Analysis of stability and kinematics of the dangerous rock mass in Zhangjiagou, Baoxing, Sichuan Province
-
摘要:
张家沟危岩体在2022年“6•1”芦山地震后被发现，稳定性差，严重威胁下方居民生命财产安全。基于稳定性计算及离散元数值分析方法对危岩体进行评价，选取稳定性最差的地震工况进行运动学分析，在上述研究基础上结合解析解与数值解成果设计相应防护措施。主要结论有：（1）张家沟危岩体结构破碎，顺坡向控制性结构面发育，破坏模式为滑移式；（2）稳定性计算与数值模拟结果皆表明张家沟危岩体在天然、暴雨、地震工况下均会失稳，其中地震工况下运动距离最长；（3）地震工况下危岩体的破坏模式为震裂—滑移式，运动过程中块石以滑移为主，跳高较小，同时坡面形态显著影响着落石运动特征；（4）落石间相互碰撞挤压会改变其运动特征及冲击动能大小，在一定程度上可增加致灾范围。成果可为类似灾害防治提供参考。
Abstract:After the “6 • 1” Lushan earthquake, unstable rock mass was discovered in Zhangjiagou, posing a severe threat to the safety of the residents and their property below. The dangerous rock mass was evaluated using stability calculation and the discrete element numerical analysis method, and the seismic condition with the highest threat level was selected for kinematic analysis. Based on this research, a combination of analytical solution and numerical solution was used to design corresponding protective measures. The main conclusions are as follows : (1) The structure of the unstable rock mass in Zhangjiagou is broken, and a controlling structural plane is developed along the slope. (2) The stability calculations and numerical simulations show that the Zhangjiagou unstable rock mass will become unstable under natural, rainstorm and seismic conditions, with the longest movement distance occurring during an earthquake. (3) The failure mode of the dangerous rock mass under seismic conditions is a shatter-slip type, where the rock mainly slips during movement, and the jump height is small. Additionally, the slope shape significantly affects the characteristics of rockfall movement. (4) The collision and extrusion between rockfalls can change their motion characteristics and impact kinetic energy, potentially increasing the scope of the disaster. The research results can provide a reference for similar disaster prevention and control efforts.
-
-
表 1 岩体力学基本参数取值（天然）
Table 1. Fundamental mechanical parameters of rock mass (natural)
岩性 密度/（kg·m−3） 节理刚度/MPa 内摩擦角/（°） 黏聚力/MPa 花岗岩 2750 47.5 11.2 基岩 2960 58.2 15.7 L1 2.2 30.5 0.8 L2 2.2 24.9 0.6 L3 2.2 25.3 0.7
下载: 导出CSV
表 2 稳定性计算参数选取
Table 2. Selection of calculation parameters for stability analysis
计算
工况重度/
（kN·m−3）后缘陡倾裂隙
深度/m裂隙或滑面充水
高度/m滑面长度/
m裂隙水压力/
（kN·m−1）软弱结构面
倾角/ （°）地震水平
系数结构面综合
黏聚力/MPa结构面综合
内摩擦角/（°）天然 26.95 6.68 1.96 25.32 19.2 45 0 0.65 31 暴雨 27.45 6.68 2.25 25.32 25.3 45 0 0.61 27 地震 26.95 6.68 1.96 25.32 19.2 45 0.16 0.65 31
下载: 导出CSV
表 3 稳定性计算结果
Table 3. Stability analysis calculation results
计算工况 破坏模式 稳定性系数 稳定状态 天然 滑移式 1.18 欠稳定 暴雨 滑移式 1.00 欠稳定 地震 滑移式 0.93 欠稳定
下载: 导出CSV
-
[1] 张倬元, 王士天, 王兰生. 工程地质分析原理[M]. 4版. 北京: 地质出版社, 2016: 1 − 5
ZHANG Zhuoyuan, WANG Shitian, WANG Lansheng. Principles of engineering geological analysis[M]. 4th ed. Beijing: Geological Publishing House, 2016: 1 − 5. （in Chinese）
[2] ASHWOOD W,HUNGR O. Estimating total resisting force in flexible barrier impacted by a granular avalanche using physical and numerical modeling[J]. Canadian Geotechnical Journal,2016,53(10):1700 − 1717. doi: 10.1139/cgj-2015-0481
[3] FAN X M,SCARINGI G,KORUP O,et al. Earthquake-induced chains of geologic hazards:patterns,mechanisms,and impacts[J]. Reviews of Geophysics,2019,57(2):421 − 503. doi: 10.1029/2018RG000626
[4] 梅雪峰. 落石冲击荷载作用下的桩板拦石墙-缓冲层组合结构动力响应[D]. 成都: 西南交通大学, 2022.
