ENRICHMENT CHARACTERISTICS AND RESOURCE POTENTIAL OF SHALE OIL IN THE FIRST MEMBER OF QINGSHANKOU FORMATION IN SOUTHERN SONGLIAO BASIN
-
摘要:
松辽盆地南部长岭凹陷青一段发育一套优质的半深湖-深湖相暗色页岩，沉积厚度大，分布稳定.页岩层系内存在大量滞留烃，具有可观的页岩油资源潜力.利用大量录井、测井、试油、岩心及分析测试资料，对青一段页岩滞留烃含量及分布、岩相组合、储集空间、矿物组成等富集主控因素进行了全面分析.结果表明，青一段页岩中滞留烃性质以中-轻质油为主，流动性好，在纵向上主要富集在1800~2500 m范围内.青一段页岩可划分为层理型、纹层型、互层型3种岩相类型，其中层理型和纹层型滞留烃含量高，TOC主体大于1.5%，有机质类型以Ⅰ、Ⅱ1型为主，热解S1主体大于2×10-3，孔隙度大于5.5%，孔径以介孔-宏孔为主，脆性矿物含量大于50%，可压性好，是主要的页岩油富集模式.通过富集主控因素叠合及有利岩相评价，优选乾安富集区部署实施吉页油1HF井，经压裂测试获得16.4 m3/d的高产页岩油流.采用热解S1法初步估算长岭凹陷青一段页岩油资源量为35×108 t，证实了松辽盆地南部具有可观的页岩油资源潜力.
Abstract:There is a set of high quality semi-deep to deep lacustrine dark shale developed in the first member of Qingshankou Formation(K2qn1) in Changling Sag, southern Songliao Basin, with large sedimentary thickness and stable distribution. A lot of residual hydrocarbon exists in shale layers with shale oil resource potential. Based on massive data of well logging, oil testing, core sampling and experimental test, the paper comprehensively analyzes the main controlling factors of enrichment including content and distribution of residual hydrocarbon, lithofacies assemblages, reservoir space and mineral compositions in the shale. The results show the residual hydrocarbon is mainly medium-light oil, with good fluidity and enrichment range of 1800-2500 m vertically. The shale of K2qn1 can be divided into bedded, laminated and interbedded lithofacies types, and the content of residual hydrocarbon in the former two types is high, with TOC more than 1.5% generally, Type Ⅰ and Type Ⅱ1 of organic matters, pyrolysis S1 more than 2×10-3, porosity more than 5.5%, mesoporous-macroporous pore size, brittle mineral content more than 50% and good fracturing property, which is the major enrichment pattern of shale oil. Through superposition of main controlling factors of enrichment and evaluation of favorable lithofacies, JYY-1HF well is optimized and deployed in Qian'an enrichment area and 16.4 m3/d of shale oil flow is yielded after fracturing. The shale oil resource of K2qn1 in Changling Sag is estimated to be 35×108 t by pyrolysis S1 method, proving that the southern Songliao Basin has considerable shale oil resource potential.
