Late Ordovician Tectono-Sedimentary Evolution of the Changma Area, Forearc Basin in the Western North Qilian Orogen
-
摘要:
北祁连早古生代多岛洋盆的古地理格局和构造演化一直存在争议。位于北祁连南、北蛇绿岩之间的昌马地区广泛出露了一套早古生代深水火山-碎屑建造。早期填图工作普遍认为其形成于寒武纪至早奥陶世。本次研究对昌马西部的鹰嘴山和车路沟山南侧剖面开展系统的野外地质调查。并对采集到的浊积岩和火山岩样品开展了锆石LA-ICP-MS U-Pb定年工作。研究结果表明，原填为寒武系a岩组的鹰嘴山剖面所采集的砂岩样品2307NQL-13最年轻的锆石给出了（456±4） Ma的加权平均年龄；车路沟山南侧，原划归为下奥陶统阴沟群的安山岩样品2307NQL-06给出了（450±4） Ma的加权平均年龄，证明研究区大面积存在晚奥陶世沉积地层，现有年代地层方案需要重新审视。砂岩样品中的碎屑锆石以寒武纪—奥陶纪年龄为主，主要源于岩浆弧的剥蚀；32颗新元古代和古元古代碎屑锆石揭示古老基底物质的大量加入，表明晚奥陶世昌马地区沉积了大量来自中祁连的碎屑物质。来自中祁连基底的碎屑物质暗示北祁连洋的南分支已经闭合；碎屑物质形成于俯冲相关构造环境暗示北祁连洋的北分支俯冲仍在继续。本次研究给出的新数据将为昌马地区进一步的地层和沉积演化提供可靠的同位素年代约束，也为探讨北祁连洋早古生代复杂的俯冲、闭合过程提供重要依据。
-
关键词:
- LA-ICP-MS U-Pb年代学 /
- 晚奥陶世 /
- 弧前盆地 /
- 北祁连洋 /
- 昌马地区
Abstract:The paleogeography and tectonic evolution history of the Early Paleozoic archipelago-type North Qilian Ocean remain controversial. A set of Early Paleozoic deep-water clastic-volcanic succussion are well exposed in the Changma Area between the north and south ophiolitic belt of the North Qilian Orogen. Previous geologic mappings generally assigned a Cambrian to Early Ordovician stratigraphic age for these strata. In this study, we conducted systemic field-based investigations on outcrops in the Yingzuishan and Chelugou Section in the western Changma, and conducted zircon LA-ICP-MS U-Pb datings on collected turbidites and volcanics. Geochronologic results indicate that the sandstone sample 2307NQL-13 from the previously termed Cambrian Number a unit of the Yingzuishan Section yielded a well-defined weighted mean age of (456±4) Ma for the youngest detrital zircons. An andesite sample 2307NQL-06 from the previously termed Early Ordovician Yingou Formation yielded a well-defined weighted mean age of (450±4) Ma. These new data solidly demonstrated the existence of Late Ordovician sedimentary strata in the Changma Area, requiring further consideration of previous mapping proposals. Detrital zircons from sandstones are mostly of Cambrian-Ordovician ages, indicating major sedimentary derivations form newly-formed magmatic arcs. Appearance of 32 Neo- to Paleoproterozoic aged zircons imply additional supply form metamorphic basement complexes, revealing depositor of detritus from the Central Qilian. This clue hints at that the southern branch of the North Qilian Ocean should have been closed in Late Ordovician to allow sedimentary materials from the Central Qilian to be transported to and deposited in the Changma Area. The subduction-related depositional setting indicates that ongoing subduction of the oceanic crust of the northern branch should sustain until then. These clues provide new geochronologic data and related observations on stratigraphy and sedimentary evolution history of the Changma Area, and yield further constraints on the composite Early Paleozoic subduction-closure history of the North Qilian Ocean.
-
Key words:
- LA−ICP−MS U−Pb dating /
- late Ordovician /
- forearc basin /
- north Qilian Ocean /
- Changma area
-
-
图 7 锆石微量元素Th/U-Nb/Hf判别图解（a） 、锆石微量元素Th/ Nb-Hf/Th判别图解（b）（据Yang et al., 2012） 、研究区地壳厚度随锆石年龄的变化图（c）
Figure 7.
图 8 早古生代北祁连洋构造演化模式图（据 Dong et al., 2021修）
Figure 8.