MEI Xuefeng. Dynamic response of pile-sheet retaining wall with cushion layer under rockfall impact[D]. Chengdu: Southwest Jiaotong University, 2022. （in Chinese with English abstract）
[5] 尹迪,董培育,曹建玲,等. 川滇地区地震危险性数值分析[J]. 地球物理学报,2022,65(5):1612 − 1627. [YIN Di,DONG Peiyu,CAO Jianling,et al. Numerical analysis of the seismic hazard in Sichuan-Yunnan region[J]. Chinese Journal of Geophysics,2022,65(5):1612 − 1627. (in Chinese with English abstract)
YIN Di, DONG Peiyu, CAO Jianling, et al. Numerical analysis of the seismic hazard in Sichuan-Yunnan region[J]. Chinese Journal of Geophysics, 2022, 65（5）: 1612-1627. （in Chinese with English abstract）
[6] MAERZ N H. New risk-consequence rockfall hazard rating system for Missouri highways using digital image analysis[J]. Environmental and Engineering Geoscience,2005,11(3):229 − 249. doi: 10.2113/11.3.229
[7] P BUDETTA, C DE LUCA ,M NAPPI. Quantitative rockfall risk assessment for an important road by means of the rockfall risk management (RO.MA.) method[J]. Bulletin of Engineering Geology and the Environment,2016,75(4):1377–1397.
[8] 杨志法,尚彦军,刘英. 关于岩土工程类比法的研究[J]. 工程地质学报,1997,5(4):299 − 305. [YANG Zhifa,SHANG Yanjun,LIU Ying. Study on the analogism in geotechnical engineering[J]. Journal of Engineering Geology,1997,5(4):299 − 305. (in Chinese with English abstract)
YANG Zhifa, SHANG Yanjun, LIU Ying. Study on the analogism in geotechnical engineering[J]. Journal of Engineering Geology, 1997, 5（4）: 299-305. （in Chinese with English abstract）
[9] 王玉锁,杨国柱. 隧道洞口段危岩落石风险评估[J]. 现代隧道技术,2010,47(6):33 − 39. [WANG Yusuo,YANG Guozhu. Rockfall risk assessment for a tunnel portal section[J]. Modern Tunnelling Technology,2010,47(6):33 − 39. (in Chinese with English abstract)
WANG Yusuo, YANG Guozhu. Rockfall risk assessment for a tunnel portal section[J]. Modern Tunnelling Technology, 2010, 47（6）: 33-39. （in Chinese with English abstract）
[10] 王新民,康虔,秦健春,等. 层次分析法-可拓学模型在岩质边坡稳定性安全评价中的应用[J]. 中南大学学报(自然科学版),2013,44(6):2455 − 2462. [WANG Xinmin,KANG Qian,QIN Jianchun,et al. Application of AHP-extenics model to safety evaluation of rock slope stability[J]. Journal of Central South University (Science and Technology),2013,44(6):2455 − 2462. (in Chinese with English abstract)
WANG Xinmin, KANG Qian, QIN Jianchun, et al. Application of AHP-extenics model to safety evaluation of rock slope stability[J]. Journal of Central South University （Science and Technology）, 2013, 44（6）: 2455-2462. （in Chinese with English abstract）
[11] 刘贺军,吴玉涛,李晓乐,等. 河北阜平县石滩地村危岩体变形破坏模式及稳定性分析[J]. 中国地质灾害与防治学报,2018,29(4):50 − 57. [LIU Hejun,WU Yutao,LI Xiaole,et al. Deformation failure mode and stability analysis of dangerous rock mass in Shitandi Village,Fuping County of Hebei Province[J]. The Chinese Journal of Geological Hazard and Control,2018,29(4):50 − 57. (in Chinese with English abstract)
LIU Hejun, WU Yutao, LI Xiaole, et al. Deformation failure mode and stability analysis of dangerous rock mass in Shitandi Village, Fuping County of Hebei Province[J]. The Chinese Journal of Geological Hazard and Control, 2018, 29（4）: 50-57. （in Chinese with English abstract）
