Study on Characteristics of Biomass Pyrolysis Gasification During Magnetization Roasting of Hematite
-
摘要:
磁化焙烧工艺是处理复杂难选铁矿石有效的途径之一，但其生产过程中需要能源和还原剂，而生物质作为一种清洁能源，可热解出CO、CO2、CH4和H2，其中的CO、CH4和H2可在铁矿石磁化焙烧的过程中作为还原剂使用，实现清洁生产。以玉米秸秆和赤铁矿为原料，研究了在磁化焙烧过程中秸秆型生物质的热解气化特性。利用气体成分分析仪和TG−FTIR，分析了不同条件下秸秆的裂解产物。气体成分分析结果表明，在焙烧温度700 ℃、N2流量300 mL/min和秸秆与赤铁矿质量配比1∶3的磁化焙烧条件下，COx的生成量达到了最大，为277.45 mL，此时秸秆热解效果最佳。TG−FTIR分析结果表明，赤铁矿的存在未改变秸秆热解产物的种类，但改变了产物的释放特性和生成量；在800 ℃以上的磁化焙烧过程中，DTG曲线出现了第二个失重峰，说明磁化焙烧过程中秸秆热解的反应速率大大加快。
Abstract:The magnetization roasting process is one of the effective ways to treat complex and refractory iron ores. However, energy and reducing agents are required during its production process. As a clean energy source, biomass can be thermally decomposed to produce CO, CO2, CH4, and H2, among which CO, CH4, and H2 can be used as reducing agents in the magnetization roasting process of iron ore, achieving clean production. Using corn straw and hematite as raw materials, the thermal decomposition and gasification characteristics of straw biomass were investigated during magnetization roasting. Gas composition analysis results showed that under the magnetization roasting conditions of 700 ℃, N2 flow rate of 300 mL/min, and straw-hematite mass ratio of 1∶3, the maximum production of COx reached 277.45 mL, indicating the optimal thermal decomposition effect of straw. TG−FTIR analysis results showed that hematite did not change the type of straw pyrolysis products, but altered the release characteristics and production of the products. In the magnetization roasting process above 800 ℃, the DTG curve exhibited a second weight loss peak, indicating a significant increase in the reaction rate of straw thermal decomposition during magnetization roasting.
-
Key words:
- hematite /
- corn straw /
- magnetization roasting /
- pyrolysis gasification /
- TG-FTIR /
- gas analyzer
-
-
表 1 赤铁矿化学成分分析结果
Table 1. Chemical composition analysis results of the samples
成分 TFe FeO SiO2 Al2O3 CaO MgO Mn TiO2 S P 含量/% 67.34 0.88 0.80 0.38 0.05 0.24 0.13 0.047 <0.01 0.04
下载: 导出CSV
表 2 赤铁矿铁物相分析结果
Table 2. Iron phase analysis results of the samples
铁物相 磁性铁
中铁碳酸铁
中铁赤铁矿
中铁硫化铁
中铁硅酸铁
中铁全铁 含量/% 1.80 0.06 64.93 0.08 0.67 67.54 分布率/% 2.67 0.08 96.13 0.12 0.09 100.00
下载: 导出CSV
表 3 秸秆成分分析结果
Table 3. Results of industrial analysis of straw
水分/% 灰分/% 挥发分/% 固定碳/% 热值/(kJ·g−1) 5.57 1.37 77.52 15.54 16.84
下载: 导出CSV
表 4 秸秆元素分析结果
Table 4. Results of elemental analysis of straw
元素 C H O N P S 含量/% 41.82 5.60 48.6 1.25 0.034 0.07
下载: 导出CSV
表 5 秸秆组分分析结果
Table 5. Results of composition analysis of straw
组分 纤维素 半纤维素 木质素 其他 含量/% 40.91 28.57 5.48 24.92
下载: 导出CSV
-
[1] 韩跃新, 孙永升, 李艳军, 等. 我国铁矿选矿技术最新进展[J]. 金属矿山, 2015(2): 1−11.
HAN Y X, SUN Y S, LI Y J, et al. Latest progress of mineral processing technology of iron ore[J]. Metal Mine, 2015(2): 1−11.
