

    [6]

    Liu Y, Zhang W, Zhao J T, et al. Selenoprotein P as the major transporter for mercury in serum from methylmercury-poisoned rats[J]. Journal of Trace Elements in Medicine and Biology, 2018, 50: 589-595. doi: 10.1016/j.jtemb.2018.04.013

    [7]

    Strohmidel P, Sperling M, Karst U. Investigations on the binding of ethylmercury from thiomersal to proteins in influenza vaccines[J]. Journal of Trace Elements in Medicine and Biology, 2018, 50: 100-104. doi: 10.1016/j.jtemb.2018.06.011

    [8]

    Chen B W, Cao F L, Lu X F, et al. Arsenic speciation in hair and nails of acute promyelocytic leukemia (APL) patients undergoing arsenic trioxide treatment[J]. Talanta, 2018, 184: 446-451. doi: 10.1016/j.talanta.2018.03.021

    [9]

    Son S H, Lee W B, Kim D, et al. An alternative analytical method for determining arsenic species in rice by using ion chromatography and inductively coupled plasma-mass spectrometry[J]. Food Chemistry, 2019, 270: 353-358. doi: 10.1016/j.foodchem.2018.07.066

    [10]

    Cui S, Kim C K, Lee K S, et al. Study on the analytical method of arsenic species in marine samples by ion chromatography coupled with mass spectrometry[J]. Microchemical Journal, 2018, 143: 16-20. doi: 10.1016/j.microc.2018.07.025

    [11]

    Chen S Y, Yuan B, Xu J J, et al. Simultaneous separation and determination of six arsenic species in Shiitake (Lentinus edodes) mushrooms: Method development and applications[J]. Food Chemistry, 2018, 262: 134-141. doi: 10.1016/j.foodchem.2018.04.036

    [12]

    Chen S Z, Zhu S P, Lu D B. Dispersive micro-solid phase extraction combined with dispersive liquid-liquid microextraction for speciation analysis of antimony by electrothermal vaporization inductively coupled plasma mass spectrometry[J]. Spectrochimica Acta Part B: Atomic Spectroscopy, 2018, 139: 70-74. doi: 10.1016/j.sab.2017.11.008

    [13]

    Hong S, Choi S D, Khim J S. Arsenic speciation in environmental multimedia samples from the Youngsan River Estuary, Korea: A comparison between freshwater and saltwater[J]. Environmental Pollution, 2018, 237: 842-850. doi: 10.1016/j.envpol.2017.11.020

    [14]

    Nan K, He M, Chen B B, et al. Arsenic speciation in tree moss by mass spectrometry based hyphenated techniques[J]. Talanta, 2018, 183: 48-54. doi: 10.1016/j.talanta.2018.02.055

    [15]

    Malejko J, Swierzewska N, Bajguz A, et al. Method development for speciation analysis of nanoparticle and ionic forms of gold in biological samples by high performance liquid chromatography hyphenated to inductively coupled plasma mass spectrometry[J]. Spectrochimica Acta Part B: Atomic Spectroscopy, 2018, 142: 1-7. doi: 10.1016/j.sab.2018.01.014

    [16]

    Drincic A, Zuliani T, Scancar J, et al. Determination of hexavalent Cr in river sediments by speciated isotope dilution inductively coupled plasma mass spectrometry[J]. Science of the Total Environment, 2018, 637-638: 1286-1294. doi: 10.1016/j.scitotenv.2018.05.112

    [17]

    陈俊良, 杨红霞, 刘崴, 等. 高效液相色谱-电感耦合等离子体质谱法测定内蒙古锡盟和新疆塔城高碘地区地下水的总碘及碘形态特征[J]. 岩矿测试, 2017, 36(6): 614-623. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201707040114

    Chen J L, Yang H X, Liu W, et al. Study on the total iodine and iodine speciation characteristics in Xilingol League, Inner Mongolia and Tacheng, Xinjiang high iodine area by high performance liquid chromatography-inductively coupled plasma mass spectrometry[J]. Rock and Mineral Analysis, 2017, 36(6): 614-623. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201707040114

    [18]

    陈登云. ICP-MS技术及其应用[J]. 现代仪器, 2001(4): 8-11. https://www.cnki.com.cn/Article/CJFDTOTAL-XDYI200104002.htm

