摘要:
与传统药剂（烃类油）相比，乳化捕收剂能降低油水界面张力，在水中的分散度高，可快速有选择性地吸附在煤表面，改善煤表面的疏水性，提高浮选效率，能够有效解决捕收性能差、选择性差和油耗高的问题。介绍了乳化捕收剂（普通乳状液和微乳液）的结构及形成机理，分析了机械搅拌、超声乳化和射流乳化三种制备乳化捕收剂的方法及优缺点，阐述了乳化捕收剂的分散度、表面改性作用及浮选速度与煤泥浮选效率提高之间的关系，总结了现阶段乳化捕收剂的研究类型及应用情况。提出针对煤泥的性质，设计及制备不同特性的乳化捕收剂，将有利于推动工业规模上煤泥的高效回收。
Abstract:Compared with traditional reagents (hydrocarbon oil), the emulsified collector has high dispersion in water due to reduce the interfacial tension between oil and water. It can be quickly and selectively adsorbed on the coal surface for improving the hydrophobicity of the coal surface to enhance the flotation efficiency. The problems of poor collection performance, poor selectivity and high fuel consumption in coal flotation can be effectively solved. The structure and formation mechanism of emulsified collector (common emulsion and microemulsion) are introduced. The advantages and disadvantages of mechanical stirring, ultrasonic emulsifying and jet emulsifying methods for preparing emulsified collector are analyzed. The relationship between the dispersibility, surface modification, flotation rate of emulsified collector and the improvement of coal slime flotation efficiency is described. The current research types and applications of emulsified collectors are summarized. It is pointed out that the design and preparation of emulsified collectors with different characteristics according to the properties of coal slime will be beneficial to promote the efficient recovery of coal slime on industrial scale.
-
Key words:
- emulsification collector /
- emulsified method /
- formation mechanism /
- fine coal /
- flotation
-
-
表 1 乳化捕收剂所用表面活性剂的种类及性质
Table 1. Types and properties of surfactants used in emulsifying collector
离子类型 商品名称 中文名称 化学式 乳化捕收剂类型 阳离子 PAM 聚丙烯酰胺 (C3H5NO)n O/W 阳离子 CTAB 十六烷基三甲基溴化铵 C19H42BrN O/W 阳离子 DTAB 十二烷基三甲基溴化铵 C15H34BrN O/W 阴离子 SDBS 十二烷基苯磺酸钠 C18H29NaO3S O/W、W/O 阴离子 SDS 十二烷基硫酸钠 C12H25SO4Na O/W 阴离子 NaOL 油酸钠 CH3(CH2)7CH=CH(CH2)7COONa O/W 阴离子 PGS 脂肪酸单甘油酯硫酸盐 − O/W 非离子 Span80 失水山梨醇脂肪酸酯 C24H44O6 O/W、W/O 非离子 Tween20 聚氧乙烯失水山梨醇单月桂酸酯 C26H50O10 O/W 非离子 Tween40 聚氧乙烯山梨醇单80棕榈酸酯 C12H18O11 O/W 非离子 Tween80 聚氧乙烯脱水山梨醇单油酸酯 C24H44O6 O/W、W/O 非离子 NPE 壬基酚聚氧乙烯醚 C15H24O(C2H4O)n O/W、W/O 非离子 OP−10 烷基酚聚氧乙烯醚−10 C34H62O11 O/W 非离子 − 三乙醇胺油酸皂 C24H47NO4 O/W
下载: 导出CSV
表 2 制备方法的特征对比
Table 2. Characteristic comparison of preparation methods
制备方法 优点 缺点 机械搅拌 设备简单，操作方便 乳状液液滴粒径一般为微米级，稳定性差 超声乳化 乳状液的液滴粒径小，稳定性好，乳化效率高 需输入高能量，制备成本高，难以大规模批量
制备乳状液射流乳化 可不添加乳化剂，节省时间和能源，易于通过调节
参数控制乳化效果，具有高效性和可控性对设备和操作要求高，对要乳化液体的
物理性质有要求
下载: 导出CSV
-
[1] 王东岳. 极性复配捕收剂对低阶煤浮选的研究[D]. 徐州: 中国矿业大学, 2018.
