Heavy metal content, source, and pollution risk assessment in core sediments of Weihai Bay
-
摘要:
根据威海湾WHW-06孔柱状沉积物样品AMS14C测年、粒度和重金属元素含量的测试结果，分析了威海湾柱状沉积物中As、Cd、Cr、Cu、Pb、Zn和Hg 7种重金属元素含量的垂向分布特征；采用富集系数(EF)、地累积指数(Igeo)和潜在生态风险指数(RI)对沉积物重金属元素进行了风险评估；结合相关性分析和主成分分析，探讨了威海湾沉积物重金属元素的来源。结果表明，威海湾柱状沉积物中As、Cd、Hg含量自下而上总体呈波动上升的趋势；Cr、Cu、Pb、Zn含量自下而上总体呈先增加后减少的趋势，与柱状沉积物平均粒径的变化趋势基本一致。富集系数(EF)评价表明，柱状沉积物部分深度的As和Hg存在轻微富集；地累积指数(Igeo)评价表明，柱状沉积物中Hg总体呈轻度污染状态，As、Cd在部分深度呈轻度污染状态；潜在生态风险指数(RI)表明，重金属呈中风险等级的样品主要集中在柱状沉积物上部。相关性分析和主成分分析结果表明，柱状沉积物中Cd、Cr、Cu、Pb和Zn元素主要为自然来源，As和Hg元素含量的变化可能受人类活动的影响。经归一化校正后，过去200 a以来重金属元素含量呈现急剧升高的趋势，可能与工业革命以来人类活动排放污染物有关。
Abstract:The vertical distribution characteristics of As, Cd, Cr, Cu, Pb, Zn and Hg in the core sediments of Weihai Bay were analyzed based on the results of AMS14 C dating, particle sizes, and heavy metal content of WHW-06 core sediment samples in Weihai Bay. Enrichment factor (EF), geoaccumulation index (Igeo), and potential ecological risk index (RI) were used to assess the risk of heavy metal pollution. Combined with correlation analysis and principal component analysis, the sources of the heavy metals were discussed. Results show that from bottom to top or the core section, the content of As, Cd, and Hg showed an overall upward trend, and the contents of Cr, Cu, Pb, and Zn increased first and then decreased, which is consistent with the variation trend of the average particle size. EF evaluation showed that As and Hg were slightly enriched at some depths. Index Igeo revealed slight Hg pollution in the core, and occasional As and Cd pollution at some depths. Index RI indicated a medium risk level of heavy metal pollution in mainly the upper part of the core. In addition, correlation analysis and principal component analysis presented that Cd, Cr, Cu, Pb, and Zn were mainly from the natural sources, and the changes in As and Hg contents may be affected by human activities. After data normalization, the heavy metal contents displayed a rapid upward trend in the past 200 years, which may be related to the pollutants from human activities since the industrial revolution.
