Distribution characteristics and origin analysis of iron and manganese in groundwater in Beijing Plain Area
-
摘要:
地下水是北京市供水的重要来源，地下水中铁、锰超标会限制水资源的开发利用。为了查明北京市平原区高铁、锰地下水的分布与成因，以平原区第四系地下水和沉积物为研究对象，基于X射线荧光光谱，铁、锰分步提取技术，利用地学数理统计、GIS空间特征等分析方法，探讨地下水中铁、锰的空间分布，地球化学特征及来源。结果表明：（1）研究区域地下水中铁的质量浓度范围为0.02～26.70 mg/L，均值为0.76 mg/L；锰的质量浓度范围为0.01～5.24 mg/L，均值为0.21 mg/L。（2）地下水中铁、锰浓度分布规律基本吻合，总体上呈现出沿着地下水流向（自西北向东南）浓度逐渐升高、随采样深度增加浓度逐渐降低的趋势。（3）典型区域沉积物中铁的质量比范围为
9.25～52.18 g/kg ，均值为19.90 g/kg ；锰的质量比范围为0.12～7.26 g/kg，均值为0.50 g/kg，沉积物中铁、锰以残余态为主，分别占总量的92.3%和86.6%。（4）尽管沉积物中铁、锰质量比没有表现出与地下水中铁、锰浓度相似的分布规律，但地下水铁、锰高值区内2 个钻孔中活性组分铁占比与地下水中铁浓度呈正相关关系（R=0.66，P>0.05）、活性组分锰与地下水中锰浓度呈显著的正相关关系（R=0.84，P<0.05），可认为区域地下水中铁、锰的富集与沉积物中活性组分铁、锰有关，同时受缓慢的地下水径流速度、较高的黏土比重等水文地质条件，以及还原环境、酸碱度等因素的影响，人类活动不是造成地下水中铁、锰超标的主导因素。研究结果可为北京市地下水资源开发和管理提供科学依据。Abstract:Groundwater is an important part of Beijing’s water supply, excessive ferric and manganese in groundwater will limit the development and utilization of water resources. The spatial distribution, geochemical characteristics, and sources of ferric and manganese in groundwater were analyzed based on X-ray fluorescence spectrometry, iron and manganese step extraction method, geological statistical analysis, and GIS spatial feature analysis. Results show that the iron concentration in groundwater in the study area ranged from 0.02 to 26.7 mg/L, with an average of 0.76 mg/L, and the manganese concentration ranged from 0.01 to 5.24 mg/L, with an average of 0.21 mg/L. The distributions of iron and manganese in groundwater were basically consistent, showing a trend of gradually increasing along the groundwater flow direction (from northwest to southeast) and gradually decreasing with the increase of sampling depth. The mass ratio of iron in the deposits ranged from 9.25 to 52.18 g/kg, with an average of 19.90 g/kg, while the mass ratio of manganese ranged from 0.12 to 7.26 g/kg, with an average of 0.50 g/kg. The mass ratios of iron and manganese in the sediments in the whole city did not show a distribution pattern similar to that in groundwater. However, there were positive correlations between the proportion of active component iron and the iron in groundwater (R=0.66, P>0.05), and between the content of active component manganese and the manganese concentration in groundwater (R=0.84, P<0.05). It can be considered that the enrichments of iron and manganese in groundwater in the study area are related to the active components of iron and manganese in sediments. They are affected by hydrogeological conditions such as slow groundwater runoff rate, high clay specific gravity, reduction environment, and pH. Human activities are not the main factors that cause excessive iron and manganese in groundwater. This study provides valuable guidance for the local government in improving the management and utilization of groundwater resources.
-
Key words:
- iron /
- manganese /
- groundwater /
- sediment /
- speciation /
- Beijing Plain
-
-
图 6 铁浓度超标点位地下水c（
${\bf{NO}}_{\boldsymbol{3}}^{\boldsymbol{-}} $ ）/c（Na+）、c（${\bf{SO}}_{\boldsymbol{4}}^{{\boldsymbol{2-}}} $ ）/c（0.5Na+）关系Figure 6.
