Prestack inversion of anisotropic coefficients and its application in fracture prediction
-
摘要: 宽方位地震资料波场正演响应特征表明:地震纵波在地下地质体中传播时,反射系数在不同的方向具有明显的方位各向异性特征。利用方位各向异性进行裂缝预测已经成为国内外的研究热点之一。本文通过地震纵波随方位变化的正演响应特征分析,结合Bakulin等提出的含流体裂缝各向异性参数之间的相互关系,对Ruger公式进行了近似简化,推导了裂缝型储层含流体情况下,可以用于表征裂缝发育的各向异性参数γ与反射系数之间的表达式,提出了一种基于各向异性参数反演的裂缝预测方法。通过理论模型和实际资料应用证明了方法的有效性和适用性,为应用宽方位叠前地震资料进行裂缝预测提供了一种可行的方法技术。Abstract: The forward modeling of wave field response characteristics of wide-azimuth seismic data shows that the reflection coefficient has apparent azimuth anisotropy when the P-waves propagate in underground geologic bodies.It has become a research hotspot at home and abroad to make a fracture prediction using azimuth anisotropy.This study analyzed the response characteristics of the changes in seismic P-waves with azimuth using forward modeling.Based on the analytical results combined with the relationship between the anisotropy parameters of fluid-bearing fractures proposed by Bakulin et al.,this study approximately simplified the Ruger formula,deduced the equation between anisotropic parameter γ that can be used to characterize fracture development and reflection coefficient,and proposed a fracture prediction method based on anisotropic parameter inversion.The validity and applicability of the method have been proven using theoretical models and practical data application.Therefore,this study provides a feasible method and technology for fracture prediction using wide-azimuth prestack seismic data.
-
-
[1] 关宝文, 郭建明, 杨燕, 等. 油气储层裂缝预测方法及发展趋势[J]. 特种油气藏, 2014, 21(1):12-17.
[2] Guan B W, Guo J M, Yang Y, et al. Methods of fracture prediction in oil & gas reservoirs and their development trend[J]. Special Oil & Gas Reservoirs, 2014, 21(1):12-17.
[3] 张昕, 郑晓东. 裂缝发育带地震识别预测技术研究进展[J]. 石油地球物理勘探, 2005, 40(6):724-731.
[4] Zhang X, Zheng X D. Research progress of seismic identification and prediction technology in fracture zone[J]. Oil Geophysical Prospecting, 2005, 40(6):724-731.
[5] 印兴耀, 张洪学, 宗兆云. OVT数据域五维地震资料解释技术研究现状与进展[J]. 石油物探, 2018, 57(2):155-178.
[6] Yin X Y, Zhang H X, Zong Z Y. Research status and progress of 5D seismic data interpretation in OVT domain[J]. Geophysical Prospecting for Petroleum, 2018, 57(2):155-178.
[7] Crampin S. Seismic-wave propagation through a cracked solid:polarization as a possible dilatancy diagnostic[J]. Geophysical Journal International, 1978, 53(3):467-496.
[8] Thomsen L. Elastic anisotropy due to aligned cracks in porous rock[J]. Geophysical Prospecting, 1995, 43(6):805-829.
[9] 张琬璐. 基于Ruger公式的地震各向异性参数反演方法研究[D]. 北京: 中国石油大学, 2016.
[10] Zhang W L. Research on seismic anisotropic parameter inversion method based on Ruger’s formula[D]. Beijing: China University of Petroleum, 2016.
[11] 任涛, 秦军, 周阳, 等. 利用叠前方位各向异性预测准噶尔盆地西北缘车476井区火山岩裂缝[J]. 石油地质与工程, 2021, 35(1):1-7.
[12] Ren T, Qin J, Zhou Y, et al. Prediction of volcanic fractures in Che 476 well block in northwestern margin of Junggar basin by using pre-stack azimuthal anisotropy[J]. Petroleum Geology and Engineering, 2021, 35(1):1-7.
[13] Rüger A. P-wave reflection coefficients for transversely isotropic models with vertical and horizontal axis of symmetry[J]. Geophysics, 1997, 62(3):713-721.
[14] 陈怀震, 印兴耀, 杜炳毅, 等. 裂缝型碳酸盐岩储层方位各向异性弹性阻抗反演[J]. 地球物理学进展, 2013, 28(6):3073-3079.
[15] Cheng H Z, Yin X Y, Du B Y, et al. Current situations and recent progress in different azimuths seismic exploration[J]. Progress in Geophysics, 2013, 28(6):3073-3079.
[16] Bakulin A, Vladimir G, Tsvankin Ilya.Estimation of fracture parameters from reflection seismic data—Part I:HTI model due to a single fracture set[J]. Geophysics, 2000, 65(6):1788-1802.
[17] 龚明平, 张军华, 王延光, 等. 分方位地震勘探研究现状及进展[J]. 石油地球物理勘探, 2018, 53(3):642-658.
[18] Gong M P, Zhang J H, Wang Y G, et al. Current situations and recent progress in different azimuths seismic exploration[J]. Oil Geophysical Prospecting, 2018, 53(3):642-658.
[19] 张保庆, 周辉, 左黄金, 等. 宽方位地震资料处理技术及应用效果[J]. 石油地球物理勘探, 2011, 46(3):396-400.
[20] Zhang B Q, Zhou H, Zuo H J, et al. Wide azimuth data processing techniques and their applications[J]. Oil Geophysical Prospecting, 2011, 46(3):396-400.
-