-
[1] 董云鹏, 张国伟, 孙圣思, 等 . 中国大陆“十字构造”形成演化及其大陆动力学意义[J]. 地质力学学报,2019 ,25 （05 ）:769 −797 .DONG Yunpeng, ZHANG Guowei, SUN Shengsi, et al . The “Cross-Tectonics” in China Continent: formation, Evolution, and its Significance for Continental Dynamics[J]. Journal of Geomechanics,2019 ,25 （05 ）:769 −797 .[2] 杜远生, 张哲, 周道华, 等 . 北祁连-河西走廊志留纪和泥盆纪古地理及其对同造山过程的沉积响应[J]. 古地理学报,2002 ,04 （04 ）:1 −8 .DU Yuansheng, ZHANG Zhe, ZHOU Daohua, et al . Silurian and Devonian Palaeogeography of Northern Qilian-Hexi Corridor and its Sedimentary Response to Synorngenesis of North Qilian Orogenic Belt[J]. Journal of Palaeogeography,2002 ,04 （04 ）:1 −8 .[3] 冯益民, 何世平 . 祁连山及其邻区大地构造基本特征-兼论早古生代海相火山岩的成因环境[J]. 西北地质科学,1995 ,16 （01 ）:92 −103 .FENG Yimin, HE Shiping . Basic Characteristics of Tectonics in the Qilian Mountains and its Neighbourings, and Genetic Environments of Early Paleozoic Marine Volcanics[J]. Northwest Geoscience,1995 ,16 （01 ）:92 −103 .[4] 甘肃省区调报告昌马幅1: 20万[R]. 兰州: 甘肃省地质调查局, 1972. [5] 黄增保, 许荣科, 张彦杰, 等 . 甘肃玉门昌马地区蛇绿混杂岩地质特征[J]. 甘肃地质学报,2001 ,10 （02 ）:12 −22 .HUANG Zengbao, XU Rongke, ZHANG Yanjie, et al . Geological Characteristics of Ophiolitic Mixtite in Changma Region, Yumen, Gansu[J]. Acta Geologica Gansu,2001 ,10 （02 ）:12 −22 .[6] 金霞, 黄增保 . 甘肃昌马地区阴沟群火山岩地质特征及构造环境探讨[J]. 甘肃地质学报,2004 ,13 （01 ）:46 −53 .JIN Xia, HUANG Zengbao . Discussion on the geological characteristics and its tectonic setting of volcanic rocks of Yingou group in Changma area, Gansu[J]. Acta Geologica Gansu,2004 ,13 （01 ）:46 −53 .[7] 史仁灯, 杨经绥, 吴才来, 等 . 北祁连玉石沟蛇绿岩形成于晚震旦世的SHRIMP年龄证据[J]. 地质学报,2004 ,78 （05 ）:649 −657 .SHI Rendeng, YANG Jingsui, WU Cailai, et al . First SHRIMP Dating for the Formation of the Late Sinian Yushigou Ophiolite, North Qilian Mountains[J]. Acta Geologica Sinica,2004 ,78 （05 ）:649 −657 .[8] 任海东, 王涛, 潘彤, 等. 东昆仑东段三叠纪岩浆岩Nd–Hf同位素组分特征、物源演变规律及其构造背景[J]. 西北地质, 2023, 56(6): 95−112. REN Haidong, WANG Tao, PAN Tong, et al. Nd–Hf Isotopic Characteristics, Evolution Trend and Tectonic Setting of Triassic Magmatic Rocks in the Eastern Segment of East Kunlun Orogeny[J]. Northwestern Geology, 2023, 56(6): 95−112.. [9] 宋述光, 吴珍珠, 杨立明, 等 . 祁连山蛇绿岩带和原特提斯洋演化[J]. 岩石学报,2019 ,35 （10 ）:2948 −2970 .SONG Shuguang, WU Zhenzhu, YANG Liming, et al . Ophiolite Belts and Evolution of the Proto-Tethys Ocean in the Qilian Orogen[J]. Acta Petrologica Sinica,2019 ,35 （10 ）:2948 −2970 .[10] 吴福元, 万博, 赵亮, 等 . 特提斯地球动力学[J]. 岩石学报,2020 ,36 （06 ）:1627 −1674 .WU Fuyuan, WAN Bo, ZHAO Liang, et al . Tethyan Geodynamics[J]. Acta Petrologica Sinica,2020 ,36 （06 ）:1627 −1674 .[11] 夏林圻, 夏祖春, 彭礼贵, 等 . 北祁连山石灰沟奥陶纪岛弧火山岩系岩浆性质的确定[J]. 岩石矿物学杂志,1991 ,10 （01 ）:1 −10 .XIA Linqi, XIA Zuchun, PENG Ligui, et al . Determination of Magmatic Nature of Ordovician Island Arc Volcanic Series in The Shihuigou Area in the Northern Qilian Mountains[J]. Acta Petrologica et Mineralogica,1991 ,10 （01 ）:1 −10 .[12] 夏林圻, 夏祖春, 徐学义 . 北祁连山构造-火山岩浆演化动力学[J]. 