渤海湾海岸带地区<sup>137</sup>Cs参考剖面——意义、方法及初步结果

王福; 田立柱; 姜兴钰; 李建芬; 杨彪; 袁海帆; 王宏

渤海湾海岸带地区¹³⁷Cs参考剖面——意义、方法及初步结果

1. 中国地质调查局天津地质调查中心, 天津 300170;
2. 中国地质调查局泥质海岸带地质环境重点实验室, 天津 300170;
3. 天津地质矿产研究所年轻沉积物测年实验室, 天津 300170;
4. 中国地质大学海洋学院, 北京 100083

收稿日期: 2016-05-19

修回日期: 2016-08-22

刊出日期: 2016-10-15

Local ¹³⁷Cs reference profile on Bohai Bay:Implications, methods and initial results

1. Tianjin Center, China Geological Survey, Tianjin 300170, China;
2. Key Laboratory of Muddy Coast Geo-environment, China Geological Survey, Tianjin 300170, China;
3. Young Sediments Dating Laboratory, Tianjin Institute of Geology and Mineral Resources, Tianjin 300170, China;
4. School of Ocean Sciences, China University of Geosciences, Beijing 100083, China

Received Date: 19 May 2016

Revised Date: 22 August 2016

Publish Date: 15 October 2016

摘要

摘要: 海岸带地区近百年来的现代地质过程重建必须以精确的年代学研究为基础，¹³⁷Cs时标法和²¹⁰Pb_exc测年法是目前广泛应用的方法。由于易受到河流沉积物供给变化、潮位状况、极端天气事件等的影响，海岸带现代过程的定量研究一直是高分辨率研究的瓶颈。区域性参考剖面可以提升现代沉积物测年方法在海岸带应用中的可靠性。因此，建立区域性的²¹⁰Pb_exc和¹³⁷Cs比活度-深度参考剖面，将改善对海岸带及邻近海区实测数据的解释。以渤海湾海岸带为研究区，选取沉积环境相对稳定、水平搬运作用较小的地区，采用人工探坑、Eijkelkamp槽型取样器获取了2个柱状岩心，通过γ能谱仪对样品进行²¹⁰Pb、²²⁶Ra及¹³⁷Cs比活度测试，绘制剖面图，结合研究区已有数据，总结出6类海岸带常见的²¹⁰Pb_exc和¹³⁷Cs比活度-深度剖面类型，并重建了渤海湾海岸带¹³⁷Cs区域性参考剖面。结果显示，¹³⁷Cs在渤海湾地区的最大峰值指示1963年，可以作为区域性主要参考时标。但是，最大峰值上部的次峰在不同区域指示不同的时标，S4和S5两个站位该峰值指示的并非1986年时标。
- Pbexc /
- ¹³⁷Cs /
- 参考剖面 /
- 海岸带 /
- 渤海湾
Abstract: Reconstruction of geological processes during the last hundred years needs accurate dating methods. ¹³⁷Cs and ²¹⁰Pb dating methods are widely used at present. As coastal areas are vulnerable to the changes of river sediment supply, the local tidal conditions, and the effects of extreme weather events, the quantitative descriptions of their modern processes have been a bottleneck for the highresolution studies. Regional reference- profiles can help improve the precision of modern sediments dating. If regional ²¹⁰Pb_exc and ¹³⁷Cs reference-profiles could be established, they will play a very positive role in the interpretation of the dating results of modern sediments. In this paper, the relatively stable salt-marsh sites with little transported activity were selected along the coastal areas of Bohai Bay. Based on systematic sampling of trench walls and Eijkelkamp cores, the authors measured the ²¹⁰Pb, ²²⁶Ra and ¹³⁷Cs activities of subsamples by γ spectrometer, combined with the existing data in the study area. Consequently, the local reference-profiles were established, six types of ²¹⁰Pb_exc and ¹³⁷Cs activity-depth profiles were summarized, and the ¹³⁷Cs regional reference-profiles were prelimiarily obtained. ¹³⁷Cs maximum peak in the Bohai Bay is correlated with 1963, which could be used as the main time-marker of the coastal area. However, the second peak above the maximum peak detected in some cores can not be correlated with 1986 but is actually controlled by local environmental factors such as those indiacated at sites S4 and S5.
- Pbexc /
- ¹³⁷Cs /
- reference profiles /
- coast /
- Bohai Bay

HTML全文

参考文献(31)