-
Key words:
- shale oil /
- enrichment characteristics /
- lithofacies type /
- JYY-1HF well /
- Qingshankou Formation /
- Songliao Basin
-
-
[1] 周志, 阎玉萍, 任收麦, 等. 松辽盆地页岩油勘探前景与对策建议[J]. 中国矿业, 2017, 26(3): 171-174. doi: 10.3969/j.issn.1004-4051.2017.03.035
Zhou Z, Yan Y P, Ren S M, et al. Prospects and strategy for shale oil exploration in Songliao Basin, China[J]. China Mining Magazine, 2017, 26(3): 171-174. doi: 10.3969/j.issn.1004-4051.2017.03.035
[2] 张君峰, 许浩, 赵俊龙, 等. 中国东北地区油气地质特征与勘探潜力展望[J]. 中国地质, 2018, 45(2): 260-273. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI201802005.htm
Zhang J F, Xu H, Zhao J L, et al. Geological characteristics and exploration potential of oil and gas in the northeast area of China[J]. Geology in China, 2018, 45(2): 260-273. https://www.cnki.com.cn/Article/CJFDTOTAL-DIZI201802005.htm
[3] 李艳, 张秀颀, 逯晓喻, 等. 松辽盆地上古生界烃源岩特征及有效性分析[J]. 地球科学与环境学报, 2013, 35(4): 39-47. doi: 10.3969/j.issn.1672-6561.2013.04.005
Li Y, Zhang X Q, Lu X Y, et al. Characteristics and validity analysis of hydrocarbon source rocks of Upper Paleozoic in Songliao Basin[J]. Journal of Earth Sciences and Environment, 2013, 35(4): 39-47. doi: 10.3969/j.issn.1672-6561.2013.04.005
[4] 张建深, 郭庆福, 冯子辉. 松辽盆地青一段泥岩生烃、排烃特征与油气藏的形成关系[J]. 大庆石油地质与开发, 1991, 10(1): 6-10. https://www.cnki.com.cn/Article/CJFDTOTAL-DQSK199101002.htm
Zhang J S, Guo Q F, Feng Z H. Relationship between characteristics of hydrocarbon generation & expelling of shale in Qing No. 1 member of Songliao Basin & generation of oil & gas reservoir[J]. Petroleum Geology & Oilfield Development in Daqing, 1991, 10(1): 6-10. https://www.cnki.com.cn/Article/CJFDTOTAL-DQSK199101002.htm
[5] 张金川, 林腊梅, 李玉喜, 等. 页岩油分类与评价[J]. 地学前缘, 2012, 19(5): 322-331. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201205032.htm
Zhang J C, Lin L M, Li Y X, et al. Classification and evaluation of shale oil[J]. Earth Science Frontiers, 2012, 19(5): 322-331. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY201205032.htm
[6] 高瑞祺. 泥岩异常高压带油气的生成排出特征与泥岩裂缝油气藏的形成[J]. 大庆石油地质与开发, 1984, 3(1): 160-167. https://www.cnki.com.cn/Article/CJFDTOTAL-DQSK198401014.htm
Gao R Q. Characteristics of petroleum generation and expulsion in abnormal pressure shale zones and the formation of fractured shale reservoirs[J]. Petroleum Geology & Oilfield Development in Daqing, 1984, 3(1): 160-167. https://www.cnki.com.cn/Article/CJFDTOTAL-DQSK198401014.htm
[7] 李微, 庞雄奇, 赵正福, 等. 松辽盆地青一段常规与非常规油气资源评价[J]. 中国海上油气, 2018, 30(5): 46-54. https://www.cnki.com.cn/Article/CJFDTOTAL-ZHSD201805006.htm
Li W, Pang X Q, Zhao Z F, et al. Evaluation on the conventional and unconventional oil and gas resources in K1qn1 of Songliao Basin[J]. China Offshore Oil and Gas, 2018, 30(5): 46-54. https://www.cnki.com.cn/Article/CJFDTOTAL-ZHSD201805006.htm
[8] 李士超, 张金友, 公繁浩, 等. 松辽盆地北部上白垩统青一段泥岩特征及页岩油有利区优选[J]. 地质通报, 2017, 36(4): 654-663. doi: 10.3969/j.issn.1671-2552.2017.04.019
Li S C, Zhang J Y, Gong F H, et al. The characteristics of mudstones of Upper Cretaceous Qingshankou Formation and favorable area optimization of shale oil in the north of Songliao Basin[J]. Geological Bulletin of China, 2017, 36(4): 654-663. doi: 10.3969/j.issn.1671-2552.2017.04.019
[9] 薛海涛, 田善思, 卢双舫, 等. 页岩油资源定量评价中关键参数的选取与校正——以松辽盆地北部青一段为例[J]. 矿物岩石地球化学通报, 2015, 34(1): 70-78. doi: 10.3969/j.issn.1007-2802.2015.01.008
Xue H T, Tian S S, Lu S F, et al. Selection and verification of key parameters in the quantitative evaluation of shale oil: A case study at the Qingshankou Formation, northern Songliao Basin[J]. Bulletin of Mineralogy, Petrology and Geochemistry, 2015, 34(1): 70-78. doi: 10.3969/j.issn.1007-2802.2015.01.008
