First−principles Study on Sodium Alginate Enhanced Sodium Oleate for Flotation Separation of Scheelite and Calcitee
-
摘要:
白钨矿与方解石的浮选分离一直是研究热点。考察了油酸钠体系下海藻酸钠对白钨矿与方解石浮选分离的影响，采用密度泛函理论，分别建立水−矿物、海藻酸钠−矿物、油酸钠−矿物三种吸附模型，比较了吸附能的差异。研究结果表明，加入海藻酸钠作为抑制剂后，当油酸钠用量为50 mg/L、海藻酸钠用量为10 mg/L、矿浆pH=9时，白钨矿和方解石回收率分别为83.20%、5.20%，分选效果良好。计算结果表明，在水体系中，海藻酸钠和矿物表面均发生吸附，但在方解石表面的吸附强于在白钨矿表面的吸附，海藻酸钠作用后油酸钠在方解石表面的吸附能为43.20 kJ/mol、在白钨矿表面的吸附能为−136.32 kJ/mol，这说明海藻酸钠在油酸钠体系下能够选择性抑制方解石，而白钨矿不受影响，原子力显微镜（AFM）观察结果同时也证实了大量海藻酸钠吸附在方解石表面。研究结果可为白钨矿、方解石的浮选分离提供理论指导。
Abstract:Flotation separation of scheelite and calcite has been a hot research topic. The effect of sodium alginate on the flotation separation of scheelite and calcite in a sodium oleate system was investigated, Density functional theory was used to establish three adsorption models of water−mineral, sodium alginate−mineral, and sodium oleate−mineral, respectively compared the differences in adsorption energy. The results of the study showed thatwhen the dosage of sodium oleate was 50 mg/L, sodium algina was 10 mg/L, and the pH = 9, the recovery of calcite could be controled to 5.20%, while the recovery of scheelite could reach to 83.20%, which showed a significant effect. The molecular simulation results indicated that sodium alginate adsorped on both surface, but the adsorption energy of calcite was stronger than scheelite. After adsorption of sodium alginate, the adsorption energy of sodium oleate on calcite was 43.20 kJ/mol, the adsorption energy of sodium oleate on scheelite was −136.32 kJ/mol. The results demonstrate alginate can selectively inhibit calcite in sodium oleate without affecting scheelite,The AFM image observed also confirmed that a large amount of sodium alginate was adsorbed on the surface of calcite, also provided constructive advice for the separation of scheelite and calcite.
-
Key words:
- scheelite /
- calcite /
- sodium alginate /
- first principles /
- AFM
-
-
表 1 表面能计算结果
Table 1. Calculation results of surface energy
白钨矿表面层数 6 9 12 15 18 表面能/(kJ·mol−1) 0.7332 0.7455 0.7458 0.7476 0.7562 方解石表面层数 12 15 18 21 24 表面能/(kJ·mol−1) 0.4235 0.4226 0.4368 0.4396 0.4462
下载: 导出CSV
表 2 水分子在矿物表面的吸附能
Table 2. Adsorption energy of water molecules on mineral surface
矿物 E(surface+H2O)/eV Esurface/eV EH2O/eV Eads/eV Eads/ (kJ·mol−1) 白钨矿 −96589.82 −96119.27 −469.77 −0.78 −74.88 方解石 −25291.69 −24819.82 −469.80 −2.07 −198.72
下载: 导出CSV
表 3 海藻酸钠分子在矿物表面的吸附能
Table 3. Adsorption energy of sodium alginate molecules on mineral surface
矿物· E(surface+SA)/eV Esurface/eV Esa/eV Eads/eV Eads/(kJ·mol−1) 白钨矿 −101582.08 −96119.27 −5459.31 −3.5 −336.00 方解石 −30284.64 −24819.82 −5457.50 −7.32 −702.72
下载: 导出CSV
表 4 水体系中海藻酸钠在矿物表面的吸附能 /(kJ·mol−1)
