Diagenesis and prediction of high quality reservoirs in the Oligocene Weizhou Formation in the Weixi’nan Sag of the Beibu Gulf Basin, South China Sea
-
摘要:
为探究南海北部湾盆地涠西南凹陷涠洲组碎屑岩成岩作用及优质储层发育规律，以涠洲X油田涠洲组三段为例，通过薄片鉴定、扫描电镜分析、阴极发光和成岩数值模拟等方法，深入分析成岩作用类型及机理、成岩演化序列、成岩相划分，并开展优质储层主控因素分析及优选。结果表明：研究区涠三段储层压实作用中等，以点-线或线接触为主；胶结作用以不同类型黏土矿物为主，总体处于中成岩A12-A21微期有利阶段；研究区经历了酸性和碱性溶蚀作用，以典型高岭石和绿泥石酸-碱性溶蚀作用产物最为突出；分流河道A11微期高岭石和分流河道A12微期高岭石沉积-成岩相是研究区优质储层发育相带。
Abstract:To explore the diagenesis and development pattern of quality reservoirs in the Weizhou Formation in the Weixi'nan Sag, Beibu Gulf Basin, South China Sea, taking the Third Member of the Oligocene Weizhou Formation in the Weizhou X Oilfield as an example, the types and mechanisms of diagenesis, the sequence of diagenetic evolution, and the division and distribution of diagenetic facies were analyzed in depth through techniques such as thin section microscopy identification, scanning electron microscopy, cathodoluminescence, and numerical simulation of diagenesis. The main controlling factors and selection of quality reservoirs were determined. Results show that the compaction effect of the reservoir in the Third Member is moderate showing mainly point-line or line-line contact. Different types of clay minerals were involved in the cementation process, which occurred in mainly the favorable stage of A12-A21 micro-facies of diagenesis. The research area has experienced acidic and then alkaline dissolution and the most prominent products are the acid-alkaline dissolution products of typical kaolinite and chlorite. The sedimentary diagenetic micro-facies of A12 in distributary channel are the favorite zones of development of quality reservoirs in the study area.
-
Key words:
- diagenesis /
- sedimentary diagenetic facies /
- high quality reservoir /
- Weizhou Formation /
- Weixi'nan Sag
-
-
表 1 涠三段不同沉积微相控制下的砂体孔渗统计
Table 1. Statistic of sand porosity and permeability in different sedimentary microfacies of theThird Member of the Oligocene Weizhou Formation (Ew3)
沉积微相 渗透率/10−3 μm2 孔隙度/% 分下分流河道
水下分流河道侧缘
水下分流间湾
注：
。
下载: 导出CSV
表 2 涠三段不同成岩相典型特征对比
Table 2. Comparison of typical characteristics of different diagenetic facies in the Third Member of the Oligocene Weizhou Formation (Ew3)
A11高岭石成岩相 A12绿泥石成岩相 A12高岭石成岩相 A21高岭石成岩相 储层类型 Ⅰ类 Ⅱ类 Ⅰ类 Ⅱ类 典型井 B33S1 A5、4 A5 A7 埋深/m 2 300～2 400 2 400～2 500（A5）
2 600～2 700（4）2 500～2 600 2 700～3 000 成岩阶段 A11 A12 A12 A21 黏土矿物 高岭石为主 绿泥石为主 高岭石为主 高岭石为主 沉积微相 分流河道 分流河道 分流河道 分流河道为主，混有河道侧缘和分流间湾 颗粒粒度/Φ 3.1 2.67 2.67 2.68 分选系数 1.85 2.97 2.97 4 孔隙度/% 19.1 12.5 16.7 15 渗透率/10−3 μm2 127.1 10.3 119.9 16.7
下载: 导出CSV
-
[1] 赵顺兰,赵亚卓,陈传福,等. 北部湾盆地涠西南凹陷缓坡类型及油气特征[J]. 天然气技术与经济,2018,12(1):8-12. doi: 10.3969/j.issn.2095-1132.2018.01.002
ZHAO S L,ZHAO Y Z,CHEN C F,et al. Oil and gas characteristics in gentle slopes,Weixi'nan Sag,Beibuwan Basin[J]. Natural Gas Technology and Economy,2018,12(1):8-12. doi: 10.3969/j.issn.2095-1132.2018.01.002
[2] 李友川,兰 蕾,王 柯,等. 北部湾盆地流沙港组湖相烃源岩的差异[J]. 石油学报,2019,40(12):1451-1459.