表 1 不同钻孔铁、锰质量比水平汇总
Table 1. Iron and manganese contents in different boreholes
/（g·kg−1） 钻孔 含水层 铁 锰 沉积物 黏土层 非黏土层 沉积物 黏土层 非黏土层 K01 一层 23.25 25.92 22.10 0.56 0.63 0.53 K02 一层 16.34 15.98 13.89 0.28 0.24 0.23 二层 14.35 26.70 11.26 0.23 0.42 0.18 三层 18.22 36.94 13.54 0.31 0.56 0.25 四层 21.07 19.02 21.58 0.33 0.25 0.35 均值 17.62 23.56 15.34 0.29 0.37 0.26 K03 一层 19.66 30.52 12.42 0.25 0.37 0.18 二层 13.89 13.89 0.22 0.22 三层 21.30 25.52 19.20 0.36 0.13 0.32 四层 21.64 25.56 16.42 1.36 2.16 0.28 均值 20.27 26.79 15.92 0.67 1.28 0.26 注：表中空白表示该层位未检测黏土层样品。
下载: 导出CSV
表 2 2 个钻孔不同赋存态铁、锰质量比占比
Table 2. Proportions of Fe and Mn in different occurrences in two boreholes
/% 钻孔 指标 F1 F2 F3 F4 F5 F6 K02 铁 0.00 0.99 4.25 1.88 1.54 91.35 锰 2.82 4.12 5.25 0.92 0.88 86.01 K03 铁 0.00 0.84 2.80 1.74 1.50 93.11 锰 3.37 4.55 3.38 0.78 0.88 87.04
下载: 导出CSV
表 3 水化学参数统计表
Table 3. Statistics of hydrochemical parameters and proportional coefficients of equivalent concentrations
含水层 ρ（Fe）
/（ mg·L−1）pH ORP
/（mV）TDS
/（ mg·L−1）ρ（ ${\mathrm{HCO}}_3^- $ ）
/（ mg·L−1）c （Ca2++Mg2+）/
c （0.5${\mathrm{HCO}}_3^- $ +${\mathrm{SO}}_4^{2-} $ ）CAI-Ⅰ CAI-Ⅱ 第一层 ≤0.3 7.66 66.8 822 387 1.06 −0.79 −0.07 >0.3 7.59 −35.2 960 542 0.89 −1.50 −0.13 第二层 ≤0.3 7.70 61.6 721 379 0.96 −1.80 −0.11 >0.3 7.75 −36.8 747 452 0.81 −3.80 −0.20 第三、四层 ≤0.3 7.99 30.0 488 285 0.67 −4.54 −0.36 >0.3 7.94 −48.1 627 380 0.64 −4.83 −0.35 注：表中c为物质的量浓度。
下载: 导出CSV
-
[1] REHMAN I U,ISHAQ M,ALI L,et al. Enrichment,spatial distribution of potential ecological and human health risk assessment via toxic metals in soil and surface water ingestion in the vicinity of Sewakht mines,district Chitral,Northern Pakistan[J]. Ecotoxicology and Environmental Safety,2018,154:127 − 136. doi: 10.1016/j.ecoenv.2018.02.033
[2] HERNDON E M,HAVIG J R,SINGER D M,et al. Manganese and iron geochemistry in sediments underlying the redox-stratified Fayetteville Green Lake[J]. Geochimica et Cosmochimica Acta,2018,231:50 − 63. doi: 10.1016/j.gca.2018.04.013
[3] 王小松,李宝学,李阳,等. 北京通州区第四系地下水化学特征及其成因分析[J]. 灌溉排水学报,2022,41(3):92 − 97. [WANG Xiaosong,LI Baoxue,LI Yang,et al. Hydrochemistry of groundwater in quaternary aquifers in Tongzhou of Beijing and the underlying determinants[J]. Journal of Irrigation and Drainage,2022,41(3):92 − 97. (in Chinese with English abstract)]
WANG Xiaosong, LI Baoxue, LI Yang, et al. Hydrochemistry of groundwater in quaternary aquifers in Tongzhou of Beijing and the underlying determinants[J]. Journal of Irrigation and Drainage, 2022, 41（3）: 92 − 97. （in Chinese with English abstract）
[4] 李圣品,李文鹏,殷秀兰,等. 全国地下水质分布及变化特征[J]. 水文地质工程地质,2019,46(6):1−8. [LI Shengpin,LI Wenpeng,YIN Xiulan,et al. Distribution and evolution characteristics of national groundwater quality from 2013 to 2017[J]. Hydrogeology & Engineering Geology,2019,46(6):1−8. (in Chinese with English abstract)]
LI Shengpin, LI Wenpeng, YIN Xiulan, et al. Distribution and evolution characteristics of national groundwater quality from 2013 to 2017[J]. Hydrogeology & Engineering Geology, 2019, 46（6）: 1−8. （in Chinese with English abstract）
