CHARACTERIZATION OF MICROSCOPIC PORE STRUCTURE IN THGHT SANDSTONE RESERVOIR: A Case Study of Yanchang Formation in Southeastern Ordos Basin
-
摘要:
微观孔喉结构是控制致密砂岩储层储集能力和流体流动的重要因素之一. 选取鄂尔多斯盆地东南部地区晚三叠世延长组致密砂岩储层代表性样品20个, 展开了铸体薄片、扫描电镜、高压压汞及储层岩石物理特征等一系列实验, 运用分形理论研究孔喉结构特征, 并分析了分形维数与物性、孔喉结构参数和矿物含量之间的关系. 研究结果表明: 根据分形曲线可将样品的孔喉结构分为介孔和微孔, 计算出对应的分形维数, 推测介孔贡献了主要的孔隙度和渗透率; 介孔的分形维数与储层物性及孔隙结构各类参数相关性好, 其分形维数越大, 孔隙分布越不均匀, 连通性越差, 非均质性越强; 石英和绿泥石对微孔和介孔虽有支撑作用, 但绿泥石对介孔的堵塞也较为严重; 长石的溶蚀虽然增加了微孔的数量, 但也在一定程度上增加了储层的非均质性.
Abstract:Micro-pore throat structure is one of the important factors controlling the storage capacity and fluid flow of tight sandstone reservoir. Selecting 20 representative samples from tight sandstone reservoir of the Late Triassic Yanchang Formation in southeastern Ordos Basin, the study carries out a series of experiments, including cast thin section, scanning electron microscope, high pressure mercury injection and reservoir petrophysical test, applying fractal theory to realize the characteristics of pore throat structure, and analyzes the relationship between fractal dimensions and physical properties, pore throat structure parameters and mineral content. The results show that the pore throat structure of the samples can be divided into mesopore and micropore according to fractal curves. Based on the calculated corresponding fractal dimension, it is inferred that the mesopore contributes to most of the porosity and permeability. The fractal dimension of mesopore has good correlation with the parameters of reservoir physical properties and pore structure. The larger the fractal dimension is, the more uneven the pore distribution is, with worse connectivity and more heterogeneity. Despite the support of quartz and chlorite to micropore and mesopore, chlorite could anyway cause severe mesopore blockage. The dissolution of feldspar increases the number of micropores, meanwhile increases the heterogeneity of reservoir to a certain extent.
-
Key words:
- pore throat structure /
- tight sandstone /
- heterogeneity /
- fractal theory /
- Yanchang Formation /
- Ordos Basin
-
-
表 1 孔隙度频率分布和渗透率频率分布
Table 1. Distribution frequency of porosity and permeability
样品编号 孔隙度贡献率/% 渗透率贡献率/% 介孔 微孔 介孔 微孔 N1 85 15 99.99 0.01 N2 78 22 99.84 0.16 N3 54 46 99.75 0.25 N4 64 36 99.75 0.25 N5 64 35 99.93 0.07
下载: 导出CSV
表 2 分形维数计算结果
Table 2. Calculation results of fractal dimensions
样品编号 大孔 微孔 D1 R2 φ1/% K1 D2 R2 φ2/% K2 N1 2.69 0.9977 8.23 0.9999 2.47 0.9829 1.39 0.0001 N2 2.61 0.9747 2.74 0.9984 2.36 0.9938 0.76 0.0016 N3 2.81 0.9697 4.80 0.9975 2.24 0.9901 4.08 0.0025 N4 2.72 0.9885 4.21 0.9975 2.40 0.9909 2.29 0.0025 N5 2.80 0.9330 4.50 0.9993 2.23 0.9820 2.50 0.0007
下载: 导出CSV
-
