Analytical study of groundwater flow field and inrush flux distribution for deeply-buried circular arched tunnels
-
摘要:
近年来，随着我国交通工程、采掘工程、地下空间工程以及长距离引调水工程建设的不断发展，隧洞突涌水灾害发生越来越频繁。但是目前针对圆拱形隧洞围岩流场的解析研究较少，使用保角变换方法求解圆拱形深埋隧洞涌水量及围岩流场的解析解，探讨了圆拱隧洞洞壁涌水流速的分布规律。研究发现：在圆拱形隧洞洞壁附近，地下水流场受隧洞形状影响较为明显，而在远离洞壁处，隧洞形状对地下水流场的影响可等效为圆形隧洞；圆拱形隧洞洞壁涌水流速的最大值出现在底板左右两端的转折点（即洞底脚）附近，而流速最小值位于底板中心点；洞底脚流速可达底板中心点流速的3倍以上；隧洞截面形状越接近于圆形，洞壁各点涌水流速的相对差距越小。研究成果可为圆拱形隧洞涌水量预测及围岩地下水流场刻画提供理论依据，为隧洞施工方案设计以及防渗/排水措施设计提供有力支撑。
Abstract:With the development of transportation engineering, mining engineering, underground space engineering, and long-distance water diversion projects in China, the occurrence of tunnel water inrush disasters has become increasingly frequent. Due to the limited analytical study on the flow field of circular arched tunnels, an analytical solution for the water inrush and the flow field in the surrounding rock around a deep-buried circular arched tunnel was obtained using the conformal transformation method. Then the distribution of water inrush around the tunnel circumference was explored. The results reveal that the groundwater flow field near the tunnel is significantly influenced by the tunnel shape, while its influence on the groundwater flow field further away from the tunnel can be approximated as that of a tunnel with a circular cross-section. The maximum flow velocity around the circular arched tunnel occurs near the inflection points (i.e., the corners of the tunnel bottom), while the minimum flow velocity is located at the center of the tunnel floor. The flow velocity at the corners of the tunnel bottom can exceed three times the flow velocity at the center of the tunnel floor. As the tunnel shape approaches a circle, the relative differences of flow velocities at various points around the tunnel circumference gradually decrease. This study can provide a theoretical basis for estimating the water inrush flux and characterizing the groundwater flow field in the surrounding rock around circular arched tunnels, and support for tunnel construction planning and the design for tunnel groundwater seepage/drainage.
-
Key words:
- conformal mapping /
- tunnel /
- groundwater /
- groundwater inrush /
- seepage flow /
- analytic method
-
-
[1] 刘琛尧,晏启祥,孙润方,等. 基于三维离散-连续耦合的岩溶隧道突水破坏模式研究[J]. 水文地质工程地质,2024,51(2):163 − 171. [LIU Chenyao,YAN Qixiang,SUN Runfang,et al. Study on water inrush failure mode of Karst tunnel based on three-dimensional discrete-continuous coupling[J]. Hydrogeology & Engineering Geology,2024,51(2):163 − 171. (in Chinese with English abstract)]
LIU Chenyao, YAN Qixiang, SUN Runfang, et al. Study on water inrush failure mode of Karst tunnel based on three-dimensional discrete-continuous coupling[J]. Hydrogeology & Engineering Geology, 2024, 51（2）: 163 − 171. （in Chinese with English abstract）
[2] 全永威,王军,熊永润,等. 爆破扰动下TBM隧洞时滞型岩爆特征及影响机制研究[J]. 水文地质工程地质,2023,50(1):94 − 103. [QUAN Yongwei,WANG Jun,XIONG Yongrun,et al. A study of the characteristics and influence mechanism of time delayed rockburst in a TBM tunnel under the blasting disturbance[J]. Hydrogeology & Engineering Geology,2023,50(1):94 − 103. (in Chinese with English abstract)]
QUAN Yongwei, WANG Jun, XIONG Yongrun, et al. A study of the characteristics and influence mechanism of time delayed rockburst in a TBM tunnel under the blasting disturbance[J]. Hydrogeology & Engineering Geology, 2023, 50（1）: 94 − 103. （in Chinese with English abstract）
[3] GOODMAN R E,MOYE D G,SCHALKWYK A,et al. Ground water inflows during tunnel driving[J]. Engineering Geology,1965,2(1):29 − 56.
[4] LEI Shizhong. An analytical solution for steady flow into a tunnel[J]. Groundwater,1999,37(1):23 − 26. doi: 10.1111/j.1745-6584.1999.tb00953.x
[5] RAYMER J. Groundwater inflow into hard rock tunnels[J]. Tunnels & Tunnelling International,2005,33(9):50 − 53.
