Effects of Goethite/Birnessite on Antimony Speciation in Yellow Soil from an Antimony Mining Area under Simulated Natural Conditions
-
摘要:
锑矿区及周边土壤锑污染严重，锑污染程度与其在土壤中的存在形态关系密切。铁锰氧化物是土壤黏土矿物中最活跃的成分，影响着锑在土壤中的形态转化。现有研究更多关注铁锰氧化物单一矿物对外源锑吸附的影响，而铁锰氧化物对实际土壤中锑形态转化的影响方面的基础研究有待加强。本文将土壤中常见的针铁矿(α-FeOOH)和水钠锰矿(δ-MnO2)以原位制备的方式，分别负载在贵州晴隆锑矿区的锑污染黄壤(原土)中，制得载铁土和载锰土，模拟土壤自然状况，淹水180天，探究了α-FeOOH和δ-MnO2介导下土壤锑形态的转化特征。结果表明，淹水改变了土壤氧化还原特性，影响铁锰氧化物的赋存形态，进而影响锑的形态分布，负载的α-FeOOH主要以无定形铁存在，负载的δ-MnO2以游离锰、无定形锰和络合锰三种形式存在。与原土相比，载铁土悬浮液锑和弱酸提取态锑含量分别降低88.3%～94.4%、21.1%～65.9%，可还原态锑和可氧化态锑含量分别增加49.0%～67.2%、74.3%～159%；载锰土中悬浮液锑、弱酸提取态锑和可还原态锑分别增加14.2%～59.5%、6.50%～32.6%、4.80%～23.3%，可氧化态锑降低16.2%～58.5%。即原土、载铁土和载锰土各形态铁、锰、锑在淹水30天变化明显或是变化趋势发生转折，负载α-FeOOH促进了土壤弱酸提取态锑向土壤可还原态锑和可氧化态锑转化，负载δ-MnO2促进了土壤可氧化态锑向土壤弱酸提取态锑和可还原态锑转化。该研究为锑污染土壤的风险评估和修复技术提供了关键科学依据，对土壤锑污染的控制需结合铁锰氧化物形态调控和氧化还原条件管理，以实现锑的长期稳定化。
Abstract:The antimony (Sb) mining area and its surrounding soil are severely polluted with antimony, and the degree of antimony pollution is closely related to its speciation in the soil. Iron and manganese oxides are the most active components of clay minerals in soil, affecting the transformation of antimony speciation in soil. Existing research focuses more on the effect of single iron and manganese oxides on the adsorption of exogenous antimony, while basic study on the effect of iron and manganese oxides on the transformation of antimony speciation in actual soil needs to be strengthened. This study described the in situ preparation of goethite (α-FeOOH) and birnessite (δ-MnO2) in soil, which were loaded onto antimony contaminated yellow soil (original soil) in the Qinglong antimony mining area, Guizhou Province to obtain Fe-loaded soil and Mn-loaded soil. Simulating the natural soil conditions, a 180-day flooding experiment of original soil, Fe-loaded soil and Mn-loaded soil was conducted. The transformation characteristics of soil antimony forms mediated by α-FeOOH and δ-MnO2 were explored. The results showed that flooding changed the redox characteristics of soil, affected the forms of iron and manganese oxides, and thus affected the distribution of antimony speciation. The loaded α-FeOOH mainly existed as amorphous iron, while the loaded δ-MnO2 existed in three forms: free manganese, amorphous manganese, and complex manganese. Compared with the original soil, the content of Sb in the suspension and weak acidic extracted antimony of Fe-loaded soil decreased by 88.3%−94.4% and 21.1%−65.9%, respectively; the content of reducible antimony and oxidizable antimony increased by 49.0%−67.2% and 74.3%−159%, respectively; Sb in the suspension, weak acidic extracted antimony, and reducible antimony in Mn-loaded soil increased by 14.2%−59.5%, 6.50%−32.6%, and 4.80%−23.3%, respectively, while oxidizable antimony decreased by 16.2%−58.5%. The various speciation of iron, manganese, and antimony in the original soil, Fe-loaded soil and Mn-loaded soil showed significant changes or a turning point in the trend after 30 days of flooding. Loading α-FeOOH promoted the transformation of weak acidic extracted antimony to reducible and oxidizable antimony in the soil, while loading δ-MnO2 promoted the transformation of oxidizable antimony to weak acidic extracted antimony and reducible antimony in the soil. This study provides a key scientific basis for the risk assessment and remediation technology of antimony contaminated soil. In the future, the control of soil antimony pollution needs to be combined with the regulation of iron and manganese oxide forms and the management of redox conditions to achieve long-term stabilization of antimony. The BRIEF REPORT is available for this paper at
