Flotation Process of Lithium from a Pegmatite-type Lithium Ore in Southern Africa
-
摘要:
矿石中锂矿物以锂辉石、含锂白云母和锂云母为主，少量羟锂磷铝石、锂电气石和磷锰锂矿，脉石矿物主要为长石和石英。原矿Li2O含量为1.60%，72.71%的锂以锂辉石形式存在，16.90%以锂云母形式存在，2.91%的锂赋存于羟锂磷铝石、磷锰锂矿等锂的磷酸盐矿物中，还有7.48%的锂以锂矿物包裹体分散于石英/长石中，可回收的锂矿物主要为锂云母和锂辉石。锂云母与锂辉石可浮性很相近，通过实验确定了适配的浮选捕收剂、调整剂及活化剂，获得了锂云母浮选精矿和锂辉石浮选精矿。以有机酸AS为捕收剂、碳酸钠和氢氧化钠为调整剂、氯化钙为活化剂，采用锂云母优先浮选工艺流程，闭路实验获得Li2O品位2.92%、Li2O回收率15.47%的锂云母精矿和Li2O品位6.36%、Li2O回收率为71.20%的锂辉石精矿，产品合计Li2O的回收率为86.67%，对应的Li2O品位为5.26%。
Abstract:The primary lithium minerals in the ore are spodumene, lithium-bearing muscovite, and lepidolite, with small quantities of montebrasite, elbaite, and lithiophyllite. The gangue minerals primarily consist of feldspar and quartz. The Li2O in the raw ore is 1.60%, 72.71% of the lithium is present in the form of spodumene, 16.90% in the form of lepidolite, 2.91% in the form of lithium phosphate minerals such as montebrasite and lepidolite, and 7.48% as lithium mineral inclusions within quartz and feldspar. The recyclable lithium minerals primarily include lepidolite and spodumene. The floatability of lepidolite and spodumene is quite similar, and their floatability can be adjusted through the use of appropriate flotation collectors, regulators, and activators, allowing for the flotation of both lepidolite and spodumene concentrates. Using organic acid AS as the collector, sodium carbonate and sodium hydroxide as regulators, and calcium chloride as the activator, lepidolite concentrate with a Li2O grade of 2.92% and a recovery of 15.47%, as well as spodumene concentrate with a Li2O grade of 6.36% and a recovery of 71.20%, were obtained through a small-scale closed-circuit test. The total Li2O recovery was 86.67%, with a corresponding Li2O grade of 5.26%.
-
Key words:
- pegmatite /
- spodumene /
- lepidolite /
- flotation
-
-
表 1 原矿主要化学成分的化学分析结果单位：%
Table 1. Main chemical composition analysis results of the raw ore
Li2O Rb2O5 Cs2O Na2O K2O CaO MgO Al2O3 SiO2 BeO P2O5 Fe 1.60 0.12 0.08 3.80 2.80 0.65 0.50 14.55 75.86 0.041 0.56 0.50
下载: 导出CSV
表 2 矿石中矿物组成及相对含量
Table 2. Mineral composition and relative content of minerals in the raw ore
矿物名称 含量/% 矿物名称 含量/% 锂辉石 13.31 绿泥石 0.65 锂磷铝石 0.28 高岭石 0.28 锂电气石 0.30 中长石 0.85 锂绿泥石 0.08 铯榴石 0.39 钠长石 29.25 绿柱石 0.31 石英 34.07 角闪石 0.46 钾长石 10.42 其他 0.80 云母（含锂云母） 8.55
下载: 导出CSV
表 3 矿石中锂矿物组成及相对含量
Table 3. Composition and relative content of lithium minerals in the raw ore
矿物名称 含量/% Li2O含量/% Li2O 占有率/% 锂辉石 13.31 7.82 72.71 锂云母（含铯榴石） 11.80 2.15 16.90 锂磷铝石 0.28 9.68 1.98 锂电气石 0.18 0.91 0.66 磷锰锂矿 0.30 10.31 0.19 锂绿泥石 0.08 1.67 0.08 石英/长石 39.25 0.14 7.48 其他 34.80 / / 合计 100.00 1.56 100.00