WANG D Y. Compound polar collector in low rank coal flotation[D]. Xuzhou: China University of Mining and Technology, 2018.
[2] JENA M S, BISWAL S K, RUDRAMUNJYAPPA M V. Study on flotation characteristics of oxidised Indian high ash sub−bituminous coal[J]. International Journal of Mineral Processing, 2008, 87(1/2): 42−50.
[3] BOYLU F, LASKOWSKI J S. Rate of water transfer to flotation froth in the flotation of low−rank coal that also requires the use of oily collector[J]. International Journal of Mineral Processing, 2007, 83(3/4): 125−131.
[4] CEBECI Y. The investigation of the floatability improvement of yozgat ayrıdam lignite using various collectors[J]. Fuel, 2002, 81: 281−89. doi: 10.1016/S0016-2361(01)00165-X
[5] QU J Z, TAO X X, HE H, et al. Synergistic effect of surfactants and a collector on the flotation of a low−rank coal[J]. International Journal of Coal Preparation and Utilization, 2015, 35(1): 14−24. doi: 10.1080/19392699.2014.904295
[6] XING Y W, GUI X H, CAO Y J, et al. Clean low−rank−coal purification technique combining cyclonic−static microbubble flotation column with collector emulsification[J]. Journal of Cleaner Production, 2017, 153: 657−72. doi: 10.1016/j.jclepro.2016.11.057
[7] ZHANG R, XIA Y C, GUO F Y, et al. Effect of microemulsion on low−rank coal flotation by mixing DTAB and diesel oil[J]. Fuel, 2020, 260: 116321. doi: 10.1016/j.fuel.2019.116321
[8] 安茂燕. 脂肪酸−烃类油浮选低阶煤协同作用机理研究[D]. 徐州: 中国矿业大学, 2019.
AN M Y. Study on synergistic mechanism of fatty acid −hydrocarbon oil for low rank coal flotation[D]. Xuzhou: China University of Mining and Technology, 2018.
[9] 王钰赛, 赵俊吉, 刘晓康, 等. 新型复合捕收剂强化细粒低阶煤浮选机理研究[J]. 矿业研究与开发, 2022, 42(5): 48−53.
WANG Y S, ZHAO J J, LIU X K, et al. Study on flotation mechanism of fine low rank coal enhanced by new composite collector[J]. Mining Research and Development, 2022, 42(5): 48−53.
[10] 斯培东. 药用乳剂和乳化剂[M]. 上海: 上海科技卫生出版社, 1958.
SPALTON L M. Medicinal emulsions and emulsifiers[M]. Shanghai: Shanghai Science and Technology Health Press, 1958.
[11] 王晓烨, 刘丽梅. 乳状液稳定性分析[J]. 福建茶叶, 2020, 42(2): 4−5.
WANG X Y, LIU L M. Emulsion stability analysis[J]. Tea in Fujian, 2020, 42(2): 4−5.
[12] 韩冰, 郑野, 徐嘉, 等. 微乳体系的制备及其稳定性研究进展[J]. 食品与发酵工业, 2020, 46(24): 284−291.
HAN B, ZHENG Y, XU J, et al. Research progress on preparation and stability of microemulsion system[J]. Food and Fermentation Industries, 2020, 46(24): 284−291.
[13] 崔正刚, 殷福珊. 微乳化技术及应用[M]. 北京: 中国轻工业出版社, 1999.
CUI Z G, YIN F S. Microemulsification technology and application[M]. Beijing: China Light Industry Press Ltd, 1999.
[14] SOLANS C, MORALES D, HOMS M. Spontaneous emulsification[J]. Current Opinion in Colloid & Interface Science, 2016, 22: 88−93.
[15] SCHULMAN J H, STOECKENIUS W, PRINCE L M. Mechanism of formation and structure of micro emulsions by electron microscopy[J]. Journal of Physical Chemistry, 1959, 63(10): 1677−1680. doi: 10.1021/j150580a027
[16] 吕玉庭, 王劲草, 吕一波. DR煤油乳化液的制备与应用[J]. 选煤技术, 2003(6): 76−78.
LV Y T, WANG J C, LV Y B. Preparation and application of DR kerosene emulsion[J], Coal Preparation Technology, 2003(6): 76−78.