-
Key words:
- Weihai Bay /
- heavy metal content /
- core sediments /
- pollution risk assessment /
- pollution source
-
-
表 1 WHW-06孔AMS14C年代数据结果
Table 1. AMS14C dating results of Core WHW-06
样品编号 深度/cm 测试材料 14C年龄/a BP 年代校正/cal a BP 日历年龄/cal a BP WHW06-83 83～84 混合底栖有孔虫 2 310±30 1 906～1 592 1 749 WHW06-122 122～123 混合底栖有孔虫 2 840±30 2 619～2 261 2 440
下载: 导出CSV
表 2 潜在生态风险指标等级划分
Table 2. Classification of potential ecological risk
Eri RI 潜在生态风险等级 ＜40 ＜150 低风险 40～80 150～300 中风险 80～160 300～600 较高风险 160～320 ≥600 高风险 ≥320 极高风险
下载: 导出CSV
表 3 WHW-06孔沉积物重金属元素含量及污染评价结果
Table 3. Heavy metal content and assessment of heavy metal pollution in Core WHW-06 sediments
As Cd Cr Cu Pb Zn Hg 含量范围/（μg/g） 5.63～21.46 0.10～0.16 69.20～85.50 21.93～33.98 19.69～28.50 66.98～99.36 0.01～0.03 平均含量/（μg/g） 11.9 0.13 78.99 27.89 24.33 84.1 0.02 EF范围 0.38～1.35 0.49～0.82 0.42～0.64 0.35～0.63 0.39～0.68 0.38～0.68 0.65～1.26 EF平均值 0.78 0.61 0.49 0.45 0.48 0.49 0.92 Igeo范围 −0.98～0.95 −0.58～0.08 −0.77～−0.47 −1.04～−0.41 −0.21～−0.09 −0.91～−0.34 −0.15～0.82 Igeo平均值 −0.008 −0.254 −0.583 −0.707 −0.142 −0.592 0.314 Eir范围 7.61～29.04 30.17～47.44 1.76～2.17 3.64～5.64 3.98～5.77 0.80～1.18 54.03～105.91 Eir平均值 16.1 37.99 2.01 4.63 4.92 1 75.69
下载: 导出CSV
表 4 WHW-06孔沉积物重金属元素主成分分析
Table 4. Principal component analysis of heavy metal elements in Core WHW-06 sediments
元素 PC1 PC2 As 0.51 0.71 Cd 0.75 0.51 Cr 0.76 0.17 Cu 0.88 0.42 Pb 0.91 0.39 Zn 0.89 0.40 Hg 0.14 0.91 Th 0.93 0.13 方差百分比/% 58.35 26.45
下载: 导出CSV
表 5 山东半岛典型海湾重金属含量特征值一览表
Table 5. Heavy metal content in typical bays of Shandong Peninsula
μg/g 位置 As Cd Cr Cu Pb Zn Hg 来源 WHW-06孔 范围 5.63～21.46 0.10～0.16 69.20～85.50 21.93～33.98 19.69～28.50 66.98～99.36 0.01～0.03 本研究 平均值 11.9 0.13 78.99 27.89 24.33 84.1 0.02 WH-05孔
背景值范围 2.22～11.99 0.06～0.13 66.11～84.38 20.74～34.22 18.75～29.50 65.74～92.22 0.01～0.05 文献[16] 平均值 7.39 0.1 78.78 30.12 24.71 84.03 0.01 莱州湾 范围 4.10～22.90 0.04～0.20 14.50～63.90 1.20～47.20 3.20～34.20 29.60～81.50 0.01～0.38 文献[32] 平均值 13.9 0.1 37.3 16.8 12.3 51.6 0.07 乳山湾 范围 6.73～10.33 0.51～1.73 \ 8.43～20.95 12.48～36.92 30.29～65.46 0.03～0.06 文献[33] 平均值 8.44 0.98 \ 12.86 19.87 47.76 0.04 靖海湾 范围 4.93～9.60 0.39～0.66 45.61～62.17 24.28～75.35 13.69～29.35 81.84～162.19 0.03～0.05 文献[34] 平均值 7.06 0.57 56.29 37.79 19.91 115.63 0.04 荣成湾 范围 \ 0.07～0.28 23.50～48.60 8.40～30.60 17.40～51.10 45.10～97.30 \ 文献[35] 平均值 \ 0.15 33 19.2 34.1 64 \ 四十里湾 范围 7.01～23.56 0.01～0.04 4.07～32.52 1.36～5.02 13.77～26.36 1.92～16.88 0.00～0.02 文献[8,36] 平均值 11.7 0.03 \ 2.98 19.08 8.84 0.01 胶州湾 范围 5.30～19.00 0.03～0.11 5.00～51.00 4.20～28.00 5.10～18.00 12.00～58.00 0.01～0.05 文献[29,37] 平均值 11.15 0.06 22.14 11.99 10.31 31.3 0.03 桑沟湾 范围 4.44～9.12 0.23～0.54 \ 8.03～17.50 8.57～14.90 35.33～55.87 0.01～0.02 文献[38] 平均值 6.13 0.41 \ 12.86 11.82 46.43 0.02 龙口湾 范围 \ 0.26～0.50 \ 18.16～77.33 14.22～24.13 18.16～159.37 \ 文献[39] 平均值 \ 0.34 \ 33.13 18.95 79.19 \ 丁字湾 范围 3.26～24.00 0.02～0.30 22.50～85.80 3.20～21.50 2.10～23.60 8.00～76.40 0.00～0.04 文献[40] 平均值 8.38 0.08 60.96 11.49 15.31 46.42 0.02 沉积物质量一类标准值 20 0.5 80 35 60 150 0.2 文献[31] 沉积物质量二类标准值 65 1.5 150 100 130 350 0.5 注：“\”为无数据。