[5] KSHETRIMAYUM K S,HEGEU H. The state of toxicity and cause of elevated Iron and Manganese concentrations in surface water and groundwater around Naga Thrust of Assam-Arakan basin,Northeastern India[J]. Environmental Earth Sciences,2016,75(7):604. doi: 10.1007/s12665-016-5372-4
[6] 蔡玲,胡成,陈植华,等. 江汉平原东北部地区高铁锰地下水成因与分布规律[J]. 水文地质工程地质,2019,46(4):18 − 25. [CAI Ling,HU Cheng,CHEN Zhihua,et al. Distribution and genesis of high Fe and Mn groundwater in the northeast of the Jianghan Plain[J]. Hydrogeology & Engineering Geology,2019,46(4):18 − 25. (in Chinese with English abstract)]
CAI Ling, HU Cheng, CHEN Zhihua, et al. Distribution and genesis of high Fe and Mn groundwater in the northeast of the Jianghan Plain[J]. Hydrogeology & Engineering Geology, 2019, 46（4）: 18 − 25. （in Chinese with English abstract）
[7] 傅雪梅,苏婧,孙源媛,等. 齐齐哈尔市高铁锰地下水分布特征及成因分析[J]. 干旱区资源与环境,2019,33(8):121 − 127. [FU Xuemei,SU Jing,SUN Yuanyuan,et al. Distribution characteristics and cause analysis of iron and manganese pollution in groundwater of Qiqihar city[J]. Journal of Arid Land Resources and Environment,2019,33(8):121 − 127. (in Chinese with English abstract)]
FU Xuemei, SU Jing, SUN Yuanyuan, et al. Distribution characteristics and cause analysis of iron and manganese pollution in groundwater of Qiqihar city[J]. Journal of Arid Land Resources and Environment, 2019, 33（8）: 121 − 127. （in Chinese with English abstract）
[8] 刘春燕,刘景涛,朱亮,等.高原河谷城市浅层地下水铁锰分布特征、影响因素及其对生态环境的影响——以西宁市为例[J].中国地质,2024,51(5):1776 − 1790. [LIU Chunyan,LIU Jingtao,ZHU Liang,et al. Distribution characteristics,influencing factors of Fe and Mn of shallow groundwater in the plateau valley city,Xining,Qinghai Province and its impacts of ecological environment[J]. Geology in China,2024,51(5):1776−1790.(in Chinese with English abstract)]
LIU Chunyan, LIU Jingtao, ZHU Liang, et al. Distribution characteristics, influencing factors of Fe and Mn of shallow groundwater in the plateau valley city, Xining, Qinghai Province and its impacts of ecological environment[J]. Geology in China, 2024, 51(5): 1776−1790.（in Chinese with English abstract）
[9] GALHARDI J A,BONOTTO D M. Hydrogeochemical features of surface water and groundwater contaminated with acid mine drainage (AMD) in coal mining areas:A case study in southern Brazil[J]. Environmental Science and Pollution Research International,2016,23(18):18911 − 18927. doi: 10.1007/s11356-016-7077-3
[10] 徐庆勇,赵微,赵杰,等. 北京市平原区地下水环境监测网运2022年年度报告[R]. 北京:北京市水文地质工程地质大队,2022. [Xu Qingyong,Zhao Wei,Zhao Jie,et al. Annual report of Beijing plain area groundwater environment monitoring network 2022 [R]. Beijing:Beijing Hydrogeology Engineering Geology Group,2022. (in Chinese)]
Xu Qingyong, Zhao Wei, Zhao Jie, et al. Annual report of Beijing plain area groundwater environment monitoring network 2022 [R]. Beijing: Beijing Hydrogeology Engineering Geology Group, 2022. （in Chinese）