Table 4. Adsorption energy of sodium alginate on mineral surface ( in water)
吸附方式 Eb 吸附方式 Ea Eads 白钨矿+水 −74.88 白钨矿+海藻酸钠 −336.00 −261.12 方解石+水 −198.72 方解石+海藻酸钠 −702.72 −504.00
下载: 导出CSV
表 5 油酸钠分子在矿物表面的吸附能
Table 5. Adsorption energy of sodium oleate molecule on mineral surface
矿物 E(surface+OA) /eV Esurface /eV EOA /eV Eads /eV Eads /(kJ·mol−1) 白钨矿 −101658.23 −96119.27 −5534.04 −4.92 −472.32 方解石 −30378.73 −24819.82 −5552.04 −6.87 −659.52
下载: 导出CSV
表 6 水体系中油酸钠在矿物表面的吸附能 /(kJ·mol−1)
Table 6. Adsorption energy of sodium oleate on mineral surface (in water)
吸附方式 Eb 吸附方式 Ea Eads 白钨矿+水 −74.88 白钨矿+油酸钠 −472.32 −397.44 方解石+水 −198.72 方解石+油酸钠 −659.52 −460.80
下载: 导出CSV
表 7 海藻酸钠作用后油酸钠在矿物表面吸附能 /(kJ·mol−1)
Table 7. Adsorption energy of sodium oleate on mineral surface after the action of sodium alginate
吸附方式 Eb） 吸附方式 Ea 吸附方式 Eads 白钨矿+
海藻酸钠−261.12 白钨矿+
油酸钠−397.44 白钨矿+
海藻酸钠+
油酸钠−136.32 方解石+
海藻酸钠−504.00 方解石+
油酸钠−460.80 方解石+
海藻酸钠+
油酸钠43.20
下载: 导出CSV
-
[1] 赵晨, 孙传尧, 印万忠, 等. 油酸钠浮选几种含钙矿物的晶体化学研究[J]. 中国钨业, 2020, 35(2): 23−28.
ZHAO C, SUN C X, YIN W Z, et al. On the crystal chemistry of several calcium minerals flotation with sodium oleate as the collector[J]. China Tungsten Industry, 2020, 35(2): 23−28.
[2] 陈伟, 张志豪, 卜显忠, 等. 抑制剂葫芦巴胶浮选分离白钨矿和方解石的作用及机理[J]. 金属矿山, 2021(12): 48−55.
CHEN W, ZHANG Z H, BU X Z, et al. Function and mechanism of depressant fenugreek gum flotation separation of scheelite and calcite[J]. Metal Mine, 2021(12): 48−55.
[3] MOHAMED A. M. ABDALLA, HUIQING PENG, HUSSEIN A. YOUNUS, et al. Effect of synthesized mustard soap on the scheelite surface during flotation[J]. Colloids and Surfaces A:Physicochemical and Engineering Aspects, 2018, 548: 108−116.
[4] 李有余, 张英, 宋国军, 等. 三种含钙矿物抑制剂研究进展及机理[J]. 中国钨业, 2016, 31(1): 52−57. doi: 10.3969/j.issn.1009-0622.2016.01.010
LI Y Y, ZHANG Y, SONG G J, et al. Mechanism and research progress of depressants for scheelite, fluorite and calcite flotation separation[J]. China Tungsten Industry, 2016, 31(1): 52−57. doi: 10.3969/j.issn.1009-0622.2016.01.010
[5] 马强, 李育彪, 李万青, 等. CMC浮选分离萤石与方解石作用机理研究[J]. 金属矿山, 2022(7): 187−192.
MA Q, LI Y B, LI W Q, Study on the reaction mechanism of fluorite and calcite flotation separation by carboxymethyl cellulose[J]. Metaj Mine, 2022(7): 187−192.
[6] 李皊值. 用改性水玻璃浮选钼矿石[J]. 有色金属(选矿部分), 2003(3): 33−34.
LI L Z. Molybdenum ores flotation with modified water glass[J]. Nonferrous Metals(Mineral Processing Section), 2003(3): 33−34.
[7] 宁江峰. Zn2+、Fe3+与水玻璃组合抑制剂对萤石、方解石浮选分离的影响研究[D]. 武汉: 武汉科技大学, 2021.
NING J F. Study on the effect of combined inhibitors of Zn2+ 、Fe3+ and sodium silicate on the flotation separation of fluorite and calcite[D]. Wuhan: Wuhan University of Science and Technology, 2021.