[2] 孙永升, 曹越, 韩跃新, 等. 磁化焙烧冷却过程中磁铁矿氧化动力学[J]. 东北大学学报(自然科学版), 2018, 39(12): 1759−1763. doi: 10.12068/j.issn.1005-3026.2018.12.017
SUN Y S, CAO Y, HAN Y X, et al. Oxidation kinetics of magnetite during magnetization roasting and cooling[J]. Journal of Northeastern University (Natural Science), 2018, 39(12): 1759−1763. doi: 10.12068/j.issn.1005-3026.2018.12.017
[3] 韩跃新, 李艳军, 高鹏, 等. 复杂难选铁矿石悬浮磁化焙烧-高效分选技术[J]. 钢铁研究学报, 2019, 31(2): 89−94. doi: 10.13228/j.boyuan.issn1001-0963.20180329
HAN Y X, LI Y J, GAO P, et al. Suspension magnetization roasting and high efficiency separation technology of complex refractory iron ore[J]. Journal of Iron and Steel Research, 2019, 31(2): 89−94. doi: 10.13228/j.boyuan.issn1001-0963.20180329
[4] 张波, 刘锐, 张岩. 合成气组分对生物质热解特性的影响研究[J]. 山西化工, 2022, 42(6): 507−515.
ZHANG B, LIU R, ZHANG Y. Effect of syngas components on pyrolysis characteristics of biomass[J]. Shanxi Chemical Industry, 2022, 42(6): 507−515.
[5] CAO Y, SUN Y S, GAO P, et al. Mechanism for suspension magnetization roasting of iron ore using straw-type biomass reductant[J]. International Journal of Mining Science and Technology, 2021, 31: 1075–1083.
[6] 李保卫, 李解, 杨仲禹, 等. 玉米秸秆热解特性及动力学研究[J]. 太阳能学报, 2017, 38(12): 3444−3449.
LI B W, LI X, YANG Z Y, et al. Pyrolysis characteristics and kinetics of corn straw[J]. Acta Solar Energy Sinica, 2017, 38(12): 3444−3449.
[7] 黄娜, 高岱巍, 李建伟, 等. 生物质三组分热解反应及动力学的比较[J]. 北京化工大学学报(自然科学版), 2007(5): 462−466. doi: 10.13543/j.cnki.bhxbzr.2007.05.019
HUANG N, GAO D W, LI J W, et al. Comparison of pyrolysis reaction and kinetics of three components of biomass[J]. Journal of Beijing University of Chemical Technology (Natural Science), 2007(5): 462−466. doi: 10.13543/j.cnki.bhxbzr.2007.05.019
[8] 汪永斌, 朱国才, 池汝安, 等. 生物质还原磁化褐铁矿的实验研究[J]. 过程工程学报, 2009, 9(3): 508−513. doi: 10.3321/j.issn:1009-606X.2009.03.016
WANG Y B, ZHU G C, CHI R A, et al. Experimental study on magnetization of limonite by biomass reduction[J]. Chinese Journal of Process Engineering, 2009, 9(3): 508−513. doi: 10.3321/j.issn:1009-606X.2009.03.016
[9] 黄冬波, 宗燕兵, 邓振强, 等. 鲕状赤铁矿生物质低温磁化焙烧[J]. 工程科学学报, 2015, 37(10): 1260−1267.
HUANG D B, ZONG Y B, DENG Z Q, et al. Low temperature magnetization roasting of oolitic hematite biomass[J]. Chinese Journal of Engineering Science, 2015, 37(10): 1260−1267.
[10] 张士元, 冯雅丽, 李浩然. 生物质磁化焙烧赤铁矿的研究[J]. 矿业工程, 2016, 14(4): 31−33. doi: 10.3969/j.issn.1671−8550.2016.04.011
ZHANG S Y, FENG Y L, LI H R. Research on magnetized roasting of hematite by biomass[J]. Mining Engineering, 2016, 14(4): 31−33. doi: 10.3969/j.issn.1671−8550.2016.04.011
[11] SWAGAT S. RATH, DANDA SRINIVAS RAO, ALOK TRIPATHY, et alBiomass briquette as an alternative reductant for low grade iron ore resources[J]. Biomass and Bioenergy, 2018, 108.
[12] SWAGAT S. RATH, DANDA S. RAO, BARADA K, et alA novel approach for reduction roasting of iron ore slime using cow dung[J]. International Journal of Mineral Processing, 2016, 157.
[13] SWAGAT S. RATH, DANDA, SRINIVAS, et alDolochar as a Reductant in the Reduction Roasting of Iron Ore Slimes[J]. International Journal of Minerals, Metallurgy and Mate, 2017, 24(12): 1341−351.
[14] ZHANG Y, SHIRO KAJITANI, MASAMI ASHIZAWA, et al. Tar destruction and coke formation during rapid pyrolysis and gasificationof biomass in a drop-tube furnace[J]. Fue, 2010, 89: 302−309.
[15] ANTAL M J, FRIEDMAN H L, ROGERS F E. Kinetics of cellulose pyrolysis in nitrogen and steam[J]. Combustion Science and Technology, 1980, 21: 141 152.
-