[11] 谢振华,刘凯,李志萍,等. 基于沉积物物质来源的地下水化学特征分析:以北京市平原区为例[J]. 地学前缘,2010,17(6):81 − 87. [XIE Zhenhua,LIU Kai,LI Zhiping,et al. Analysis of groundwater chemical characteristics based on sediment provenance analysis:A case study of Beijing Plain[J]. Earth Science Frontiers,2010,17(6):81 − 87. (in Chinese with English abstract)]
XIE Zhenhua, LIU Kai, LI Zhiping, et al. Analysis of groundwater chemical characteristics based on sediment provenance analysis: A case study of Beijing Plain[J]. Earth Science Frontiers, 2010, 17（6）: 81 − 87. （in Chinese with English abstract）
[12] 王新娟,周训. 北京市永定河流域地下水14C年龄的初步分析[J]. 地质论评,2006,52(2):283 − 288. [WANG Xinjuan,ZHOU Xun. A preliminary analysis of the14C age of groundwater in the Yongdinghe River Plain in Beijing[J]. Geological Review,2006,52(2):283 − 288. (in Chinese with English abstract)]
WANG Xinjuan, ZHOU Xun. A preliminary analysis of the14C age of groundwater in the Yongdinghe River Plain in Beijing[J]. Geological Review, 2006, 52（2）: 283 − 288. （in Chinese with English abstract）
[13] 徐庆勇,林健. 北京平原区浅层地下水演化的生态环境效应评价指标初探[J]. 城市地质,2021,16(1):56 − 61. [XU Qingyong,LIN Jian. Preliminary study on evaluation index of eco-environmental effect of shallow groundwater in Beijing plain area[J]. Urban Geology,2021,16(1):56 − 61. (in Chinese with English abstract)]
XU Qingyong, LIN Jian. Preliminary study on evaluation index of eco-environmental effect of shallow groundwater in Beijing plain area[J]. Urban Geology, 2021, 16（1）: 56 − 61. （in Chinese with English abstract）
[14] 陈吉吉,吴悦,陶蕾,等. 生态态补水对永定河沿岸地下水水位、水质的影响[J]. 地球与环境,2023,51(3):266 − 273. [Chen Jiji,WU Yue,Tao Lei,et al. Effects of ecological state replenishment on groundwater level and water quality along Yongding River [J]. Earth and Environment,2023,51(3):266 − 273. (in Chinese with English abstract)]
Chen Jiji, WU Yue, Tao Lei, et al. Effects of ecological state replenishment on groundwater level and water quality along Yongding River [J]. Earth and Environment, 2023, 51（3）: 266 − 273. （in Chinese with English abstract）
[15] 中华人民共和国生态环境部. 地下水环境监测技术规范:HJ 164—2020[S]. 北京:中国环境科学出版社,2020. [Ministry of Ecology and Environment of the People's Republic of China. Technical specifications for environmental monitoring of groundwater:HJ 164—2020[S]. Beijing:China Environmental Science Press,2020. (in Chinese)]
Ministry of Ecology and Environment of the People's Republic of China. Technical specifications for environmental monitoring of groundwater: HJ 164—2020[S]. Beijing: China Environmental Science Press, 2020. （in Chinese）
[16] 国家质量监督检验检疫总局,中国国家标准化管理委员会. 地下水质量标准:GB/T 14848—2017[S]. 北京:中国标准出版社,2017. [General Administration of Quality Supervision,Inspection and Quarantine of the People’s Republic of China,Standardization Administration of the People’s Republic of China. Standard for groundwater quality:GB/T 14848—2017[S]. Beijing:Standards Press of China,2017. (in Chinese)]
General Administration of Quality Supervision, Inspection and Quarantine of the People’s Republic of China, Standardization Administration of the People’s Republic of China. Standard for groundwater quality: GB/T 14848—2017[S]. Beijing: Standards Press of China, 2017. （in Chinese）
