摘要:
白云石是低品质菱镁矿中主要的含钙杂质，但是白云石与菱镁矿的晶体结构相似、组成相近，导致钙镁矿物浮选分离困难。开发新型高效脱钙捕收剂是提高白云石与菱镁矿分离效率的主要手段。基于此，探索性地将十二烷基硫酸钠（SDS）作为白云石的捕收剂进行钙镁分离，考察了矿浆pH值、SDS浓度以及可溶性离子Ca2+、Mg2+和Fe3+对菱镁矿与白云石浮选性能的影响，结果表明：在SDS浓度为20×10−5 mol/L、矿浆pH值为10时，白云石与菱镁矿有较好的浮选分离效果。Ca2+和Mg2+对菱镁矿与白云石均有抑制作用，对两种矿的浮选性差异影响较小。Fe3+对白云石的抑制作用较小，对菱镁矿的抑制作用较大，有利于两种矿的浮选分离。FTIR与Zeta电位结果表明，SDS在白云石表面的吸附量远远大于在菱镁矿表面的吸附量，且Fe3+可以促进SDS在白云石表面的吸附，抑制SDS在菱镁矿表面的吸附，从而增大白云石与菱镁矿间的可浮性差异。
Abstract:Dolomite is the main calcium-containing impurity of low quality magnesite ore. However, the similar crystal structure and composition resulted in the difficult flotation separation of dolomite and magnesite. Developing novel and efficient collectors is the main means to improve the separation efficiency of magnesite and dolomite. Based on this, sodium dodecyl sulfate (SDS) was used as the collector of dolomite. The effects of slurry pH value, collector concentration and soluble ions of Ca2+, Mg2+ and Fe3+ on the flotation performance of magnesite and dolomite were investigated. The results showed that a better flotation separation result was obtained when the SDS concentration was 20×10−5 mol/L and pulp was 10. The ions of Ca2+ and Mg2+ could simultaneously inhibit the flotation of magnesite and dolomite, which had little effect on the flotation difference of the two minerals. The inhibitory of Fe3+ on dolomite was weaker than that of magnesite, which was conducive to the flotation separation. The FTIR and Zeta potential results indicated that the adsorption capacity of SDS on the dolomite surface was much greater than that on the magnesite surface, and Fe3+ could promote the SDS adsorption on the dolomite surface and inhibit the SDS adsorption on the magnesite surface, thus increasing the flotation difference between dolomite and magnesite.
-
Key words:
- sodium dodecyl sulfate /
- magnesite /
- dolomite /
- metal ions /
- inhibition
-
-
表 1 菱镁矿与白云石的主要化学成分分析
Table 1. Analysis of the main chemical composition of magnesite and dolomite
/% 组分 MgO CaO SiO2 Fe2O3 菱镁矿 45.75 1.08 0.19 — 白云石 20.35 32.48 2.08 0.38
下载: 导出CSV
-
[1] 钟文兴, 印万忠, 姚金, 等. 聚丙烯酸在细粒菱镁矿反浮选中的选择性抑制作用[J]. 金属矿山, 2021(2): 96−102.
ZHONG W X, YIN W Z, YAO J, et al. Selective depressing effect of polyacrylic acid in fine magnesite reverse flotation[J]. Metal Mine, 2021(2): 96−102.
[2] 朱阳戈, 杨林峰, 胡晓星, 等. 以羧甲基纤维素为抑制剂浮选分离石英和菱镁矿[J]. 中国有色金属学报(英文版), 2022, 32(5): 1623−1637. doi: 10.1016/S1003-6326(22)65898-9
ZHU Y G, YANG L F, HU X X, et al. Flotation separation of quartz from magnesite using carboxymethyl cellulose as depressant[J]. Transactions of Nonferrous Metals Society of China, 2022, 32(5): 1623−1637. doi: 10.1016/S1003-6326(22)65898-9
[3] ZHAO P X, LIU W B , LIU W G, et al. Efficient separation of magnesite and quartz using eco-friendly dimethylaminopropyl lauramide experimental and mechanistic studies[J]. Minerals Engineering, 2022, 188: 107814.
[4] 孙文瀚, 刘文刚, 杨婷, 等. TX-100对油酸钠体系下菱镁矿与白云石浮选分离的影响[J]. 东北大学学报(自然科学版), 2021, 42(2): 226−231. doi: 10.12068/j.issn.1005-3026.2021.02.012
SUN W H, LIU W G, YANG T, et al. Effect of TX-100 on flotation separation of magnesite and dolomite in sodium oleate system[J]. Journal of Northeastern University (Natural Science Edition), 2021, 42(2): 226−231. doi: 10.12068/j.issn.1005-3026.2021.02.012
[5] 张兴业. 提高我国菱镁矿资源利用率的途径[J]. 矿产保护与利用, 2008(4): 23−25.
ZHANG X Y. Ways to improve the utilization rate of magnesite resources in our country[J]. Conservation and Utilization of Mineral Resources, 2008(4): 23−25.
