Study on the stability evaluation method of fuzzy mathematical landslide improved by entropy weight method
-
摘要:
滑坡是中国最为常见的一种地质灾害类型，其具有的易发、频发特点使得人民的生命财产安全受到了严重的威胁，滑坡的稳定性评价是滑坡防灾减灾工作中最为关键的一项工作。鉴于滑坡诱发因素具有模糊性的特点，文章以陕西省勉县新铺镇发育的典型堆积层滑坡为例，在地质环境条件分析的基础上，考虑了采用模糊数学法进行滑坡稳定性评价，并引入热力学中“熵”的概念，采用熵权法确定了滑坡诱发因子的权重，进而提出了一种基于熵权法改进的模糊数学滑坡稳定性评价新方法。结果表明：新提出的基于熵权法改进的模糊数学滑坡稳定性评价方法克服了传统模糊综合评价方法主观性判断滑坡影响因子权重的弊端；通过数值模拟法进行滑坡稳定性定量化分析验证，发现两种方法评价结论较为吻合，说明了所提出的新方法具有一定的可靠性。基于熵权法改进的模糊数学滑坡稳定性评价方法较为快速简捷，可用于临灾快速预警、应急救援等突发情况下的滑坡防灾减灾工作。
Abstract:Landslide are one of the most common types of geological disasters in China, posing a serious threat to the safety of people's lives and properties due to their propensity and frequency. The stability assessment of landslides is crucial in landslide disaster prevention and mitigation works. Considering the fuzzy nature of landslide inducing factors, a certain accumulation layer landslide in Xinpu Town, Mianxian County is taken as an example in this article. Based on the analysis of geological environmental conditions, a fuzzy mathematical method is employed for landslide stability assessment. The concept of "entropy" from thermodynamics is introduced, and the entropy weight method is used to determine the weights of landslide inducing factors. Consequently, a new method for landslide stability assessment based on the improved entropy weighting method in fuzzy mathematics is proposed. The results show that the proposed method overcomes the subjectivity in determining the weights of landslide influencing factors in traditional fuzzy comprehensive evaluation methods. Validation through quantitative analysis of landslide stability using numerical simulation method found that the evaluation conclusions of the two methods were in good consistent, indicating the reliability of the proposed new method. The improved fuzzy mathematical landslide stability assessment based on entropy weighting method is relatively fast and simple, making it suitable for landslide disaster prevention and mitigation works in emergency situations such as rapid disaster warning of impending disasters and emergency rescue.
-
-
表 1 新铺镇地区滑坡稳定性评价指标数据
Table 1. Data of landslide stability evaluation indicators in Xinpu Town area
滑坡名称 平均坡度/（°） 斜坡结构 堆积层厚度/m 切坡高度/m 风化程度 距水系距离/m 坡体高差/m 距道路距离/m 坡形 杜家山滑坡 31 4 3.5 4 7 50 51 50 1 舒家坝滑坡 44 3 1.5 2 7 300 17.1 100 5 枣树湾滑坡 40 1 6 2 9 300 80 100 1 古墓坪滑坡 28 4 6.5 3 7 500 56 100 5 郑家营四组滑坡 38 4 8 2.5 7 300 53 50 3 花石崖滑坡 35 4 8 4 7 500 60 50 3 马家梁滑坡 26 3 10 3.5 1 300 75 50 1 塘子湾滑坡 34 4 3 1 7 500 25 50 1 钦家坝滑坡 35 2 6 3 9 300 65 50 3 余家坪滑坡 33 1 7.5 7 7 50 95 50 1 注：斜坡结构按照（逆向坡、块状坡）=1、近水平层状坡=2、横向坡=3、斜向坡=4、顺向坡=5划分；风化程度按照未风化=1、微风化=3、中风化=5、强风化=7、全风化=9划分；坡形按照直线形=1、凹形=3、凸形=5划分；上述描述按照赋值从小到大的顺序进行排列。
下载: 导出CSV
表 2 滑坡稳定性评价指标体系及分级标准
Table 2. Indicator system and grading standards for landslide stability evaluation
稳定性分级 平均坡度/（°） 斜坡结构 堆积层厚度/m 切坡高度/m 风化程度 距水系距离/m 坡体高差/m 距道路距离/m 坡形 稳定 [0, 25) [0, 2) [0, 1) [0, 6) [0, 4) [300, ∞) [0, 50) [300, ∞) [0, 2] 基本稳定 [45, 90) [2, 3) [9, ∞) [6, 12) [4, 6) [100, 300) [50, 100) [100, 300) [2, 3] 欠稳定 [25, 35) [3, 4) [1, 3)∪[6, 9) [12, 25) [6, 8) [50, 100) [100, 300) [50, 100) [3, 4] 不稳定 [35, 45) [4, 5) [3, 6) [25, ∞) [8, 10) [0, 50) [300, ∞) [0, 50) [4, 5]