下载: 导出CSV
-
[1] ACHARY M S,PANIGRAHI S,SATPATHY K K,et al. Health risk assessment and seasonal distribution of dissolved trace metals in surface waters of Kalpakkam,southwest coast of Bay of Bengal[J]. Regional Studies in Marine Science,2016,6:96-108. doi: 10.1016/j.rsma.2016.03.017
[2] LI G G,HU B Q,BI J Q,et al. Heavy metals distribution and contamination in surface sediments of the coastal Shandong Peninsula (Yellow Sea)[J]. Marine Pollution Bulletin,2013,76(1):420-426.
[3] LYU J X,HU R J,WANG N,et al. Distribution and movement of heavy metals in sediments around the coastal areas under the influence of multiple factors:a case study from the junction of the Bohai Sea and the Yellow Sea[J]. Chemosphere,2021,278:130352. doi: 10.1016/j.chemosphere.2021.130352
[4] SERRANO O,MATEO M A,DUEÑAS-BOHÓRQUEZ A,et al. The Posidonia oceanica marine sedimentary record:a Holocene archive of heavy metal pollution[J]. Science of the Total Environment,2011,409(22):4831-4840. doi: 10.1016/j.scitotenv.2011.08.001
[5] XU F J,LIU Z Q,CAO Y C,et al. Assessment of heavy metal contamination in urban river sediments in the Jiaozhou Bay catchment,Qingdao,China[J]. Catena,2017,150:9-16. doi: 10.1016/j.catena.2016.11.004
[6] ZHAO J R,CHU F Y,JIN X L,et al. The spatial multiscale variability of heavy metals based on factorial kriging analysis:a case study in the northeastern Beibu Gulf[J]. Acta oceanologica Sinica,2015,34(12):137-146. doi: 10.1007/s13131-015-0768-7
[7] YANG L J,MA X C,LUAN Z D,et al. The spatial-temporal evolution of heavy metal accumulation in the offshore sediments along the Shandong Peninsula over the last 100 years:anthropogenic and natural impacts[J]. Environmental Pollution,2021,289:117894. doi: 10.1016/j.envpol.2021.117894
[8] ZHAO M W,WANG E K,XIA P,et al. Distribution and pollution assessment of heavy metals in the intertidal zone environments of typical sea areas in China[J]. Marine Pollution Bulletin,2019,138:397-406. doi: 10.1016/j.marpolbul.2018.11.050
[9] 徐刚,刘健,孔祥淮,等. 近海沉积物重金属污染来源分析[J]. 海洋地质前沿,2012,28(11):47-52.
XU G,LIU J,KONG X H,et al. Analysis of sources of heavy metal pollution in near-shore sediments[J]. Marine Geology Frontiers,2012,28(11):47-52.
[10] 贾磊,刘文涛,唐得昊,等. 三亚湾及周边海域表层沉积物重金属分布特征及生态风险评价[J]. 海洋地质前沿,2020,36(12):22-31.
JIA L,LIU W T,TANG D H,et al. Distribution characteristics and ecological risk assessment of heavy metals in surface sediments in Sanya Bay and surrounding waters[J]. Marine Geology Frontiers,2020,36(12):22-31.
