Removal of Phosphate in Waste Water by Hydrothermal Synthesis Zeolite from Coal Fly Ash
-
摘要:
以粉煤灰为原料，采用水热法合成了低成本的P型沸石吸附剂，运用X射线衍射仪（XRD）、扫描电镜（SEM）和X射线能谱仪（EDAX）等手段对粉煤灰及合成沸石进行了系统表征，并通过静态吸附实验，探究了不同合成时间、碱液浓度及合成温度等条件得到的合成沸石对含磷废水中磷吸附效果的影响。结果表明，水热合成过程中，粉煤灰颗粒失去其原有形态，并在产物中出现P型沸石、羟基方钠石或八面沸石的晶体，且合成时间越长沸石晶体的结晶程度越好、表面也越粗糙。碱液浓度或合成温度越低，越不利于沸石吸附剂的合成。在合成时间8 h、碱液浓度1 mol/L、合成温度120 ℃的条件下，合成沸石产品处理初始浓度为5 mg/L模拟废水，其对磷的去除率可达30.1%。
Abstract:In this paper, the coal fly ash was used as the main raw material, and the low-cost P-type zeolite adsorbent was synthesized through the hydrothermal process.The coal fly ash and synthetic zeolite were systematically characterized by means of X-ray diffraction (XRD), scanning electronic microscope (SEM), and energy-dispersive X-ray analysis (EDAX). The effects of synthetic zeolites obtained at different conditions such as synthesis time, alkali concentration, and temperature on the phosphorus content of simulated phosphorus-containing wastewater was investigated through single-factor static adsorption experiments.The results show that during hydrothermal synthesis, the coal fly ash particles will lose their original form, and P-type zeolite, hydroxy-sodalite or faujasite crystals will be found in the synthesis products. The longer the synthesis time is, the better the crystallinity of the zeolite crystal and the rougher the surface are. The lower the alkali concentration or the synthesis temperature are, the more unfavorable for the synthesis of zeolite adsorbent is. At the conditions of synthesis time of 8 hours, alkali concentration of 1 mol/L, and synthesis temperature of 120 °C, the synthetic zeolite product was treated with an initial concentration of 5 mg/L simulated wastewater, and its removal rate of phosphorus could reached 30.1%.
-
Key words:
- coal fly ash /
- synthetic zeolite /
- phosphorus removal /
- adsorption /
- wastewater treatment
-
-
表 1 试样多元素分析结果 单位：%
Table 1. Results of elemental analysis of the samples
SiO2 Al2O3 Fe2O3 CaO MgO K2O Others Si/Al 46.54 34.88 6.77 5.04 0.60 0.46 5.71 1. 18
下载: 导出CSV
-
[1] Dalu T, Wasserman R J, Magoro M L, et al. River nutrient water and sediment measurements inform on nutrient retention, with implications for eutrophication[J]. Science of the Total Environment, 2019, 684:296-302. doi: 10.1016/j.scitotenv.2019.05.167
[2] 武旭源, 郑晓英, 郝瑞霞, 等. 天然沸石结构对合成分子筛吸附脱氮性能影响[J]. 中国环境科学, 2021, 41(7):3193-3200.WU X Y, ZHENG X Y, HAO R X, et al. Influence of natural zeolite structure on the adsorption and denitrification performance of synthetic molecular sieve[J]. China Environmental Science, 2021, 41(7):3193-3200.
WU X Y, ZHENG X Y, HAO R X, et al. Influence of natural zeolite structure on the adsorption and denitrification performance of synthetic molecular sieve[J]. China Environmental Science, 2021, 41(7):3193-3200.
[3] 孙彤, 郝瑞霞, 武旭源, 等. 天然沸石合成A型分子筛的吸附与再生特性[J]. 中国环境科学, 2020, 40(7):2926-2933.SUN T, HAO R X, WU X Y, et al. Adsorption and regeneration characteristics of type-A molecular sieve synthesized from natural zeolite[J]. China Environmental Science, 2020, 40(7):2926-2933.
SUN T, HAO R X, WU X Y, et al. Adsorption and regeneration characteristics of type-A molecular sieve synthesized from natural zeolite[J]. China Environmental Science, 2020, 40(7):2926-2933.
[4] REN X, QU R, LIU S, et al. Synthesis of zeolites from coal fly ash for the removal of harmful gaseous pollutants: A review[J]. Aerosol and Air Quality Research, 2020, 20(5):1127-1144. doi: 10.4209/aaqr.2019.12.0651
[5] 付有为. MAL改性沸石复合吸附剂处理含磷废水的研究[D].武汉:华中科技大学,2017.FU Y W. Study on phosphate removal form aqueous by MAL modified zeolite composite adsorbent[D]. Wuhan: Huazhong University of Science and Technology, 2017.
