Experimental Study on Iron Recovery from Flotation Tailings of Donganshan Iron Ore by Combined Magnetic Separation and Flotation Process
-
摘要:
东鞍山烧结厂浮选尾矿TFe品位为22.82%，FeO含量为9.87%，SiO2的含量为51.24%，S和P含量较低，均为0.03%，属于低硫、低磷、高硅型铁尾矿。此外，该尾矿-0.038 mm粒级含量高达56.44%，同时铁矿物主要集中在该粒级中，铁分布率达到67.62%。为了实现该铁尾矿的高效回收利用，本试验采用搅拌磨磨矿—弱磁选—强磁粗选—强磁精选—反浮选流程开展了系统的试验研究。结果表明：在搅拌磨磨矿细度为−0.038 mm占95%、弱磁选磁感应强度95 kA/m、强磁粗选磁场磁感应强度796 kA/m、强磁精选磁场磁感应强度398 kA/m的条件下，可获得TFe品位为38.20%、TFe回收率为63.51%的混合磁选精矿指标；将混合磁选精矿在矿浆温度40 ℃、矿浆pH值为11.5、淀粉用量1000 g/t、CaO用量900 g/t、粗选捕收剂TD-2用量600 g/t、一次精选捕收剂TD-2用量为300 g/t、二次精选捕收剂TD-2用量为300 g/t的条件下进行反浮选，闭路试验可获得TFe品位为62.34%、TFe作业回收率为55.10%的浮选精矿。全流程TFe回收率为35.00%，综合尾矿TFe品位为17.01%。试验结果可为东鞍山浮选尾矿中的铁矿物高效选矿回收提供指导。
Abstract:The flotation tailings of the Donganshan sintering plant contain 22.82% Fe, 9.87% FeO, 51.24% SiO2 and a low S and P content of 0.03%, which belongs to low sulphur, low phosphorus and high silicon type iron tailings. In addition, the tailings contain 56.44% of the −0.038 mm particles. Also, the distribution of iron minerals in this size-level was 67.62%. In order to achieve efficient recovery of iron from this tailings, a systematic experimental study was carried out in this experiment using the process of stirred mill grinding - low intensity magnetic - high magnetic roughing - high magnetic selection - reverse flotation. The results showed that a mixed magnetic separation concentrate with a TFe grade of 38.20% and a TFe recovery of 63.51% was obtained at a fineness of −0.038 mm (95%), a magnetic induction of 95 kA/m for the low magnetic separation, high intensity magnetic field strength of 796 kA/m for roughing magnetic separation and high intensity magnetic field strength of 398 kA/m for cleaning magnetic separation. The appropriate reverse flotation conditions for mixed magnetic concentrates were pulp temperature 40 ℃, pulp pH 11.5, starch dosage of 1000 g/t, CaO dosage of 900 g/t, rougher collector TD-2 dosage of 600 g/t, primary cleaning collector dosage of 300 g/t and secondary cleaning collector dosage of 300 g/t. The flotation concentrate with iron grade of 62.34% and iron recovery of 55.10% was obtained by closed-circuit test. The continuous test for complete flow were carried out, the iron concentrate with iron grade of 62.43% and iron recovery of 35.00% was obtained, and the iron grade of comprehensive tailings was 17.01%. The test results can provide guidance for the high-efficiency beneficiation and recovery of iron minerals in the flotation tailings of Donganshan.
-
Key words:
- Donganshan iron tailings /
- magnetic separation /
- flotation /
- stirring mill
-
-
表 1 化学多元素分析结果
Table 1. Results of chemical multi-element analysis of minerals
/% 元素 TFe FeO SiO2 Al2O3 CaO MgO S P 烧失 含量 22.82 9.87 51.24 0.73 1.56 1.74 0.03 0.03 5.88
下载: 导出CSV
表 2 尾矿粒度分析结果
Table 2. Particle size analysis of tailings
/% 粒级/mm 产率 负累计
产率TFe
品位TFe
分布率负累计
TFe分布率+0.425 0.05 100.00 9.48 0.03 100.00 −0.425+0.150 0.30 99.95 9.68 0.12 99.97 −0.150+0.100 3.96 99.66 10.60 1.83 99.85 −0.100+0.074 9.62 95.69 13.09 5.49 98.02 −0.074+0.043 15.91 86.08 17.19 11.94 92.53 −0.043+0.038 13.73 70.17 21.64 12.97 80.59 −0.038 56.43 56.44 27.45 67.62 67.62 合计 100.00 — 22.91 100.00 —
下载: 导出CSV
表 3 主要磁选设备型号
Table 3. The main magnetic separation equipment
设备名称 设备型号 生产厂家 滚筒磁选机 RK/CRSΦ400×300 武汉洛克制造
有限公司永磁筒式磁选机 GHC-46 北方重工沈矿集团
有限责任公司立式感应湿式强磁选机 LOe-500 沈阳隆基电磁科技
有限公司立式感应湿式强磁选机 LOe-1000 沈阳隆基电磁科技
有限公司
下载: 导出CSV
表 4 闭路浮选试验结果
Table 4. Results of closed-circuit flotation
产品名称 作业产率/% TFe品位/% TFe回收率/% 浮选精矿 33.71 62.43 55.10 浮选尾矿 66.29 25.87 44.90 合计 100.00 38.20 100.00
下载: 导出CSV
表 5 全流程试验结果
