Determination of Carbofuran and 3-Hydroxycarbofuran in Groundwater by Small Volume Liquid-Liquid Extraction Combined with GC-MS
-
摘要:
克百威和3-羟基克百威是一对典型的农药母体及其代谢产物，由于其水溶性高、毒性大，可通过地表水或地下水进行长距离迁移，对人类健康和环境安全造成危害。以往通常采用液相萃取或固相萃取的方式提取样品中的克百威和3-羟基克百威，但这些方法操作繁琐、耗时较长，不利于室内模拟实验中多组样品的检测。为实现克百威与3-羟基克百威在地下水中的快速定量，本文建立了一种小体积液液萃取的前处理方法进行提取，并采用气相色谱-质谱（GC-MS）进行检测，对影响克百威和3-羟基克百威萃取效率的因素进行了研究。通过实验对比不同萃取剂、不同pH、不同离子强度条件下克百威与3-羟基克百威的回收率，优化了前处理条件。结果表明，选择二氯甲烷作为萃取剂且用量为1mL，调节水样pH=5，氯化钠用量为40g/L时克百威和3-羟基克百威的回收率最高，分别为75.1%~98.6%、55.0%~66.3%。性能评价结果显示，方法精密度和方法准确度满足测试要求（相对标准偏差 < 10%，n=5），克百威和3-羟基克百威的方法检出限分别为15.3μg/L、10.2μg/L。该方法操作简便、快速、消耗溶剂少，与传统的液液萃取法相比，本方法耗时约为前者的1/8，消耗溶剂量约比前者小2个数量级，能够满足室内模拟实验需求。
Abstract:BACKGROUND Carbofuran and 3-hydroxycarbofuran are typical pesticides with the relationship of parent and metabolite. Due to high water solubility and toxicity, carbofuran and 3-hydroxycarbofuran can be transported through surface water or groundwater for long distances, causing harm to human health and environmental safety. In the past, carbofuran and 3-hydroxycarbofuran in samples were usually extracted by liquid or solid phase extraction. However, these methods are cumbersome to operate and time-consuming, which is not conducive to the detection of multiple sets of samples in indoor simulation experiments.
OBJECTIVES In order to realize the rapid quantification of carbofuran and 3-hydroxycarbofuran in groundwater.
METHODS A small volume liquid-liquid extraction pretreatment method was established for extraction, combined with gas chromatography-mass spectrometry to detect factors affecting the extraction efficiency of carbofuran and 3-hydroxycarbofuran. To improve the extraction efficiency of carbofuran and 3-hydroxycarbofuran, [JP] factors such as the type of extraction solvent, pH and dosage of NaCl were optimized.
RESULTS Results showed that the extraction efficiency of carbofuran and 3-hydroxycarbofuran was highest when 1mL methylene chloride was selected as the extraction agent under pH=5, and 40g/L NaCl was added in the water samples. The extraction recoveries for carbofuran and 3-hydroxycarbofuran were 75.1%-98.6% and 55.0%-66.3%, respectively. The performance evaluation results showed that the instrument precision and method precision meet test requirements (n=5, relative standard deviation < 10%). The detection limits of carbofuran and 3-hydroxycarbofuran in water were 15.3μg/L and 10.2μg/L, respectively.
CONCLUSIONS This method is simple and fast with less solvent. Compared with the traditional liquid-liquid extraction method, this method takes about 1/8 time of the former, and consumes about two orders of magnitude less solvent than the former, which can meet the needs of indoor simulation experiments.