FU Y W. Study on phosphate removal form aqueous by MAL modified zeolite composite adsorbent[D]. Wuhan: Huazhong University of Science and Technology, 2017.
[6] Mushtaq F, Zahid M, Bhatti I A, et al. Possible applications of coal fly ash in wastewater treatment[J]. Journal of Environmental Management, 2019, 240:27-46.
[7] 宋明铭. 高碳粉煤灰综合利用技术研究[J]. 矿产综合利用, 2021(3):93-98.SONG M M. Study on comprehensive utilization technology of high carbon fly ash[J]. Multipurpose Utilization of Mineral Resources, 2021(3):93-98.
SONG M M. Study on comprehensive utilization technology of high carbon fly ash[J]. Multipurpose Utilization of Mineral Resources, 2021(3):93-98.
[8] 肖永丰. 粉煤灰提取氧化铝方法研究[J]. 矿产综合利用, 2020(4):156-162.XIAO Y F. Study on the methods of leaching alumina from fly ash[J]. Multipurpose Utilization of Mineral Resources, 2020(4):156-162.
XIAO Y F. Study on the methods of leaching alumina from fly ash[J]. Multipurpose Utilization of Mineral Resources, 2020(4):156-162.
[9] 丁佳栋, 陈迤岳, 陈晓飞, 等. 不同改性粉煤灰处理含磷废水效果比较研究[J]. 杭州师范大学学报(自然科学版), 2018, 17(3):264-268.DING J D, CHEN Y Y, CHEN X F, et al. Comparative study on the treatment of phosphorus-containing wastewater with different modified fly ash[J]. Journal of Hangzhou Normal University(Natural Sciences Edition), 2018, 17(3):264-268.
DING J D, CHEN Y Y, CHEN X F, et al. Comparative study on the treatment of phosphorus-containing wastewater with different modified fly ash[J]. Journal of Hangzhou Normal University(Natural Sciences Edition), 2018, 17(3):264-268.
[10] 聂轶苗, 刘攀攀, 夏淼, 等. 粉煤灰在碱性条件下的反应行为研究进展[J]. 矿产综合利用, 2021(2):77-84.NIE Y M, LIU P P, XIA M, et al. Research progress of fly ash reaction behavior in alkaline conditions[J]. Multipurpose Utilization of Mineral Resources, 2021(2):77-84.
NIE Y M, LIU P P, XIA M, et al. Research progress of fly ash reaction behavior in alkaline conditions[J]. Multipurpose Utilization of Mineral Resources, 2021(2):77-84.
[11] Tauanov Z, Azat S, Baibatyrova A. A mini-review on coal fly ash properties, utilization and synthesis of zeolites[J]. International Journal of Coal Preparation and Utilization, 2020: 1-23.
[12] 闫玉兵. 改性粉煤灰对含磷废水的处理研究[J]. 矿产综合利用, 2020(5):34-44.YAN Y B. Research on modified fly ash treats for phosphorus wastewater[J]. Multipurpose Utilization of Mineral Resources, 2020(5):34-44.
YAN Y B. Research on modified fly ash treats for phosphorus wastewater[J]. Multipurpose Utilization of Mineral Resources, 2020(5):34-44.
[13] Zhang K, Van Dyk L, He D, et al. Synthesis of zeolite from fly ash and its adsorption of phosphorus in wastewater[J]. Green Processing and Synthesis, 2021, 10(1):349-360. doi: 10.1515/gps-2021-0032
[14] 邹萍. 粉煤灰水热合成法制备4A型分子筛研究进展[J]. 矿产综合利用, 2020(3):33-39.ZOU P. Research development of 4A zeolite preparation from coal fly ash by hydrothermal synthesis method[J]. Multipurpose Utilization of Mineral Resources, 2020(3):33-39.
ZOU P. Research development of 4A zeolite preparation from coal fly ash by hydrothermal synthesis method[J]. Multipurpose Utilization of Mineral Resources, 2020(3):33-39.
[15] 孙延文, 王连勇, 杨湘澜, 等. 粉煤灰基沸石的制备及应用研究进展[J]. 硅酸盐通报, 2021, 40(1):123-132.SUN Y W, WANG L Y, YANG X L, et al. Research progress on synthesis and application of zeolite based on coal fly ash[J]. Bulletin of the Chinese Ceramic Society, 2021, 40(1):123-132.
SUN Y W, WANG L Y, YANG X L, et al. Research progress on synthesis and application of zeolite based on coal fly ash[J]. Bulletin of the Chinese Ceramic Society, 2021, 40(1):123-132.
[16] 于成龙, 熊楠, 宋杰,等. 近20年来中国利用粉煤灰合成分子筛研究进展[J]. 矿产综合利用, 2020(4):26-35.YU C L, XIONG N, SONG J, et al. Development of molecular sieves composition from fly ash in china in the last two decades[J]. Multipurpose Utilization of Mineral Resources, 2020(4):26-35.
