Evolution Characteristics of Groundwater System in Deep Mining Areas in Western China Based on Feflow Software
-
摘要:
西部某深部矿区分布着水量丰富、水质优良的第四系潜水和白垩系洛河组含水层，是查干淖水厂饮用水水源及湖泊湿地重要补给源，该区域地下水资源保护要求高，水环境敏感。为了给矿区未来采煤安全生产和水资源综合利用提供可靠依据，首先通过相似模拟实验确定2 − 2煤开采后导水裂隙带发育高度；其次运用数值模拟法，定性描述各含水层相互影响及时空演化规律，定量描述各含水层补给与排泄主控因子及矿井涌水量。结果表明：（1）矿区导水裂隙带发育高度最大为148 m，未贯穿安定组隔水层；（2）采动导致直罗组及延安组水位明显下降，形成降水漏斗，白垩系志丹群含水层开采前后水位变化不明显；（3）矿区一井涌水量为
17032 m³/d。研究揭示了煤炭开采覆岩裂隙场和渗流场演化规律，为矿区“保水采煤”提供理论基础。Abstract:In the deep mining area of western China, there are abundant and high−quality Quaternary phreatic water and Cretaceous Luohe Formation aquifers, which serve as crucial recharge sources for the Chagannao Water Plant's drinking water supply and lake wetlands. This region exhibits high requirements for groundwater resource protection and sensitive water environments. This study aims to provide a reliable basis for future safe coal mining and comprehensive water resource utilization in the mining area. The research first determines the development height of water−conducting fracture zones after mining the 2−2 coal seam through similar simulation experiments. Subsequently, numerical simulation methods are employed to qualitatively describe the mutual influences and spatiotemporal evolution patterns among aquifers, while quantitatively analyzing the main controlling factors of aquifer recharge/discharge and mine water inflow. Key findings include: (1) The maximum height of water−conducting fractures reaches 148 m, not penetrating the Anding Formation aquiclude; (2) Mining activities cause significant water level decline in Zhiluo and Yan'an Formations, forming depression cones, while the Cretaceous Zhidan Group aquifer shows negligible water level changes; (3) The mine water inflow is calculated to be 17 032 m³/d. This study reveals the evolution patterns of overburden fracture fields and seepage fields during coal mining, and provides theoretical support for implementing "water−preserved coal mining" strategies in the area.
-
-
表 1 水文地质参数
Table 1. List of hydrogeological parameters
含隔水层分区 渗透系数 /(m·d−1) Kx Ky Kz 第四系含水层 3.95～12 3.95～12 3.95～12 志丹群含水层 0.178～1.5 0.178～1.5 0.017 8~0.15 安定组隔水层 0.000 531～
0.020 40.000 531～
0.020 40.000 0531～
0.002 04安定组越流区域 0.2 0.2 0.02 直罗组含水层 0.007~1.4 0.007~1.4 0.000 7~0.14 延安组隔水层 1e−7 1e−7 1e−8
下载: 导出CSV
表 2 主要含水层地下水均衡
Table 2. Groundwater budget in main aquifers
含水层 补给排泄 类型 水量/（d·m−3） 占比/% 第四系 补给项 侧向补给 13 508 44.97 降雨+河流补给 14 798 49.27 越流补给 78 2.32 2.6 释水补给 947.88 3.16 排泄项 径流排泄 29 297 97.54 岩层储水 739.74 2.46 白垩系志丹群 补给项 径流补给 18 330 98.03 释水补给 336.93 1.81 其他补给 30.59 0.16 排泄项 径流排泄 18 550 99.21 岩层储水 147.52 0.79 侏罗系直罗组及延安组 补给项 释水补给 4 531.3 26.59 径流补给 12 509 73.41 排泄项 岩层储水 8.3 0.05 矿井排水 17 032 99.95
下载: 导出CSV
-
[1] 曹志国, 何瑞敏, 王兴峰. 地下水受煤炭开采的影响及其储存利用技术[J]. 煤炭科学技术, 2014, 42(12): 113−116+128.