[11] GU X,XIN M,WANG J,et al. Historical records of trace metals in two sediment cores of Jiaozhou Bay,North China[J]. Marine Pollution Bulletin,2022,175:113400. doi: 10.1016/j.marpolbul.2022.113400
[12] 何彦龙,袁一鸣,王腾,等. 典型半封闭海湾生态敏感性评估方法研究:以惠州市大亚湾海域为例[J]. 亚热带资源与环境学报,2022,17(3):49-56.
HE Y L,YUAN Y M,WANG T,et al. Study on the evaluation method of ecological sensitivity of typical semi closed bay:a case study of Daya Bay[J]. Journal of Subtropical Resources and Environment,2022,17(3):49-56.
[13] 段云莹,裴绍峰,廖名稳,等. 莱州湾表层沉积物重金属分布特征、污染评价与来源分析[J]. 海洋地质与第四纪地质,2021,41(6):67-81.
DUAN Y Y,PEI S F,LIAO M W,et al. Spatial distribution of heavy metals in the surface sediments of Laizhou Bay and their sources and pollution assessment[J]. Marine Geology & Quaternary Geology,2021,41(6):67-81.
[14] 杨立平,张学超,李晓敏,等. 威海湾沉积物重金属含量分布及其潜在生态危害评价[J],海洋科学. 2010,34(6):39-43.
YANG L P,ZHANG X C,LI X M,et al. Distribution features and evaluation on potential ecological risk of heavy metals in surface sediments of Weihai Bay[J]. Marine Sciences,2010,34(6):39-43.
[15] WU Z,LIU L L,ZHANG X X,et al. Distribution and pollution assessment of heavy metals in surface sediments along the Weihai coast,China[J]. Marine Pollution Bulletin,2023,190:114885. doi: 10.1016/j.marpolbul.2023.114885
[16] ZHU Y T,ZHU L H,LIU T,et al. Sediment grain size and heavy metal pollution characteristics in the mud deposit area offshore the Shandong Peninsula before 5 000 years[J]. Earth and Environmental Science,2021,621(1):12084.
[17] 郝榕荣,杨怡红,朱龙海,等. 环境敏感因子在威海湾沉积环境中的应用比较[J]. 沉积学报,2023,41(3):763-777.
HAO R R,YANG Y H,ZHU L H,et al. Application of environmentally sensitive factors in bay sedimentary environments[J]. Acta Sedimentologica Sinica,2023,41(3):763-777.
[18] 钟伟,朱龙海,吴建政,等. 威海湾夏季上升流现象及其对悬浮体输运的影响[J]. 海洋地质与第四纪地质,2020,40(5):58-67.
ZHONG W,ZHU L H,WU J Z,et al. Summer upwelling current in Weihai Bay and its contribution to transportation of suspended matters[J]. Marine Geology & Quaternary Geology,2020,40(5):58-67.
[19] ACEVEDO-FIGUEROA D,JIMÉNEZ B D,RODRÍGUEZ-SIERRA C J. Trace metals in sediments of two estuarine lagoons from Puerto Rico[J]. Environmental Pollution,2006,141(2):336-342. doi: 10.1016/j.envpol.2005.08.037
[20] LIU J,SAITO Y,KONG X H,et al. Geochemical characteristics of sediment as indicators of post-glacial environmental changes off the Shandong Peninsula in the Yellow Sea[J]. Continental Shelf Research,2009,29(7):846-855. doi: 10.1016/j.csr.2009.01.002
[21] MULLER G. Index of geoaccumulation in sediments of the Rhine River[J]. Geojournal,1969,3(2):108-118.
[22] HAKANSON L. An ecological risk index for aquatic pollution control:a sedimentological approach[J]. Water Research,1980,14(8):975-1001. doi: 10.1016/0043-1354(80)90143-8
[23] 陈明,蔡青云,徐慧,等. 水体沉积物重金属污染风险评价研究进展[J]. 生态环境报,2015,24(6):1069-1074.
