CHARACTERISTICS OF PETROLEUM ACCUMULATIONS IN THE SOUTH CHINA SEA AND THEIR EXPLORATION POTENTIAL
-
摘要:
在南海区域地质综合研究基础上，通过对南海海域已发现油气藏系统分析，并对典型油气藏解剖，按照生、运、聚、保等特点，从纵向上将南海海域盆地划分出基岩、下部、中部、上部4套成藏组合，并剖析了各成藏组合内油气有利聚集带与油气成藏主控因素。最后指出南海北部以中下成藏组合为主、南部以中上成藏组合为主、上部成藏组合是南海深水区最重要的成藏组合。
Abstract:Influenced by the specific geopolitical position and the complicated engineering geological background, oil exploration in the deepwater basins of the SCS is much delayed. It has led to a lack of understanding of hydrocarbon accumulation conditions, favorable enrichment areas and main controlling factors. Through system analysis and case studies of some typical fields, based on the regional geological background, and the patterns of "source rocks, migration, accumulation and preservation", this paper reveals four petroleum plays, including the Pre-Tertiary basement play, lower play, middle play and upper play. At the same time, the hydrocarbon favorable accumulation zones and the main controlling factors of each play are described and discussed. From the study, the following conclusions are reached. First, the middle and lower plays are the main ones for the northern part of SCS. Second, the middle and upper plays are the main ones for the southern part of SCS. Third, the upper play is the most important one for deepwater areas.
-
Key words:
- petroleum play /
- exploration potential /
- buried hill /
- carbonate reef /
- deepwater deposition /
- South China Sea
-
-
表 1 南海不同成藏组合油气特征
Table 1. Reservoir characteristics of different plays in South China Sea
成藏组合 油气藏个数 探明可
采油当量/亿t占南海总储量
百分比/%上部成藏组合 165 26.7 35.25 中部成藏组合 300 41.6 54.92 下部成藏组合 76 3.46 4.57 基岩成藏组合 16 3.99 5.27
下载: 导出CSV
表 2 2011—2015年南海不同成藏组合探明油气可采储量
Table 2. The characteristics of proven recoverable reserves from different plays in the South China Sea in 2011—2015
成藏组合 探明可采储量 油/万t 气/亿m3 油当量/亿t 上部 3.69 3 732 3.11 中部 4.13 5 082 4.24 下部 2.03 26 0.02 基岩 0.35 52 0.04 合计 10.20 8 892 7.41
下载: 导出CSV
-
[1] 姚伯初, 万玲, 刘振湖.南海海域新生代沉积盆地构造演化的动力学特征及其油气资源[J].地球科学-中国地质大学学报, 2004, 29(5): 543-549. doi: 10.3321/j.issn:1000-2383.2004.05.007
YAO Bochu, WAN Ling, LIU Zhenhu. Tectonic dynamics of Cenozoic sedimentary basins and hydrocarbon resources in the South China Sea[J]. Earth Science-Journal of China University of Geosciences, 2004, 29(5): 543-549. doi: 10.3321/j.issn:1000-2383.2004.05.007
[2] IHS. IHS oil & gas field, reservoir & reserves data[DB/OL]. (2015-11-07). http://www.ihs.comproductsoil-gas-informationfield-reservoir-data.
