Sedimentary distribution model and oil & gas geological significance of oolitic limestone in Feixianguan Formation of the Paleo-Central Depression in Northern Sichuan
-
摘要:
四川盆地北部古中坳陷飞仙关组是天然气高产层位，其中，白云化鲕粒灰岩是优质储层，其发育受沉积相的控制。深入研究鲕粒灰岩的沉积特征、分布模式有助于指导该区天然气的勘探与开发。为区分飞仙关组具体的沉积相带，利用研究区Q1井岩石取芯资料，通过偏光显微镜对岩石薄片进行观察。观察结果表明，研究区包含6类鲕粒，主要以表鲕、方解石变晶鲕为主，其次为真鲕、负鲕、白云石变晶鲕以及少量的复鲕。各类鲕粒在不同深度段混杂沉积，主要富集于泥晶鲕粒灰岩、泥晶含云鲕粒灰岩、亮晶鲕粒灰岩中。鲕粒的产出特征及其镜下特征分析结果认为，鲕粒沉积于有障壁海岸的台地环境，其沉积微相包含鲕粒滩、鲕滩生物礁、潮汐通道、生屑滩、潟湖泥和静水泥共6类，其中，鲕粒见于鲕粒滩、鲕滩生物礁和潮汐通道这3类微相中。根据沉积相划分结果，白云石变晶鲕沉积在开阔台地相带内的浪基面附近，多富集在泥晶含云鲕粒灰岩中。亮晶鲕粒灰岩包含所有鲕粒类型；泥晶鲕粒灰岩仅含方解石变晶鲕和负鲕，可以指示潮汐通道微相，作为局限台地相的判断标志；泥晶含云鲕粒灰岩中的变晶鲕均呈白云石变晶特征，归属于开阔台地相。沉积相的确立有利于还原研究区的古地理环境，进而判断优质储层的位置，为测井解释评价和油气开采提供可靠依据。
Abstract:The Feixianguan Formation in the Paleo-Central Depression of the Northern Sichuan Basin hosts high-yield quality natural gas reservoirs in the dolomitized oolitic limestone under the control of sedimentary facies. Understanding the sedimentary characteristics and distribution patterns of the oolitic limestone could help guide the exploration and development of natural gas in this area. Specific sedimentary facies zones of the Feixianguan Formation were distinguished using rock core from Well Q1 in the study area via microscopic thin-section observation. Results indicate that the study area contains 6 types of ooids, mainly surface ooids and calcitic-metacrystic ooids, followed by true ooids, “negative ooids” (or hollow ooids due to selective dissolution after oolite formation), dolomitic-metacrystic ooids, and some complex ooids. Various types of ooids were mixed and deposited at different depths, enriched in mainly micritic-oolitic limestone, micritic dolomictic-oolitic limestone, and oolitic sparite. The analysis on the occurrence and microscopic characteristics of ooids suggested that the ooids were deposited in a platform environment with barrier coasts, and their sedimentary microfacies include 6 types: ooid beach, oolitic biological reef, tidal channel, bioclastic beach, lagoon ooze, and stagnant water ooze. Ooids were found in 3 types of microfacies: ooid beach, oolitic biological reef, and tidal channel. Classification of sedimentary facies showed that metacrystic ooids were deposited near wave base in open platform, and enriched mostly in micritic dolomictic-oolitic limestone. The oolitic sparite contains all types of ooids, while the micritic dolomictic-oolitic limestone contains only calcitic-metacrystic oolites and “negative oolites”, indicating tidal channel microfacies and restricted platform facies. The metacrystic ooids in the dolomictic-oolitic limestone are characteristic of dolomitic metacrysts, representing open platform facies. The establishment of sedimentary facies is beneficial for paleogeographic reconstruction of the study area, thereby determining the location of quality productive reservoirs, and providing reliable basis for logging data interpretation and evaluation for effective oil and gas extraction.