[12] 邬爱清. 基于关键块体理论的岩体稳定性分析方法及其在三峡工程中的应用[J]. 长江科学院院报,2019,36(2):1 − 7. [WU Aiqing. Series methods of analyzing rock mass stability based on key block theory and their applications to Three Gorges project[J]. Journal of Yangtze River Scientific Research Institute,2019,36(2):1 − 7. (in Chinese with English abstract)
WU Aiqing. Series methods of analyzing rock mass stability based on key block theory and their applications to Three Gorges project[J]. Journal of Yangtze River Scientific Research Institute, 2019, 36（2）: 1-7. （in Chinese with English abstract）
[13] 陈宙翔,叶咸,张文波,等. 基于无人机倾斜摄影的强震区公路高位危岩崩塌形成机制及稳定性评价[J]. 地震工程学报,2019,41(1):257 − 267. [CHEN Zhouxiang,YE Xian,ZHANG Wenbo,et al. Formation mechanism analysis and stability evaluation of dangerous rock collapses based on the oblique photography by unmanned aerial vehicles[J]. China Earthquake Engineering Journal,2019,41(1):257 − 267. (in Chinese with English abstract)
CHEN Zhouxiang, YE Xian, ZHANG Wenbo, et al. Formation mechanism analysis and stability evaluation of dangerous rock collapses based on the oblique photography by unmanned aerial vehicles[J]. China Earthquake Engineering Journal, 2019, 41（1）: 257-267. （in Chinese with English abstract）
[14] 马显东, 周剑, 张路青, 等. 强震区公路沿线崩塌危岩体特征提取及失稳分析[J]. 岩石力学与工程学报, 2022, 41（增刊1）: 2901 − 2914
MA Xiandong, ZHOU Jian, ZHANG Luqing, et al. Feature extraction and instability analysis of dangerous rock mass along highway in meizoseismal areas[J]. Chinese Journal of Rock Mechanics and Engineering, 2022, 41（Sup 1）: 2901 − 2914. （in Chinese with English abstract）
[15] 刘宝臣,王良玉,曾榕,等. 桂林翻山危岩稳定性评价的离散元分析[J]. 科学技术与工程,2022,22(6):2409 − 2418. [LIU Baochen,WANG Liangyu,ZENG Rong,et al. Discrete element analysis of stability evaluation of Guilin Fanshan dangerous rock[J]. Science Technology and Engineering,2022,22(6):2409 − 2418. (in Chinese with English abstract) doi: 10.3969/j.issn.1671-1815.2022.06.034
LIU Baochen, WANG Liangyu, ZENG Rong, et al. Discrete element analysis of stability evaluation of Guilin Fanshan dangerous rock[J]. Science Technology and Engineering, 2022, 22（6）: 2409-2418. （in Chinese with English abstract） doi: 10.3969/j.issn.1671-1815.2022.06.034
[16] 刘国阳,孟海怡,宁宝宽,等. 基于三维非连续变形分析的巨石崩塌运动研究[J]. 岩土力学,2022,43(1):246 − 256. [LIU Guoyang,MENG Haiyi,NING Baokuan,et al. Study on collapse and movement of a boulder based on 3D discontinuous deformation analysis[J]. Rock and Soil Mechanics,2022,43(1):246 − 256. (in Chinese with English abstract)
LIU Guoyang, MENG Haiyi, NING Baokuan, et al. Study on collapse and movement of a boulder based on 3D discontinuous deformation analysis[J]. Rock and Soil Mechanics, 2022, 43（1）: 246-256. （in Chinese with English abstract）
[17] 王朋,贾洪彪,马淑芝,等. 梳妆台危岩体稳定性评价及落石运动特征研究[J]. 安全与环境工程,2022,29(4):139 − 146. [WANG Peng,JIA Hongbiao,MA Shuzhi,et al. Stability evaluation of dangerous rock mass in dressing table and study on characteristics of rockfall movement[J]. Safety and Environmental Engineering,2022,29(4):139 − 146. (in Chinese)