    Chen D Y. ICP-MS and its application[J]. Modern Instruments, 2001(4): 8-11. https://www.cnki.com.cn/Article/CJFDTOTAL-XDYI200104002.htm

    [19]

    王中瑗, 张宏康, 陈思敏, 等. 电感耦合等离子体质谱法分析元素形态的研究进展[J]. 理化检验(化学分册), 2016, 52(11): 1359-1364. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201611033.htm

    Wang Z Y, Zhang H K, Chen S M, et al. Recent progress of ICP-MS in speciation analysis of elements[J]. Physical Testing and Chemical Analysis (Part B: Chemical Analysis), 2016, 52(11): 1359-1364. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201611033.htm

    [20]

    冷桃花, 郑翌, 陆志芸. 电感耦合等离子体质谱联用技术在食品中5种元素形态分析中的应用[J]. 食品安全质量检测学报, 2019, 10(18): 6176-6183. https://www.cnki.com.cn/Article/CJFDTOTAL-SPAJ201918037.htm

    Leng T H, Zheng Y, Lu Z Y. Application of inductively coupled plasma mass spectrometry in speciation analysis of 5 kinds of elements in food[J]. Journal of Food Safety and Quality, 2019, 10(18): 6176-6183. https://www.cnki.com.cn/Article/CJFDTOTAL-SPAJ201918037.htm

    [21]

    Castro J, Neubauer K, Zhang Z. The analysis of mercury speciation in biological tissue by GC-ICP-MS[J]. Environmental Chemistry, 2017, 36(10): 2295-2296.

    [22]

    冷金慧, 王立军, 刘亮, 等. 全自动蒸馏前处理-ID/GC-ICP-MS测定海水中痕量甲基汞[J]. 分析测试学报, 2018, 37(9): 1071-1075. doi: 10.3969/j.issn.1004-4957.2018.09.015

    Leng J H, Wang L J, Liu L, et al. Determination of trace of methylmercury in seawater by isotope dilution/gas-chromatography-inductively coupled plasma mass spectrometry with an automatic distillation[J]. Journal of Instrumental Analysis, 2018, 37(9): 1071-1075. doi: 10.3969/j.issn.1004-4957.2018.09.015

    [23]

    Bergant M, Milačič R, Ščančar J. Determination of polybrominated diphenyl ethers in human serum by gas chromatography-inductively coupled plasma mass spectrometry[J]. Journal of Chromatography A, 2018, 1572: 112-118. doi: 10.1016/j.chroma.2018.08.043

    [24]

    Zhang C, Li X Q, Chen Y L, et al. The compound-independent calibration of polybrominated diphenyl ethers isomers using gas chromatography-inductively coupled plasma mass spectrometry[J]. Journal of Chromatography A, 2018, 1576: 120-130. doi: 10.1016/j.chroma.2018.09.035

    [25]

    李金英, 鲁盛会, 石磊, 等. 毛细管电泳-电感耦合等离子体质谱联用技术及其元素形态分析的新进展[J]. 质谱学报, 2012, 33(4): 193-201. https://www.cnki.com.cn/Article/CJFDTOTAL-ZPXB201204002.htm

    Li J Y, Lu S H, Shi L, et al. Recent progress of trace element speciation analysis by capillary electrophoresis-inductively coupled plasma mass spectrometry[J]. Journal of Chinese Mass Spectrometry Society, 2012, 33(4): 193-201. https://www.cnki.com.cn/Article/CJFDTOTAL-ZPXB201204002.htm

    [26]

    Olesik J W, Kinzer J A, Olesik S V. Capillary electrophoresis inductively coupled plasma spectrometry for rapid elemental speciation[J]. Analytical Chemistry, 1995, 67(1): 1-12. doi: 10.1021/ac00097a003

    [27]

    韩梅, 赵国兴, 李淑珍, 等. 毛细管电泳-电感耦合等离子体质谱法测定地下水中不同形态的砷[J]. 分析化学, 2013, 41(11): 1780-1781. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201311037.htm

    Han M, Zhao G X, Li S Z, et al. Speciation analysis of arsenic in groundwater by capillary electrophoresis-inductively coupled plasma mass spectrometry[J]. Chinese Journal of Analytical Chemistry, 2013, 41(11): 1780-1781. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201311037.htm

    [28]