[3] 张强, 吕福亮, 王彬, 等.南海油气分布特征及主控因素探讨[J].海相油气地质, 2012, 17(3): 1-8. doi: 10.3969/j.issn.1672-9854.2012.03.001
ZHANG Qiang, LV Fuliang, WANG Bin, et al. Characteristics and controlling factors of hydrocarbon distribution in South China Sea[J]. Marine Origin Petroleum Geology, 2012, 17(3): 1-8. doi: 10.3969/j.issn.1672-9854.2012.03.001
[4] 朱伟林, 张功成, 钟锴, 等.中国南海油气资源前景[J].中国工程科学, 2010, 12(5): 46-50. doi: 10.3969/j.issn.1009-1742.2010.05.007
ZHU Weilin, ZHANG Gongcheng, ZHONG Kai, et al. South China Sea: Oil and gas outlook[J]. Engineering Science, 2010, 12(5): 46-50. doi: 10.3969/j.issn.1009-1742.2010.05.007
[5] 姚伯初.南海新生代的构造演化与沉积盆地[J].南海地质研究, 1998: 1-17. http://d.old.wanfangdata.com.cn/Periodical/dqkx200405007
Yao Bochu. The tectonic evolution and sedimentary basins of South China Sea in cenozoic[J]. Geological Research of South China Sea, 1998: 1-17. http://d.old.wanfangdata.com.cn/Periodical/dqkx200405007
[6] 张功成, 屈红军, 刘世翔, 等.边缘海构造旋回控制南海深水区油气成藏[J].石油学报, 2015, 36(5): 533-545. http://d.old.wanfangdata.com.cn/Periodical/syxb201505002
ZHANG Gongcheng, QU Hongjun, LIU Shixiang, et al. Tectonic cycle of marginal sea controlled the hydrocarbon accumulation in deep-water areas of South China Sea[J]. Acta Petrolei Sinica, 2015, 36(5): 533-545. http://d.old.wanfangdata.com.cn/Periodical/syxb201505002
[7] 朱伟林, 吴景富, 张功成, 等.中国近海新生代盆地构造差异性演化及油气勘探方向[J].地学前缘, 2015, 22(1): 88-101. http://d.old.wanfangdata.com.cn/Periodical/dxqy201501008
Zhu Weilin, Wu Jingfu, Zhang Gongcheng, et al. Discrepancy tectonic evolution and petroleum exploration in China offshore Cenozoic basins[J]. Earth Science Frontiers, 2015, 22(1): 88-101. http://d.old.wanfangdata.com.cn/Periodical/dxqy201501008
[8] 李友川, 米立军, 张功成, 等.南海北部深水区烃源岩形成和分布研究[J].沉积学报, 2011, 29(5): 970-979. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cjxb201105016
Li Youchuan, Mi Lijun, Zhang Gongcheng, et al. The formation and distribution of source rocks for deep water area in the northern of South China Sea[J]. Acta Sedimentologica Sinica, 2011, 29(5): 970-979. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cjxb201105016
[9] 李友川, 傅宁, 张枝焕.南海北部深水区盆地烃源条件和油气源[J].石油学报, 2013, 34(2): 247-254. http://d.old.wanfangdata.com.cn/Periodical/syxb201302006
LI Youchuan, FU Ning, ZHANG Zhihuan. Hydrocarbon source conditions and origins in the deepwater area in the northern South China Sea[J]. Acta Petrolei Sinica, 2013, 34(2): 247-254. http://d.old.wanfangdata.com.cn/Periodical/syxb201302006
[10] 李友川, 邓运华, 张功成.中国近海海域烃源岩和油气的分带性[J].中国海上油气, 2012, 24(1): 6-12. doi: 10.3969/j.issn.1673-1506.2012.01.002
LI Youchuan, DENG Yunhua, ZHANG Gongcheng. Zoned distribution of source rocks and hydrocarbon offshore China[J]. China Offshore Oil and Gas, 2012, 24(1): 6-12. doi: 10.3969/j.issn.1673-1506.2012.01.002
[11] IHS Energy. IHS Baram Delta[DB]. IHS Basin Monitor, Baram_Delta_gen.pdf, 2009 (unpublished PDF database).
[12] IHS Energy. IHS CentrallLuconiaProvince[DB]. IHS Basin Monitor, Centrall_Luconia_Province_gen.pdf, 2009 (unpublished PDF database).
[13] IHS Energy. IHS NamConSon Basin[DB]. IHS Basin Monitor, Nam_Con_SonBasin_gen.pdf, 2009 (unpublished PDF database).
[14] IHS Energy. IHS NorthwestSabah Province[DB]. IHS Basin Monitor, Northwest_Sabah_Province_gen.pdf, 2009 (unpublished PDF database).
