边坡地震系数剪切梁计算方法研究

,  ,  ,  ,

文章导航 > 中国地质灾害与防治学报 > 2024 > 35(6): 98-105

上一篇

下一篇

王梦晨, 邓亚虹, 慕焕东, 杨楠, 钱法桥. 边坡地震系数剪切梁计算方法研究[J]. 中国地质灾害与防治学报, 2024, 35(6): 98-105. doi: 10.16031/j.cnki.issn.1003-8035.202410024
引用本文: 王梦晨, 邓亚虹, 慕焕东, 杨楠, 钱法桥. 边坡地震系数剪切梁计算方法研究[J]. 中国地质灾害与防治学报, 2024, 35(6): 98-105. doi: 10.16031/j.cnki.issn.1003-8035.202410024
shu
WANG Mengchen, DENG Yahong, MU Huandong, YANG Nan, QIAN Faqiao. Study on the calculation method of seismic coefficient for slope stability using shear beam theory[J]. The Chinese Journal of Geological Hazard and Control, 2024, 35(6): 98-105. doi: 10.16031/j.cnki.issn.1003-8035.202410024
Citation: WANG Mengchen, DENG Yahong, MU Huandong, YANG Nan, QIAN Faqiao. Study on the calculation method of seismic coefficient for slope stability using shear beam theory[J]. The Chinese Journal of Geological Hazard and Control, 2024, 35(6): 98-105. doi: 10.16031/j.cnki.issn.1003-8035.202410024
shu

边坡地震系数剪切梁计算方法研究

  • 1.

    长安大学地质工程与测绘学院，陕西 西安　710054

  • 2.

    自然资源部矿山地质灾害成灾机理与防控重点实验室，陕西 西安　710054

  • 3.

    西安理工大学岩土工程研究所，陕西 西安　710048

  • 基金项目: 国家自然科学基金项目（41772275）
详细信息
    作者简介: 王梦晨（1998—），男，博士研究生，主要从事地震边坡稳定性分析研究工作。E-mail：2020226082@chd.edu.cn
    通讯作者: 邓亚虹（1978—），男，博士，教授，博士生导师，主要从事土动力学与地震工程方面的研究。E-mail：dgdyh@chd.edu.cn

  • 中图分类号: P694

Study on the calculation method of seismic coefficient for slope stability using shear beam theory

  • 1.

    College of Geology Engineering and Geomatics, Chang’an University, Xi’an, Shaanxi　710054, China

  • 2.

    Key Laboratory of Mine Geological Hazards Mechanism and Control, MNR, Xi’an, Shaanxi　710054, China

  • 3.

    Institute of Geotechnical Engineering, Xi’an University of Technology, Xi’an, Shaanxi　710048, China

  • Fund Project: This research is financially supported by National Natural Science Foundation of China, No. 41772275
More Information

    摘要

  • 拟静力法是评价地震边坡稳定性的常用方法之一，该方法中地震系数的选择直接关系到评估结果的准确性。 因此，深入研究拟静力法中地震系数的确定方法和取值具有重要的理论与工程实际意义。文章依据剪切梁理论，推导了直角梯形边坡的地震边坡响应加速度公式，同时分析了各因素对边坡响应加速度的影响，并确定了不同地震烈度下的地震系数推荐值。最终确定地震烈度分别为Ⅵ、Ⅶ、Ⅷ、Ⅸ度时，所对应的地震系数推荐值分别为0.04，0.07，0.11，0.21。研究结果能够反映边坡的动力响应特征，为地震系数的选择提供科学的理论支持。

    Pseudo-static method is a common used approach to evaluate the seismic stability of slopes, where the choice of seismic coefficients directly affects the accuracy of the evaluation. Therefore, thoroughly exploring the determination methods and values of seismic coefficients in the quasi-static method is of great significant both theoretically and in engineering practice. Based on shear beam theory, this paper derives the formula for the seismic response acceleration for rectangular trapezoidal slopes and analyzes the impact of various factors on slope response acceleration. Recommended seismic coefficients under different seismic intensities were determined as follows: 0.04 for Intensity Ⅵ, 0.07 for Intensity Ⅶ, 0.11 for Intensity Ⅷ, and 0.21 for Intensity Ⅸ. The research results reflect the dynamic response characteristics of slopes and provide scientific theoretical support for the selection of seismic coefficients.