CHEN M,CAI Q Y,XU H,et al. Research progress of risk assessment of heavy metals pollution in water body sediments[J]. Ecology and Environmental Sciences,2015,24(6):1069-1074.
[24] YOUNG M S,ISHIGA H,ROSER P B,et al. Geochemistry of sediments in three sectors of Trincomalee Bay,Sri Lanka:provenance,modifying factors and present environmental status[J]. Journal of Soils and Sediments,2014,14(1):204-217. doi: 10.1007/s11368-013-0798-8
[25] XU F J,HU B Q,DOU Y G,et al. Prehistoric heavy metal pollution on the continental shelf off Hainan Island,South China Sea:from natural to anthropogenic impacts around 4.0 kyr BP[J]. The Holocene,2017,28(3):455-463.
[26] LI A N,HAN Z Z,WU X,et al. How did the climate and human activities modulate the sedimentary evolution of the central Yellow Sea mud,China[J]. Journal of Asian Earth Sciences,2022,235:105299. doi: 10.1016/j.jseaes.2022.105299
[27] KRITSANANUWAT R,KUMAR S S,FUKUSHI M,et al. Distribution of rare earth elements,thorium and uranium in Gulf of Thailand’s sediment[J]. Environmental Earth Sciences,2014,73(7):3361-3374.
[28] SHAH S B. Heavy Metals in Scleractinian Corals[M]. Berlin:Springer Briefs in Earth Sciences,2021:14.
[29] 张栋华,吕钊臻,邵主峰,等. 胶州湾沉积物柱状样重金属垂向分布特征及其控制因素[J]. 海洋环境科学,2020,39(5):664-669. doi: 10.12111/j.mes.20190090
ZHANG D H,LYU Z Z,SHAO Z F,et al. The vertical distribution patterns of heavy metals in a sediment core of the Jiaozhou Bay and their controlling factors[J]. Marine Environmental Science,2020,39(5):664-669. doi: 10.12111/j.mes.20190090
[30] SUN X S,HU L M,SUN X,et al. Mercury burial in modern sedimentary systems of the East China marginal seas:the role of coastal oceans in global mercury cycling[J]. Global Biogeochemical Cycles,2023,37(9):e2023GB007760. doi: 10.1029/2023GB007760
[31] 中华人民共和国国家质量监督检验检疫总局. GB 18668—2002,海洋沉积物质量[S]. 北京:中国标准出版社,2004.
General Administration of Quality Supervision,Inspection and Quarantine of the People’s Republic of China. GB 18668—2002 Marine Sediment Quality[S]. Beijing:China Standard Press,2004.
[32] WANG Y,LING M,LIU R H,et al. Distribution and source identification of trace metals in the sediment of Yellow River Estuary and the adjacent Laizhou Bay[J]. Physics and Chemistry of the Earth,2017,97:62-70. doi: 10.1016/j.pce.2017.02.002
[33] 崔毅,辛福言,马绍赛,等. 乳山湾沉积物重金属污染及其生态危害评价[J]. 中国水产科学,2005,12(1):83-90. doi: 10.3321/j.issn:1005-8737.2005.01.015
CUI Y,XIN F Y,MA S S,et al. Pollution of heavy metals in sediments and its evaluation of potential ecological harm in Rushan Bay,Shandong Peninsula[J]. Journal of Fishery Sciences of China,2005,12(1):83-90. doi: 10.3321/j.issn:1005-8737.2005.01.015
[34] 徐林波,高勤峰,董双林,等. 靖海湾重金属污染及铅稳定同位素溯源研究[J]. 环境科学,2013,34(2):476-483.
XU L B,GAO Q F,DONG S L,et al. Study on heavy metal contaminations and the sources of Pb pollution in Jinghai Bay using the stable isotope technique[J]. Environmental Science,2013,34(2):476-483.