    Shuai P Y, Yang X J, Qiu Z Q, et al. Determination of arsenic species in Solanum Lyratum Thumb using capillary electrophoresis with inductively coupled plasma mass spectrometry[J]. Journal of Separation Science, 2016, 39: 3239-3245. doi: 10.1002/jssc.201600415

    [29]

    王淑霞, 赵金泉, 于红卫, 等. 毛细管电泳-电感耦合等离子体质谱法测定藻类中3种不同形态的铅化合物[J]. 中国医药科学, 2017, 7(16): 18-22. doi: 10.3969/j.issn.2095-0616.2017.16.006

    Wang S X, Zhao J Q, Yu H W, et al. The determination of three different types of lead compounds in algae by capillary electrophoresis-inductively coupled plasma mass spectrometry[J]. China Medicine and Pharmacy, 2017, 7(16): 18-22. doi: 10.3969/j.issn.2095-0616.2017.16.006

    [30]

    Willberger C, Amayri S, Reich T. Determination of kinetic parameters of redox reactions using CE-ICP-MS: A case study for the reduction of Np(Ⅴ) by hydroxylamine hydrochloride[J]. Electrophoresis, 2018, 39(23): 3013-3021. doi: 10.1002/elps.201800318

    [31]

    Legat J, Matczuk M, Timerbaev A R, et al. Cellular processing of gold nanoparticles: CE-ICP-MS evidence for the speciation changes in human cytosol[J]. Analytical and Bioanalytical Chemistry, 2018, 410(3): 1151-1156. doi: 10.1007/s00216-017-0749-0

    [32]

    Wang X X, Sun W J, Zhang S, et al. Elucidating the effects of cerium oxide nanoparticles and zinc oxide nanoparticles on arsenic uptake and speciation in rice (Oryza sativa) in a hydroponic system[J]. Environmental Science and Technology, 2018, 52: 10040-10047. doi: 10.1021/acs.est.8b01664

    [33]

    Shakoor M B, Bibi I, Niazi N K, et al. The evaluation of arsenic contamination potential, speciation and hydrogeo-chemical behavior in aquifers of Punjab, Pakistan[J]. Chemosphere, 2018, 199: 737-746. doi: 10.1016/j.chemosphere.2018.02.002

    [34]

    刘德晔, 姜新. 离子色谱-电感耦合等离子体质谱法测定饮用水中痕量无机锑(Ⅲ)[J]. 食品安全质量检测学报, 2019, 10(23): 8056-8061. https://www.cnki.com.cn/Article/CJFDTOTAL-SPAJ201923043.htm

    Liu D Y, Jiang X. Detection of trace inorganic antimony(Ⅲ) in water by ion chromatography-inductively coupled plasma mass spectrometry[J]. Journal of Food Safety and Quality, 2019, 10(23): 8056-8061. https://www.cnki.com.cn/Article/CJFDTOTAL-SPAJ201923043.htm

    [35]

    林立, 王琳琳, 孙海波, 等. 离子色谱-电感耦合等离子体质谱法测定乳粉的汞形态[J]. 岩矿测试, 2014, 33(3): 390-396. doi: 10.3969/j.issn.0254-5357.2014.03.018 http://www.ykcs.ac.cn/article/id/ca3c637e-137e-4850-9043-11d01493500c

    Lin L, Wang L L, Sun H B, et al. Speciation analysis of mercury in milk powder using ion chromatography-inductively coupled plasma mass spectrometry technique[J]. Rock and Mineral Analysis, 2014, 33(3): 390-396. doi: 10.3969/j.issn.0254-5357.2014.03.018 http://www.ykcs.ac.cn/article/id/ca3c637e-137e-4850-9043-11d01493500c

    [36]

    赵新颖, 屈锋, 牟世芬. 离子色谱技术的重要进展和我国近年的发展概况[J]. 色谱, 2017, 35(3): 223-228. https://www.cnki.com.cn/Article/CJFDTOTAL-SPZZ201703001.htm

    Zhao X Y, Qu F, Mou S F. Important progress in ion chromatography and its recent developments in China[J]. Chinese Journal of Chromatography, 2017, 35(3): 223-228. https://www.cnki.com.cn/Article/CJFDTOTAL-SPZZ201703001.htm

    [37]