下载: 导出CSV
表 4 锂云母粗选调整剂种类浮选实验结果
Table 4. Flotation test results of lepidolite roughing regulator types
实验药剂及用量/
（g/t 原矿）产品
名称产率/
%Li2O
品位 /%Li2O
回收率 /%硫酸 200 粗精矿 12.28 2.17 16.66 尾矿 87.72 1.52 83.34 原矿 100.00 1.60 100.00 六偏磷酸钠800 粗精矿 15.28 1.68 16.09 尾矿 84.72 1.58 83.91 原矿 100.00 1.60 100.00 水玻璃1 000 粗精矿 11.08 2.45 16.91 尾矿 88.92 1.50 83.09 原矿 100.00 1.61 100.00 碳酸钠800 粗精矿 15.08 1.75 16.61 尾矿 84.92 1.56 83.39 原矿 100.00 1.59 100.00
下载: 导出CSV
表 5 锂云母精选次数实验结果
Table 5. Test results of lepidolite concentration times
实验条件 产品名称 产率/ % 品位 /%
Li2OLi2O回收
率 /%精选一次 锂云母精矿 62.75 3.25 83.02 中矿 37.25 1.12 16.98 给矿 100.00 2.46 100.00 精选二次 锂云母精矿 53.20 3.52 73.26 中矿1 24.35 1.27 12.10 中矿2 46.80 0.80 14.65 给矿 100.00 2.56 100.00
下载: 导出CSV
表 6 锂辉石浮选活化剂实验结果
Table 6. Test results of spodumene flotation activator
活化剂种类
用量/（g/t）产品名称 产率/% Li2O
品位/%Li2O
回收率/%氯化钙 0 锂辉石粗精矿 25.40 5.02 88.60 尾矿 74.60 0.22 11.40 给矿 100.00 1.44 100.00 氯化钙 200 锂辉石粗精矿 25.40 5.16 91.18 尾矿 74.60 0.17 8.82 给矿 100.00 1.44 100.00
氯化钙 400锂辉石粗精矿 25.56 5.12 90.71 尾矿 74.44 0.18 9.29 给矿 100.00 1.44 100.00 硝酸铅 500 锂辉石粗精矿 25.00 5.21 91.53 尾矿 74.44 0.16 9.29 给矿 100.00 4.31 100.00 氯化铁 300 锂辉石粗精矿 25.16 5.18 91.59 尾矿 74.84 0.16 8.41 给矿 100.00 1.42 100.00
下载: 导出CSV
表 7 锂辉石捕收剂种类浮选实验结果
Table 7. Flotation test results of spodumene collectors
捕收剂种类及
用量/（g/t 原矿）产品名称 产率/ % Li2O
品位/%Li2O
回收率/%氧化石蜡皂
900粗精矿 27.20 4.82 90.91 尾矿 72.80 0.18 9.09 给矿 100.00 1.44 100.00 环烷酸皂
900粗精矿 27.60 4.92 91.69 尾矿 72.40 0.17 8.31 给矿 100.00 1.48 100.00 苯甲羟肟酸
1 000粗精矿 24.40 5.22 88.45 尾矿 75.60 0.22 11.55 给矿 100.00 1.44 100.00 有机酸AS
900粗精矿 25.16 5.32 91.79 尾矿 74.84 0.16 8.21 给矿 100.00 1.46 100.00
下载: 导出CSV
表 8 闭路实验结果
Table 8. Closed-circuit test results
产品名称 产率/ % Li2O品位/% Li2O回收率/% 锂云母精矿 8.48 2.92 15.47 锂辉石精矿 17.92 6.36 71.20 锂云母+锂辉石合计 26.40 5.26 86.67 尾矿 73.60 0.29 13.33 原矿 100.00 1.60 100.00
下载: 导出CSV
-
[1] 李承元, 李勤, 朱景和. 国内外锂资源概况及其选冶加工工艺综述[J]. 世界有色金属, 2001(8):4-8.LI C Y, LI Q, ZHU J H. Overview of lithium resources at home and abroad and its processing technology[J]. World Nonferrous Metals, 2001(8):4-8
LI C Y, LI Q, ZHU J H. Overview of lithium resources at home and abroad and its processing technology[J]. World Nonferrous Metals, 2001(8):4-8
[2] 马艳红,孙志健,万丽,等. 常见外界离子影响锂辉石捕收剂性能的研究进展[J]. 矿产综合利用, 2023(5):1-6.MA Y H, SUN Z J, WAN L, et al. Review on the influence of common external ions on the properties of spodumene collectors[J]. Multipurpose Utilization of Mineral Resources, 2023(5):1-6.
MA Y H, SUN Z J, WAN L, et al. Review on the influence of common external ions on the properties of spodumene collectors[J]. Multipurpose Utilization of Mineral Resources, 2023(5):1-6.