-
-
表 1 分析物目标离子质量数
Table 1. Characteristic ions for target compounds
化合物 CAS登录号 定量离子 参考离子 克百威 1563-66-2 164 149，122 3-羟基克百威 16655-82-6 137 180，147 苊-d10(IS) 15067-26-2 164 162 2-氟联苯(SS) 321-60-8 172 171
下载: 导出CSV
表 2 仪器精密度
Table 2. Precision tests of the instrument
目标物质 配制浓度
(μg/L)实测浓度
(μg/L)相对标准偏差
(%)100 79.2±7.3 9.2 克百威 400 394.2±17.1 4.3 800 690.3±15.4 2.2 100 100.0±6.6 6.6 3-羟基克百威 400 419.2±16.9 4.0 800 896.4±20.7 2.3
下载: 导出CSV
表 3 方法准确度
Table 3. Accuracy tests of the method
目标物质 配制浓度
(μg/L)实测浓度
(μg/L)相对标准
偏差(%)回收率
(%)克百威 100 75.4±3.9 5.2 71.1~79.5 800 680.5±20.6 3.0 82.5~88.6 3-羟基克百威 100 43.4±1.4 3.3 41.3~45.9 800 425.3±4.9 1.1 52.7~54.4
下载: 导出CSV
表 4 方法检出限
Table 4. Detection limits of the method
目标物质 配制浓度
(μg/L)实测浓度
(μg/L)相对标准
偏差(%)检出限
(μg/L)克百威 100 81.9±4.9 5.9 15.3 3-羟基克百威 100 42.1±3.3 7.7 10.2
下载: 导出CSV
-
[1] Donovan S, Taggart M, Richards N. An overview of the chemistry, manufacture, environmental fate and detection of carbofuran[M]//Richards N. Carbofuran and wildlife poisoning. 2011: 1-18.
[2] 聂荣荣, 何啸峰, 沈洁, 等. GC-MS法测定红薯中克百威和3-羟基克百威的残留量[J]. 食品安全导刊, 2019(3): 152-154. https://www.cnki.com.cn/Article/CJFDTOTAL-SPAQ201903150.htm
Nie R R, He X F, Shen J, et al. Determination of carbofuran and 3-hydroxycarbofuran residues in sweet potatoes by GC-MS[J]. China Food Safety Magazine, 2019(3): 152-154. https://www.cnki.com.cn/Article/CJFDTOTAL-SPAQ201903150.htm
[3] 杜秋红, 赵国宇, 李玉梅, 等. 呋喃丹特性及生物降解研究进展[J]. 北方园艺, 2010(14): 210-212. https://www.cnki.com.cn/Article/CJFDTOTAL-BFYY201014085.htm
Du Q H, Zhao G Y, Li Y M, et al. Research of carbofuran characteristics and biodegradation[J]. Northern Horticulture, 2010(14): 210-212. https://www.cnki.com.cn/Article/CJFDTOTAL-BFYY201014085.htm
[4] Otieno P O, Lalah J O, Munir V, et al. Soil and water contamination with carbofuran residues in agricultural farmlands in Kenya following the application of the technical formulation Furadan[J]. Journal of Environmental Science and Health, 2010, 45(2): 137-144. doi: 10.1080/03601230903472058
[5] 王素利, 杨素萍, 刘丰茂, 等. 液相微萃取技术在农药残留分析中的应用研究进展[J]. 农药学学报, 2012, 14(5): 461-474. doi: 10.3969/j.issn.1008-7303.2012.05.01
Wang S L, Yang S P, Liu F M, et al. Review on the application of liquid phase microextraction in pesticide residue analysis[J]. Chinese Journal of Pesticide Science, 2012, 14(5): 461-474. doi: 10.3969/j.issn.1008-7303.2012.05.01
[6] Mudiam M K R, Ch R, Saxena P N. Gas chromatography-mass spectrometry based metabolomic approach for optimi-zation and toxicity evaluation of earthworm sub-lethal responses to carbofuran[J]. PLoS One, 2013, 8(12): e81077. doi: 10.1371/journal.pone.0081077