[35] HUANG L L,PU X M,PAN J F,et al. Heavy metal pollution status in surface sediments of Swan Lake lagoon and Rongcheng Bay in the northern Yellow Sea[J]. Chemosphere,2013,93(9):1957-1964. doi: 10.1016/j.chemosphere.2013.06.080
[36] WANG C C,PAN D W,HAN H T,et al. Distribution and contamination assessment of arsenic and mercury in surface sediments from the intertidal zone of Yantai Sishili Bay,China[J]. Human and Ecological Risk Assessment,2018,24(8):2024-2035. doi: 10.1080/10807039.2018.1436435
[37] WANG X C,FENG H,MA H Q. Assessment of metal contamination in surface sediments of Jiaozhou Bay,Qingdao,China[J]. Clean-Soil,Air,Water,2007,35(1):62-70. doi: 10.1016/j.marpolbul.2018.02.008
[38] 蒋增杰,方建光,张继红,等. 桑沟湾沉积物重金属含量分布及潜在生态危害评价[J]. 农业环境科学学报,2008,27(1):301-305.
JIANG Z J,FANG J G,ZHANG J H,et al. Distribution features and evaluation on potential ecological risk of heavy metals in surface sediments of Sungo Bay[J]. Journal of Agro-Environment Science,2008,27(1):301-305.
[39] 任鹏. 龙口湾海区沉积环境研究[D]. 青岛:青岛大学,2016:42.
REN P. Study on sedimentary environment of Longkou Bay[D]. Qingdao:Qingdao University,2016:42.
[40] 顾效源,孔祥淮,王伟,等. 山东丁字湾表层沉积物重金属分布及污染评价[J]. 海洋地质前沿,2019,35(3):13-21.
GU X Y,KONG X H,WANG W,et al. Distribution and environment assessment of heavy metals in the sediments of Dingzi Bay,Shandong Province[J]. Marine Geology Frontiers,2019,35(3):13-21.
[41] 刘素美,张经. 沉积物中重金属的归一化问题:以Al为例[J]. 东海海洋,1998,16(3):49-56.
LIU S M,ZHANG J. Normalization of heavy metals to aluminum in marine sediments[J]. Donghai Marine Science,1998,16(3):49-56.
[42] TANSEL B,RAFIUDDIN S. Heavy metal content in relation to particle size and organic content of surficial sediments in Miami River and transport potential[J]. International Journal of Sediment Research,2016,31(4):324-329. doi: 10.1016/j.ijsrc.2016.05.004
[43] ZHOU X,SUN L G,LIU Y,et al. Detection and calibration of anthropogenic lead emission in coastal sediments of China during the past 250 years[J]. Environmental Science and Pollution Research International,2015,22(20):16164-16172. doi: 10.1007/s11356-015-4702-5
[44] YANG Z K,SUI H L,ZHANG Y A,et al. Reconstruction,assessment,and calibration of potential toxic elements (PTEs) in a 3 500-year-long sedimentary record off the northern coast of Shandong Peninsula,China[J]. Environmental Pollution,2022,312:120075. doi: 10.1016/j.envpol.2022.120075
[45] 蒋佳. 两汉气候变化与农业的发展[D]. 长沙:湖南大学,2016:17-20.
JIANG J. Climate change and agricultural development in Han Dynasty[D]. Changsha:Hunan University,2016:17-20.
[46] 郁通. 黄、东海陆架沉积物中重金属污染的长期记录与评价[D]. 青岛:青岛科技大学,2014:43.
YU T. Long-term record and evaluation of heavy metal pollution in the sediments of the Yellow Sea and the East China Sea continental shelf[D]. Qingdao:Qingdao University of Science and Technology,2014:43.
[47] 何中发,杨守业,赵宝成,等. 长江口地区近1500年以来沉积物重金属含量变化及其对流域环境响应[J]. 海洋地质与第四纪地质,2019,39(2):21-30.
HE Z F,YANG S Y,ZHAO B C,et al. Changes in heavy metal elements in the sediments from Changjiang Estuary and their environmental responses in recent 1500 years[J].Marine Geology & Quaternary Geology,2019,39(2):21-30.
-