下载: 导出CSV
-
[1] 李媛,杨旭东,尹春荣,等. 中国地质灾害时空分布及防灾减灾[M]. 北京:地质出版社,2019. [LI Yuan,YANG Xudong,YIN Chunrong,et al. Spatial-temporal distribution and disaster prevention and mitigation of geological disasters in China [M]. Beijing:Geological Publishing House,2019. ( in Chinese)]
LI Yuan, YANG Xudong, YIN Chunrong, et al. Spatial-temporal distribution and disaster prevention and mitigation of geological disasters in China ［M］. Beijing: Geological Publishing House, 2019. （ in Chinese） [2] 贾雨霏,魏文豪,陈稳,等. 基于SOM-I-SVM耦合模型的滑坡易发性评价[J]. 水文地质工程地质,2023,50(3):125 − 137. [JIA Yufei,WEI Wenhao,CHEN Wen,et al. Landslide susceptibility assessment based on the SOM-I-SVM model[J]. Hydrogeology & Engineering Geology,2023,50(3):125 − 137. (in Chinese with English abstract)]
JIA Yufei, WEI Wenhao, CHEN Wen, et al . Landslide susceptibility assessment based on the SOM-I-SVM model［J］. Hydrogeology & Engineering Geology,2023 ,50 （3 ）:125 −137 . （in Chinese with English abstract）[3] 冯凡,唐亚明,潘学树,等. 不同尺度下地质灾害风险评价方法探讨——以陕西吴堡县为例[J]. 中国地质灾害与防治学报,2022,33(2):115 − 124. [FENG Fan,TANG Yaming,PAN Xueshu,et al. An attempt of risk assessment of geological hazards in different scales:a case study in Wubao County of Shaanxi Province[J]. The Chinese Journal of Geological Hazard and Control,2022,33(2):115 − 124. (in Chinese with English abstract)]
FENG Fan, TANG Yaming, PAN Xueshu, et al . An attempt of risk assessment of geological hazards in different scales: a case study in Wubao County of Shaanxi Province［J］. The Chinese Journal of Geological Hazard and Control,2022 ,33 （2 ）:115 −124 . （in Chinese with English abstract）[4] 桑凯. 近60年中国滑坡灾害数据统计与分析[J]. 科技传播,2013,5(10):129. [SANG Kai. Statistics and analysis of landslide disaster data in China in recent 60 years[J]. Public Communication of Science & Technology,2013,5(10):129. (in Chinese with English abstract)]
SANG Kai . Statistics and analysis of landslide disaster data in China in recent 60 years［J］. Public Communication of Science & Technology,2013 ,5 （10 ）:129 . （in Chinese with English abstract）[5] 汪继平,汤罗圣,黄璇,等. 基于室内大型剪切试验及工程地质类比法的弃渣场抗剪强度参数综合取值与稳定性研究[J]. 地质科技通报,2022,41(4):266 − 273. [WANG Jiping,TANG Luosheng,HUANG Xuan,et al. Determination of shear strength parameters and stability analysis of waste disposal area using laboratory large-scale shear testing and engineering geologic analogy method[J]. Bulletin of Geological Science and Technology,2022,41(4):266 − 273. (in Chinese with English abstract)]
WANG Jiping, TANG Luosheng, HUANG Xuan, et al . Determination of shear strength parameters and stability analysis of waste disposal area using laboratory large-scale shear testing and engineering geologic analogy method［J］. Bulletin of Geological Science and Technology,2022 ,41 （4 ）:266 −273 . （in Chinese with English abstract）[6] 胡家驹,许明,刘先珊,等. 基于极限分析上限原理的简化毕肖普法分析[J]. 兰州大学学报(自然科学版),2021,57(5):622 − 626. [HU Jiaju,XU Ming,LIU Xianshan,et al. A simplified Bishop method based on the upper bound limit theory[J]. Journal of Lanzhou University (Natural Sciences),2021,57(5):622 − 626. (in Chinese with English abstract)]