WANG Peng, JIA Hongbiao, MA Shuzhi, et al. Stability evaluation of dangerous rock mass in dressing table and study on characteristics of rockfall movement[J]. Safety and Environmental Engineering, 2022, 29（4）: 139-146. （in Chinese）
[18] 张青宇,唐世明,沈军辉. 四川麻柳沟地震崩塌落石运动特征分析[J]. 人民长江,2015,46(13):39 − 41. [ZHANG Qingyu,TANG Shiming,SHEN Junhui. Analysis of movement characteristics of collapse rockfall in Maliugou earthquake[J]. Yangtze River,2015,46(13):39 − 41. (in Chinese with English abstract)
ZHANG Qingyu, TANG Shiming, SHEN Junhui. Analysis of movement characteristics of collapse rockfall in Maliugou earthquake[J]. Yangtze River, 2015, 46（13）: 39-41. （in Chinese with English abstract）
[19] 王栋,王剑锋,李天斌,等. 西南山区某铁路隧道口高位落石三维运动特征分析[J]. 地质力学学报,2021,27(1):96 − 104. [WANG Dong,WANG Jianfeng,LI Tianbin,et al. Analysis of three-dimensional movement characteristics of rockfall:A case study at a railway tunnel entrance in the southwestern mountainous area,China[J]. Journal of Geomechanics,2021,27(1):96 − 104. (in Chinese with English abstract)
WANG Dong, WANG Jianfeng, LI Tianbin, et al. Analysis of three-dimensional movement characteristics of rockfall: a case study at a railway tunnel entrance in the southwestern mountainous area, China[J]. Journal of Geomechanics, 2021, 27（1）: 96-104. （in Chinese with English abstract）
[20] 李源亮,郭阿龙. 高风险落石运动分析及边坡防护综合设计[J]. 长江科学院院报,2022,39(9):65 − 70. [LI Yuanliang,GUO Along. Analysis of highly risky rockfall movement and comprehensive design of slope protection[J]. Journal of Yangtze River Scientific Research Institute,2022,39(9):65 − 70. (in Chinese with English abstract)
LI Yuanliang, GUO Along. Analysis of highly risky rockfall movement and comprehensive design of slope protection[J]. Journal of Yangtze River Scientific Research Institute, 2022, 39（9）: 65-70. （in Chinese with English abstract）
[21] 柳万里,晏鄂川,魏鹏飞,等. 落石运动特征试验及影响因素敏感性分析[J]. 山地学报,2021,39(1):47 − 58. [LIU Wanli,YAN Echuan,WEI Pengfei,et al. Experimental study on rockfall and sensitivity analysis of influencing factors[J]. Mountain Research,2021,39(1):47 − 58. (in Chinese with English abstract)
LIU Wanli, YAN Echuan, WEI Pengfei, et al. Experimental study on rockfall and sensitivity analysis of influencing factors[J]. Mountain Research, 2021, 39（1）: 47-58. （in Chinese with English abstract）
[22] 黎尤,何坤,胡卸文,等. 震裂山体崩塌形成特征及运动学三维模拟—以汶川县三官庙村崩塌为例[J]. 工程地质学报,2022,30(2):542 − 552. [LI You,HE Kun,HU Xiewen,et al. Formation characteristics and kinematics 3-D simulation of rockfall evolved from shattered mountain:Case study of Sanguanmiao village rockfall in Wenchuan County[J]. Journal of Engineering Geology,2022,30(2):542 − 552. (in Chinese with English abstract)
LI You, HE Kun, HU Xiewen, et al. Formation characteristics and kinematics 3-d simulation of rockfall evolved from shattered mountain—case study of Sanguanmiao village rockfall in Wenchuan County[J]. Journal of Engineering Geology, 2022, 30（2）: 542-552. （in Chinese with English abstract）