[3] 唐珏,王俊,储瑶,等. 新能源发展战略下锂资源形势与对策[J]. 矿产综合利用, 2023(6):71-76.TANG J,WANG J, CHU Y, et al. Lithium resource situation and countermeasures under new energy development strategy[J]. Multipurpose Utilization of Mineral Resources, 2023(6):71-76. doi: 10.3969/j.issn.1000-6532.2023.06.011
TANG J,WANG J, CHU Y, et al. Lithium resource situation and countermeasures under new energy development strategy[J]. Multipurpose Utilization of Mineral Resources, 2023(6):71-76. doi: 10.3969/j.issn.1000-6532.2023.06.011
[4] 孙传尧,印万忠 . 硅酸盐矿物浮选原理[M ]. 北京:科学出版社,2001 .SUN C Y, YIN W Z. Flotation principle of silicate minerals [M]. Beijing:Science Press,2001.
SUN C Y, YIN W Z. Flotation principle of silicate minerals [M]. Beijing:Science Press,2001.
[5] 程仁举,李成秀,刘星,等. 新疆某伟晶岩型锂辉石矿浮选实验研究[J]. 矿产综合利用, 2023(4):88-94.CHEN R J, LI C X, LIU X, et al. Flotation of a pegmatite type spodumene ore in Xinjiang[J]. Multipurpose Utilization of Mineral Resources, 2023(4):88-94.
CHEN R J, LI C X, LIU X, et al. Flotation of a pegmatite type spodumene ore in Xinjiang[J]. Multipurpose Utilization of Mineral Resources, 2023(4):88-94.
[6] 李晓波,许浩,王航,等. 江西某钽铌尾矿中锂云母的浮选实验研究[J]. 矿产综合利用, 2023(5):36-40.LI X B, XU H, WANG H, et al. Flotation research on recovery of lithionite from Ta-Nb tailing in Jiangxi[J]. Multipurpose Utilization of Mineral Resources, 2023(5):36-40.
LI X B, XU H, WANG H, et al. Flotation research on recovery of lithionite from Ta-Nb tailing in Jiangxi[J]. Multipurpose Utilization of Mineral Resources, 2023(5):36-40.
[7] 吕玲芝. 某复杂难选低品位锂辉石矿综合回收工艺[J]. 有色金属工程, 2014, 4(2):54-57.LYU L Z. Comprehensive recovery process of a complex refractory low-grade spodumene[J]. Nonferrous Metal Engineering, 2014, 4(2):54-57. doi: 10.3969/j.issn.2095-1744.2014.02.012
LYU L Z. Comprehensive recovery process of a complex refractory low-grade spodumene[J]. Nonferrous Metal Engineering, 2014, 4(2):54-57. doi: 10.3969/j.issn.2095-1744.2014.02.012
[8] 钱志博, 周少珍. 某低品位锂辉石矿石浮选试验研究[J]. 有色金属(选矿部分), 2019(6):62-68.QIAN Z B,ZHOU S Z. Experimental study on flotation of a low-grade spodumene ore[J]. Nonferrous Metals(Minera Processing Section), 2019(6):62-68.
QIAN Z B,ZHOU S Z. Experimental study on flotation of a low-grade spodumene ore[J]. Nonferrous Metals(Minera Processing Section), 2019(6):62-68.
[9] 孙志健, 周少珍, 钱志博. 国外某难选锂辉石矿选矿试验研究[J]. 中国矿业, 2019, 28(S1):169-171.SUN Z J, ZHOU S Z, QIAN Z B. Experimental study on mineral processing of a refractory spodumene ore abroad[J]. China Ming Magazine, 2019, 28(S1):169-171.
SUN Z J, ZHOU S Z, QIAN Z B. Experimental study on mineral processing of a refractory spodumene ore abroad[J]. China Ming Magazine, 2019, 28(S1):169-171.
[10] 余利红,高玉德,张国范,等. 非洲某锂辉石矿分选工艺[J]. 矿产综合利用, 2023(5):27-31.YU L H, GAO Y D, ZHANG G F, et al. Separation technology of a spodumene ore in Africa[J]. Multipurpose Utilization of Mineral Resources, 2023(5):27-31.
YU L H, GAO Y D, ZHANG G F, et al. Separation technology of a spodumene ore in Africa[J]. Multipurpose Utilization of Mineral Resources, 2023(5):27-31.
-