HU Jiaju, XU Ming, LIU Xianshan, et al . A simplified Bishop method based on the upper bound limit theory［J］. Journal of Lanzhou University （Natural Sciences）,2021 ,57 （5 ）:622 −626 . （in Chinese with English abstract）[7] 宋盛渊,王清,潘玉珍,等. 基于突变理论的滑坡危险性评价[J]. 岩土力学,2014,35(增刊2):422 − 428. [SONG Shengyuan,WANG Qing,PAN Yuzhen,et al. Landslide risk assessment based on catastrophe theory[J]. Rock and Soil Mechanics,2014,35(Sup 2):422 − 428. (in Chinese)]
SONG Shengyuan, WANG Qing, PAN Yuzhen, et al. Landslide risk assessment based on catastrophe theory［J］. Rock and Soil Mechanics, 2014, 35（Sup 2）: 422 − 428. （in Chinese） [8] 吴益平,唐辉明,葛修润. BP模型在区域滑坡灾害风险预测中的应用[J]. 岩土力学,2005,26(9):1409 − 1413. [WU Yiping,TANG Huiming,GE Xiurun. Application of BP model to landslide hazard risk prediction[J]. Rock and Soil Mechanics,2005,26(9):1409 − 1413. (in Chinese with English abstract)]
WU Yiping, TANG Huiming, GE Xiurun . Application of BP model to landslide hazard risk prediction［J］. Rock and Soil Mechanics,2005 ,26 （9 ）:1409 −1413 . （in Chinese with English abstract）[9] 黄盛锋, 陈志波, 郑道哲. 基于灰色关联度法和强度折减法的边坡稳定性影响因素敏感性分析[J]. 中国地质灾害与防治学报,2020,31(3):35 − 40. [HUANG Shengfeng, CHEN Zhibo, ZHENG Daozhe. Sensitivity analysis of factors influencing slope stability based on grey correlation and strength reduction method[J]. The Chinese Journal of Geological Hazard and Control,2020,31(3):35 − 40. (in Chinese with English abstract)]
HUANG Shengfeng, CHEN Zhibo, ZHENG Daozhe . Sensitivity analysis of factors influencing slope stability based on grey correlation and strength reduction method［J］. The Chinese Journal of Geological Hazard and Control,2020 ,31 （3 ）:35 −40 . （in Chinese with English abstract）[10] 涂长红,商建林,谢叶彩,等. 改进的灰色关联分析在滑坡危险性评价中的应用——以广东省滑坡危险性评价为例[J]. 灾害学,2007,22(1):86 − 89. [TU Changhong,SHANG Jianlin,XIE Yecai,et al. An application of improved grey association analysis method in evaluating landslide hazard in Guangdong Province[J]. Journal of Catastrophology,2007,22(1):86 − 89. (in Chinese with English abstract)]
TU Changhong, SHANG Jianlin, XIE Yecai, et al . An application of improved grey association analysis method in evaluating landslide hazard in Guangdong Province［J］. Journal of Catastrophology,2007 ,22 （1 ）:86 −89 . （in Chinese with English abstract）[11] 周钜乾,唐川. 模糊评判模型在边坡稳定性评价中的应用[J]. 自然灾害学报,1995,4(3):73 − 82. [ZHOU Juqian,TANG Chuan. The model of fuzzy comprehensive judgement applied in evaluations of slope stability[J]. Journal of Natural Disasters,1995,4(3):73 − 82. (in Chinese with English abstract)]
ZHOU Juqian, TANG Chuan . The model of fuzzy comprehensive judgement applied in evaluations of slope stability［J］. Journal of Natural Disasters,1995 ,4 （3 ）:73 −82 . （in Chinese with English abstract）[12] 王新民,段瑜,彭欣. 采空区灾害危险度的模糊综合评价[J]. 矿业研究与开发,2005,25(2):83 − 85. [WANG Xinmin,DUAN Yu,PENG Xin. Fuzzy comprehensive evaluation of disaster risk in goaf[J]. Mining Research and Development,2005,25(2):83 − 85. (in Chinese with English abstract)]