    曾艳, 徐开来, 侯贤灯. 色谱与原子荧光光谱联用技术在元素形态分析中的应用[J]. 分析科学学报, 2014, 30(3): 428-432. https://www.cnki.com.cn/Article/CJFDTOTAL-FXKX201403033.htm

    Zeng Y, Xu K L, Hou X D. Application of chromatography-atomic fluorescence spectrometry in elemental speciation analysis[J]. Journal of Analytical Science, 2014, 30(3): 428-432. https://www.cnki.com.cn/Article/CJFDTOTAL-FXKX201403033.htm

    [38]

    侯艳霞, 刘丽萍, 潘浩, 等. 高效液相色谱-电感耦合等离子体质谱分析大米粉中砷形态化合物[J]. 分析试验室, 2013, 32(10): 103-107. https://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201310027.htm

    Hou Y X, Liu L P, Pan H, et al. Determination of arsenic species in rice by HPLC-ICP-MS[J]. Chinese Journal of Analysis Laboratory, 2013, 32(10): 103-107. https://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201310027.htm

    [39]

    刘崴, 胡俊栋, 杨红霞, 等高效液相色谱-电感耦合等离子体质谱法测定禽类生物样品中7种砷形态[J]. 理化检验(化学分册), 2017, 53(3): 299-304. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201703011.htm

    Liu W, Hu J D, Yang H X, et al. Determination of seven arsenic species in poultry biological samples by HPLC-ICP-MS[J]. Physical Testing and Chemical Analysis (Part B: Chemical Analysis), 2017, 53(3): 299-304. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201703011.htm

    [40]

    秦冲, 施畅, 万秋月, 等. 高效液相色谱-电感耦合等离子体质谱联用检测土壤中的无机硒形态[J]. 岩矿测试, 2018, 37(6): 664-670. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201803200024

    Qin C, Shi C, Wan Q Y, et al. Speciation analysis of inorganic selenium in soil by high performance liquid chromatography-inductively coupled plasma-mass spectrometry[J]. Rock and Mineral Analysis, 2018, 37(6): 664-670. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201803200024

    [41]

    Liu W, Hu J D, Yang H X. Stabilities of iodide and iodate for iodine speciation analysis in soils[J]. Geochemistry: Exploration, Environment, Analysis, 2019, 19: 39-45. doi: 10.1144/geochem2017-035

    [42]

    王欣, 幸苑娜, 陈泽勇, 等. 高效液相色谱-电感耦合等离子体质谱法检测富硒食品中6种硒形态[J]. 分析化学, 2013, 41(11): 1669-1674. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201311011.htm

    Wang X, Xing Y N, Chen Z Y, et al. Determination of 6 selenium species in selenium-enriched food by hyphenated technique of high performance liquid chromatography-inductively coupled plasma mass spectrometry[J]. Chinese Journal of Analytical Chemistry, 2013, 41(11): 1669-1674. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201311011.htm

    [43]

    杨程, 刘德晔. 人全血中锶元素的分布及血浆中锶元素的形态分析[J]. 分析试验室, 2014, 33(1): 96-99. https://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201401021.htm

    Yang C, Liu D Y. Study on strontium distribution in human blood and strontium species in human plasma[J]. Chinese Journal of Analysis Laboratory, 2014, 33(1): 96-99. https://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201401021.htm

    [44]

    王媛, 刘德晔. 人体尿液和血浆中碘元素形态分析方法学的研究[J]. 江苏预防医学, 2018, 29(1): 1-4. https://www.cnki.com.cn/Article/CJFDTOTAL-JSYF201801001.htm

    Wang Y, Liu D Y. A study of iodine species in human urine and plasma[J]. Jiangsu Journal of Preventive Medicine, 2018, 29(1): 1-4. https://www.cnki.com.cn/Article/CJFDTOTAL-JSYF201801001.htm

    [45]

    陈绍占, 杜振霞, 刘丽萍, 等. 高效液相色谱-电感耦合等离子质谱法分析雄黄在大鼠脏器中代谢的砷形态[J]. 分析化学, 2014, 42(3): 349-354. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201403008.htm

    Chen S Z, Du Z X, Liu L P, et al. Analysis of arsenic metabolites of realgar in rat viscera by HPLC-ICP-MS[J]. Chinese Journal of Analytical Chemistry, 2014, 42(3): 349-354. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201403008.htm