LI Y C,LAN L,WANG K,et al. Differences in lacustrine source rocks of Liushagang Formation in the Beibuwan Basin[J]. Acta Petrolei Sinica,2019,40(12):1451-1459.
[3] 叶加仁,赵牛斌,杨宝林,等. 涠西南凹陷流沙港组烃源岩生产力及发育模式[J]. 地质科技通报,2020,39(1):105-113.
YE J R,ZHAO N B,YANG B L,et al. Productivity and development model of source rock of the Liushagang Formation in the Weixi'nan Sag[J]. Bulletin of Geological Science and Technology,2020,39(1):105-113.
[4] 郇金来,孟元林,武景龙,等. 涠西南凹陷X油田中块渐新统储层碳酸盐胶结物特征及孔隙演化模式[J]. 海洋地质前沿,2023,39(7):13-24.
HUAN J L,MENG Y L,WU J L,et al. Carbonate cement characteristics and porosity evolution model of the Oligocene reservoir in the middle block of X Oilfield in Weixi'nan Sag[J]. Marine Geology Frontiers,2023,39(7):13-24.
[5] 郇金来,漆智,杨朝强,等. 莺歌海盆地东方区黄流组一段储层成岩作用机理及孔隙演化[J]. 地质科技情报,2016,35(1):87-93.
HUAN J L,QI Z,YANG Z Q,et al. Diagenesis mechanism and porosity evolution of the First Member of Huangliu Formation reservoirs in Dongfang area,Yinggehai Basin[J]. Geological Science and Technology Information,2016,35(1):87-93.
[6] 孟元林,胡越,李新宁,等. 致密火山岩物性影响因素分析与储层质量预测:以马朗-条湖凹陷条湖组为例[J]. 石油与天然气地质,2014,35(2):244-252.
MENG Y L,HU Y,LI X N,et al. Controlling factors on physical property of tight volcanic rocks and reservoir quality prediction:a case study of the Tiaohu Formation in Marlang-Tiaohu Sag[J]. Oil & Gas geology,2014,35(2):244-252.
[7] 孟元林,张磊,曲国辉,等. 异常低压背景下储集层成岩特征:以渤海湾盆地辽河坳陷西部凹陷南段古近系为例[J]. 石油勘探与开发,2016,43(4):669-674.
MENG Y L,ZHANG L,QU G H,et al. Diagenetic characteristics under abnormally low pressure:a case from the Paleocene of southern Western Sag of Liaohe Depression,Bohai Bay Basin[J]. Petroleum Exploration and Development,2016,43(4):669-674.
[8] 吴仕玖,范彩伟,招湛杰,等. 莺歌海盆地乐东区碳酸盐胶结物成因及地质意义[J]. 地球科学,2019,44(8):2686-2694.
WU S J,FAN C W,ZHAO Z J,et al. Origin of carbonate cement in reservoirs of Ledong area,Yinggehai Basin and its geological significance[J]. Earth Science,2019,44(8):2686-2694.
[9] 张青青,刘可禹,衡立群,等. 珠江口盆地番禺A油田珠江组“顶钙”发育特征、成因与分布模式[J]. 地球科学,2021,46(5):1783-1796.
ZHANG Q Q,LIU K Y,HENG L Q,et al. Characteristics and genetic distribution model of top calcareous cementation layers within Zhujiang Formation in Panyu A Oilfield,Pearl River Mouth Basin[J]. Earth Science,2021,46(5):1783-1796.
[10] 姜平,王珍珍,邹明生,等. 文昌A凹陷珠海组砂岩碳酸盐胶结物发育特征及其对储层质量的影响[J]. 地球科学,2021,46(2):600-620.
JIANG P,WANG Z Z,ZOU M S,et al. Development characteristics of carbonate cement and its influence on reservoir quality in sandstones from Zhuhai Formation in Wenchang A Depression[J]. EarthScience,2021,46(2):600-62.