[17] EICHE E,NEUMANN T,BERG M,et al. Geochemical processes underlying a sharp contrast in groundwater arsenic concentrations in a village on the Red River delta,Vietnam[J]. Applied Geochemistry,2008,23(11):3143 − 3154. doi: 10.1016/j.apgeochem.2008.06.023
[18] 曾昭华. 四川省土壤元素含量和生态农业地质研究[J]. 四川地质学报,2005,25(1):44 − 50. [ZENG Zhaohua. A study of elemental contents in soil and ecologic and agricultural geology in Sichuan[J]. Acta Geologica Sichuan,2005,25(1):44 − 50. (in Chinese with English abstract)]
ZENG Zhaohua. A study of elemental contents in soil and ecologic and agricultural geology in Sichuan[J]. Acta Geologica Sichuan, 2005, 25（1）: 44 − 50. （in Chinese with English abstract）
[19] 张超莹. 青岛王圈水库铁锰存在形态和释放规律的研究[D]. 青岛:中国海洋大学,2013. [ZHang Chaoying. Speciation and release behavior of of iron and manganese in the sediments of Wangquan Reservoir,Qingdao [D]. Qingdao:Ocean University of China,2013. (in Chinese with English abstract)]
ZHang Chaoying. Speciation and release behavior of of iron and manganese in the sediments of Wangquan Reservoir, Qingdao [D]. Qingdao: Ocean University of China, 2013. （in Chinese with English abstract）
[20] 胡昱欣,周瑞静,宋炜,等. 北京市丰台区永定河以东浅层地下水水化学演变规律及成因分析[J]. 环境科学,2024,45(5):2651 − 2664. [HU Yuxin,ZHOU Ruijing,SONG Wei,et al. Analysis on hydrochemical evolution of shallow groundwater east of Yongding River in Fengtai district,Beijing[J]. Environmental Science,2024,45(5):2651 − 2664. (in Chinese with English abstract)]
HU Yuxin, ZHOU Ruijing, SONG Wei, et al. Analysis on hydrochemical evolution of shallow groundwater east of Yongding River in Fengtai district, Beijing[J]. Environmental Science, 2024, 45（5）: 2651 − 2664. （in Chinese with English abstract）
[21] 张春潮,侯新伟,李向全,等. 三姑泉域岩溶地下水水化学特征及形成演化机制[J]. 水文地质工程地质,2021,48(3):62 − 71. [ZHANG Chunchao,HOU Xinwei,LI Xiangquan,et al. Hydrogeochemical characteristics and evolution mechanism of Karst groundwater in the catchment area of the Sangu Spring[J]. Hydrogeology & Engineering Geology,2021,48(3):62 − 71. (in Chinese with English abstract)]
ZHANG Chunchao, HOU Xinwei, LI Xiangquan, et al. Hydrogeochemical characteristics and evolution mechanism of Karst groundwater in the catchment area of the Sangu Spring[J]. Hydrogeology & Engineering Geology, 2021, 48（3）: 62 − 71. （in Chinese with English abstract）
[22] 吴吉春,张景飞. 水环境化学[M]. 北京:中国水利水电出版社,2009:2 − 5. [WU Jichun,ZHANG Jingfei. Water Environmental Chemistry[M]. Beijing:China Water & Power Press,2009:2 − 5. (in Chinese)]
WU Jichun, ZHANG Jingfei. Water Environmental Chemistry[M]. Beijing: China Water & Power Press, 2009: 2 − 5. （in Chinese）
[23] 李军,张翠云,蓝芙宁,等. 区域地下水不同深度微生物群落结构特征[J]. 中国环境科学,2019,39(6):2614 − 2623. [LI Jun,ZHANG Cuiyun,LAN Funing,et al. Structure characteristics of microbial community at different depths of groundwater[J]. China Environmental Science,2019,39(6):2614 − 2623. (in Chinese with English abstract)]
LI Jun, ZHANG Cuiyun, LAN Funing, et al. Structure characteristics of microbial community at different depths of groundwater[J]. China Environmental Science, 2019, 39（6）: 2614 − 2623. （in Chinese with English abstract）