[10] 刘和甫, 梁慧社, 李晓清, 等. 中国东部中新生代裂陷盆地与伸展山岭耦合机制[J]. 地学前缘, 2000, 7(4): 477-486. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY200004025.htm
Liu H F, Liang H S, Li X Q, et al. The coupling mechanisms of Mesozoic-Cenozoic rift basins and extensional mountain system in eastern China[J]. Earth Science Frontiers, 2000, 7(4): 477-486. https://www.cnki.com.cn/Article/CJFDTOTAL-DXQY200004025.htm
[11] 郭少斌, 曲永宝, 王树学. 陆相盆地层序及体系域模式——以松辽盆地西部斜坡为例[J]. 地质科技情报, 1998, 17(4): 38-43. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ804.006.htm
Guo S B, Qu Y B, Wang S X. Model of terrestrial basin sequence and system tracts: Taking the western slope of Songliao Basin as an example[J]. Geological Science and Technology Information, 1998, 17(4): 38-43. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ804.006.htm
[12] Feng Z Q, Jia C Z, Xie X N, et al. Tectonostratigraphic units and stratigraphic sequences of the nonmarine Songliao Basin, Northeast China[J]. Basin Research, 2010, 22(1): 79-95. doi: 10.1111/j.1365-2117.2009.00445.x
[13] 侯启军, 冯志强, 冯子辉. 松辽盆地陆相石油地质学[M]. 北京: 石油工业出版社, 2009: 65-88.
Hou Q H, Feng Z Q, Feng Z H. Continental petroleum geology in the Songliao Basin[M]. Beijing: Petroleum Industry Press, 2009: 65-88.
[14] 张文军, 胡望水, 官大勇, 等. 松辽裂陷盆地反转期构造分析[J]. 中国海上油气, 2004, 16(4): 230-234. doi: 10.3969/j.issn.1673-1506.2004.04.003
Zhang W J, Hu W S, Guan D Y, et al. An analysis of tectonic inversion in Songliao Basin[J]. China Offshore Oil and Gas, 2004, 16(4): 230-234. doi: 10.3969/j.issn.1673-1506.2004.04.003
[15] 张君峰, 徐兴友, 白静, 等. 松辽盆地南部白垩系青一段深湖相页岩油富集模式及勘探实践[J]. 石油勘探与开发, 2020, 47(4): 637-652. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK202004002.htm
Zhang J F, Xu X Y, Bai J, et al. Enrichment characteristics and exploration practice of deep lacustrine shale oil in the first member of Qingshankou Formation, southern Songliao Basin, NE China[J]. Petroleum Exploration and Development, 2020, 47(4): 637-652. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK202004002.htm
[16] 卓弘春, 林春明, 李艳丽, 等. 松辽盆地北部上白垩统青山口-姚家组沉积相及层序地层界面特征[J]. 沉积学报, 2007(1): 29-38. doi: 10.3969/j.issn.1000-0550.2007.01.004
Zhuo H C, Lin C M, Li Y L, et al. Characteristics of sedimentary facies and sequence boundary in Upper Cretaceous Qingshankou-Yaojia Formation of northern Songliao Basin[J]. Acta Sedimentologica Sinica, 2007(1): 29-38. doi: 10.3969/j.issn.1000-0550.2007.01.004
[17] 高有峰, 王璞珺, 程日辉, 等. 松科1井南孔白垩系青一段沉积序列精细描述: 岩石地层、沉积相与旋回地层[J]. 地学前缘, 2009, 16(2): 314-323. doi: 10.3321/j.issn:1005-2321.2009.02.023
Gao Y F, Wang P J, Cheng R H, et al. Description of Cretaceous sedimentary sequence of the first member of the Qingshankou Formation recovered by CCSD-SK-Is borehole in Songliao Basin: Lithostratigraphy, sedimentary facies and cyclic stratigraphy[J]. Earth Science Frontiers, 2009, 16(2): 314-323. doi: 10.3321/j.issn:1005-2321.2009.02.023
[18] 孙钰, 孙贺龙. 松辽盆地南部长岭凹陷上白垩统沉积有机相研究[J]. 应用基础与工程科学学报, 2008, 16(4): 537-545. doi: 10.3969/j.issn.1005-0930.2008.04.009
Sun Y, Sun H L. Sedimentary organic facies study of late Cretaceous in Changling Sag of southern Songliao Basin[J]. Journal of Basic Science and Engineering, 2008, 16(4): 537-545. doi: 10.3969/j.issn.1005-0930.2008.04.009
[19] Jarvie D M. Shale resource systems for oil and gas: Part 2-Shale-oil resource systems[C]//Breyer J A. Shale reservoirs-Giant resources for the 21st Century. AAPG Memoir 97, 2012: 89-119.
