298.2 K四元体系MgCl2+CaCl2+AlCl3+H2O 相平衡研究

何志意; 方滇东; 郑秋风; 任思颖; 罗军; 于旭东

doi:10.13779/j.cnki.issn1001-0076.2022.06.018

298.2 K四元体系MgCl₂+CaCl₂+AlCl₃+H₂O 相平衡研究

1.
四川省冶勘设计集团有限公司, 四川成都 610051

2.
成都理工大学材料与化学化工学院, 四川成都 610059

详细信息

作者简介: 何志意（1989—）,女,硕士,工程师,研究方向为分析检测；E-mail：2298049880@qq.com

通讯作者: 于旭东（1985—）,男,博士,副教授,研究方向为相平衡与相分离技术；E-mail：xwdlyxd@126.com。

中图分类号: TF111.3

收稿日期: 2022-10-16

刊出日期: 2022-12-26

Phase Equilibria of Aqueous Quaternary System MgCl₂+CaCl₂+AlCl₃+H₂O at 298.2 K

1.
Sichuan Metallurgical Geological Survey and Design Group Co., Ltd, Chengdu 610051, China

2.
College of Materials and Chemistry & Chemical Engineering, Chengdu University of Technology, Chengdu 610059, China

More Information

Corresponding author: YU Xudong, xwdlyxd@126.com

Received Date: 16 October 2022

Publish Date: 26 December 2022

摘要

摘要:
为获取粉煤灰含铝溶浸液中铝与共存钙、镁之间的作用规律，采用等温溶解平衡法开展了298.2 K时四元体系MgCl₂+CaCl₂+AlCl₃+H₂O相平衡研究，测定了平衡液相组成及平衡液相密度，同时，绘制了该四元体系的干基相图、水图、密度-组成图。研究发现：298.2 K四元体系MgCl₂+CaCl₂+AlCl₃+H₂O 稳定相图由2个共饱点、4个结晶区以及5条单变量曲线组成，有复盐溢晶石（2MgCl₂·CaCl₂·12H₂O）生成，为复杂四元体系。4个结晶区分别对应3个单盐结晶区MgCl₂·6H₂O、CaCl₂·6H₂O、AlCl₃·6H₂O和1个复盐结晶区2MgCl₂·CaCl₂·12H₂O，结晶区按照AlCl₃·6H₂O、MgCl₂·6H₂O、CaCl₂·6H₂O、2MgCl₂·CaCl₂·12H₂O顺序依次减小，对应AlCl₃·6H₂O溶解度最小，2MgCl₂·CaCl₂·12H₂O溶解度最大。
- 相平衡 /
- 四元体系MgCl₂+CaCl₂+AlCl₃+H₂O /
- 溶解度 /
- 溢晶石
Abstract:
In order to obtain the interaction law between aluminum and coexisting calcium and magnesium in leaching solution containing aluminum of fly ash, the phase equilibria of the quaternary system MgCl₂+CaCl₂+AlCl₃+H₂O was investigated by isothermal dissolution method at 298.2 K. The composition of liquid phase and density were determined. Meanwhile, the phase diagram, water diagram and density vs composition diagram of the quaternary system were drawn, respectively. It was found that the stable phase diagram of the quaternary system MgCl₂+CaCl₂+AlCl₃+H₂O consisted of two invariant points, four crystallization regions and five univariate curves, which belonged to a complex system with the double salt of tachyhydrite formed. These four crystallization regions corresponded to single salts MgCl₂·6H₂O, CaCl₂·6H₂O, AlCl₃·6H₂O and double salt 2MgCl₂·CaCl₂·12H₂O, respectively. The crystallization regions decreaseed in the order of AlCl₃·6H₂O, MgCl₂·6H₂O, CaCl₂·6H₂O and 2MgCl₂·CaCl₂·12H₂O, the solubility of AlCl₃·6H₂O was the smallest and the solubility of 2MgCl₂·CaCl₂·12H₂O is the highest.
- phase equilibria /
- quaternary system /
- solubility /
- tachyhydrite

HTML全文

图 1 298.2 K四元体系MgCl₂+CaCl₂+AlCl₃+H₂O 稳定相图

Figure 1.

下载: 全尺寸图片幻灯片

图 2 298.2 K四元体系MgCl₂+CaCl₂+AlCl₃+H₂O 共饱点F₁处平衡固相XRD谱图

Figure 2.

下载: 全尺寸图片幻灯片

图 3 298.2 K四元体系MgCl₂+CaCl₂+AlCl₃+H₂O 共饱点F₂处平衡固相XRD谱图

Figure 3.

下载: 全尺寸图片幻灯片

图 4 298.2 K四元体系MgCl₂+CaCl₂+AlCl₃+H₂O 水含量−组成图

Figure 4.

下载: 全尺寸图片幻灯片

图 5 298.2 K四元体系MgCl₂+CaCl₂+AlCl₃+H₂O 密度−组成图

Figure 5.