[24] 余东,周金龙,陈劲松,等. 新疆喀什地区高铁锰地下水空间分布特征及成因分析[J]. 环境化学,2020,39(11):3235 − 3245. [YU Dong,ZHOU Jinlong,CHEN Jinsong,et al. Spatial distribution characteristics and genesis of groundwater with high iron and manganese content in Kashi Prefecture,Xinjiang[J]. Environmental Chemistry,2020,39(11):3235 − 3245. (in Chinese with English abstract)]
YU Dong, ZHOU Jinlong, CHEN Jinsong, et al. Spatial distribution characteristics and genesis of groundwater with high iron and manganese content in Kashi Prefecture, Xinjiang[J]. Environmental Chemistry, 2020, 39（11）: 3235 − 3245. （in Chinese with English abstract）
[25] 张虹,魏兴萍,彭名涛. 重庆市浅层地下水污染源解析与环境影响因素识别[J]. 环境科学研究,2021,34(12):2896 − 2906. [ZHANG Hong,WEI Xingping,PENG Mingtao. Analysis of pollution sources and identification of environmental influencing factors of shallow groundwater in Chongqing,China[J]. Research of Environmental Sciences,2021,34(12):2896 − 2906. (in Chinese with English abstract)]
ZHANG Hong, WEI Xingping, PENG Mingtao. Analysis of pollution sources and identification of environmental influencing factors of shallow groundwater in Chongqing, China[J]. Research of Environmental Sciences, 2021, 34（12）: 2896 − 2906. （in Chinese with English abstract）
[26] ZHAI Yuanzheng,MA Tianyi, ZHOU Jingjing,et al. Impacts of leachate of landfill on the groundwater hydrochemistry and size distributions and heavy metal components of colloids:A case study in NE China[J]. Environmental Science and Pollution Research,2019,26(6):5713 − 5723. doi: 10.1007/s11356-018-4053-0
[27] 吕晓立,刘景涛,周冰,等. 新疆塔城盆地地下水中铁锰分布特征及人类活动的影响[J]. 中国地质,2020,47(6):1765 − 1775. [LYU Xiaoli,LIU Jingtao,ZHOU Bing,et al. Fe and Mn distribution of groundwater in the Tacheng Basin,Xinjiang and its impact of human activities[J]. Geology in China,2020,47(6):1765 − 1775. (in Chinese with English abstract)]
LYU Xiaoli, LIU Jingtao, ZHOU Bing, et al. Fe and Mn distribution of groundwater in the Tacheng Basin, Xinjiang and its impact of human activities[J]. Geology in China, 2020, 47（6）: 1765 − 1775. （in Chinese with English abstract）
[28] 肖勇,莫培,尹世洋,等. 北京南郊平原地下水化学特征及成因分析[J]. 环境工程,2021,39(8):99 − 107. [XIAO Yong,MO Pei,YIN Shiyang,et al. Hydrochemical characteristics and genesis of groundwater in southern suburb of Beijing plain[J]. Environmental Engineering,2021,39(8):99 − 107. (in Chinese with English abstract)]
XIAO Yong, MO Pei, YIN Shiyang, et al. Hydrochemical characteristics and genesis of groundwater in southern suburb of Beijing plain[J]. Environmental Engineering, 2021, 39（8）: 99 − 107. （in Chinese with English abstract）
[29] 崔彤,程刚,华岚英,等. 北京市污染源监测年报[R]. 北京:北京市生态环境监测中心,2021. [Cui Tong,Cheng Gang,Hua Lanying,et al. Beijing pollution sources monitoring report[R]. Beijing:Beijing Ecological Environment Monitoring Center,2021. (in Chinese)]
Cui Tong, Cheng Gang, Hua Lanying, et al. Beijing pollution sources monitoring report[R]. Beijing: Beijing Ecological Environment Monitoring Center, 2021. （in Chinese）
-