    [46]

    史俊稳, 张新颖, 李亮, 等. 基于电感耦合等离子体质谱的单细胞分析[J]. 生物化学与生物物理进展, 2016, 4(8): 739-746. https://www.cnki.com.cn/Article/CJFDTOTAL-SHSW201608002.htm

    Shi J W, Zhang X Y, Li L, et al. Inductively coupled plasma mass spectrometry-based techniques for single cell analysis[J]. Progress in Biochemistry and Biophysics, 2016, 4(8): 739-746. https://www.cnki.com.cn/Article/CJFDTOTAL-SHSW201608002.htm

    [47]

    龚晓云, 熊行创, 张四纯, 等. 单细胞质谱分析方法研究进展[J]. 中国科学: 化学, 2016, 46(2): 133-152. https://www.cnki.com.cn/Article/CJFDTOTAL-JBXK201602001.htm

    Gong X Y, Xiong X C, Zhang S C, et al. Recent advances in mass spectrometry based single cell analysis methods[J]. Science China: Chemistry, 2016, 46(2): 133-152. https://www.cnki.com.cn/Article/CJFDTOTAL-JBXK201602001.htm

    [48]

    黄理金, 何蔓, 陈贝贝, 等. 基于纳米材料的固相萃取在痕量元素及其形态分析中的应用[J]. 中国科学: 化学, 2016, 46(5): 452-465. https://www.cnki.com.cn/Article/CJFDTOTAL-JBXK201605005.htm

    Huang L J, He M, Chen B B, et al. Nanomaterials-based solid phase extraction for the separation/preconcentration of trace elements and their species[J]. Science China: Chemistry, 2016, 46(5): 452-465. https://www.cnki.com.cn/Article/CJFDTOTAL-JBXK201605005.htm

    [49]

    Chen Z N, Chen B B, He M, et al. Magnetic metal-organic framework composites for dual-column solid-phase microextraction combined with ICP-MS for speciation of trace levels of arsenic[J]. Microchimic Acta, 2020, 187: 48-56. doi: 10.1007/s00604-019-4055-8

    [50]

    张颖, 杨清清, 宋毅, 等. 高效液相色谱-电感耦合等离子体质谱联用技术测定富硒食品中无机硒和有机硒的含量[J]. 中国食品卫生杂志, 2017, 29(2): 181-185. https://www.cnki.com.cn/Article/CJFDTOTAL-ZSPZ201702014.htm

    Zhang Y, Yang Q Q, Song Y, et al. Determination of inorganic and organic selenium in food by high performance liquid chromatography-inductively coupled plasma mass spectrometry[J]. Chinese Journal of Food Hygiene, 2017, 29(2): 181-185. https://www.cnki.com.cn/Article/CJFDTOTAL-ZSPZ201702014.htm

    [51]

    吕小丽, 郭平, 王文君, 等. 食品及食品接触材料中铬元素形态分析研究进展[J]. 江西农业学报, 2019, 31(2): 74-79. https://www.cnki.com.cn/Article/CJFDTOTAL-JXNY201902015.htm

    Lv X L, Guo P, Wang W J, et al. Research progress in form analysis of chromium in food and food contact materials[J]. Acta Agriculturae Jiangxi, 2019, 31(2): 74-79. https://www.cnki.com.cn/Article/CJFDTOTAL-JXNY201902015.htm

    [52]

    杨婷, 张夏兰, 丁晓雯. 元素形态对食品安全影响的研究进展[J]. 食品与发酵工业, 2018, 44(10): 295-303. https://www.cnki.com.cn/Article/CJFDTOTAL-SPFX201810048.htm

    Yang T, Zhang X L, Ding X W. Advances studies of element formation impact on food safety[J]. Food and Fermentation Industries, 2018, 44(10): 295-303. https://www.cnki.com.cn/Article/CJFDTOTAL-SPFX201810048.htm

    [53]

    Chen S Z, Guo Q Z, Liu L P. Determination of arsenic species in edible mushrooms by high-performance liquid chromatography coupled to inductively coupled plasma mass spectrometry[J]. Food Analytical Methods, 2017, 10(3): 740-748. doi: 10.1007/s12161-016-0629-9

    [54]