[6] 杨俊峰, 余跃, 王曦. 我国菱镁矿业绿色高质量发展对策研究[J]. 中国矿山工程, 2022, 51(4): 25−28.
YANG J F, YU Y, WANG X. Research on green and high quality development countermeasures of magnesite mining in China[J]. China Mine Engineering, 2022, 51(4): 25−28.
[7] 朱一民, 马玉宁, 杨雪莹, 等. 新型捕收剂DXY对石英的浮选及泡沫性能研究[J]. 金属矿山, 2022(10): 95−100.
ZHU Y M, MA Y N, YANG X Y, et al. Study on flotation and foam performance of quartz with new collector DXY[J]. Metal Mine, 2022(10): 95−100.
[8] 董庆国, 白阳, 吴清峰, 等. 辽宁某低品位菱镁矿浮选除杂试验研究[J]. 非金属矿, 2018, 41(3): 100−102. doi: 10.3969/j.issn.1000-8098.2018.03.033
DONG Q G, BAI Y, WU Q F, et al. Experimental study on impurity removal by flotation of a low grade magnesite in Liaoning[J]. Non-metallic Mines, 2018, 41(3): 100−102. doi: 10.3969/j.issn.1000-8098.2018.03.033
[9] 胡晓星, 朱阳戈, 吕建业, 等. 六偏磷酸钠对菱镁矿与白云石浮选分离动力学的影响[J]. 有色金属工程, 2020, 10(9): 72−78+97.
HU X X, ZHU Y G, LV J Y, et al. Effect of sodium hempetaphosphate on flotation separation kinetics of magnesite and dolomite[J]. Nonferrous Metals Engineering, 2020, 10(9): 72−78+97.
[10] 胡晓星, 朱阳戈, 郑桂兵, 等. BK434在某低品位菱镁矿正浮选降钙中的应用[J]. 矿业研究与开发, 2016, 36(9): 24−26.
HU X X, ZHU Y G, ZHENG G B, et al. Application of BK434 in calcium reduction by direct flotation of a low-grade magnesite[J]. Mining Research and Development, 2016, 36(9): 24−26.
[11] 李彩霞, 刘高全, 白阳, 等. 油酸钠体系中菱镁矿-白云石浮选试验研究[J]. 非金属矿, 2018, 41(4): 77−79. doi: 10.3969/j.issn.1000-8098.2018.04.024
LI C X, LIU G Q, BAI Y, et al. Experimental study on flotation of magnesite and dolomite in sodium oleate system[J]. Non-metallic Mines, 2018, 41(4): 77−79. doi: 10.3969/j.issn.1000-8098.2018.04.024
[12] 李彩霞, 刘高全, 白阳, 等. 抑制剂对菱镁矿与白云石分离影响研究[J]. 非金属矿, 2019, 42(1): 70−72. doi: 10.3969/j.issn.1000-8098.2019.01.021
LI C X, LIU G Q, BAI Y, et al. Study on the effect of inhibitors on the separation of magnesite and dolomite[J]. Non-metallic Mines, 2019, 42(1): 70−72. doi: 10.3969/j.issn.1000-8098.2019.01.021
[13] 罗娜, 魏德洲, 李明阳, 等. 白云石对菱镁矿浮选行为的影响[J]. 东北大学学报(自然科学版), 2017, 38(7): 1007−1011. doi: 10.12068/j.issn.1005-3026.2017.07.020
LUO N, WEI D Z, LI M Y, et al. Influence of dolomite on flotation behavior of magnesite[J]. Journal of Northeastern University (Natural Science), 2017, 38(7): 1007−1011. doi: 10.12068/j.issn.1005-3026.2017.07.020
[14] 谭欣, 苏建芳, 朱阳戈, 等. 辽宁某低品位菱镁矿提质降杂试验研究与工业实践[J]. 矿产保护与利用, 2018(1): 54−60.
TAN X, SU J F, ZHU Y G, et al. Experimental study and industrial practice on quality improvement and impurity reduction of a low-grade magnesite in Liaoning[J]. Conservation and Utilization of Mineral Resources, 2018(1): 54−60.
[15] QIN W Q, HU J J, ZHU H L, et al. Effect of depressants on flotation separation of magnesite from dolomite and calcite[J]. International Journal of Mining Science and Technology, 2023, 33(1): 83−91. doi: 10.1016/j.ijmst.2022.09.018
[16] SUN W, LIU W G, DAI S, et al. Effect of Tween 80 on flotation separation of magnesite and dolomite using NaOL as the collector [J]. Journal of Molecular Liquids, 2020, 315(prepublish).
[17] YIN W Z, TANG Y. Interactive effect of minerals on complex ore flotation: A brief review[J]. International journal of minerals metallurgy materials, 2020, 27(5): 571−583. doi: 10.1007/s12613-020-1999-y
[18] 刘文刚, 姚广铮, 卢位, 等. 十二胺体系中金属离子对菱镁矿和白云石浮选行为的影响[J]. 矿产保护与利用, 2018(3): 67−70+76.