http://www.ykcs.ac.cn/en/article/doi/10.15898/j.ykcs.202502280032 .-
Key words:
- α-FeOOH /
- δ-MnO2 /
- soil /
- antimony /
- speciation transformation /
- atomic absorption spectroscopy
-
-
[1] 米艳华, 雷梅, 黎其万, 等. 滇南矿区重金属污染耕地的植物修复及其健康风险[J]. 生态环境学报, 2016, 25(5): 864−871. doi: 10.16258/j.cnki.1674-5906.2016.05.020
Mi Y H, Lei M, Li Q W, et al. Plant remediation and health risks of heavy metal contaminated farmland in southern Yunnan mining area[J]. Journal of Ecological Environment, 2016, 25(5): 864−871. doi: 10.16258/j.cnki.1674-5906.2016.05.020
[2] Mbadugha L, Cowper D, Dossanov S, et al. Geogenic and anthropogenic interactions at a former Sb mine: Environmental impacts of As and Sb[J]. Environmental Geochemistry and Health, 2020, 42: 11−24. doi: 10.1007/s10653-020-00652-w
[3] Ning Z P, Xiao T F, Xiao E Z. Antimony in the soil-plant system in an Sb mining/smelting area of Southwest China[J]. International Journal of Phytoremediation, 2015, 17(11): 1081−1089. doi: 10.1080/15226514.2015.1021955
[4] 李聪, 杨爱江, 陈蔚洁, 等. 锑胁迫对鱼腥草抗氧化能力及渗透调节物质的影响[J]. 江苏农业科学, 2019, 47(13): 175−179. doi: 10.15889/j.issn.1002-1302.2019.13.043
Li C, Yang A J, Chen W J, et al. The effect of antimony stress on the antioxidant capacity and osmoregulatory substances of Houttuynia cordata[J]. Jiangsu Agricultural Sciences, 2019, 47(13): 175−179. doi: 10.15889/j.issn.1002-1302.2019.13.043
[5] 莫昌琍, 吴丰昌, 符志友, 等. 湖南锡矿山锑矿区农用土壤锑、砷及汞的污染状况初探[J]. 矿物学报, 2013, 33(3): 344−350. doi: 10.16461/j.cnki.1000-4734.2013.03.005
Mo C L, Wu F C, Fu Z Y, et al. Preliminary study on the pollution status of antimony, arsenic, and mercury in agricultural soil of tin mine antimony mining area in Hunan Province[J]. Acta Mineralogica Sinica, 2013, 33(3): 344−350. doi: 10.16461/j.cnki.1000-4734.2013.03.005
[6] Ren W, Ran Y Y, Mou Y W, et al. Pollution characteristics and risk assessment of antimony and arsenic in a typical abandoned antimony smelters[J]. Environmental Geochemistry and Health, 2023, 45(7): 5467−5480. doi: 10.1007/s10653-023-01559-y
[7] Lai Z Y, He M C, Lin C Y, et al. Interactions of antimony with biomolecules and its effects on human health[J]. Ecotoxicology and Environmental Safety, 2022, 233: 113317. doi: 10.1016/j.ecoenv.2022.113317
[8] 谢晓峰. 贵州晴隆锑矿山废弃物中锑的表生迁移转化过程和机制[D]. 贵阳: 贵州大学, 2023.
Xie X F. Surface migration and transformation process and mechanism of antimony in Qinglong antimony mine waste in Guizhou Province[D]. Guiyang: Guizhou University, 2023.
[9] 李婉霞, 陈梅青, 刘奕安, 等. 水钠锰矿界面铁矿物的形成对Sb迁移转化的影响机理[J]. 中国环境科学, 2025, 45(3): 1341−1350. doi: 10.19674/j.cnki.issn1000-6923.20241028.009
Li W X, Chen M Q, Liu Y A, et al. Mechanism of the influence of iron mineral formation at the interface of sodium manganese ore on antimony migration and transformation[J]. China Environmental Science, 2025, 45(3): 1341−1350. doi: 10.19674/j.cnki.issn1000-6923.20241028.009
[10] 崔婷, 叶欣, 朱霞萍, 等. 土壤铁锰氧化物形态测定及吸附Sb(Ⅲ)的主控因子研究[J]. 岩矿测试, 2023, 42(1): 167−176. doi: 10.15898/j.cnki.11-2131/td.202111250187
Cui T, Ye X, Zhu X P, et al. Determination of soil iron and manganese oxide forms and study on the main control factors of Sb(Ⅲ) adsorption[J]. Rock and Mineral Analysis, 2023, 42(1): 167−176. doi: 10.15898/j.cnki.11-2131/td.202111250187
[11] 胡敏, 李芳柏. 土壤微生物铁循环及其环境意义[J]. 土壤学报, 2014, 51(4): 683−698. doi: 10.1002/3527602097
Hu M, Li F B. Soil microbial iron cycling and its environmental significance[J]. Journal of Soil Science, 2014, 51(4): 683−698. doi: 10.1002/3527602097
[12] Cornell R M, Schwertmann U. The iron oxides: Structure, properties, reactions, occurrences, and uses[M]. Clay Minerals, 1999, 34(1): 209−211.
