页岩气解析测试中的几个问题——以柴达木盆地柴页1井为例
Some problems concerning measuring shale gas content of rocks with gas desorption method
-
摘要: 岩石含气量是页岩气资源量评价及勘探开发的关键性技术指标,其测试技术与方法尚处于发展与完善过程中。利用恒温解析-氢火焰离子检测法对柴达木盆地柴页1井侏罗系大煤沟组不同岩性的岩心进行了页岩气解析测试,通过对解析曲线和含气量数据分析研究发现:①页岩气解析测试的气体释放过程包括一系列的复杂解析过程,而非简单的解吸附过程,具有多级性,其解析速率曲线表现出多峰性;②岩石中吸附气的解吸量在早期恒温解析阶段遵循USBM直线规律,这一时间段的解析数据适合于计算损失气量;③岩石中的残余气是被岩石的物理构造所限滞的气体部分,应该在将岩石粉碎后测定;④将含页岩气岩心短期封存对于解析气测定结果的影响不大,在30天内完成测试即可。这些认识对于页岩气解析测试技术方法的改进、完善与规范具有重要参考价值。Abstract: The measurement of shale gas content using isotherm desorption method for the complex Jurassic shale-mudstone-sand-stone-coal rock system was conducted with cores from the Chaiye-1 well drilled in Qaidam Basin. According to the data achieved, methodology for measuring shale gas content of rocks with isotherm desorption method was discussed based on practice. First, the shale gas desorption curve of rocks commonly exhibits multiple desorption peaks, due to the fact that the shale gas in rock represents not only adsorbed gas but also physically bound gas, and it desorbs when the micro physical structure in the rock is altered by the desorption process. Second, the lost shale gas portion of the rocks should be restored with the desorption data achieved at the early stage, which represents desorption of adsorbed gas at a stable manner. Third, residue gas of the rocks should only be measured by cracking the rocks to powder, since it is physically enclosed in the rocks. Fourth, shale gas in cores can be measured with isotherm desorption method later after the cores are canned and sealed in the desorption chamber without unreasonably data discrimination within 30 days.
-
Key words:
- shale gas /
- gas desorption measurement method /
- Chaiye-1 well
-
-
[1] 陈永武,王少波,韩征,等. 页岩气资源/储量计算与评价技术规范[S]. 中华人民共和国地质矿产行业标准,DZ/T 0254-2014,中华人民共和国国土资源部发布.
[2] 陈元千,周翠. 中国《页岩气资源/储量计算与评价技术规范》计算方法存在的问题与建议[J]. 油气地质与采收率, 2015,22(1):1-4.
[3] 刘洪林,闫刚,李晓波,等. 页岩含气量测定方法[S]. 中华人民共和国石油天然气行业标准,SY/T 6940-2013,国家能源局发布.
[4] 刘洪林,邓泽,刘德勋,等. 页岩含气量测试中有关损失气量估算方法[J]. 石油钻采工艺,2010,32(增刊):156-158.
[5] 王瑞,张宁生,刘晓娟,等. 页岩气吸附与解析附机理研究进展[J]. 科学技术与工程,2013,13(19):5561-5567.
[6] 赵群,王红岩,杨慎,等. 一种计算页岩岩心解析测试中损失气量的新方法[J]. 天然气工业,2013,33(5):30-34
[7] 薛晓辉,岳小金,韦巍. 页岩含气量测定过程中的几点建议[J]. 中国煤炭地质,2013,25(4):27-29.
[8] 王瑞,张宁生,刘晓娟,等. 页岩气吸附与解析附机理研究进展[J]. 科学技术与工程,2013,13(19):5561-5567.
[9] 李玉喜,乔德武,姜文利, 等. 页岩气含气量和页岩气地质评价综述[J]. 地质通报,2011,30(2/3):308-317.
[10] 方俊华,朱炎铭,魏伟,等. 页岩等温吸附异常初探[J]. 吐哈油气, 2010,15(4):317-320.
[11] Bustin A M M, Bustin R M, Russel-Houston J. Horseshoe Can-yon and Belly River coal measures, south central Alberta:Part 2-Modeling reservoir properties and producible gas[J]. Bulletin of Canadian Petroleum Geology, 2011,59(3):235-260.
[12] Ross D J K, Bustin R M. Characterizing the shalegas resource potential of Devonian-Mississippianstrata in the Western Canada sedi-mentary basin:Application of an integratedformation evaluation[J]. AAPG Bulletin, 2008, 92(1):87-125.
[13] 莫修文,李舟波,潘保芝.页岩气测井地层评价的方法与进展[J].地质通报,2011,30(2/3):400-405.
[14] Montgomery S L, Jarvie D M, Bowker K A, et al. Mississippian Barnett Shale, Fort Worth basin, north-central Texas:Gas-shale play withmulti-trillion cubic foot potential[J]. AAPG Bulletin, 2005, 89(2):155-175.
[15] Strapoc D, Mastalerz M, Schimmelmann A, et al. Geochemical constraints onthe origin and volume of gasin the New Albany Shale(Devonian-Mississippian),eastern Illinois Basin[J]. AAPG Bulletin, 2010, 94(11):1713-1740.
[16] 李武广,杨胜来,陈峰,等.温度对页岩吸附解析的敏感性研究[J]. 矿物岩石,2012,32(2):115-120.
[17] 张金川,薛会,张德明,等. 页岩气及其成藏机理[J]. 现代地质, 2003,17(4):466.
[18] 张金川,金之钧,袁明生. 页岩气成藏机理和分布[J]. 天然气工业, 2004,24(7):15-8.
[19] 王飞宇,贺志勇,孟晓辉,等. 页岩气赋存形式和初始原地气量(OGIP)预测技术[J]. 天然气地球科学,2011,22(3):501-510.
[20] Curtis J B. Fractured shale-gas systems[J].AAPG Bulletin, 2002, 86(11):1921-1938.
-