[6] KOLYMBAS D,WAGNER P. Groundwater ingress to tunnels–The exact analytical solution[J]. Tunnelling and Underground Space Technology,2007,22(1):23 − 27. doi: 10.1016/j.tust.2006.02.001
[7] 应宏伟,朱成伟,龚晓南. 考虑注浆圈作用水下隧道渗流场解析解[J]. 浙江大学学报(工学版),2016,50(6):1018 − 1023. [YING Hongwei,ZHU Chengwei,GONG Xiaonan. Analytic solution on seepage field of underwater tunnel considering grouting circle[J]. Journal of Zhejiang University (Engineering Science),2016,50(6):1018 − 1023. (in Chinese with English abstract)]
YING Hongwei, ZHU Chengwei, GONG Xiaonan. Analytic solution on seepage field of underwater tunnel considering grouting circle[J]. Journal of Zhejiang University （Engineering Science）, 2016, 50（6）: 1018 − 1023. （in Chinese with English abstract）
[8] PARK K H,OWATSIRIWONG A,LEE J G. Analytical solution for steady-state groundwater inflow into a drained circular tunnel in a semi-infinite aquifer:A revisit[J]. Tunnelling and Underground Space Technology,2008,23(2):206 − 209. doi: 10.1016/j.tust.2007.02.004
[9] 杜朝伟,王梦恕,谭忠盛. 水下隧道渗流场解析解及其应用[J]. 岩石力学与工程学报,2011,30(增刊2):3567 − 3573. [DU Zhaowei,WANG Mengshu,TAN Zhongsheng. Analytic solution for seepage field of subsea tunnel and its application[J]. Chinese Journal of Rock Mechanics and Engineering,2011,30(Sup 2):3567 − 3573. (in Chinese with English abstract)]
DU Zhaowei, WANG Mengshu, TAN Zhongsheng. Analytic solution for seepage field of subsea tunnel and its application[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30（Sup 2）: 3567 − 3573. （in Chinese with English abstract）
[10] 朱成伟,应宏伟,龚晓南. 任意埋深水下隧道渗流场解析解[J]. 岩土工程学报,2017,39(11):1984 − 1991. [ZHU Chengwei,YING Hongwei,GONG Xiaonan. Analytical solutions for seepage fields of underwater tunnels with arbitrary burial depth[J]. Chinese Journal of Geotechnical Engineering,2017,39(11):1984 − 1991. (in Chinese with English abstract)] doi: 10.11779/CJGE201711005
ZHU Chengwei, YING Hongwei, GONG Xiaonan. Analytical solutions for seepage fields of underwater tunnels with arbitrary burial depth[J]. Chinese Journal of Geotechnical Engineering, 2017, 39（11）: 1984 − 1991. （in Chinese with English abstract） doi: 10.11779/CJGE201711005
[11] YING Hongwei,ZHU Chengwei,SHEN Huawei,et al. Semi-analytical solution for groundwater ingress into lined tunnel[J]. Tunnelling and Underground Space Technology,2018,76:43 − 47. doi: 10.1016/j.tust.2018.03.009
[12] JIANG Chong,HAN Haixia,XIE Hansong,et al. Karst aquifer water inflow into tunnels:An analytical solution[J]. Geofluids,2021,2021:6672878.
[13] 李嘉诚,王渭明,吕显州,等. 爆破振动下海底隧道涌水量预测研究[J]. 水文地质工程地质,2023,50(4):127 − 136. [LI Jiacheng,WANG Weiming,LV Xianzhou,et al. Research on the prediction method of water gushing volume under the blasting vibration effect of a sub-sea tunnel[J]. Hydrogeology & Engineering Geology,2023,50(4):127 − 136. (in Chinese with English abstract)]
LI Jiacheng, WANG Weiming, LV Xianzhou, et al. Research on the prediction method of water gushing volume under the blasting vibration effect of a sub-sea tunnel[J]. Hydrogeology & Engineering Geology, 2023, 50（4）: 127 − 136. （in Chinese with English abstract）
[14] FRENELUS W,PENG Hui,ZHANG Jingyu. Evaluation methods for groundwater inflows into rock tunnels:A state-of-the-art review[J]. International Journal of Hydrology,2021,5(4):152 − 168. doi: 10.15406/ijh.2021.05.00277
[15] 吴建,周志芳,李鸣威,等. 隧洞涌水量预测计算方法研究进展[J]. 工程地质学报,2019,27(4):890 − 902. [WU Jian,ZHOU Zhifang,LI Mingwei,et al. Advance on the methods for predicting water inflow into tunnels[J]. Journal of Engineering Geology,2019,27(4):890 − 902. (in Chinese with English abstract)]
WU Jian, ZHOU Zhifang, LI Mingwei, et al. Advance on the methods for predicting water inflow into tunnels[J]. Journal of Engineering Geology, 2019, 27（4）: 890 − 902. （in Chinese with English abstract）
[16] BUTSCHER C. Steady-state groundwater inflow into a circular tunnel[J]. Tunnelling and Underground Space Technology,2012,32:158 − 167. doi: 10.1016/j.tust.2012.06.007
[17] 周亚峰. 水工隧洞渗流—应力—损伤/开裂耦合理论及方法研究[D]. 武汉:武汉大学,2016. [ZHOU Yafeng. Study on seepage-stress-damage/crack coupling theory and method for hydraulic tunnel[D]. Wuhan:Wuhan University,2016. (in Chinese with English abstract)]
ZHOU Yafeng. Study on seepage-stress-damage/crack coupling theory and method for hydraulic tunnel[D]. Wuhan: Wuhan University, 2016. （in Chinese with English abstract）
[18] STRACK O D L. Groundwater mechanics[M]. Englewood Cliffs:Prentice Hall,1989.
[19] 李永新,李向峰,鲁琴. 小浪底北岸灌区某隧洞F29断层承压水涌水数值模拟分析[J]. 资源环境与工程,2016,30(3):519 − 523. [LI Yongxin,LI Xiangfeng,LU Qin. Numerical simulation analysis on the north bank of the Xiaolangdi Dam irrigation area of F29 fault confined water gushing[J]. Resources Environment & Engineering,2016,30(3):519 − 523. (in Chinese with English abstract)]
LI Yongxin, LI Xiangfeng, LU Qin. Numerical simulation analysis on the north bank of the Xiaolangdi Dam irrigation area of F29 fault confined water gushing[J]. Resources Environment & Engineering, 2016, 30（3）: 519 − 523. （in Chinese with English abstract）
-