    Cheng H Y, Cheng X P, Shen L H, et al. Ion-pairing reversed-phase chromatography coupled to inductively coupled plasma mass spectrometry as a tool to determine mercurial species in freshwater fish[J]. Journal of Chromatography A, 2018, 1531: 104-111. doi: 10.1016/j.chroma.2017.11.029

    [55]

    耿安静, 王旭, 李秋剑, 等. 高效液相色谱-电感耦合等离子体质谱法测定水稻中的5种砷形态[J]. 农产品质量与安全, 2019(4): 13-19. doi: 10.3969/j.issn.1674-8255.2019.04.003

    Ge A J, Wang X, Li Q J, et al. Detection of five arsenic speciation in rice by high performance liquid chromatography-inductively coupled plasma mass spectrometry[J]. Quality and Safety of Agro-products, 2019(4): 13-19. doi: 10.3969/j.issn.1674-8255.2019.04.003

    [56]

    吴思霖, 王欣美, 于建, 等. 高效液相色谱-电感耦合等离子体质谱联用测定鸡肉及鸡肝中10种砷形态化合物[J]. 分析测试学报, 2018, 37(4): 482-486. doi: 10.3969/j.issn.1004-4957.2018.04.016

    Wu S L, Wang X M, Yu J, et al. Determination of ten arsenic species compounds in chicken and chicken liver by HPLC-ICP-MS[J]. Journal of Instrumental Analysis, 2018, 37(4): 482-486. doi: 10.3969/j.issn.1004-4957.2018.04.016

    [57]

    Wang Z W, Nadeau L, Sparling M. Determination of arsenic species in fruit juice and fruit drink products using ion pair chromatography coupled to inductively coupled plasma mass spectrometry[J]. Food Analytical Methods, 2015, 8: 173-179. doi: 10.1007/s12161-014-9888-5

    [58]

    李晓玉, 刘丽萍, 陈绍占. 高效液相色谱-电感耦合等离子体质谱法测定保健食品类袋泡茶中5种砷形态[J]. 中国食品卫生杂志, 2018, 30(5): 491-496. https://www.cnki.com.cn/Article/CJFDTOTAL-ZSPZ201805013.htm

    Li X Y, Liu L P, Chen S Z. Determination of five arsenic species in the soaking solution of healthy food teabag by high performance liquid chromatography-inductively coupled plasma mass spectrometry[J]. Chinese Journal of Food Hygiene, 2018, 30(5): 491-496. https://www.cnki.com.cn/Article/CJFDTOTAL-ZSPZ201805013.htm

    [59]

    孟珊, 邵阳, 胡伟杰, 等. 高效液相色谱-电感耦合等离子体质谱法测定植物源保健食品中6种砷形态化合物[J]. 分析化学, 2019, 47(7): 1121-1123. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201907024.htm

    Meng S, Shao Y, Hu W J, et al. Determination of 6 arsenic speciation in plant-derived food by high performance liquid chromatography coupled with inductively coupled plasma mass spectrometry[J]. Chinese Journal of Analytical Chemistry, 2019, 47(7): 1121-1123. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201907024.htm

    [60]

    林立, 孙海波, 孙继红. 离子色谱-电感耦合等离子体质谱法测定奶粉中的硒形态[J]. 理化检验(化学分册), 2015, 51(9): 907-911. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201509004.htm

    Lin L, Sun H B, Sun J H. Determination of selenium species in milk powder by IC-ICP-MS[J]. Physical Testing and Chemical Analysis (Part B: Chemical Analysis), 2015, 51(9): 907-911. https://www.cnki.com.cn/Article/CJFDTOTAL-LHJH201509004.htm

    [61]

    陈贵宇, 潘煜辰, 李清清, 等. 高效液相色谱-电感耦合等离子质谱法分析富硒茶叶中硒的形态[J]. 食品科学, 2018, 39(8): 155-159. https://www.cnki.com.cn/Article/CJFDTOTAL-SPKX201808026.htm

    Chen G Y, Pan Y C, Li Q Q, et al. Speciation analysis of selenium in selenium-enriched tea by HPLC-ICP-MS[J]. Food Science, 2018, 39(8): 155-159. https://www.cnki.com.cn/Article/CJFDTOTAL-SPKX201808026.htm

    [62]