[8] 周贺鹏, 吴寒丹, 龚磊, 等. 新型有机抑制剂对萤石和方解石浮选分离的影响及作用机理[J]. 金属矿山, 2023(5): 122−128.
ZHOU H P, WU H D, GONG L, et al. Effect and mechanism of novel organic inhibitors on flotation separation of fluorite and calcite[J]. Metal Mine, 2023(5): 122−128.
[9] 路倩倩, 韩海生, 陈占发, 等. 典型有机抑制剂在萤石和方解石浮选分离中的作用机制及其应用[J]. 金属矿山, 2023(1): 216−222.
LU Q Q, HAN H S, CHEN Z F, et al. Application and mechanism of typical organic inhibitors on flotation separation of fluorite and calcite[J]. Metal Mine, 2023(1): 216−222.
[10] CHEN W, FENG Q M, ZHANG G F, et al. The effect of sodium alginate on the flotation separation of scheelite from calcite and fluorite[J]. Minerals Engineering, 2017, 113: 1−7. doi: 10.1016/j.mineng.2017.07.016
[11] 冯博, 张文谱, 郭蔚, 等. 组合捕收剂及海藻酸钠在白钨矿和方解石浮选分离中的作用及机理[J]. 中国有色金属学报, 2019, 29(1): 203−210.
FENG B, ZHANG W P, GUO W, et al. Role and mechanism of combined collector and sodium alginate in flotation separation of scheelite and calcite[J]. The Chinese Journal of Nonferrous Metals, 2019, 29(1): 203−210.
[12] 李宇浩, 谭泽凌, 吴志强, 等. 白铅矿表面硫化及黄药吸附的密度泛函理论研究[J]. 矿业研究与开发, 2023, 43(7): 192−198.
LI Y H, TAN Z L, WU Z Q, et al. Study on density functional theory in sulfidation and xanthate adsorption on cerussite surface[J]. Mining Research and Development, 2023, 43(7): 192−198.
[13] 高志勇, 孙伟, 刘晓文, 等. 白钨矿和方解石晶面的断裂键差异及其对矿物解理性质和表面性质的影响[J]. 矿物学报, 2010, 30(4): 470−475.
GAO Z Y, SUN W, LIU X W, et al. Influences on cleavage and surface properties by broken bonds in the surface of scheelite and calcite[J]. Acta Mineralogica Sinica, 2010, 30(4): 470−475.
[14] 史新章, 王介良, 曹钊. 独居石电子结构和辛基羟肟酸在其(100)面的吸附机理[J]. 中国有色金属学报, 2021, 31(8): 2238−2246.
SHI X Z, WANG J L, CAO Z. Electronic structure of monazite and adsorption mechanism of octyl hydroxamic acid on its (100) plane[J]. The Chinese Journal of Nonferrous Metals, 2021, 31(8): 2238−2246.
[15] 魏桢伦, 李育彪. 辉钼矿晶面各向异性及其对浮选的影响机制[J]. 矿产保护与利用, 2018(3): 31−36.
WEI Z L, LI Y B. Anisotropy of molybdenite surface and its effects on flotation mechanism[J]. Conservation and Utilization of Mineral Resources, 2018(3): 31−36.
[16] 王泽红, 毛勇, 田鹏程, 等. 氯化钙与油酸钠对石英粉磨效率的影响及机理[J]. 有色金属(选矿部分), 2022(5): 24−31.
WANG Z H, MAO Y, TIAN P C, et al. Effect and mechanism of calcium chloride and sodium oleate on grinding efficiency of quartz powder[J]. Nonferrous Metals(Mineral Processing Section), 2022(5): 24−31.
[17] 毛勇, 王泽红, 田鹏程, 等. 组合助磨剂对石英粉磨的影响及其作用机理研究[J]. 中国矿业, 2021, 30(8): 117−124. doi: 10.12075/j.issn.1004-4051.2021.08.021
MAO Y, WANG Z H, TIAN P C, et al. Effect of combined grinding aids on quartz grinding and its mechanism[J]. China Mining Magazine, 2021, 30(8): 117−124. doi: 10.12075/j.issn.1004-4051.2021.08.021
-