    • HTML全文
  • 加载中

  • 图 1  二维边坡剪切梁模型

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  剪切梁微元示意图

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 3  不同PGA放大因子下边坡响应加速度曲线图

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  Rg随弹性模量变化图

    Figure 4.

    下载: 全尺寸图片 幻灯片

    图 5  Rg随阻尼比变化图

    Figure 5.

    下载: 全尺寸图片 幻灯片

    图 6  Rg随坡高变化图

    Figure 6.

    下载: 全尺寸图片 幻灯片

    图 7  Rg随坡角变化图

    Figure 7.

    下载: 全尺寸图片 幻灯片

    图 8  简化边坡模型的拟静力法原理图

    Figure 8.

    下载: 全尺寸图片 幻灯片

    图 9  Rg与PGA关系图

    Figure 9.

    下载: 全尺寸图片 幻灯片

    图 10  Rg与PGA关系曲线拟合图

    Figure 10.

    下载: 全尺寸图片 幻灯片

    图 11  综合影响系数物理示意图

    Figure 11.

    下载: 全尺寸图片 幻灯片

    图 12  地震系数对比图

    Figure 12.

    下载: 全尺寸图片 幻灯片

    表 1  PGA与烈度对应关系及地震波基本信息表

    Table 1.  Correspondence between PGA and intensity and basic information on seismic waves

    PGA/g ≤0.05 （0.05,0.1] （0.1,0.2] （0.2,0.4] ＞0.4
    区域 Ⅰ Ⅱ Ⅲ Ⅳ Ⅴ
    数量/条 163 82 117 52 21
    PGAmax/g 0.04934 0.09949 0.2 0.39481 1.23307
    PGAmin/g 0.0029 0.05077 0.10155 0.20021 0.40112
    平均PGA/g 0.03 0.072 0.143 0.298 0.647
    平均卓越周期/s 0.481 0.41 0.241 0.221 0.238
    平均卓越频率/Hz 2.08 2.4 4.149 4.52 4.2
    　　注：PGAmax、PGAmin分别为所划分区域的地震动数据PGA的最大值与最小值。
    下载: 导出CSV

    表 2  计算参数汇总表

    Table 2.  Summary table of calculation parameters

    H/m B/m α/（°） 阻尼比 E/MPa
    5/10/15/20/25/
    30/35/40/45/50    		 70 30 0.1 15
    15 70 20/30/40/50/60/70 0.1 15
    15 70 30 0.1/0.15/0.2/0.25/0.3 15
    15 70 30 0.1 3～25
    下载: 导出CSV

    表 3  地震波信息表

    Table 3.  Seismic wave information table

    地震名称 卓越周期/s 卓越频率/Hz
    1995年日本神户地震 0.16 6.25
    1992年美国兰德斯地震 0.08 12.5
    1999年台湾集集地震 0.12 8.3
    下载: 导出CSV

    表 4  地震系数建议取值表

    Table 4.  Table of recommended values for seismic coefficients

    地震烈度 Ⅵ Ⅶ Ⅷ Ⅸ
    PGA/g 0.05 0.10 0.20 0.40
    Rg 1.62 1.42 1.22 1.13
    地震系数 0.04 0.07 0.11 0.21
    下载: 导出CSV

    表 5  地震系数对比表

    Table 5.  Comparison table of seismic coefficients

    来源 取值依据和条件 地震系数
    Terzaghi[18] 地震震级 对于“严重”“破坏性”和“灾难性”地震，水平地震系数分别为0.1、0.2和0.5
    Seed[22] 地震震级且安全系数Fs > 1.15 当震级M=6.5时，k=0.1；当震级M=8.5时，k=0.2
    Hynes-Griffin[20] 地震烈度且安全系数Fs > 1 Ⅵ：0.025、Ⅶ：0.05、Ⅷ：0.1、Ⅸ：0.2
    Marcuson[24] 地震烈度且安全系数Fs > 1 Ⅵ：0.017～0.025、Ⅶ：0.03～0.05、Ⅷ：0.06～0.1、Ⅸ：0.13～0.2
    Baker[21] 地震烈度 Ⅵ：0.0375、Ⅶ：0.075、Ⅷ：0.15、Ⅸ：0.3
    本文计算结果 地震烈度 Ⅵ：0.04、Ⅶ：0.07、Ⅷ：0.11、Ⅸ：0.21
    下载: 导出CSV