    姚真真, 哈雪姣, 马智宏, 等. 高效液相色谱-电感耦合等离子体质谱法检测富硒苹果中5种硒形态[J]. 食品安全质量检测学报, 2018, 9(3): 475-480. doi: 10.3969/j.issn.2095-0381.2018.03.004

    Yao Z Z, Ha X J, Ma Z H, et al. Determination of 5 kinds of selenium species in selenium-enriched apples by high performance liquid chromatography-inductively coupled plasma mass spectrometry[J]. Journal of Food Safety and Quality, 2018, 9(3): 475-480. doi: 10.3969/j.issn.2095-0381.2018.03.004

    [63]

    秦冲, 施畅, 万秋月, 等. HPLC-ICP-MS法测定富硒小麦中硒的形态[J]. 食品研究与开发, 2019, 40(2): 140-144. doi: 10.3969/j.issn.1005-6521.2019.02.026

    Qin C, Shi C, Wan Q Y, et al. Speciation analysis of selenium in selenium-enriched wheat by HPLC-ICP-MS[J]. Food Research and Development, 2019, 40(2): 140-144. doi: 10.3969/j.issn.1005-6521.2019.02.026

    [64]

    曹玉嫔, 闫丽珍, 黄红丽, 等. 超声辅助提取结合高效液相色谱-电感耦合等离子体质谱联用技术测定牛蒡和三七中硒形态[J]. 分析化学, 2015, 43(9): 1329-1334. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201509014.htm

    Cao Y P, Yan L Z, Huang H L, et al. Determination of selenium species in Burdock and Panax Notoginseng using ultrasonic assistant extraction combined with high performance liquid chromatography-inductively coupled plasma mass spectrometry[J]. Chinese Journal of Analytical Chemistry, 2015, 43(9): 1329-1334. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201509014.htm

    [65]

    张珂, 高舸, 张钦龙. 超声辅助酸提取-液相色谱-电感耦合等离子体质谱法测定鱼肉中3种汞形态[J]. 中国食品卫生杂志, 2017, 29(5): 581-584. https://www.cnki.com.cn/Article/CJFDTOTAL-ZSPZ201705012.htm

    Zhang K, Gao G, Zhang Q L. Determination of inorganic mercury, methyl mercury and ethyl mercury in fish samples by liquid chromatogram-inductively coupled plasma mass spectrometry with ultrasound-assisted acid extraction procedure[J]. Chinese Journal of Food Hygiene, 2017, 29(5): 581-584. https://www.cnki.com.cn/Article/CJFDTOTAL-ZSPZ201705012.htm

    [66]

    Zou H M, Zhou C, Li Y X, et al. Speciation analysis of mercury in wild edible mushrooms by high-performance liquid chromatography hyphenated to inductively coupled plasma mass spectrometry[J]. Analytical and Bioanalytical Chemistry, 2020, 412: 2829-2840. doi: 10.1007/s00216-020-02515-w

    [67]

    Liu H, Luo J Y, Ding T, et al. Speciation analysis of trace mercury in sea cucumber species of Apostichopus japonicas using high-performance liquid chromatography conjunction with inductively coupled plasma mass spectrometry[J]. Biological Trace Element Research, 2018, 186: 554-561. doi: 10.1007/s12011-018-1309-y

    [68]

    李杰, 陆庆, 易路遥, 等. 高效液相色谱-电感耦合等离子体质谱法检测水产品中铅的形态[J]. 中国卫生检验杂志, 2017, 27(20): 2908-2911. https://www.cnki.com.cn/Article/CJFDTOTAL-ZWJZ201720006.htm

    Li J, Lu Q, Yi L Y, et al. Speciation detection of lead in aquatic products by high performance liquid chromatography-inductively coupled plasma mass spectrometry[J]. Chinese Journal of Health Laboratory Technology, 2017, 27(20): 2908-2911. https://www.cnki.com.cn/Article/CJFDTOTAL-ZWJZ201720006.htm

    [69]

    李景喜, 孙承君, 郑立, 等. 毛细管电泳-电感耦合等离子体质谱联用测定海藻中铅形态化合物[J]. 分析化学, 2016, 44(11): 1659-1664. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201611005.htm

    Li J X, Sun C J, Zheng L, et al. Determination of lead species in algae by capillary electrophoresis-inductively coupled plasma mass spectrometry[J]. Chinese Journal of Analytical Chemistry, 2016, 44(11): 1659-1664. https://www.cnki.com.cn/Article/CJFDTOTAL-FXHX201611005.htm

