Application of Comprehensive Geophysical and Geochemical Exploration Method in the Daxigou Fluorite Deposit, Kalaqin banner, Inner Mongolia
-
摘要:
笔者以大西沟热液裂隙充填型萤石矿床为例，结合地质调查，联合应用1∶5万水系沉积物测量、1∶1万土壤地球化学剖面、1∶1万高精度磁测、1∶1万高密度电阻率剖面和1∶1万电阻率剖面综合技术方法开展了萤石找矿勘查的有效性试验研究。结果表明：1∶5万水系沉积物测量工作可以缩小找矿目标区域；高精度磁测、高密度电阻率和视电阻率联合剖面物探技术方法相结合可有效地探测控矿断裂浅地表的空间延伸情况及规模；土壤地球化学剖面圈出的高F异常可有效地识别断裂构造的含矿性。将上述物探和化探综合技术方法应用到大西沟矿床外围，探测到控矿构造北西延伸至画匠沟村以北1000 m以上，并在地表发现两处矿化露头。对矿化露头经地表槽探工程揭露，浅地表矿体达工业规模，这为矿山外围深部勘查扩增工作提供了依据。同时该方法组合可为区域热液裂隙充填型萤石矿找矿工作提供一定的借鉴。
Abstract:In order to test the effectiveness of fluorite mineralization prospecting, we conducted geological survey, 1∶50 000 stream sediment survey, 1∶10000 soil geochemical profile, 1∶10000 high-precision magnetic survey, 1∶10 000 high-density resistivity profile and 1∶10000 resistivity profile in the Daxigou hydrothermal fissure filling fluorite deposit of Inner Mongolia. The results show that the 1∶50000 stream sediment survey can reduce the target area of prospecting. The geophysical exploration combination of high-precision magnetic survey, high-density resistivity and apparent resistivity profile can effectively detect the spatial extension and scale of surface ore-controlling faults. In addition, the high F anomalies in the soil geochemical profile can effectively identify the mineralization potential of the fault structure. By applying the combined geophysical and geochemical exploration techniques to the periphery of the Daxigou deposit, it is suggested that the ore-controlling structure extends to the northwest of more than 1000 m to the north of Huajianggou Village and two mineralized outcrops were found on the surface. On the basis of the surface trough exploration, it is revealed that the shallow surface ore body reached the industrial scale, which provided guidance for deep exploration in the periphyry. Furthermore, the here untilized exploration methods can provide some reference for prospecting of regional hydrothermal fissure filling fluorite deposits.
-
Key words:
- Daxigou /
- fluorite /
- geophysical and geochemical exploration /
- application
-
-
表 1 研究区岩、矿石磁性参数测定统计表
Table 1. Statistical table for determination of magnetic parameters of rocks and ores in the study area
岩矿石名称 块数 磁化率（10−5SI） 变化范围 平均值 蚀变花岗岩 10 110～960 521 花岗岩 10 320～11900 6625 安山岩 6 140～13884 9461 流纹质碎屑岩 5 1215.96～6080.13 3307.32 萤石矿 10 1～56.7 18 石英 12 3～1000 58
下载: 导出CSV
表 2 研究区岩、矿石电性参数测定统计表
Table 2. Statistical table for determination of electrical parameters of rocks and ores in the study area
岩矿石名称 块数 ρs（Ω·M） 变化范围 平均值 流纹质碎屑岩 10 690～4850 1790 安山质碎屑岩 4 520～3870 1530 花岗岩 8 470～3260 1590 萤石（完整） 6 1360～5720 2150 萤石（风化） 4 560～2620 1150 萤石矿化硅化花岗岩
（破碎带）4 650～3530 1260 石英 12 453～5314 2098
下载: 导出CSV
-
[1] 曹华文, 张寿庭, 邹灏, 等 . 内蒙古林西萤石矿床石英ESR年龄及其地质意义[J]. 现代地质,2013 ,27 （4 ）:888 −894 .CAO Huawen, ZHANG Shouting, ZHOU Hao, et al . ESR Dating of Quartz from Linxi Fluorite Deposits, Inner Mongolia and Its Geological Implications[J]. Geoscience,2013 ,27 （4 ）:888 −894 .[2] 段吉学, 刘江 . 综合物化探在内蒙萤石多金属矿普查中的应用研究[J]. 西北地质,2019 ,52 （3 ）:265 −274 .DUAN Jixue, LIU Jiang . Application of Comprehensive Physical and Chemical Exploration Method for Prospecting Fluorite Polymetallic Deposit in Inner Mongolia[J]. Northwestern Geology,2019 ,52 （3 ）:265 −274 .