西北地质科学,1995 ,16 （01 ）:1 −28 .XIA Linqi, XIA Zuchun, XU Xueyi . Dynamics of Tectono-Volcano-Magmatic Evolution from North Qilian Mountains, China[J]. Northwest Geoscience,1995 ,16 （01 ）:1 −28 .[13] 夏林圻, 夏祖春, 徐学义 . 南秦岭中～晚元古代火山岩性质与前寒武纪大陆裂解[J]. 中国科学(D辑: 地球科学),1996 ,26 （03 ）:237 −243 .XIA Linqi, XIA Zuchun, XU Xueyi . Properties of Middle to Late Proterozoic Volcanic Rocks in South Qinling and Precambrian Continental Cracking[J]. Science in China (Earth Sciences),1996 ,26 （03 ）:237 −243 .[14] 熊万宇康, 赵梦琪, 于淼, 等. 造山带洋陆转换过程与岩浆作用: 以东昆仑都兰地区古生代花岗岩为例[J]. 西北地质, 2023, 56(6): 113−139. XIONG Wanyukang, ZHAO Mengqi, YU Miao, et al. Ocean−Continent Transition Process and Magmatism in Orogenic Belts: A Case Study of Paleozoic Granites in the Dulan Area of East Kunlun[J]. Northwestern Geology, 2023, 56(6): 113−139.. [15] 肖序常, 陈国铭, 朱志直 . 祁连山古蛇绿岩带的地质构造意义[J]. 地质学报,1978 （04 ）:281 −295+338 .XIAO Xuchang, CHEN Guoming, ZHU Zhizhi . A Preliminary Study on the Tectonics of Ancient Ophiolites in the Qilian Mountain, Northwest China[J]. Acta Geologica Sinica,1978 （04 ）:281 −295+338 .[16] 徐亚军, 杜远生, 杨江海 . 北祁连造山带晚奥陶世-泥盆纪构造演化: 碎屑锆石年代学证据[J]. 地球科学,2013 ,38 （05 ）:934 −946 .XU Yajun, DU Yuansheng, YANG Jianghai . Tectonic Evolution of the North Qilian Orogenic Belt from the Late Ordovician to Devonian: Evidence from Detrital Zircon geochronology[J]. Earth Sciences,2013 ,38 （05 ）:934 −946 .[17] 许志琴, 徐惠芬, 张建新, 等 . 北祁连走廊南山加里东俯冲杂岩增生地体及其动力学[J]. 地质学报,1994 ,68 （01 ）:1 −15 .XU Zhiqin, XU Huifeng, ZHANG Jianxin, et al . The Zhoulangnanshan Caledonian Subductive Complex in the Northern Qilian Mountains and its Dynamics[J]. Acta Geologica Sinica,1994 ,68 （01 ）:1 −15 .[18] 张国伟, 董云鹏, 姚安平 . 造山带与造山作用及其研究的新起点[J]. 西北地质,2001 ,34 （01 ）:1 −9 .ZHANG Guowei, DONG Yunpeng, YAO Anping . Review on the Development of Studies on the Tectonic and Orogen Process of Orogenic Belt, and Discussing on Some New Key Problems[J]. Northwestern Geology,2001 ,34 （01 ）:1 −9 .[19] 张建新, 宫江华 . 阿拉善地块性质和归属的再认识[J]. 岩石学报,2018 ,34 （4 ）:940 −962 .ZHANG Jianxin, GONG Jianghua . Revisiting the Nature and Affinity of the Alxa Block[J]. Acta Petrologica Sinica,2018 ,34 （4 ）:940 −962 .[20] 张建新, 许志琴, 李海兵, 等 . 北祁连加里东造山带从挤压到伸展造山机制的转换[J]. 长春地质学院学报,1997 ,27 （03 ）:38 −44 .ZHANG Jianxin, XU Zhiqin, LI Haibing, et al . The Transition of Orogenic Mechanism from Compression to Extension in Northern Qilian Orogenic Belt[J]. Journal of Changchun University of Earth Sciences,1997 ,27 （03 ）:38 −44 .[21] 张建新, 于胜尧, 李云帅, 等 . 原特提斯洋的俯冲、增生及闭合: 阿尔金-祁连-柴北缘造山系早古生代增生/碰撞造山作用[J]. 岩石学报,2015 ,31 （12 ）:3531 −3554 .ZHANG Jianxin, YU Shenyao, LI Yunshuai, et al . Subduction, Accretion and Closure of Proto-Tethyan Ocean: Early Paleozoic Accretion or Collision Orogeny in the Altun-Qilian-North Qaidam Orogenic System[J]. Acta Petrologica Sinica,2015 ,31 （12 ）:3531 −3554 .[22] 左国朝, 吴茂炳, 毛景文, 等 . 北祁连西段早古生代构造演化史[J]. 甘肃地质学报,1999 ,8 （01 ）:7 −14 .ZUO Guochao, WU Maobing, MAO Jingwen, et al . Structural Evolution of Early Paleozoic Tectonic Belt in the West Section of Northern Qilian Area[J]. Acta Geologica Gansu,1999 ,8 （01 ）:7 −14 .