CAO Z G, HE R M, WANG X F. Coal mining affected to underground water and underground water storage and utilization technology[J]. Coal Science and Technology, 2014, 42(12): 113−116+128.
[2] 张凤娟, 杨子龙, 邢学睿, 等. 岩溶区地下水数值模拟分析及开采方案比选[J]. 中国矿业, 2024, 33(1): 200−204.
ZHANG F J, YANG Z L, XING X R, et al. Numerical simulation analysis of groundwater in karst area and comparison of mining schemes[J]. China Mining Magazine, 2024, 33(1): 200−204.
[3] 张成行, 郑洁铭, 徐智敏, 等. 基于水化学特征的顺和煤矿太灰水动力条件分析[J]. 煤炭工程, 2020, 52(6): 126−129.
ZHANG C H, ZHENG J M, XU Z M, et al. Hydrodynamic conditions analysis of Taiyuan Formation limestone aquifer in Shunhe Coal Mine based on hydrochemical characteristics[J]. Coal Engineering, 2020, 52(6): 126−129.
[4] 宫厚健, 刘守强, 李哲, 等. 基于Visual Modflow的矿井涌水量数值模拟预测研究[J]. 煤炭技术, 2018, 37(8): 155−157.
GONG H J, LIU S Q, LI Z, et al. Prediction of numerical simulation for mine water inflow based on Visual Modflow[J]. Coal Technology, 2018, 37(8): 155−157.
[5] 韩汝宁. 基于Dimine与Visual Modflow协同建模的矿区水文地质模型研究[J]. 中国矿业, 2018, 27(7): 139−143.
HAN R N. Research of mine hydrogeological model baesd on collaborative modeling with Dimine and Visual Modflow[J]. China Mining Magazine, 2018, 27(7): 139−143.
[6] 张保建. 基于Visual Modflow的台格庙勘查区矿井涌水量预测[J]. 煤炭科学技术, 2015, 43(S1): 146−149+172.
ZHANG B J. Mine water inflow forecast based on Visual Modflow in Taigemiao Exploration Area[J]. Coal Science and Technology, 2015, 43(S1): 146−149+172.
[7] 许珂. 台格庙矿区顶板涌(突)水危险性评价与矿井涌水量预测[D]. 北京: 中国矿业大学(北京), 2016.
XU K. Roof aquifer water inrush risk evaluation and mine water inflow prediction in Taigemiao coal mine[D]. Beijing: China University of Mining & Technology (Beijing), 2016.
[8] 黄天瑞, 李贵仁, 赵珍. 北洺河铁矿深部开采放水试验及数值模拟分析[J]. 中国矿业, 2015, 24(11): 107−112.
HUANG T R, LI G R, ZHAO Z. The dewatering test for deep mining and numerical simulation analysis in Beiminghe iron mine[J]. China Mining Magazine, 2015, 24(11): 107−112.
[9] 任晓波, 刘守强, 吴瑞芳. 基于子域解析元素法的煤矿疏降水量预测研究[J]. 煤炭工程, 2021, 53(7): 108−113.
REN X B, LIU S Q, WU R F. Prediction of coal mine dewatering rate based on subdomains−analytic element method[J]. Coal Engineering, 2021, 53(7): 108−113.
[10] 冯翔. 基于GMS三维地下水模型的矿井涌水量预测研究[D]. 北京: 中国地质大学(北京), 2017.
FENG X. The mine water inflow prediction research based on three−dimensional groundwater model in GMS[D]. Beijing: China University of Geosciences (Beijing), 2017.
[11] 王鸿, 姚云琦, 马建花, 等. 基于GMS的三维地质建模与地下水数值模拟−以永靖县黑台为例[J]. 兰州大学学报(自然科学版), 2023, 59(5): 601−609+619.