[17] 吕玉庭, 刘慧莹, 高美. PAM对煤油乳化及煤泥浮选的影响[J]. 黑龙江科技学院学报, 2009, 19(6): 420−422+438.
LV Y T, LIU H Y, GAO M. Influence of PAM on oil emulsified and slurry flotation[J]. Journal of Heilongjiang University of Science, 2009, 19(6): 420−422+438.
[18] LIU J, ZHANG R, BAO X, et al. New insight into the role of the emulsified diesel droplet size in low rank coal flotation[J]. Fuel, 2023, 338: 127388. doi: 10.1016/j.fuel.2023.127388
[19] 张峰, 王怀法. 乳化捕收剂稳定性的探索及应用的研究[J]. 矿产综合利用, 2019(6): 55−59.
ZHANG F, WANG H F. Research and application of stability of emulsifying collector[J]. Multipurpose Utilization of Mineral Resources, 2019(6): 55−59.
[20] 庹必阳, 杜瑞康, 顾点发, 等. ST−柴油微乳液捕收剂强化煤泥浮选的机理研究[J]. 矿产保护与利用, 2023, 43(4): 24−32.
TUO B Y, DU R K, GU D F, et al. Enhanced flotation of coal slime with ST−diesel microemulsion[J]. Conservation and Utilization of Mineral Resources, 2023, 43(4): 24−32.
[21] 孙冬, 段旭琴, 章剑. 捕收剂乳化提高浮选性能研究[J]. 太原理工大学学报, 1998(5): 3−5.
SUN D, DUAN X Q, ZHANG J. Study on improving selectivity of collecting agent emulsified[J]. Journal of Taiyuan University of Technology, 1998(5): 3−5.
[22] 王建平, 郭志斌, 万忠东. 乳化捕收剂的浮选效果分析[J]. 选煤技术, 2009(5): 44−45.
WANG J P, GUO Z B, WAN Z D. Flotation effect analysis of emulsified collector[J]. Coal Preparation Technology, 2009(5): 44−45.
[23] 线梦瑶, 郭晓滨, 高瑞, 等. 低温焦油乳化制备煤炭浮选剂的实验研究[J]. 煤炭技术, 2016, 35(12): 308−310.
XIAN M Y, GUO X B, GAO R, et al. Experimental study on emulsion of low temperature tar to prepare coal flotation agent[J]. Coal Technology, 2016, 35(12): 308−310.
[24] 闫一诺, 曹珂珂, 安可心, 等. 焦油−氨水乳化制备煤炭捕收剂研究[J]. 山西化工, 2021(6): 22−24.
YAN Y N, CAO K K, AN K X, et al. Study on preparation of coal collector by tar ammonia emulsification[J]. Shanxi Chemical Industry, 2021(6): 22−24.
[25] 王豪. 轮胎热解油及其乳状液作为新型煤用浮选捕收剂的试验研究[D]. 太原: 太原理工大学, 2015.
WANG H. Experimental study on tire pyrolysis oil and emulsions as new coal flotation collector[D]. Taiyuan: Taiyuan University of Technology, 2015.
[26] 康文泽, 王慧, 孔小红, 等. 超声乳化煤油的浮选性能研究[J]. 煤炭学报, 2008(1): 89−93. doi: 10.3321/j.issn:0253-9993.2008.01.020
KANG W Z, WANG H, KONG X H, et al. Study of flotation performance of kerosene after ultrasonic emulsified[J]. Journal of China Coal Society, 2008(1): 89−93. doi: 10.3321/j.issn:0253-9993.2008.01.020
[27] 李昕帆. 煤浮选捕收剂的超声乳化研究及其自动化设计[D]. 太原: 太原理工大学, 2010.
LI X F. Supersonic emulsifying coal flotation collector and its automatic design[D]. Taiyuan: Taiyuan University of Technology, 2015.
[28] 李吉辉, 马力强, 吴伦, 等. 高剪切调浆和捕收剂乳化处理对煤泥浮选效果的影响研究[J]. 选煤技术, 2009(1): 67−71.
LI J H, MA L Q, WU L, et al. Study of effect of high−shear pulp conditioning and collector emulsification on fine coal flotation performance[J]. Coal Preparation Technology, 2009(1): 67−71.