Table 5. Results of closed circuit test
产品名称 作业产率/% TFe品位/% TFe回收率/% 精矿 12.79 62.43 35.00 尾矿 87.21 17.01 65.00 合计 100.00 22.82 100.00
下载: 导出CSV
-
[1] 杨光, 苏兴国, 马自飞, 等. 东鞍山贫杂铁矿石选矿技术研究进展[J]. 矿产保护与利用, 2021, 41(5): 140−148. doi: 10.13779/j.cnki.issn1001-0076.2021.05.020
YANG G, SU X G, MA Z F, et al. Research status and development trend of beneficiation technology for Donganshan iron ore with low grade and complex composition[J]. Conservation and Utilization of Mineral Resources, 2021, 41(5): 140−148. doi: 10.13779/j.cnki.issn1001-0076.2021.05.020
[2] 宋长春, 傅国辉, 李子豪, 等. 齐大山富铁矿石混磁精矿的新型捕收剂浮选试验[J]. 现代矿业, 2022, 38(4): 23−25. doi: 10.3969/j.issn.1674-6082.2022.04.007
SONG C C, FU G H, LI Z H, et al. Flotation test of mixed magnetic concentrate of rich iron ore in Qidashan using new collector[J]. Modern Mining, 2022, 38(4): 23−25. doi: 10.3969/j.issn.1674-6082.2022.04.007
[3] 高鹏, 余建文, 张淑敏, 等. 东鞍山铁矿混磁精矿悬浮焙烧—弱磁选试验研究[J]. 金属矿山, 2016(12): 18−21. doi: 10.3969/j.issn.1001-1250.2016.12.005
GAO P, YU J W, ZHANG S M, et al. Experimental study on suspension roasting - low intensity magnetic separation of magnetic mixed concentrate from Donganshan[J]. Metal Mine, 2016(12): 18−21. doi: 10.3969/j.issn.1001-1250.2016.12.005
[4] 韩跃新, 孙永升, 李艳军, 等. 我国铁矿选矿技术最新进展[J]. 金属矿山, 2015(2): 1−11.
HAN Y X, SUN Y S, LI Y J, et al. New development on mineral processing technology of iron ore resources in China[J]. Metal Mine, 2015(2): 1−11.
[5] 韩跃新, 高鹏, 李艳军, 等. 我国铁矿资源“劣质能用、优质优用”发展战略研究[J]. 金属矿山, 2016(12): 2−8. doi: 10.3969/j.issn.1001-1250.2016.12.002
HAN Y X, GAO P, LI Y J, et al. Development strategies of available use of inferior quality and optimal use of high quality for domestic iron ore resources[J]. Metal Mine, 2016(12): 2−8. doi: 10.3969/j.issn.1001-1250.2016.12.002
[6] 李文博, 唐志东, 杨光, 等. 东鞍山含碳酸盐正浮选尾矿悬浮焙烧—弱磁选试验[J]. 金属矿山, 2016(12): 13−17.
LI W B, TANG Z D, YANG G, et al. Research on suspension roasting - low intensity magnetic separation of Donganshan direct-flotation tailings containing carbonate[J]. Metal Mine, 2016(12): 13−17.
[7] 周立波, 李文博, 徐瑞清, 等. 鞍钢东部尾矿资源特征及磁选预富集工艺研究[J]. 金属矿山, 2018(11): 176−180.
ZHOU L B, LI W B, XU R Q, et al. Study on resources process mineralogy and magnetic pre-concentration of eastern tailings in Ansteel[J]. Metal Mine, 2018(11): 176−180.
[8] 程绍凯, 李文博, 韩跃新. 东鞍山浮选尾矿预富集—磁化焙烧—磁选试验研究[J]. 金属矿山, 2021(5): 91−95.
CHENG S K, LI W B, HAN Y X. Experimental study on preconcentration followed by magnetization roasting and low intensity magnetic separation for Donganshan flotation tailings[J]. Metal Mine, 2021(5): 91−95.
[9] 马崇振. 用重选—磁选—反浮选法回收鞍山某尾矿中的铁[J]. 矿产保护与利用, 2021, 41(5): 111−117.
MA C Z. Recovery of iron from a tailing in Anshan by gravity concentration - magnetic separation - reverse flotation[J]. Conservation and Utilization of Mineral Resources, 2021, 41(5): 111−117.
[10] 范喜杰, 韦文杰, 徐冬林, 等. 鞍千预选混磁精矿搅拌磨细磨—磁选—反浮选工艺研究[J]. 矿产保护与利用, 2022, 42(2): 144−151.
FAN X J, WEI W J, XU D L, et al. Research on stirring grinding - magnetic separation - reverse flotation process of preconcentration mixed magnetic moncentrate in Anqian[J]. Conservation and Utilization of Mineral Resources, 2022, 42(2): 144−151.
[11] 杨光, 马自飞, 杨会利, 等. 东鞍山铁矿石高效分选新技术研究[J]. 金属矿山, 2021(8): 88−94.
YANG G, MA Z F, YANG H L, et al. Research on innovative technology of high efficiency separation of Donganshan iron ore[J]. Metal Mine, 2021(8): 88−94.
[12] 王建雄, 张淑敏, 李艳军, 等. 鞍山某铁矿石磁选—反浮选试验研究[J]. 矿产保护与利用, 2021, 41(3): 150−154.
WANG J X, ZHANG S M, LI Y J, et al. Study on magnetic separation - reverse flotation tests of the iron ore from Anshan[J]. Conservation and Utilization of Mineral Resources, 2021, 41(3): 150−154.
-