    [70]

    陈绍占, 刘丽萍, 杜宏举, 等. 高效液相色谱-电感耦合等离子体质谱法分析经牛黄解毒片暴露后大鼠血清中砷形态[J]. 质谱学报, 2017, 38(2): 177-186. https://www.cnki.com.cn/Article/CJFDTOTAL-ZPXB201702002.htm

    Chen S Z, Liu L P, Du H J, et al. Arsenic species in rat serum after oral administration of Niuhuang Jiedu Tablet by HPLC-ICP-MS[J]. Journal of Chinese Mass Spectrometry Society, 2017, 38(2): 177-186. https://www.cnki.com.cn/Article/CJFDTOTAL-ZPXB201702002.htm

    [71]

    赵彤, 陈翠红. 高效液相色谱-电感耦合等离子体质谱联用测定沉积物中不同形态的砷[J]. 南开大学学报(自然科学版), 2020, 53(3): 97-101. https://www.cnki.com.cn/Article/CJFDTOTAL-NKDZ202003018.htm

    Zhao T, Chen C H. Speciation analysis of arsenic in sediment by HPLC-ICP-MS[J]. Acta Scientiarum Naturalium Universitatis Nankaiensis, 2020, 53(3): 97-101. https://www.cnki.com.cn/Article/CJFDTOTAL-NKDZ202003018.htm

    [72]

    安娅丽, 赵艳萍, 刘宁, 等. 高效液相色谱-电感耦合等离子体串联质谱法同时测定土壤中的阿散酸、洛克沙胂及其降解产物[J]. 分析测试学报, 2019, 38(11): 1353-1357. doi: 10.3969/j.issn.1004-4957.2019.11.011

    An Y L, Zhao Y P, Liu N, et al. Simulation determination of p-arsanilic acid, roxarsone and their degradation products in soils by HPLC-ICP-MS/MS[J]. Journal of Instrumental Analysis, 2019, 38(11): 1353-1357. doi: 10.3969/j.issn.1004-4957.2019.11.011

    [73]

    杨志强, 胡晋伟, 潘青山, 等. HPLC-ICP-MS法测定环境水样中Cr(Ⅲ)和Cr(Ⅵ)及方法在复杂基体水样适用性[J]. 分析试验室, 2020, 39(4): 427-431. https://www.cnki.com.cn/Article/CJFDTOTAL-FXSY202004011.htm

    Yang Z Q, Hu J W, Pan Q S, et al. Determination of Cr(Ⅲ) and Cr(Ⅵ) in environment water sample by HPLC-ICP-MS and preliminary analysis of method applicability in water sample with complicated matrix[J]. Chinese Journal of Analysis Laboratory, 2020, 39(4): 427-431. https://www.cnki.com.cn/Article/CJFDTOTAL-FXSY202004011.htm

    [74]

    Dickson D, Liu G L, Cai Y. Adsorption kinetics and isotherms of arsenite and arsenate on hematite nanoparticles and aggregates[J]. Journal of Environmental Management, 2017, 186: 261-267. http://www.sciencedirect.com/science/article/pii/S0301479716305059

    [75]

    Yu P, Yang H M, Zhang H Y, et al. Microbe mediated arsenic release from iron minerals and arsenic methylation in rhizosphere controls arsenic fate in soil-rice system after straw incorporation[J]. Environmental Pollution, 2018, 236: 598-608. http://europepmc.org/abstract/MED/29433100

    [76]

    Cheng L, Wang L, Geng Y M, et al. Occurrence, speciation and fate of mercury in the sewage sludge of China[J]. Ecotoxicology and Environmental Safety, 2019, 186: 1-6. http://www.sciencedirect.com/science/article/pii/S0147651319311182

    • 相关文章
  • 施引文献
  • 资源附件(0)
  • 加载中

表(1)

计量
  • 文章访问数:  3174
  • PDF下载数:  87
  • 施引文献:  0
出版历程
收稿日期:  2020-06-11
修回日期:  2020-12-21
录用日期:  2021-03-29
刊出日期:  2021-05-28

目录

    版权所有：中国地质调查局发展研究中心 copyright @2020
    返回