[23] 蔡国军,陈锡锐,尹保国,等. 岩体力学参数对反倾边坡稳定性影响的数值模拟研究[J]. 人民珠江,2020,41(9):25 − 31. [CAI Guojun,CHEN Xirui,YIN Baoguo,et al. Numerical simulation study on influence of rock mass mechanical parameters on stability of anti-dip slope[J]. Pearl River,2020,41(9):25 − 31. (in Chinese with English abstract)
CAI Guojun, CHEN Xirui, YIN Baoguo, et al. Numerical simulation study on influence of rock mass mechanical parameters on stability of anti-dip slope[J]. Pearl River, 2020, 41（9）: 25-31. （in Chinese with English abstract）
[24] ASTERIOU P,SAROGLOU H,TSIAMBAOS G. Geotechnical and kinematic parameters affecting the coefficients of restitution for rock fall analysis[J]. International Journal of Rock Mechanics and Mining Sciences,2012,54:103 − 113. doi: 10.1016/j.ijrmms.2012.05.029
[25] 蔡国军,陈锡锐,孙文鹏,等. 强震作用下斜坡表面放大效应的三维离散元模拟[J]. 地质科技通报,2022,41(2):104 − 112. [CAI Guojun,CHEN Xirui,SUN Wenpeng,et al. Three-dimensional discrete element simulation of the amplification effect of the slope surface under the action of strong earthquakes[J]. Bulletin of Geological Science and Technology,2022,41(2):104 − 112. (in Chinese with English abstract)
CAI Guojun, CHEN Xirui, SUN Wenpeng, et al. Three-dimensional discrete element simulation of the amplification effect of the slope surface under the action of strong earthquakes[J]. Bulletin of Geological Science and Technology, 2022, 41（2）: 104-112. （in Chinese with English abstract）
[26] 唐建辉. 隧道洞口坡面落石运动特性及冲击明洞作用机理研究[D]. 成都: 西南交通大学, 2022.
TANG Jianhui. Study on movement characteristics of rockfall on the slope of tunnel portal and the mechanism of impacting open cut tunnel[D]. Chengdu: Southwest Jiaotong University,2022. （in Chinese with English abstract）
[27] 宋德光, 吴瑞安, 马德芹, 等. 四川泸定昔格达组滑坡灾害运动过程模拟分析[J]. 地质通报,2023,42(12):2185 − 2197. [SONG Deguang, WU Ruian, MA Deqin, et al. Simulation analysis of landslide disaster movement process in Xigeda Formation, Luding County, Sichuan Province[J]. Geological Bulletin of China,2023,42(12):2185 − 2197. (in Chinese with English abstract)
SONG Deguang, WU Ruian, MA Deqin, et al. Simulation analysis of landslide disaster movement process in Xigeda Formation, Luding County, Sichuan Province[J]. Geological Bulletin of China, 2023, 42(12): 2185-2197.(in Chinese with English abstract)
[28] 庞鑫, 袁明, 卢渊, 等. 基于无人机LiDAR仿地飞行技术的高陡边坡危岩体快速识别方法[J]. 地质科技通报,2023,42(6):21 − 30. [PANG Xin, YUAN Ming, LU Yuan, et al. Rapid identification method for the dangerous rock mass of a high-steep slope based on UAV LiDAR and ground imitation flight[J]. Bulletin of Geological Science and Technology,2023,42(6):21 − 30. (in Chinese with English abstract)
PANG Xin, YUAN Ming, LU Yuan, et al. Rapid identification method for the dangerous rock mass of a high-steep slope based on UAV LiDAR and ground imitation flight[J]. Bulletin of Geological Science and Technology, 2023, 42(6): 21-30.(in Chinese with English abstract)
-