[15] IHS Energy. IHS NorthwestPalawan Basin[DB]. IHS Basin Monitor, IHSNorthwest_Palawan_Basin_gen.pdf, 2009 (unpublished PDF database).
[16] 童晓光.论成藏组合在勘探评价中的意义[J].西南石油大学学报:自然科学版, 2009, 31(6): 1-8. http://d.old.wanfangdata.com.cn/Periodical/xnsyxyxb200906001
TONG Xiaoguang. Discussion on the role of Accumulation Association in the Explorationg evaluation[J]. Journal of Southwest Petroleum University: Science & Technology Edition, 2009, 31(6): 1-8. http://d.old.wanfangdata.com.cn/Periodical/xnsyxyxb200906001
[17] IHS Energy. IHS CuuLongBasin[DB]. IHS Basin Monitor, Cuu_Long_Basin_ima_198393.pdf, 2009 (unpublished PDF database).
[18] IHS Energy. IHS NorthwestPalawan Basin[DB]. IHS Basin Monitor, IHS Northwest_Palawan_Basin_ima_112205.pdf, 2009 (unpublished PDF database).
[19] IHS Energy. IHS BaramDelta[DB]. IHS Basin Monitor, Baram_Delta_ima_186445.pdf, 2009 (unpublished PDF database).
[20] 谯汉生.南海第三纪海浸旋回及其含油性[J].石油勘探与开发, 1980(6): 9-11.
QIAO Hansheng. Marine transgression cycle and its control of hydrocarbon potential in South China Sea[J]. Petroleum Exploration and Development, 1980(6): 9-11.
[21] 邱燕.南海南部主要含油气盆地沉积体系初步分析[J].海洋地质, 1996(2): 10-19. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199601018918
QIU Yan. A preliminary analysis of the main oil and gas basin sedimentary system in the southern South China Sea[J]. Marine Geology, 1996(2): 10-19. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199601018918
[22] 邱燕, 王英民.南海第三纪生物礁分布与古构造和古环境[J].海洋地质与第四纪地质, 2001, 21(1): 65-67. http://www.cnki.com.cn/Article/CJFDTotal-HYDZ200101012.htm
QIU Yan, WANG Yingmin. Reefs and paleostructure and paleoenvironment in the South China Sea[J]. Marine Geology & Quaternary Geology, 2001, 21(1): 65-67. http://www.cnki.com.cn/Article/CJFDTotal-HYDZ200101012.htm
[23] 寇养琦, 杜德莉.南海海域大油气田与中国东南海区油气地质分析[J].海洋地质与第四纪地, 1995, 15(4): 1-12. http://www.cnki.com.cn/Article/CJFDTotal-HYDZ504.000.htm
KOU Yangqi, DU Deli. Geologic analysis of oil and gas in Southeastern China Sea areas on the basis of large oil and gas fields in the South China Sea[J]. Marine Geology & Quaternary Geology, 1995, 15(4): 1-12. http://www.cnki.com.cn/Article/CJFDTotal-HYDZ504.000.htm
[24] IHS Energy. IHS CentralLuconiaProvince[DB]. IHS Basin Monitor, Central_Luconia_Province_ima_194773.pdf, 2009 (unpublished PDF database).
[25] IHS Energy. IHS NorthwestPalawan Basin[DB]. IHS Basin Monitor, IHS Northwest_Palawan_Basin_ima_112207.pdf, 2009 (unpublished PDF database).