-
-
表 1 Q2井飞仙关组气测显示记录
Table 1. Gas logging record of the Feixianguan Formation in Well Q2
序号 层位/m 井段 岩性 气测显示 1 4 932.00～4 935.79 飞三—飞一段 褐灰色灰岩 气侵 2 4 941.00～4 944.59 飞三—飞一段 灰色灰岩 气测异常 3 4 964.00～4 968.00 飞三—飞一段 褐灰色含云灰岩 气测异常 4 4 975.00～4 981.50 飞三—飞一段 褐灰色含云灰岩 气测异常
下载: 导出CSV
表 2 Q2井飞仙关组测井综合解释成果
Table 2. Comprehensive log interpretation of the Feixianguan Formation in Well Q2
井段/m 厚度/m 孔隙度/% 含水饱和度/% 解释结论 岩性 微相 亚相 相 4933.6 ～4936.5 2.9 2.0～2.3 19～32 差气层 泥晶鲕粒灰岩 潮汐通道 局限台地 有障壁海岸 4960.0 ～4973.5 13.5 2.0～2.4 13～17 差气层 泥晶含云灰岩 潟湖泥 开阔台地
下载: 导出CSV
-
[1] 马永生. 四川盆地普光超大型气田的形成机制[J]. 石油学报,2007,28(2):9-14. doi: 10.3321/j.issn:0253-2697.2007.02.002
MA Y S. Generation mechanism of Puguang Gas Field in Sichuan Basin[J]. Acta Petroleum Sinica,2007,28(2):9-14. doi: 10.3321/j.issn:0253-2697.2007.02.002
[2] 黄思静,佟宏鹏,刘丽红,等. 川东北飞仙关组白云岩的主要类型、地球化学特征和白云化机制[J]. 岩石学报,2009,25(10):2363-2372.
HUANG S J,TONG H P,LIU L H,et al. Petrography,geochemical and dolomitization mechanisms of Feixianguan dolomites in Triassic,NE Sichuan,China[J]. Acta Petrologica Sinica,2009,25(10):2363-2372.
[3] 张 新,梁子锐,汪建辉. 川东南涪陵地区上二叠统长兴组生物礁特征及分布规律[J]. 海洋地质前沿,2012,28(4):23-29.
ZHANG X,LIANG Z R,WANG J H. Distribution of the organic reefs in the Upper Permian Changxing Formation in Fuling area of Sortheastern Sichuan[J]. Marine Geology Frontiers,2012,28(4):23-29.
[4] 张延充,彭 才,杨 雨,等. 四川盆地飞仙关组高能鲕滩储层地震层序识别[J]. 天然气工业,2010,30(3):8-11, 125-126.
ZHANG Y C,PENG C,YANG Y,et al. Identification of seismic sequences of high-energy oolitic beach reservoirs in the Feixianguan Formation in the Sichuan Basin[J]. Natural Gas Industry,2010,30(3):8-11, 125-126.
[5] 刘宝珺,许效松,徐 强,等. 东秦岭柞水-镇安地区泥盆纪沉积环境和沉积盆地演化[J]. 沉积学报,1990,8(4):3-12.
LIU B J,XU X S,XU Q,et al. Devonian sedimentary environment and basin evolution in Zhashui-Zhenan district eastern Qinling,China[J]. Acta Sedimentologica Sinica,1990,8(4):3-12.
[6] 吴 斌,肖世洪,冯明友. 川北地区飞仙关组储层形成与演化分析[J]. 重庆科技学院学报(自然科学版),2014,16(4):9-12.
WU B,XIAO S H,FENG M Y. A discussion of Feixianguan reservoir formation and evolution in North Sichuan[J]. Journal of Chongqing University of Science and Technology (Natural Science Edition),2014,16(4):9-12.
[7] 侯振学,王兴志,宋光建,等. 川北地区下三叠统飞仙关组优质鲕滩储层成岩演化序列[J]. 海相油气地质,2012,17(3):18-24. doi: 10.3969/j.issn.1672-9854.2012.03.003
HOU Z X,WANG X Z,SONG G J,et al. Diagenetic evolution sequence of lower Triassic Feixianguan excellent oolitic beach reservoir in Northern Sichuan Basin[J]. Marine origin petroleum geology,2012,17(3):18-24. doi: 10.3969/j.issn.1672-9854.2012.03.003
[8] SARG J F. The sequence stratigraphy,sedimentology,and eco-nomic importance of evaporite-carbonate transitions:a review[J]. Sedimentary Geology,2001,140(1):9-34.