[29] 杨春晖, 侯艺, 童美, 等. 不同类型表面活性剂乳化煤油对低阶煤浮选的影响研究[J]. 煤炭工程, 2023, 55(9): 158−164.
YANG C H, HOU Y, TONG M, et al. Impacts of kerosene emulsified by different surfactant on low rank coal flotation[J]. Coal Engineering, 2023, 55(9): 158−164.
[30] 赵鸣, 皇甫京华, 刘翼州. RP乳化剂在煤泥浮选中的作用[J]. 煤炭转化, 1998(1): 94−96.
ZHAO M, HUANGFU J H, LIU J Z. Effects of RP emulsifier in slime flotation[J]. Coal Conversion, 1998(1): 94−96.
[31] 阮继政, 冯莉, 宋俊华, 等. 超声乳化柴油捕收剂制备及应用[J]. 煤炭技术, 2011, 30(6): 147−149.
RUAN J Z, FENG LI, SONG J H, et al. Preparation and application of ultrasonic emulsified diesel collector[J]. Coal Technology, 2011, 30(6): 147−149.
[32] 黄波, 徐宏祥, 李旭林. 微乳型捕收剂的稳定性和浮选性能的试验研究[J]. 煤炭学报, 2019, 44(9): 2878−2885.
HUANG B, XU H X, LI X L. Experimental study on stability and flotation performance of micro−emulsion collector[J]. Journal of China Coal Society, 2019, 44(9): 2878−2885.
[33] 李琳, 崔广文, 刘惠杰, 等. 超声微乳捕收剂的制备及煤泥浮选性能研究[J]. 洁净煤技术, 2016, 22(4): 68−72.
LI L, CUI G W, LIU H J, et al. Preparation and flotation performance of ultrasonic microemulsified collector for slime[J]. Clean Coal Technology, 2016, 22(4): 68−72.
[34] 王志东. 基于柴油乳化的褐煤浮选提质试验[J]. 洁净煤技术, 2021, 27(S2): 134−139.
WANG Z D. Experimental study on lignite flotation upgrading based on diesel oil emulsification[J]. Clean Coal Technology, 2021, 27(S2): 134−139.
[35] 解维伟. 煤乳化浮选药剂的制备与应用机理研究[D]. 北京: 中国矿业大学(北京), 2009.
XIE W W. Research on the preparation and application mechanism of the emulsified coal flotation agent[D]. Beijing: China University of Mining and Technology (Beijing), 2009.
[36] 王慧. 煤油超声乳化及其性能研究[D]. 哈尔滨: 黑龙江科技学院, 2007.
WANG H. Study on ultrasonic emulsified kerosene and properties[D]. Harbin: Heilongjiang University of Science and Technology, 2007.
[37] 江明东, 闫锐敏, 于一栋. 浮选剂乳化系统在选煤厂的推广应用[J]. 煤质技术: 2006(4): 7−10.
JIANG M D, YAN R M, YU Y D, et al. The popularization and application of the flotation emulsion system in coal preparation plants [J]. Coal Quality Technology, 2006(4): 7−10.
[38] 王永君, 刘文礼, 符东旭, 等. 喷射技术乳化浮选药剂的规律研究[J]. 选煤技术, 2008(4): 7−10. doi: 10.3969/j.issn.1001-3571.2008.04.009
WANG Y J, LIU W L, FU D X, et al. Study on the law of emulsion flotation reagent by jet technology[J]. Coal Preparation Technology, 2008(4): 7−10. doi: 10.3969/j.issn.1001-3571.2008.04.009
[39] 邓建军, 郭崇涛, 王传真. 基于射流原理的风力射流乳化器在涡北选煤厂的应用实践[J]. 选煤技术, 2016(5): 63−66.
DENG J J, GUO C T, WANG C Z. Application of the pneumatic emulsifier working on getting principle at Wobei coal preparation plant[J]. Coal Preparation Technology, 2016(5): 63−66.
[40] 陆宏圻. 喷射技术理论及应用[M]. 武汉: 武汉大学出版社, 2004.
LU H Q. Theory and application of jet technology[M]. Wuhan: Wuhan University Press, 2004.