[26] 吴能友, 曾维军, 宋海斌, 等.南海区域构造沉降特征[J].海洋地质与第四纪地质, 2003, 23(1): 55-65. http://www.cnki.com.cn/Article/CJFDTotal-HYDZ200301009.htm
Wu Nengyou, Zeng Weijun, Song Haibin, et al. Tectonic subsidence of the South China Sea[J]. Marine Geology and Quaternary Geology, 2003, 23(1): 55-65. http://www.cnki.com.cn/Article/CJFDTotal-HYDZ200301009.htm
[27] Ingram G M, Chisholm T J, Grant C J, et al. Deepwater North West Borneo: hydrocarbon accumulation in an active fold and thrust belt[J]. Marine and Petroleum Geology. 2004, 21(7): 879-887. doi: 10.1016/j.marpetgeo.2003.12.007
[28] Morley C K, King R, Hillis R, et al. Deepwater fold and thrust belt classification, tectonics, structure and hydrocarbon prospectivity: A review[J]. Earth-Science Reviews, 2011, 104(1-3): 41-91. doi: 10.1016/j.earscirev.2010.09.010
[29] 王振峰, 孙志鹏, 朱继田, 等.南海西部深水区天然气地质与大气田重大发现[J].天然气工业, 2015, 35(10): 11-20. doi: 10.3787/j.issn.1000-0976.2015.10.002
Wang Zhenfeng, Sun Zhipeng, Zhu Jitian, et al. Natural gas geological characteristics and great discovery of large gas fields in deep water area of the western South China Sea[J]. Natural Gas Industry, 2015, 35(10): 11-20. doi: 10.3787/j.issn.1000-0976.2015.10.002
[30] 杨金海, 李才, 李涛, 等.琼东南盆地深水区中央峡谷天然气成藏条件与成藏模式[J].地质学报, 2014, 88(11): 2141-2149. http://d.old.wanfangdata.com.cn/Periodical/dizhixb201411011
YANG Jinhai, LI Cai, LI Tao, et al. Accumulation condition and model of gas reservoir in central caynon in deepwater area of northern South China Sea[J]. Acta Geologica Sinica, 2014, 88(11): 2141-2149. http://d.old.wanfangdata.com.cn/Periodical/dizhixb201411011
[31] 王建桥, 姚伯初, 万玲, 等.南海海域新生代沉积盆地的油气资源[J].海洋地质与第四纪地质, 2005, 25(2): 91-100. http://www.cnki.com.cn/Article/CJFDTotal-HYDZ200502018.htm
WANG Jianqiao, YAO Bochu, WAN Ling, et al. Characteristics of tectonic dynamics of the Cenozoic sedimentary basins and the petroleum resources in the South China Sea[J]. Marine Geology & Quaternary Geology, 2005, 25(2): 91-100. http://www.cnki.com.cn/Article/CJFDTotal-HYDZ200502018.htm
[32] Hesse S, Back S, Franke D. The structural evolution of folds in a deepwater fold and thrust belt-a case study from the Sabah continental margin offshore NW Borneo, SE Asia[J]. Marine and petroleum geology, 2010, 27(2): 442-454. doi: 10.1016/j.marpetgeo.2009.09.004
[33] Cullen A B. Transverse segmentation of the Baram-Balabac Basin, NW Borneo: refining the model of Borneo's tectonic evolution[J]. Petroleum Geoscience, 2010, 16(1): 3-29.
[34] 颜佳新, 周蒂.南海北部陆缘区中特提斯构造演化研究[J].海洋地质与第四纪地质, 2001, 21(4): 49-54. http://www.cnki.com.cn/Article/CJFDTotal-HYDZ200104011.htm
YAN Jiaxin, ZHOU Di. Advancement on the meso-Tethys along the northern of The South China Sea[J]. Marine Geology & Quaternary Geology, 2001, 21(4): 49-54. http://www.cnki.com.cn/Article/CJFDTotal-HYDZ200104011.htm
[35] 周蒂, 孙珍, 陈汉宗, 等.南海及其围区中生代岩相古地理和构造演化[J].地学前缘, 2005, 12(3): 204-218. doi: 10.3321/j.issn:1005-2321.2005.03.022
Zhou Di, Sun Zhen, Chen Hanzong, et al. Mesozoic lithofacies, paleogeography, and tectonic evolution of the South China Sea and surrounding area[J]. Earth Science Frontiers, 2005, 12(3): 204-218. doi: 10.3321/j.issn:1005-2321.2005.03.022
-