[11] 唐海忠,魏军,周在华,等. 酒泉盆地营尔凹陷深层下沟组砂岩方解石胶结物特征[J]. 天然气地球科学,2019,30(5):652-661.
TANG H Z,WEI J,ZHOU Z H,et al. Characteristics of calcite cements in deep Xiagou Formation sandstones of Ying'er Depression,Jiuquan Basin[J]. Natural Gas Geoscience,2019,30(5):652-661.
[12] 郇金来,孟元林,吴其林,等. 北部湾盆地涠西南凹陷涠洲组黏土矿物异常转化对储层质量的影响[J]. 岩石矿物学杂志,2023,42(5):711-722.
HUAN J L,MENG Y L,WU Q L,et al. Influence of abnormal transformation of clay minerals on reservoir quality in Weizhou Formation,Weixi'nan Sag,Beibuwan Basin[J]. Acta Petrologica et Mineralogica,2023,42(5):711-722.
[13] 陈国松,孟元林,郇金来,等. 自生绿泥石对储集层质量影响的定量评价:以北部湾盆地涠西南凹陷涠洲组三段为例[J]. 古地理学报,2021,23(3):640-650.
CHEN G S,MENG Y L,HUAN J L,et al. Quantitative evaluation of impact of authigenic chlorite on reservoir quality:a case study of the Member 3 of Weizhou Formation in Weixi'nan Sag,Beibu Gulf Basin[J]. Journal of Palaeogeography,2021,23(3):640-650.
[14] 许月明,袁丙龙,张辉,等. 北部湾盆地涠洲X油田涠洲组三段储层物性特征与影响因素[J]. 东北石油大学学报,2020,44(3):46-56.
XU Y M,YUAN B L,ZHANG H,et al. Reservoir physical characteristics and influencing factors of the Third Member of Weizhou Formation in Weizhou 12-X Oilfield,Beibu Gulf Basin[J]. Journal of Northeast Petroleum University,2020,44(3):46-56.
[15] 陈国松. 砂岩储层异常高渗带的成因及分布预测[D]. 大庆:东北石油大学,2022.
CHEN G S. Origin and distribution prediction of abnormally high permeability zones in sandstone reservoirs[D]. Daqing:Northeast Petroleum University,2022.
[16] 刘平,李文龙,唐圣明,等. 北部湾盆地雷东凹陷主控断层发育特征及其形成机制[J]. 海洋地质前沿,2017,33(2):48-55.
LIU P,LI W L,TANG S M,et al. Development and forming mechanism of major faults in Leidong Sag,Beibuwan Basin[J]. Marine Geology Frontiers,2017,33(2):48-55.
[17] WALDERHAUG O,ELIASSEN A,AASE N E. Prediction of permeability in quartz-rich sandstones:examples from the Norwegian continental shelf and the Fontainebleau Sandstone[J]. Journal of Sedimentary Research,2012,82(11):899-912.
[18] 不同地质时期孔隙度预测方法[P]. 中国:发明专利,CN202010508448.X,2020.
Porosity prediction method for different geological periods [P]. China:Invention Patent,CN202010508448.X, 2020
[19] 孟元林,张磊,陶士振,等. 碎屑岩成岩阶段细分与应用:以松辽盆地齐家-古龙地区为例[J]. 中国矿业大学学报,2020,49(5):920-930.
MENG Y L,ZHANG L,TAO S Z,et al. The subsection of diagenetic stages in clastic rocks and applications:a case study of Qijia-Gulong area of Songliao Basin[J]. Journal of China University of Mining & Technology,2020,49(5):920-930.
[20] CHEN G S,MENG Y L,HUAN J L,et al. Distribution and origin of anomalously high permeability zones in Weizhou Formation,Weizhou X Oilfield,Weixi'nan Sag,China[J]. Earth Science Informatics,2021,14:2003-2015.
[21] 应凤祥, 何东博, 龙玉梅, 等. SY/T5477—2003,中国石油行业标准-碎屑岩成岩阶段划分[S].北京:石油工业出版社,2003.
YING F X, HE D B, LONG Y M, et al. SY/T5477-2003, Chinese petroleum industry standard - Classification of diagenetic stages of detrital rocks[S]. Beijing: Petroleum Industry Press, 2003.
-