[13] 郭贵宾, 袁晓雅, 黄理金, 等. 土壤中典型矿物对锑的吸附-沉积行为研究[J]. 岩矿测试, 2025, 44(1): 127−139. doi: 10.15898/j.ykcs.202404210093
Guo G B, Yuan X Y, Huang L J, et al. Study on the adsorption deposition behavior of typical minerals in soil towards antimony[J]. Rock and Mineral Analysis, 2025, 44(1): 127−139. doi: 10.15898/j.ykcs.202404210093
[14] Zhou W Q, Zhou J W, Feng X B, et al. Antimony isotope fractionation revealed from EXAFS during adsorption on Fe(oxyhydr)oxides[J]. Environmental Science & Technology, 2023, 57(25): 9353−9361. doi: 10.1021/acs.est.3c01906
[15] Yu S H, Wang Y, Wan Y Y, et al. Enhance antimony adsorption from aquatic environment by microwave-assisted prepared Fe3O4 nanospherolites[J]. Environmental Science and Pollution Research, 2023, 30(41): 94401−94413. doi: 10.1007/s11356-023-29060-0
[16] 向超, 王媛媛, 曾嘉庆, 等. 冶炼渣堆周边土壤砷锑垂向迁移分布及影响因素[J]. 中国有色金属学报, 2024, 34(8): 2773−2786. doi: 10.11817/j.ysxb.1004.0609.2024-44745
Xiang C, Wang Y Y, Zeng J Q, et al. Vertical migration distribution and influencing factors of arsenic and antimony in the soil around the smelting slag heap[J]. The Chinese Journal of Nonferrous Metals, 2024, 34(8): 2773−2786. doi: 10.11817/j.ysxb.1004.0609.2024-44745
[17] Xu W, Wang H J, Liu R P, et al. The mechanism of antimony(Ⅲ) removal and its reactions on the surfaces of Fe-Mn binary oxide[J]. Journal of Colloid and Interface Science, 2011, 363(1): 320−326. doi: 10.1016/j.jcis.2011.07.026
[18] Mitsunobu S, Muramatisu C, Watanabe K, et al. Behavior of antimony(Ⅴ) during the transformation of ferrihydrite and its environmental implications[J]. Environmental Science & Technology, 2013, 47(17): 9660−9667. doi: 10.1021/es4010398
[19] Kuang L Y, Liu Y Y, Fu D D, et al. FeOOH-graphene oxide nanocomposites for fluoride removal from water: Acetate mediated nano FeOOH growth and adsorption mechanism[J]. Journal of Colloid and Interface Science, 2017, 490: 259−269. doi: 10.1016/j.jcis.2016.11.071
[20] Liu Z G, Zhang F S. Removal of lead from water using biochars prepared from hydrothermal liquefaction of biomass[J]. Journal of Hazardous Materials, 2009, 167(1-3): 933−939. doi: 10.1016/j.jhazmat.2009.01.085
[21] Zhou C C, Li C, Yang K L, et al. Sb(Ⅴ) removal by different iron oxides from simulated textile-wastewater[J]. Acta Scientiae Circumstantiae, 2022, 42(2): 96−107. doi: 10.13671/j.hjkxxb.2021.0155
[22] Burton E D, Hockmann K, Karimian N. Antimony sorption to goethite: Effects of Fe(Ⅱ)-catalyzed recrystallization[J]. ACS Earth and Space Chemistry, 2020, 4(3): 476−487. doi: 10.1021/acsearthspacechem.0c00013
[23] Shangguan Y X, Qin X P, Zhao L, et al. Effects of iron oxide on antimony(V) adsorption in natural soils: Transmission electron microscopy and X-ray photoelectron spectroscopy measurements[J]. Journal of Soils & Sediments, 2016, 16(2): 509−517. doi: 10.1007/s11368-015-1229-9
[24] Guo W J, Fu Z Y, Wang H, et al. Removal of antimonate (Sb(Ⅴ)) and antimonite (Sb(Ⅲ)) from aqueous solutions by coagulation-flocculation-sedimentation (CFS): Dependence on influencing factors and insights into removal mechanisms[J]. Science of the Total Environment, 2018, 644: 1277−1285. doi: 10.1016/j.scitotenv.2018.07.034
[25] Lu H B, Han X G, Ren J M, et al. Enhanced removal of Sb(Ⅲ) and Sb(Ⅴ) by acid birnessite with doped titanium ions[J]. Technology of Water Treatment, 2023, 49(8): 30−39.