[7] Simone M G. Optimization and validation of liquid-liquid extraction with low temperature partitioning for determination of carbamates in water[J]. Analytica Chimica Acta, 2010, 671(1-2): 41-47. doi: 10.1016/j.aca.2010.05.003
[8] 杨清华, 史玉坤, 施逸岚, 等. 气相色谱-质谱联用测定蔬菜中克百威、三羟基克百威及丁硫克百威残留[J]. 中国卫生检验杂志, 2017, 27(11): 1539-1541. https://www.cnki.com.cn/Article/CJFDTOTAL-ZWJZ201711006.htm
Yang Q H, Shi Y K, Shi Y L, et al. Determination of the carbofuran, 3-hydroxycarbofuran and carbosulfan residues in vegetables by gas chromatography mass spectrometry[J]. Chinese Journal of Health Laboratory Technology, 2017, 27(11): 1539-1541. https://www.cnki.com.cn/Article/CJFDTOTAL-ZWJZ201711006.htm
[9] Otieno P O, Lalah J O, Virani M, et al. Carbofuran and its toxic metabolites provide forensic evidence for furadan exposure in vultures (gyps africanus) in Kenya[J]. Bulletin of Environmental Contamination and Toxicology, 2010, 84(5): 536-544. doi: 10.1007/s00128-010-9956-5
[10] Ma Q, Liu X L, Zhang Y. Fe3O4 nanoparticles coated with polyhedral oligomeric silsesquioxanes and beta-cyclodextrin for magnetic solid-phase extraction of carbaryl and carbofuran[J]. Journal of Separation Science, 2020, 43(8): 1514-1522. doi: 10.1002/jssc.201900896
[11] Zhang W, Li D, Xu Y, et al. Synthesis and application of novel molecularly imprinted solid phase extraction materials based on carbon nanotubes for determination of carbofuran in human serum by high performance liquid chromatography[J]. Journal of Agricultural and Food Chemistry, 2019, 67(18): 5105-5112. doi: 10.1021/acs.jafc.9b00967
[12] Zhang C, He H, Yu J, et al. Residues of carbosulfan and its metabolites carbofuran and 3-hydroxy carbofuran in rice field ecosystem in China[J]. Journal of Environmental Science and Health, Part B: Pesticides, Food Contaminants, and Agricultural Wastes, 2016, 51(6): 351-357. http://dx.doi.org/10.1080/03601234.2015.1120606
[13] 李晓晶, 于鸿, 杨蓉, 等. 超声辅助分散液液微萃取/超高效液相色谱-串联质谱法检测水中多种磺胺类抗生素残留[J]. 分析测试学报, 2016, 35(10): 1255-1260. doi: 10.3969/j.issn.1004-4957.2016.10.006
Li X J, Yu H, Yang R, et al. Ultrasound-assisted dispersion liquid-liquid microextraction/ultra performance liquid chromatography-tandem mass spectrometry for detection of multiple sulfonamide antibiotic residues in water[J]. Journal of Instrumental Analysis, 2016, 35(10): 1255-1260. doi: 10.3969/j.issn.1004-4957.2016.10.006
[14] 王青. 超声辅助分散液-液微萃取/高效液相色谱联用测定环境水样中的有机污染物[D]. 兰州: 西北师范大学, 2013.
Wang Q. Determination of organic pollutants in environ-mental water by ultrasonication assisted dispersive liquid-liquid microextraction coupled with HPLC[D]. Lanzhou: Northwest Normal University, 2013.