[20] 柳波, 石佳欣, 付晓飞, 等. 陆相页岩层系岩相特征与页岩油富集条件——以松辽盆地古龙凹陷白垩系青一段富有机质页岩为例[J]. 石油勘探与开发, 2018, 45(5): 828-838. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201805009.htm
Liu B, Shi J X, Fu X F, et al. Petrological characteristics and shale oil enrichment of lacustrine fine-grained sedimentary system: A case study of organic-rich shale in first member of Cretaceous Qingshankou Formation in Gulong Sag, Songliao Basin, NE China[J]. Petroleum Exploration and Development, 2018, 45(5): 828-838. https://www.cnki.com.cn/Article/CJFDTOTAL-SKYK201805009.htm
[21] 柳波, 吕延防, 冉清昌, 等. 松辽盆地北部青山口组页岩油形成地质条件及勘探潜力[J]. 石油与天然气地质, 2014, 35(2): 280-285. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201402019.htm
Liu B, Lü Y F, Ran Q C, et al. Geological conditions and exploration potential of shale oil in Qingshankou Formation, northern Songliao Basin[J]. Oil & Gas Geology, 2014, 35(2): 280-285. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201402019.htm
[22] 李吉君, 史颖琳, 黄振凯, 等. 松辽盆地北部陆相页岩孔隙特征及其对页岩油赋存的影响[J]. 中国石油大学学报(自然科学版), 2015, 39(4): 27-34. doi: 10.3969/j.issn.1673-5005.2015.04.004
Li J J, Shi Y L, Huang Z K, et al. Pore characteristics of continental shale and its impact on storage of shale oil in northern Songliao Basin[J]. Journal of China University of Petroleum (Edition of Natural Science), 2015, 39(4): 27-34. doi: 10.3969/j.issn.1673-5005.2015.04.004
[23] 黄文彪, 邓守伟, 卢双舫, 等. 页岩有机非均质性评价及其在页岩油资源评价中的应用——以松辽盆地南部青一段为例[J]. 石油与天然气地质, 2014, 35(5): 704-711. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201405018.htm
Huang W B, Deng S W, Lu S F, et al. Shale organic heterogeneity evaluation method and its application to shale oil resource evaluation -A case study from Qingshankou Formation, southern Songliao Basin[J]. Oil & Gas Geology, 2014, 35(5): 704-711. https://www.cnki.com.cn/Article/CJFDTOTAL-SYYT201405018.htm
[24] 李士超, 张金友, 公繁浩, 等. 松辽盆地北部青一段一、二段泥岩七性特征及页岩油有利区优选[J]. 地质论评, 2017, 63(S1): 71-72. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP2017S1037.htm
Li S C, Zhang J Y, Gong F H, et al. The seven properties characteristics of mudstone in the first and second member of Upper Cretaceous Qingshankou Formation and favorable area optimization of shale oil in the north of Songliao Basin[J]. Geological Review, 2017, 63(S1): 71-72. https://www.cnki.com.cn/Article/CJFDTOTAL-DZLP2017S1037.htm
[25] 秦梦华, 王中鹏. 松辽盆地长岭坳陷上白垩统页岩油有利区优选及资源潜力[J]. 科学技术与工程, 2014, 14(31): 209-215. doi: 10.3969/j.issn.1671-1815.2014.31.039
Qin M H, Wang Z P. Optimization of the favorable area and analysis of the resource potential for the Upper Cretaceous shale oil in Changling Depression, Songliao Basin[J]. Science Technology and Engineering, 2014, 14(31): 209-215. doi: 10.3969/j.issn.1671-1815.2014.31.039
-