[26] Sun Q, Liu C, Alves M E, et al. The oxidation and sorption mechanism of Sb on δ-MnO2[J]. Chemical Engineering Journal, 2018, 342: 429−437. doi: 10.1016/j.cej.2018.02.091
[27] Sun W N, Sun X X, Li B Q, et al. Bacterial response to antimony and arsenic contamination in rice paddies during different flooding conditions[J]. Science of the Total Environment, 2019, 675: 273−285. doi: 10.1016/j.scitotenv.2019.04.146
[28] 崔晓丹, 王玉军, 周东美. 水分管理对污染土壤中砷锑形态及有效性的影响[J]. 农业环境科学学报, 2015, 34(9): 1665−1673. doi: 10.11654/jaes.2015.09.006
Cui X D, Wang Y J, Zhou D M. The impact of water management on the forms and availability of arsenic and antimony in polluted soil[J]. Journal of Agro-Environmental Science, 2015, 34(9): 1665−1673. doi: 10.11654/jaes.2015.09.006
[29] 张又弛, 唐晓达, 罗文邃. 淹水还原条件下红壤中葡萄糖及腐植酸对铁锰形态的影响[J]. 土壤学报, 2014, 51(2): 270−277. doi: 10.11766/trxb201303140117
Zhang Y C, Tang X D, Luo W S. The effect of glucose and humic acid on iron and manganese forms in red soil under flooding reduction conditions[J]. Journal of Soil Science, 2014, 51(2): 270−277. doi: 10.11766/trxb201303140117
[30] 姚冬菊, 刘恩光, 宁增平, 等. 贵州某锑冶炼厂周边农田土壤锑、砷污染与人体健康风险评估[J]. 地球与环境, 2021, 49(6): 673−683. doi: 10.14050/j.cnki.1672-9250.2021.49.058
Yao D J, Liu E G, Ning Z P, et al. Assessment of soil antimony and arsenic pollution and human health risks in the surrounding farmland of an antimony smelter in Guizhou Province[J]. Earth and Environment, 2021, 49(6): 673−683. doi: 10.14050/j.cnki.1672-9250.2021.49.058
[31] 吴琼, 张洋, 孟昭福. 十二烷基二甲基甜菜碱(BS-12)在合成针铁矿表面的吸附特征[J]. 环境科学学报, 2019, 39(9): 3045−3052. doi: 10.13671/j.hjkxxb.2019.0225
Wu Q, Zhang Y, Meng Z F. Adsorption characteristics of dodecyl dimethyl betaine (BS-12) on the surface of synthetic goethite[J]. Journal of Environmental Science, 2019, 39(9): 3045−3052. doi: 10.13671/j.hjkxxb.2019.0225
[32] 梁慧锋, 马子川, 刘占牛. 新生态二氧化锰的性质及pH值影响除砷效果的研究[J]. 无机化学学报, 2006, 22(4): 743−747. doi: 10.3321/j.issn:1001-4861.2006.04.029
Liang H F, Ma Z C, Liu Z N. Study on the properties of new ecological manganese dioxide and the influence of pH value on arsenic removal efficiency[J]. Journal of Inorganic Chemistry, 2006, 22(4): 743−747. doi: 10.3321/j.issn:1001-4861.2006.04.029
[33] 冉继伟, 张旭, 宁平, 等. 全国主要土壤铁重金属形态及其与土壤性质的关系[J]. 环境科学导刊, 2017, 36(4): 1−4. doi: 10.13623/j.cnki.hkdk.2017.04.001
Ran J W, Zhang X, Ning P, et al. The forms of iron and heavy metals in major soils nationwide and their relationship with soil properties[J]. Environmental Science Survey, 2017, 36(4): 1−4. doi: 10.13623/j.cnki.hkdk.2017.04.001
[34] 何群, 陈家坊. 土壤中游离铁和络合态铁的测定[J]. 土壤, 1983, 1(6): 242−244.
He Q, Chen J F. Determination of free iron and complexed iron in soil[J]. Soil, 1983, 1(6): 242−244.
[35] 徐晨瀛, 胡启武, 张桂华, 等. 鄱阳湖湿地剖面土壤铁结合态有机碳沿高程的分布特征[J]. 应用生态学报, 2024, 35(12): 3488−3496. doi: 10.13287/j.1001-9332.202412.017
Xu C Y, Hu Q W, Zhang G H, et al. Distribution characteristics of soil iron bound organic carbon along elevation in Poyang Lake wetland profile[J]. Journal of Applied Ecology, 2024, 35(12): 3488−3496. doi: 10.13287/j.1001-9332.202412.017
[36] Villalobos M, Toner B, Bargar J, et al. Characterization of the manganese oxide produced by pseudomonas putida strain MnB1[J]. Geochimica et Cosmochimica Acta, 2003, 67(14): 2649−2662. doi: 10.1016/S0016-7037(3)00217-5
-