[1]	Pennington W, Tutin T G. Observation on Lake Sediments using Fallout ¹³⁷Cs as a Tracer[J]. Nature, 1973, 242:324-326.
[2]	DeLaune R D, Patrick Jr, W H, Buresh R J. Sedimentation rates de-termined by ¹³⁷Cs dating in a rapidly accreting salt marsh[J]. Nature, 1978, 275:532-533.
[3]	Milan C S, Swenson E M, Turner R E, et al. Assessment of the ¹³⁷Cs method for estimating sediment accumulation rates:Louisiana salt marshes[J]. Journal of Coastal Research, 1995, 11(2):296-307.
[4]	Goodbred S L, Kuehl S A. Floodplain processes in the Bengal Basin and the storage of Ganges-Brahmaputra River sediment:An accre-tion study using ¹³⁷Cs and ²¹⁰Pb geochronology[J]. Sedimentary Geol-ogy, 1998, 121(3):239-258.
[5]	Callaway J C, Delaune R D, Patrick W H. Chernobyl Cs-137 used to determine sediment accretion rates at selected north European coastal wetlands[J]. Limnology and Oceanography, 1996, 41(3):444-450.
[6]	Mishra U C, Lalit B Y, Sethi S K, et al. Some observations based on the measurements on fresh fallout from the recent Chinese and French nuclear explosion[J]. Journal of Geophysical Research, 1975, 80(36):5045-5049.
[7]	Jha S K, Chavan S B, Pandit G G, et al. Geochronology of Pb and Hg pollution in a coastal marine environment using global fallout ¹³⁷Cs[J]. Journal of Environmental Radioactivity, 2003, 69(1/2):145-157.
[8]	Krishnaswamy S, Lal D, Marin J M, et al. Geochronology of lake sediments[J]. Earth and Planetary Science Letters, 1971, 11(1/5):407-414.
[9]	Appleby P G, Oldfield F. The calculation of ²¹⁰Pb dates assuming a constant rate of supply of unsupported ²¹⁰Pb to the sediment[J]. Cate-na, 1978, 5(1):1-8.
[10]	Meng W, Lei K, Zheng B H, et al. Modern sedimentation rates in the intertidal zone on the west coast of the Bohai Gulf[J]. Acta Oceanologica Sinica, 2005, 24(3):46-53.
[11]	Andersen T J, Svinth S, Pejrup M. Temporal variation of accumula-tion rates on a natural salt marsh in the 20th century-The impact of sea level rise and increased inundation frequency[J]. Marine Ge-ology, 2011, 279(1/4):178-187.
[12]	Teasdale P A, Collins P E F, Firth C R, et al. Recent estuarine sedi-mentation rates from shallow inter-tidal environments in western Scotland:implications for future sea-level trends and coastal wet-land development[J]. Quaternary Science Reviews, 2011, 30:109-129.
[13]	Gehrels W R, Callard S L, Moss P T, et al. Nineteenth and twenti-eth century sea-level changes in Tasmania and New Zealand[J]. Earth and Planetary Science Letters, 2012, 315/316:94-102.
[14]	Goldberg E D, Koide M. Rates of sediment accumulation in the In-dian Ocean[C]//Geiss J, Goldberg E D. Earth Science and Meteor-itics. Amsterdam:North-Holland publishing company, 1963:90-102.
[15]	Koide M, Bruland K W, Goldberg E D. ²²⁸Th/²³²Th and ²¹⁰Pb geo-chronologies in marine and lake sediments[J]. Geochimica et Cos-mochimica Acta, 1973, 37:1171-1187.
[16]	苏贤泽, 马文通, 徐胜利, 等. 海洋沉积物的铅-210地质年代学方法[J]. 1984, 3(1):50-58.
[17]	康兴伦. ²¹⁰Pb测年法的数据处理问题[J]. 海洋科学, 1986, 10(6):13-17.
[18]	业渝光, 和杰. 现代黄河三角洲²¹⁰Pb剖面的标准化方法——粒度相关法[J]. 地理科学, 1992, 12(4):379-386.
[19]	万国江. 现代沉积的²¹⁰Pb计年[J]. 第四纪地质, 1997, 3:230-239.
[20]	范德江, 杨作升, 郭志刚. 中国陆架²¹⁰Pb测年应用现状与思考[J]. 地球科学进展, 2000, 15(3):297-302.
[21]	Wright S M, Howard B J, Strand P. Prediction of ¹³⁷Cs deposition from atmospheric nuclear weapons tests within the Arctic[J]. Envi-ronmental Pollution, 1999, 104:131-143.
[22]	王福, 王宏. 海岸带地区¹³⁷Cs沉积剖面类型划分及其意义[J]. 地质通报, 2011, 30(7):1009-1110.
[23]	夏威岚, 薛滨. 吉林小龙湾沉积速率的²¹⁰Pb和¹³⁷Cs年代学方法测定[J]. 第四纪研究, 2004, 24(1):124-125.
[24]	杨彪, 王福, 田立柱, 等. 独流减河盐沼²¹⁰Pb_exc和¹³⁷Cs剖面记录的现代洪水事件沉积[J]. 海洋学研究, 2016, 34:25-34.
[25]	Wang F, Wang H, Zong Y, et al. Sedimentary dynamics along the West Coast of Bohai Bay, China, during the 20th century[J]. Jour-nal of coastal research, 2014, 30(2):379-388.
[26]	李建芬, 王宏, 夏威岚, 等. 渤海湾西岸²¹⁰Pb_exc和¹³⁷Cs测年与现代沉积速率[J]. 地质调查与研究, 2003, 26(2):114-128.
[27]	Wang F, Wang H, Li J F, et al. ²¹⁰Pb and ¹³⁷Cs measurement on the Circum Bohai Sea (CBS) Region:sedimentation and implication[J]. Frontiers of Earth Science in China, 2008, 2(3):276-282.
[28]	王福. 渤海湾海岸带²¹⁰Pb、¹³⁷Cs示踪与测年研究:现代沉积及环境意义[D]. 中国地质科学院博士学位论文, 2009:1-101.
[29]	Wang F, Zong Y, Li J F, et al. Recent sedimentation dynamics in-dicated by ²¹⁰Pb_exc and ¹³⁷Cs records from the subtidal area of Bohai Bay, China[J]. Journal of Coastal Research, 2015, 32(2):416-423.
[30]	王福, 杨彪, 田立柱, 等. 开放潮坪地区²¹⁰Pb_exc测年CIC和CRS计算模式的选择[J]. 地球科学, 2016, 41(6):971-981.
[31]	王宏, 姜义, 李建芬, 等. 渤海湾老狼坨子海岸带¹⁴C、¹³⁷Cs、²¹⁰Pb测年与现代沉积速率的加速趋势[J]. 地质通报, 2003, 22(9):658-664.