[9] 张 新,唐德海,汪建辉. 古海相致密碳酸盐岩储层描述技术:以川东南涪陵南部地区飞仙关组三段鲕粒灰岩为例[J]. 海洋地质前沿,2017,33(9):60-65.
Reservoir description for marine carbonate rock:a case study of oolitic limestone in 3rd member of Feixianguan Formation in south Fuling area of southeast Sichuan[J]. Marine Geology Frontiers,2017,33(9):60-65.
[10] BOLILA S,GALBRUN B,MILLER K G,et al. On the origin of Cenozoic and Mesozoic “third-order” eustatic sequences[J]. Earth-Science Reviews,2011,109(3/4):94-112.
[11] BAIOUMY H,OMRAN M,FABRITIUS T. Mineralogy,geochemistry and the origin of high-phosphorus oolitic iron ores of Aswan,Egypt[J]. Ore Geology Reviews,2017,80:185-199. doi: 10.1016/j.oregeorev.2016.06.030
[12] 刘建强. 川东北地区飞仙关组鲕滩分布规律[D]. 成都:西南石油大学,2012.
Oolitic-shoal distribution pattern of Feixianguan Formation,northeastern Sichuan area[D]. Chengdu:Southwest Petroleum University,2012.
[13] 颜 磊. 川北米仓山前缘二叠系—三叠系礁滩相储层特征及发育模式研究[D]. 成都:成都理工大学,2009.
YAN L. Study on characteristics and development model of Permian-Triassic reef-shallow reservoir in the front edge of Micang mountain,Northern Sichuan Basin[D]. Chengdu:Chengdu University of Technology,2009.
[14] BORCHERT H. Genesis of marine sedimentary iron ores[J]. Transactions of the Institution of Mining and Metallurgy,1960,69:261-279.
[15] KNOX R W O B. Chamosite ooliths from the Winter Gill ironstone(Jurassic)of Yorkshire,England[J]. Journal of Sedimentary Petrology,1970,40(4):1216-1225.
[16] 许 光. 四川盆地东北缘三叠纪构造体制转换与多种能源矿产成藏(矿)特征研究[D]. 北京:中国地质大学(北京),2019.
XU G. Research on transformation of tectonic framwork in the northeast Sichuan Basin on Triassic and it’s control of multi minerals deposition[D]. Beijing:China University of Geosciences (Beijing ),2019.
[17] LI F,YAN J X,CHEN Z Q,et al. Global oolite deposits across the Permian-Triassic boundary:a synthesis and implications for palaeoceanography immediately after the End-Permian biocrisis[J]. Earth Science Reviews,2015,149:163-180.
[18] 李朋威,周川闽,金廷福,等. 太原西山七里沟剖面本溪组铁质鲕粒成因探讨[J]. 沉积学报,2013,31(3):396-403.
LI P W,ZHOU C M,JIN T F,et al. Origin of the ferriferous ooids in the Benxi Formation at the Qiligou Section,Taiyuan Xishan[J]. Acta Sedimentologica Sinica,2013,31(3):396-403.
[19] 倪子尧. 龙门山区甘溪中泥盆统养马坝组铁质鲕粒沉积成因分析[D]. 成都:成都理工大学,2020.
NI Z Y. Genetic analysis of iron oolitic deposition in the Middle Devonian Yangmaba Formation in Ganxi prolife,Beichuan County,Longmenshan area[D]. Chengdu:Chengdu University of Technology,2020.
[20] 倪子尧,徐绪东,陈政安,等. 龙门山地区北川石沟里泥盆系养马坝组铁质鲕粒沉积及其环境分析[J]. 沉积学报,2019,37(4):702-712.
NI Z Y,XU X D,CHENG Z A,et al. The iron oolitic deposits and environmental analysis of the Devonian Yangmaba Formation in Shigouli prolife,Beichuan county,Longmenshan area[J]. Acta Sedimentologica Sinica,2019,37(4):702-712.
-