LIU W G, YAO G Z, LU W, et al. Effect of metal ions on flotation behavior of magnesite and dolomite in dodecylamine system[J]. Conservation and Utilization of Mineral Resources, 2018(3): 67−70+76.
[19] 袁世泉, 张洪恩. 菱镁矿、白云石表面电性研究[J]. 矿冶工程, 1990(4): 19−23+36.
YUAN S Q, ZHANG H E. Study on surface electrical properties of magnesite and dolomite[J]. Mining and Metallurgy Engineering, 1990(4): 19−23+36.
[20] 李强, 孙明俊, 印万忠, 等. 菱镁矿浮选特性研究[J]. 金属矿山, 2010(11): 91−94+188.
LI Q, SUN M J, YIN W Z, et al. Research on flotation characteristics of magnesite[J]. Metal Mine, 2010(11): 91−94+188.
[21] 刘秉锋, 郭小飞, 代淑娟, 等. 金属离子对菱镁矿浮选体系的影响研究进展[J]. 金属矿山, 2020(12): 136−142.
LIU B F, GUO X F, DAI S J, et al. Research progress of influence of metal ions on flotation system of magnesite[J]. Metal Mine, 2020(12): 136−142.
[22] 张作金, 代淑娟, 韩佳宏, 等. 菱镁矿浮选体系中金属离子对脉石矿物可浮性影响研究进展[J]. 矿产保护与利用, 2019, 39(2): 118−123.
ZHANG Z J, DAI S J, HAN J H, et al. Research progress on effect of metal ions on gangue minerals floatability in magnesite flotation system[J]. Conservation and Utilization of Mineral Resources, 2019, 39(2): 118−123.
[23] 张孟, 代淑娟, 马芳源, 等. 钙、镁离子对菱镁矿与白云石浮选行为的影响[J]. 非金属矿, 2015, 38(5): 50−53.
ZHANG M, DAI S J, MA F Y, et al. Effect of calcium and magnesium ions on flotation behavior of magnesite and dolomite[J]. Non-metallic Ores, 2015, 38(5): 50−53.
[24] SUN K, LIU T, ZHANG Y M, et al. Application and mechanism of anionic collector sodium dodecyl sulfate (SDS) in phosphate beneficiation [J]. Minerals, 2017, 7(2).
[25] EL-MIDANY A A, ARAFAT Y. Enhancing phosphate grade using oleic acid-sodium dodecyl sulfate mixtures[J]. Chemical Engineering Communications, 2016, 203(5): 660−665. doi: 10.1080/00986445.2015.1078797
[26] LIU L, TIAN M, DENG X, et al. The removal of dolomite from collophane using reverse flotation process enhanced by compound collector[J]. Physicochemical Problems of Mineral Processing, 2023, 59(1).
[27] 孙浩然, 印万忠, 唐远, 等. 菱镁矿及其主要伴生矿物白云石的浮选动力学研究[J]. 矿产保护与利用, 2019, 39(1): 10−16.
SUN H R, YIN W Z, TANG Y, et al. Study on flotation kinetics of magnesite and its main associated mineral dolomite[J]. Conservation and Utilization of Mineral Resources, 2019, 39(1): 10−16.
[28] 王雪, 黎艳, 王晓军, 等. Fe3+、Fe2+对白云石、高岭土、石英浮选行为的影响研究[C]//2017年中国非金属矿科技与市场交流大会, 2017: 174-180.
WANG X, LI Y, WANG X J, et al. Study on the influence of Fe3+ and Fe2+ on the flotation behavior of dolomite, kaolin and quartz[C]//2017 China Non-metallic Ore Technology and Market Exchange Conference, 2017: 174-180.
[29] 班小淇, 顾畔, 印万忠, 等. 菱镁矿浮选体系中Fe3+对白云石的选择性活化及机理分析[J]. 矿产综合利用, 2022(5): 125−129.
BAN X Q, GU P, YIN W Z, et al. Selective activation of dolomite by Fe3+ in magnesite flotation system and its mechanism analysis[J]. Comprehensive Utilization of Mineral Resources, 2022(5): 125−129.
[30] GAO X D, CHOROVER J. Adsorption of sodium dodecyl sulfate (SDS) at ZnSe and α-Fe2O3 surfaces: combining infrared spectroscopy and batch uptake studies [J]. Journal of Colloid and Interface Science, 2010, 348(1).
[31] SUN W H, LIU W G, LIU W B, et al. Utilization of a novel bisphosphonic acid surfactant for reverse froth flotation of magnesite and dolomite[J]. Minerals Engineering, 2022, 185.
[32] 宋振国. 几种金属阳离子对方解石与菱镁矿浮选的影响[J]. 矿产保护与利用, 2014(6): 15−18.
SONG Z G. Effect of several metal cations on flotation of calcite and magnesite[J]. Conservation and Utilization of Mineral Resources, 2014(6): 15−18.
-