[3] 方乙. 中国东部地区萤石矿隐伏矿体定位预测技术方法组合研究[D]. 北京: 中国地质大学(北京), 2015. FANG YI. The Study of Comprehensive Exploration Methods for the Prediction of Concealed Fluorite Deposit in East China[D]. Beijing: China University of Geosciences (Beijing), 2015. [4] 高峰. 地面伽马能谱测量在内蒙古赤峰浅覆盖区萤石矿勘查中的应用[D]. 北京: 中国地质大学(北京), 2013. GAO Feng. Application of Ground Gamma-Ray Spectrometry on Fluorite Mine Exploration in Shallow Covered Area of Chifeng, Inner Mongolia[D]. Beijing: China University of Geosciences (Beijing), 2013. [5] 时永志, 李凯成 . 综合物化探方法在地质找矿“攻深探盲”中的应用[J]. 物探与化探,2014 ,38 （5 ）:910 −915 .SHI Yongzhi, LI Kaicheng . The Application of Integrated Geophysical and Geochemical Exploration Methods to the Prospecting for Deep and Eoncealed Orebodies[J]. Geophysical and Geochemical Exploration,2014 ,38 （5 ）:910 −915 .[6] 商朋强, 代晓光, 谢晓亮, 等. 东部地区硼磷萤石等重要非金属矿产调查项目成果报告[R]. 北京: 中化地质矿山总局, 2019. [7] 王小红, 杨建国, 王磊, 等 . 地质物化探综合方法在甘肃北山红柳沟铜镍矿的应用[J]. 西北地质,2023 ,56 （6 ）:254 −261 .WANG Xiaohong, YANG Jianguo, WANG Lei, et al. The Application Effect of Geological Geophysical and Geochemical Exploration Comprehensive Method in Hongliugou Copper–Nickel Deposit, Beishan, Gansu Province[J]. Northwestern Geology,2023 ,56 （6 ）:254 −261 .[8] 王吉平, 商朋强, 牛桂芝 . 中国萤石矿主要矿集区及其资源潜力探讨[J]. 化工矿产地质,2010 ,32 （2 ）:87 −95 .WANG Jiping, SHANG Pengqiang, NIU Guizhi . Discussion on China Fluorite-Concentrating Area and the Resource Potntialhina[J]. Geology of Chemical Minerals,2010 ,32 （2 ）:87 −95 .[9] 席玉林, 郭济海, 等. 喀喇沁旗幅K-50-23 1/20万地球化学图说明书: 水系沉积物测量[R]. 石家庄: 河北省地质矿产局区域地质调查大队五分队,1992. [10] 俞胜, 蒙轸, 尤关进 . 等. 物化探综合找矿方法在西口沟钼矿勘查中的应用[J]. 地质与勘探,2016 ,52 （5 ）:838 −845 .YU Sheng, MENG Zhen, YOU Guanjin, et al . Application of Integrated Geophysical and Geochemical Methods to Prospecting of the Xikougou Molybdenum Deposit[J]. Geology and Exploration,2016 ,52 （5 ）:838 −845 .[11] 杨镜明, 庞星, 陈黎呁 . 物化探方法在新疆克峡希一带金属多金属找矿中的应用[J]. 地质论评,2013 ,59 （z1 ）:843 −844 .YANG Jingming, PANG Xing, CHEN Lijun . Application of Geophysical and Geochemical Methods in Prospecting for Polymetallic Deposits In Kexiaxi Area, Xinjiang[J]. Geological Review,2013 ,59 （z1 ）:843 −844 .[12] 周圣华, 鄢云飞, 李艳军 . 矿产勘查中的物化探技术应用与地质效果[J]. 地质与勘探,2007 ,43 （6 ）:58 −62 .ZHOU Shenghua, YAN Yunfei, LI Yanjun . Application and Efficieny of Geophysical and Geochemical Exploration Methods in Present Ore Prospecting[J]. Geology and Exploration,2007 ,43 （6 ）:58 −62 .[13] 张鹏. 便携式X荧光仪在内蒙古赤峰浅覆盖区萤石矿勘查中的应用[D]. 北京: 中国地质大学(北京), 2013. ZHANG Peng. Application of Portable X-ray Fluorescence on Fluorite Mine Exploration in Shallow Covered Area of Chifeng, Inner Mongolia[D]. Beijing: China University of Geosciences (Beijing), 2013. [14] 张寿庭, 陈守余. 中国东部地区萤石矿隐伏矿体定位预测技术方法组合研究报告[R]. 北京: 中国地质大学(北京), 2015. [15] 张成信, 商朋强, 焦森, 等 . 内蒙古喀喇沁旗地区萤石矿床地质特征及成因探讨[J]. 中国地质调查,2019 ,6 （6 ）:79 −87 .ZHANG Chengxin, SHANG Pengqiang, JIAO Sen, et al . Geological Characteristics and Genesisi of Fluorite Deposits in KaraQinQi Area, Inner Mongolia[J]. Geological Survey of China,2019 ,6 （6 ）:79 −87 .[16] 翟明国, 朱日祥, 刘建明, 等 . 华北东部中生代构造体制转折的关键时限[J]. 中国科学(D辑: 自然科学),2003 ,33 （10 ）:913 −920 .ZHAI Mingguo, ZHU Rixiang, LIU Jingming, et al . The Key Timing of the Mesozoic TectonicIin Northesstern China[J]. Science in Chinese (Series D),2003 ,33 （10 ）:913 −920 . -