WANG H, YAO Y Q, MA J H, et al. 3D geological modeling and groundwater numerical simulation research based on GMS: A case study of the Heitai terrace, Yongjing Country[J]. Journal of Lanzhou University (Natural Sciences), 2023, 59(5): 601−609+619.
[12] SINGH M K , et al. Groundwater flow modeling for cachar, India using MODFLOW: a case study[J]. ISH Journal of Hydraulic Engineering, 2020(4): 1−11.
[13] FERNANDEZ P, ALVAREZ ALVAREZ, et al. Groundwater numerical simulation in an open pit mine in a limestone formation using MODFLOW[J]. International Journal of Mine Water, 2016, 35: 145−155.
[14] 董东林, 王存社, 陈书客, 等. 典型煤矿地下水运动及污染数值模拟[M]. 北京: 地质出版社, 2010.
DONG D L, WANG C S, CHEN S K, et al. Numerical simulation of groundwater movement and pollution in typical coal mines[M]. Beijing: Geological Publishing House, 2010.
[15] 靖晶. CO2储存过程多因素影响的数值模拟研究−以鄂尔多斯盆地石千峰组为例[D]. 武汉: 中国地质大学, 2021.
JING J. Numerical simulation of multiple factors influence on CO2 storage process: A case study of shiqianfeng formation in ordos basin[D]. Wuhan: China University of Geosciences, 2021.
[16] 李海祥, 曹志国, 王路军, 等. 台格庙矿区地下水水化学特征与演变规律研究[J]. 煤炭科学技术, 2023, 51(9): 284−291.
LI H X, CAO Z G, WANG L J, et al. Study on the chemical characteristics and evolution law of groundwater in Taigemiao mining area[J]. Coal Science and Technology, 2023, 51(9): 284−291.
[17] 杨建. 蒙陕接壤区深埋型煤层顶板水文地质及水文地球化学特征[J]. 煤矿安全, 2016, 47(10): 176−179+183.
YANG J. Hydrogeological and hydrogeochemical characteristics of deep buried coal seam roof in Shaanxi and Inner Mongolia Contiguous Area[J]. Safety in Coal Mines, 2016, 47(10): 176−179+183.
[18] 李海祥, 曹志国, 吴宝杨, 等. 煤矿覆岩裂隙地下水渗流特征的试验研究[J]. 煤炭科学技术, 2023, 51(6): 168−176.
LI H X, CAO Z G, WU B Y, et al. Experimental study on characteristics of grounawater fracture in coalmine overlying rock[J]. Coal Science and Technology, 2023, 51(6): 168−176.
[19] 吴宝杨, 李全生, 曹志国, 等. 煤矿地下水库高盐矿井水封存对地下水的影响[J]. 煤炭学报, 2021, 46(7): 2360−2369.
WU B Y, LI Q S, CAO Z G, et al. Influence of high salt mine water storaged in underground reservoir of coal mine on groundwater[J]. Journal of China Coal Society, 2021, 46(7): 2360−2369.
[20] 薛禹群. 地下水动力学[M]. 北京: 地质出版社, 1997.
XUE Y Q. Groundwater dynamics[M]. Beijing: Geological Publishing House, 1997.
[21] 吕情绪, 狄军贞, 李果, 等. 高强度采矿活动对地下水影响的数值模拟研究[J]. 煤炭科学技术, 2023, 51(5): 193−199.
LU Q X, DI J Z, LI G, et al. Numerical simulation study on the impact of high intensity mining activities on groundwater[J]. Coal Science and Technology, 2023, 51(5): 193−199.
[22] 崔春兰. 鄂尔多斯新街矿区台格庙3矿井涌水量预测[J]. 煤炭技术, 2015, 34(1): 140−143.
CUI C L. Forecasting water inflow of Taigemiao No. 3 Mine of Xinjie Coal Mine in Erdos[J]. Coal Technology, 2015, 34(1): 140−143.
-