[41] 王铁成. 射流泵流场计算[J]. 水泵技术, 2003(6): 3−6+39.
WANG T C. Flow field calculation of jet pump[J]. Pump Technology, 2003(6): 3−6+39.
[42] 刘焕胜, 刘瑞芹. 浮选药剂连续乳化法的研究与试验[J]. 煤炭加工与综合利用, 2003(4): 17−20+61.
LIU H S, LIU R Q. Research and experiment of the continuous emulsification of flotation reagent[J]. Coal Processing & Comprehensive Utilization, 2003(4): 17−20+61.
[43] 吕一波, 李勃. 浮选药剂射流乳化参数的试验研究[J]. 选煤技术, 2009(6): 6−9+1.
LV Y B, LI B. Experimental study on fluidic emulsification parameters of flotation reagents[J]. Coal Preparation Technology, 2009(6): 6−9+1.
[44] SHEN L, WANG H F, GUO B L, et al. The application of fatty acids emulsions in thermal coal reverse flotation[J]. International Journal of Coal Preparation and Utilization, 2015, 36(3): 163−173.
[45] YU X, YE Y, MILLER J D. Advances in fine particles processing[M]. Boston: Springer, 1990: 345−355.
[46] 吕玉庭, 王劲草, 周国江, 等. 煤油乳化捕收剂作用机理与应用[J]. 矿产综合利用, 2003(6): 33−35.
LV Y T, WANG J C, ZHOU G J, et al. The mechanism of kerosene emulsifier and its application as collector[J]. Multipurpose Utilization of Mineral Resources, 2003(6): 33−35.
[47] 李志斌, 杨康, 李小乐, 等. 柴油乳化及其对浮选影响的研究[J]. 选煤技术, 2017(2): 6−9.
LI Z B, YANG K, LI X L, et al. A study of the effect on flotation performance produced by diesel oil emulsification[J]. Coal Preparation Technology, 2017(2): 6−9.
[48] 廖寅飞, 安茂燕, 夏文成. 煤油乳化捕收剂在细粒煤浮选中的研究[J]. 洁净煤技术, 2010, 2010,16(2): 17−19.
LIAO Y F, AN M Y, XIA W C. Research on kerosene emulsifier as collector in fine coal flotation[J]. Clean Coal Technology, 2010, 2010,16(2): 17−19.
[49] 周弘文, 亓欣, 刘丙顺, 等. 乳化浮选药剂处理孙村细粒煤的试验研究[J]. 选煤技术, 2007(6): 12−15. doi: 10.3969/j.issn.1001-3571.2007.06.005
ZHOU H W, QI X, LIU B S, et al. Experimental research on the treatment of Suncun fine coal by emulsion flotation reagent[J]. Coal Preparation Technology, 2007(6): 12−15. doi: 10.3969/j.issn.1001-3571.2007.06.005
[50] 沈正义, 卓金武, 匡亚莉, 等. 乳化浮选药剂浮选性能的研究[J]. 煤炭科学技术, 2017(2): 6−9.
SHEN Z Y, ZHUO J W, KUANG Y L, et al. Research on flotation performances of emulsified flotation agent[J]. Coal Preparation Technology, 2017(2): 6−9.
[51] 符东旭, 朱书全, 贺兰鸿, 等. ZFC乳化油对东庞煤泥浮选效果的研究[J]. 选煤技术, 2010(5): 9−11+17.
FU D X, ZHU S Q, HE L H, et al. Study on the flotation effect of ZFC emulsified oil on Dongpang slime [J]. Coal Preparation Technology, 2007(06): 2010(5): 9−11+17.
[52] 黄汉富, 杨颋, 李国洲, 等. 乳化煤焦油在细粒煤浮选中的作用[J]. 选煤技术, 2007(6): 10−12.
HUANG H F, YANG T, LI G Z, et al. The role of emulsified coal tar in the fine coal flotation[J]. Coal Preparation Technology, 2007(6): 10−12.
[53] 唐云敏. 微纳HIP乳液对矿物颗粒表面改性作用研究[D]. 哈尔滨: 哈尔滨工业大学, 2020.