WANG Xinmin, DUAN Yu, PENG Xin . Fuzzy comprehensive evaluation of disaster risk in goaf［J］. Mining Research and Development,2005 ,25 （2 ）:83 −85 . （in Chinese with English abstract）[13] 于开宁, 吴涛, 魏爱华, 等. 基于AHP-突变理论组合模型的地质灾害危险性评价——以河北平山县为例[J]. 中国地质灾害与防治学报,2023,34(2):146 − 155. [YU Kaining, WU Tao, WEI Aihua, et al. Geological hazard assessment based on the models of AHP, catastrophe theory and their combination: a case study in Pingshan County of Hebei Province[J]. The Chinese Journal of Geological Hazard and Control,2023,34(2):146 − 155. (in Chinese with English abstract)]
YU Kaining, WU Tao, WEI Aihua, et al . Geological hazard assessment based on the models of AHP, catastrophe theory and their combination: a case study in Pingshan County of Hebei Province［J］. The Chinese Journal of Geological Hazard and Control,2023 ,34 （2 ）:146 −155 . （in Chinese with English abstract）[14] 胡启芳,范雷,董治军,等. 基于模糊综合评价的改进层次分析法在滑坡危险评价中的应用[J]. 长江科学院院报,2014,31(5):29 − 33. [HU Qifang,FAN Lei,DONG Zhijun,et al. Application of modified analytic hierarchy process based on fuzzy comprehensive evaluation to landslide risk assessment[J]. Journal of Yangtze River Scientific Research Institute,2014,31(5):29 − 33. (in Chinese with English abstract)]
HU Qifang, FAN Lei, DONG Zhijun, et al . Application of modified analytic hierarchy process based on fuzzy comprehensive evaluation to landslide risk assessment［J］. Journal of Yangtze River Scientific Research Institute,2014 ,31 （5 ）:29 −33 . （in Chinese with English abstract）[15] 饶军,沈简,唐绪波,等. 基于信息熵的模糊评价法及其在滑坡危险性评价中的应用[J]. 长江科学院院报,2017,34(6):62 − 66. [RAO Jun,SHEN Jian,TANG Xubo,et al. Risk assessment of landslide based on fuzzy comprehensive evaluation and information entropy[J]. Journal of Yangtze River Scientific Research Institute,2017,34(6):62 − 66. (in Chinese with English abstract)]
RAO Jun, SHEN Jian, TANG Xubo, et al . Risk assessment of landslide based on fuzzy comprehensive evaluation and information entropy［J］. Journal of Yangtze River Scientific Research Institute,2017 ,34 （6 ）:62 −66 . （in Chinese with English abstract）[16] 中华人民共和国国土资源部,滑坡防治工程勘察规范 GBT 32864—2016[S]. 北京:中国标准出版社,2016. [Ministry of Land and Resources of the People's Republic of China, Survey Code for Landslide Prevention and Control Engineering GBT 32864—2016[S]. Beijing:China Standards Press,2016.]
Ministry of Land and Resources of the People's Republic of China, Survey Code for Landslide Prevention and Control Engineering GBT 32864—2016［S］. Beijing: China Standards Press, 2016. [17] 夏卜敬. 基于模糊综合评价和神经网络对边坡稳定性的分析研究[D]. 武汉:武汉科技大学,2008. [XIA Bujing. Analysis and research on slope stability based on fuzzy comprehensive evaluation and neural network[D]. Wuhan:Wuhan University of Science and Technology,2008. (in Chinese with English abstract)]
XIA Bujing. Analysis and research on slope stability based on fuzzy comprehensive evaluation and neural network［D］. Wuhan: Wuhan University of Science and Technology, 2008. （in Chinese with English abstract） -