[15] 王世玉, 刘菲, 吴文勇, 等. 影响12种壬基酚同分异构体液液萃取效率的因素研究[J]. 岩矿测试, 2014, 33(4): 570-577. doi: 10.3969/j.issn.0254-5357.2014.04.019 http://www.ykcs.ac.cn/article/id/74df3f1c-5cbe-4588-b4d5-1a7be0bb9fe6
Wang S Y, Liu F, Wu W Y, et al. Study on impact factors of affecting liquid-liquid extraction efficiency of 12 nonylphenol isomers[J]. Rock and Mineral Analysis, 2014, 33(4): 570-577. doi: 10.3969/j.issn.0254-5357.2014.04.019 http://www.ykcs.ac.cn/article/id/74df3f1c-5cbe-4588-b4d5-1a7be0bb9fe6
[16] Trotter D M, Kent R A, Wong M P. Aquatic fate and effect of carbofuran[J]. Critical Reviews in Environmental Science and Technology, 1991, 21(2): 137-176. http://europepmc.org/abstract/AGR/IND91042211
[17] 李冠华, 沈彬, 张占恩. 液相微萃取GC/MS法测定甲霜灵、三唑酮和二甲戊灵[J]. 苏州科技学院学报(工程技术版), 2008(3): 38-42. https://www.cnki.com.cn/Article/CJFDTOTAL-SZCJ200803011.htm
Li G H, Shen B, Zhang Z E. Determination of metalaxyl, triadimefon, pendimet in water using hollow fiber membrane liquid-phase microextraction combined with gas chromatography-mass spectrometry[J]. Journal of University of Science and Technology of Suzhou(Engineering and Technology), 2008(3): 38-42. https://www.cnki.com.cn/Article/CJFDTOTAL-SZCJ200803011.htm
[18] 陈志岳. 分析工作中精密度、回收率和准确度的正确计算与表示[J]. 环保科技, 1984(1): 42-46. https://www.cnki.com.cn/Article/CJFDTOTAL-GZHB198401008.htm
Chen Z Y. Correct calculation and expression of precision, recovery rate and accuracy in analytical work[J]. Environmental Protection and Technology, 1984(1): 42-46. https://www.cnki.com.cn/Article/CJFDTOTAL-GZHB198401008.htm
[19] 罗俊凯. 丁硫克百威及其代谢产物在烟田中的残留和水解研究[D]. 长沙: 湖南农业大学, 2014.
Luo J K. The residue and hydrolysis of carbosulfan and its metabolites in tobacco field[D]. Changsha: Hunan Agricultural University, 2014.
[20] 林国斌, 林麟, 杨艳. 化学污染物监测中方法检出限及其确定方法[J]. 海峡预防医学杂志, 2011, 17(2): 61-63. https://www.cnki.com.cn/Article/CJFDTOTAL-HXYF201102038.htm
Lin G B, Lin L, Yang Y. Detection limits and determination methods of chemical pollutant monitoring[J]. Strait Journal of Preventive Medicine, 2011, 17(2): 61-63. https://www.cnki.com.cn/Article/CJFDTOTAL-HXYF201102038.htm
[21] 杨丽莉, 胡恩宇, 母应锋, 等. 水中呋喃丹气相色谱-质谱的测定方法研究[J]. 中国环境监测, 2007, 23(2): 16-19. https://www.cnki.com.cn/Article/CJFDTOTAL-IAOB200702003.htm
Yang L L, Hu E Y, Mu Y F, et al. Determination of carbofuran in water by gas chromatography-mass spectrometry[J]. Environmental Monitoring in China, 2007, 23(2): 16-19. https://www.cnki.com.cn/Article/CJFDTOTAL-IAOB200702003.htm
[22] 侯宪文, 李勤奋, 邓晓, 等. 高效液相色谱法分析丁硫克百威及其降解产物[J]. 农药, 2009, 48(9): 654-655. https://www.cnki.com.cn/Article/CJFDTOTAL-NYZZ200909010.htm
Hou X W, Li Q F, Deng X, et al. Analysis of carbofuran and its degradation products by high performance liquid chromatography[J]. Agrochemicals, 2009, 48(9): 654-655. https://www.cnki.com.cn/Article/CJFDTOTAL-NYZZ200909010.htm
[23] 白雪媛. 地下水中82种农药测试方法开发与应用[D]. 北京: 中国地质大学(北京), 2017.
Bai X Y. Development and application for test method of 82 kinds of pesticides in groundwater[D]. Beijing: China University of Geosciences (Beijing), 2017.
-