下载: 全尺寸图片幻灯片

表 1 298.2 K四元体系MgCl₂+CaCl₂+AlCl₃+H₂O 平衡溶液的溶解度和密度

Table 1. The solubilities and densities of the quaternary system MgCl₂+CaCl₂+AlCl₃+H₂O at 298.2 K

编号	密度/(g·cm⁻³)	液相组成, w(B) /%					干盐指数 J(B) (g/100g S)				平衡固相
		液相组成, w(B) /%				J(MgCl₂)+J(CaCl₂)+J(AlCl₃)=100
		w(MgCl₂)	w(CaCl₂)	w(AlCl₃)	w(H₂O)		J(MgCl₂)	J(CaCl₂)	J(AlCl₃)	J(H₂O)
1, A	1.4415	10.20	35.03	0.00	54.77		22.55	77.45	0.00	121.09	CaCl₂·6H₂O+Tac
2	1.4419	8.99	36.00	0.22	54.78		19.89	79.62	0.50	121.15	CaCl₂·6H₂O+Tac
3	1.4435	8.39	36.39	0.40	54.82		18.58	80.54	0.89	121.33	CaCl₂·6H₂O+Tac
4	1.4439	7.42	37.16	0.53	54.89		16.45	82.37	1.18	121.67	CaCl₂·6H₂O+Tac
5	1.4442	6.65	37.85	0.59	54.91		14.75	83.94	1.31	121.77	CaCl₂·6H₂O+Tac
6	1.4462	5.61	38.82	0.68	54.90		12.43	86.07	1.50	121.73	CaCl₂·6H₂O+Tac
7, F₁	1.4477	4.03	39.59	1.42	54.96		8.95	87.90	3.15	121.99	CaCl₂·6H₂O+AlCl₃·6H₂O+Tac
8	1.4285	5.63	38.21	1.25	54.91		12.48	84.74	2.78	121.76	AlCl₃·6H₂O+Tac
9	1.4163	8.56	34.71	1.41	55.32		19.16	77.69	3.15	123.84	AlCl₃·6H₂O+Tac
10	1.4150	9.41	33.95	1.30	55.34		21.06	76.02	2.92	123.9	AlCl₃·6H₂O+Tac
11	1.4132	11.30	32.46	1.05	55.19		25.22	72.43	2.35	123.16	AlCl₃·6H₂O+Tac
12	1.4134	12.24	31.58	0.97	55.21		27.33	70.51	2.16	123.26	AlCl₃·6H₂O+Tac
13, F₂	1.4171	13.97	29.20	0.71	56.12		31.84	66.54	1.62	127.92	MgCl₂·6H₂O+AlCl₃·6H₂O+Tac
14	1.4172	13.39	29.81	0.65	56.15		30.54	67.98	1.48	128.02	MgCl₂·6H₂O+Tac
15	1.4170	14.44	28.84	0.54	56.18		32.95	65.81	1.24	128.20	MgCl₂·6H₂O+Tac
16	1.4167	14.96	28.43	0.40	56.22		34.17	64.93	0.90	128.41	MgCl₂·6H₂O+Tac
17	1.4162	16.08	27.60	0.10	56.22		36.72	63.04	0.23	128.44	MgCl₂·6H₂O+Tac
18	1.4158	16.65	27.08	0.04	56.24		38.04	61.88	0.09	128.50	MgCl₂·6H₂O+Tac
19, B	1.4163	17.27	26.48	0.00	56.25		39.47	60.53	0.00	128.57	MgCl₂·6H₂O+Tac
20, C	1.3403	30.45	0.00	5.65	63.90		84.35	0.00	15.65	177.01	MgCl₂·6H₂O+AlCl₃·6H₂O
21	1.3436	28.36	2.85	4.91	63.88		78.52	7.89	13.59	176.88	MgCl₂·6H₂O+AlCl₃·6H₂O
22	1.3450	27.03	6.05	3.97	62.95		72.96	16.32	10.72	169.92	MgCl₂·6H₂O+AlCl₃·6H₂O
23	1.3513	24.75	10.48	3.18	61.59		64.42	27.29	8.29	160.29	MgCl₂·6H₂O+AlCl₃·6H₂O
24	1.3679	23.42	13.81	2.42	60.35		59.07	34.82	6.11	152.17	MgCl₂·6H₂O+AlCl₃·6H₂O
25	1.3797	21.03	18.04	1.65	59.28		51.64	44.31	4.05	145.58	MgCl₂·6H₂O+AlCl₃·6H₂O
26	1.3911	18.25	22.03	1.16	58.56		44.04	53.16	2.80	141.32	MgCl₂·6H₂O+AlCl₃·6H₂O
27	1.4048	15.67	26.38	1.05	56.90		36.37	61.20	2.43	132.04	MgCl₂·6H₂O+AlCl₃·6H₂O
28, D	1.4436	0.00	42.32	2.37	55.31		0.00	94.70	5.30	123.76	CaCl₂·6H₂O+AlCl₃·6H₂O
29	1.4431	0.84	42.29	2.06	54.81		1.85	93.58	4.57	121.29	CaCl₂·6H₂O+AlCl₃·6H₂O
30	1.4446	1.58	42.20	1.74	54.48		3.46	92.71	3.82	119.68	CaCl₂·6H₂O+AlCl₃·6H₂O
31	1.4450	2.21	41.99	1.59	54.21		4.83	91.69	3.48	118.37	CaCl₂·6H₂O+AlCl₃·6H₂O
注：Tac为2MgCl₂·CaCl₂·12H₂O。温度、密度的标准不确定度分别为0.2 K、0.0002 g/cm³; w(MgCl₂)、w(CaCl₂)及w(AlCl₃)的相对不确定度分别为0.0021、 0.0030、0.0026。

下载: 导出CSV