TANG Y M. Surface modeification of mineral particles via micro−nano high internal phase(HIP) emulsion[D]. Harbin: Harbin Institute of Technology, 2020.
[54] ZHAO X M, TANG Y M, ZHAO B L, et al. Collecting behaviors of high internal phase (HIP) emulsion in flotation of ultrafine high−ash content coal slime[J]. International Journal of Coal Preparation and Utilization, 2021(11): 1−21.
[55] 申世钰. 高内相油包水型乳液制备及其在浮选中的应用研究[D]. 太原: 太原理工大学, 2022.
SHEN S Y. Preparation of high internal phase water−in−oil emulsion and its application in flotation[D]. Taiyuan: Taiyuan University of Technology, 2022.
[56] 杨远雄. 一种新型的煤油基选煤浮选剂研究[J]. 化学工程与装备, 2018(11): 50−52.
[57] LU Y, WANG X M, LIU W P, et al. Dispersion behavior and attachment of high internal phase water−in−oil emulsion droplets during fine coal flotation[J]. Fuel, 2019, 253: 273−282. doi: 10.1016/j.fuel.2019.05.012
[58] LI B, ZHANG L, LIU S Y, et al. The effects of surfactant headgroups on oil−in−water emulsion droplet formation: an experimental and simulation study[J]. Journal of surfactants and detergents, 2019, 22(1): 85−93. doi: 10.1002/jsde.12206
[59] CUI H R, ZHU S Q, XU D F, et al. Preparation and impact on coal flotation of octanol emulsion[J]. Arabian Journal of Geosciences, 2017, 10(15): 320. doi: 10.1007/s12517-017-3117-7
[60] 张峰, 王怀法. 柴油微乳化及其在煤泥浮选中的应用[J]. 矿业研究与开发, 2018, 38(10): 106−110.
ZHANG F, WANG H F. The micro−emulsification of diesel and its application in the flotation of coal[J]. Mining Research and Development, 2018, 38(10): 106−110.
[61] 李涵. MECC煤泥微乳捕收剂的制备与性能研究[J]. 煤炭技术, 2015, 34(7): 315−317.
LI H. Research on preparation and property of MECC coal slime microemulsion collector[J]. Coal Technology, 2015, 34(7): 315−317.
[62] 王运来, 李琳, 韩瑞, 等. 煤泥微乳捕收剂浮选性能试验研究[J]. 选煤技术, 2014(6): 9−11+29.
WANG Y L, LI L, HAN R, et al. Experimental research on micro−emulsion collector on coal flotation[J]. Coal Preparation Technology, 2014(6): 9−11+29.
[63] 李琳, 刘炯天, 王运来, 等. 阴−非离子表面活性剂微乳捕收剂的制备及应用[J]. 煤炭学报, 2014, 39(11): 2315−2320.
LI L, LIU J T, WANG Y L, et al. Preparation and application of anionic−nonionic surfactant microemulsified[J]. Journal of China Coal Society, 2014, 39(11): 2315−2320.
[64] 贺兰鸿, 解维伟, 王佳, 等. 新型微乳液在煤泥浮选中的应用研究[J]. 煤炭工程, 2011(12): 97−99.
HE L H, XIE W W, WANG J, et al. Applied study on new micro−emulsion to smile flotation[J]. Coal Engineering, 2011(12): 97−99.
[65] 王驰, 崔广文. Gemini表面活性剂在地沟油制备微乳捕收剂中的应用[J]. 煤炭工程, 2019, 51(3): 130−135.
WANG C, CUI G W. Application of Gemini surfactant in preparation of micro−emulsion collector made from swill−cooked dirty oil[J]. Coal Engineering, 2019, 51(3): 130−135.
[66] 李琳, 贺萌, 李晓腾, 等. 生物基微乳捕收剂的制备及其在煤泥浮选中的应用[J]. 中国矿业大学学报, 2022, 51(4): 779−790. doi: 10.3969/j.issn.1000-1964.2022.4.zgkydxxb202204014
LI L, HE M, LI X T, et al. Preparation of bio−based microemulsion collector and its application in coal smile flotation[J]. Journal of China University of Mining & Technology, 2022, 51(4): 779−790. doi: 10.3969/j.issn.1000-1964.2022.4.zgkydxxb202204014
-