[23] Belousova E A, Griffin W L, O’Reilly S Y, et al . Igneous zircon: trace element composition as an indicator of source rock type[J]. Contributions to Mineralogy and Petrology,2002 ,143 （5 ）:602 −622 .[24] Cawood P A, Hawkesworth C J, Dhuime B . Detrital zircon record and tectonic setting[J]. Geology,2012 ,40 （10 ）:875 −878 .[25] Dong Y P, He D F, Sun S S, et al . Subduction and accretionary tectonics of the East Kunlun orogen, western segment of the Central China Orogenic System[J]. Earth-Science Reviews,2018 ,186 :231 −261 .[26] Dong Y P, Sun S S, Santosh M, et al . Central China Orogenic Belt and amalgamation of East Asian continents[J]. Gondwana Research,2021 ,100 （05 ）:131 −194 .[27] Ludwig K R . A geochronological toolkit for Microsoft Excel[J]. Isoplot,2003 ,3 :1 −70 .[28] Sláma J, Košler J, Condon D J, et al . Plešovice zircon-a new natural referen−ce material for U–Pb and Hf isotopic microanalysis[J]. Chemical Geology,2008 ,249 （1-2 ）:1 −35 .[29] Song S G, Niu Y L, Li S, et al . Tectonics of the North Qilian orogen, NW China[J]. Gondwana Research,2013 ,23 （4 ）:1378 −1401 .[30] Sun J P, Dong Y P . Ordovician tectonic shift in the western North China Craton constrained by stratigraphic and geochronological analyses[J]. Basin Research,2020 ,32 （6 ）:1413 −1440 .[31] Sun J P, Dong Y P, Chen Q, et al . Ordovician tectonic transition from passive margin into peripheral foreland in the southern Ordos: A diagnostic insight into the closure of Erlangping Ocean between the North Qinling Arc and North China Block[J]. Basin Research,2023 ,35 （1 ）:336 −362 .[32] Tang M, Ji W Q, Chu X, et al . Reconstructing crustal thickness evolution from europium anomalies in detrital zircons[J]. Geology,2021 ,49 （1 ）:76 −80 .[33] Wiedenbeck M A P, Corfu F Y, et al . Three natural zircon standards for U-Th-Pb, Lu-Hf, trace element and REE analyses[J]. Geostandards Newsletter,1995 ,19 （1 ）:1 −23 .[34] Xiao W J, Windley B F Y Y, et al . Early Paleozoic to Devonian multiple-accretionary model for the Qilian Shan, NW China[J]. Journal of Asian Earth Sciences,2009 ,35 （3−4 ）:323 −333 .[35] Yan Z, Fu C L, Aitchison J C, et al . Retro-foreland Basin Development in Response to Proto-Tethyan Ocean Closure, NE Tibet Plateau[J]. Tectonics,2019 ,38 （12 ）:4229 −4248 .[36] Yan Z, Xiao W J, Aitchison J C, et al . Age and origin of accreted ocean plate stratigraphy in the North Qilian belt, NE Tibet Plateau: evidence from microfossils and geochemistry of cherts and siltstones[J]. Journal of the Geological Society,2021 ,178 （6 ）:jgs2020 −231 .[37] Yang J H, Cawood P A, Du Y S, et al . Large Igneous Province and magmatic arc sourced Permian–Triassic volcanogenic sediments in China[J]. Sedimentary Geology,2012 ,261 :120 −131 .[38] Yin A, Harrison T M . Geologic evolution of the Himalayan-Tibetan orogen[J]. Annual Review of Earth and Planetary Sciences,2000 ,28 （1 ）:211 −280 . -