YU C L, XIONG N, SONG J, et al. Development of molecular sieves composition from fly ash in china in the last two decades[J]. Multipurpose Utilization of Mineral Resources, 2020(4):26-35.
[17] 褚琳琳,宋媛媛,吕晓昊. 粉煤灰制备沸石的合成方法研究及环保应用[J]. 河北环境工程学院学报, 2021, 31(5):62-66+81.CHU L L, SONG Y Y, LYU X H. Synthesis and environmental application prospect of zeolite prepared from fly ash[J]. Journal of Hebei University of Environmental Engineering, 2021, 31(5):62-66+81.
CHU L L, SONG Y Y, LYU X H. Synthesis and environmental application prospect of zeolite prepared from fly ash[J]. Journal of Hebei University of Environmental Engineering, 2021, 31(5):62-66+81.
[18] Längauer D, Čablík V, Hredzák S, et al. preparation of synthetic zeolites from coal fly ash by hydrothermal synthesis[J]. Materials, 2021, 14(5):1267. doi: 10.3390/ma14051267
[19] 白芸, 张发旺, 宋佩佩, 等. 基于水热法利用粉煤灰制备沸石的研究进展[J]. 云南化工, 2021, 48(8):33-37.BAI Y, ZHANG F W, SONG P P, et al. Research progress of preparing zeolite from fly ash based on hydrothermal method[J]. Yunnan Chemical Technology, 2021, 48(8):33-37.
BAI Y, ZHANG F W, SONG P P, et al. Research progress of preparing zeolite from fly ash based on hydrothermal method[J]. Yunnan Chemical Technology, 2021, 48(8):33-37.
[20] Pengthamkeerati P, Satapanajaru T, Chularuengoaksorn P. Chemical modification of coal fly ash for the removal of phosphate from aqueous solution[J]. Fuel, 2008, 87(12):2469-2476. doi: 10.1016/j.fuel.2008.03.013
[21] Chareonpanich M, Jullaphan O, Tang C. Bench-scale synthesis of zeolite A from subbituminous coal ashes with high crystalline silica content[J]. Journal of Cleaner Production, 2011, 19(1):58-63. doi: 10.1016/j.jclepro.2010.08.012
[22] 李艳青. 粉煤灰沸石合成条件优化及初步应用研究[D].上海:上海交通大学,2007.LI Y Q. Optimization and preliminary application of coal fly ash zeolite synthesis conditions[D]. Shanghai: Shanghai Jiaotong University, 2007.
LI Y Q. Optimization and preliminary application of coal fly ash zeolite synthesis conditions[D]. Shanghai: Shanghai Jiaotong University, 2007.
[23] Murayama N, Yamamoto H, Shibata J. Mechanism of zeolite synthesis from coal fly ash by alkali hydrothermal reaction[J]. International Journal of mineral processing, 2002, 64(1):1-17. doi: 10.1016/S0301-7516(01)00046-1
[24] Ruen-ngam D, Rungsuk D, Apiratikul R, et al. Zeolite formation from coal fly ash and its adsorption potential[J]. Journal of the Air & Waste Management Association, 2009, 59(10):1140-1147.
[25] 吴德意, 孔海南, 赵统刚, 等. 合成条件对粉煤灰合成沸石过程中沸石生成和品质的影响[J]. 无机材料学报, 2005(5):1153-1158.WU D Y, KONG H N, ZHAO T G, et al. Effects of synthesis conditions on the formation and quality of zeolite during the hydrothermal zeolitization processes of fly ash[J]. Journal of Inorganic Materials, 2005(5):1153-1158.
WU D Y, KONG H N, ZHAO T G, et al. Effects of synthesis conditions on the formation and quality of zeolite during the hydrothermal zeolitization processes of fly ash[J]. Journal of Inorganic Materials, 2005(5):1153-1158.
[26] 郭畅, 邓慧, 何晓蕾. 粉煤灰沸石合成转化的研究[J]. 粉煤灰综合利用, 2012(5):53-56.GUO C, DENG H, HE X L. Study on synthesis and conversion of zeolite from fly ash[J]. Fly Ash Comprehensive Utilization, 2012(5):53-56.
GUO C, DENG H, HE X L. Study on synthesis and conversion of zeolite from fly ash[J]. Fly Ash Comprehensive Utilization, 2012(5):53-56.
[27] 付克明, 路迈西, 朱虹. 粉煤灰合成P型沸石研究[J]. 煤炭工程, 2007(2):85-87.FU K M, LU M X, ZHU H. Research on synthesis P type zeolite with fly ash[J]. Coal Engineering, 2007(2):85-87.
FU K M, LU M X, ZHU H. Research on synthesis P type zeolite with fly ash[J]. Coal Engineering, 2007(2):85-87.
-
