Analysis of reservoir-forming conditions and key controlling factors of Huagang Formation in the central anticlinal belt of Xihu Sag of East China Sea—Taking the reservoir H3 for example
-
摘要:
近年来，西湖凹陷中央背斜带渐新统花港组油气勘探取得重要突破，发现多个大中型含油气构造，在不同的含油气构造中，气藏的气柱高度及圈闭充满度差别大，说明不同的含油气构造具有不同的成藏主控因素。基于三维地震及多口钻井资料，从烃源岩、圈闭条件、储盖组合配置关系等方面，以H3气藏为例，通过对典型气藏的解剖，对H3气藏的成藏条件进行研究，分析了不同构造气藏的成藏主控因素。结果表明，中央背斜带油气主要来自于始新统煤系烃源岩，渐新统花港组具备良好的圈闭条件及储盖组合配置关系，油气成藏主控因素为有效的输导体系，而良好的后期保存条件则是控制油气富集程度（油气充满度）的重要因素。
Abstract:A great breakthrough in oil and gas exploration has been made recently from the Huagang Formation in the central anticline belt of the Xihu Sag. Several medium to large oil and gas fields have been discovered. However, the gas column height and fullness ratio of trap differs from each other which suggests that every reservoir has its own key controlling factors. Based on seismic and drilling data, this paper selects the H3 reservoir as a case to study the accumulation conditions of source rocks, traps and combination of reservoir-cap systems. Also this paper sums up the key controlling factor of each reservoir by dissecting four typical reservoirs. The results show that the oil and gas accumulated in H3 reservoir come from the source rocks in Pinghu Formation; the reservoir and caprocks matched each other excellently, and the key factors to control oil and gas accumulation are the effective migration system and fault sealing, and the reservoir preservation condition has great influence on hydrocarbon accumulation.
-
Key words:
- H3 reservoir /
- key controlling factors /
- Huagang Formation /
- central anticline belt /
- Xihu Sag
-
-
表 1 中央背斜带天然气、烃源岩碳同位素值
Table 1. Statistical table of carbon isotope value of natural gas and source rock in central anticlinal belt
碳同位素值/‰（样品数） 丁烷 花港组泥 花港组煤 平湖组泥 平湖组煤 G构造 −27.3（8） −26.7（5） − −26.4（2） − H构造 −23.7（3） −25.6（3） −24.5（1） − − C构造 −24.0（1） −26.2（19） −25.7（2） − − A构造 −27.1（9） − − − − B构造 −27.0（6） −26.4（4） − −25.8（7） −25.7（2）
下载: 导出CSV
表 2 H1-H3砂层组地层岩性统计
Table 2. The statistical table of lithology form sand group H1 to H3
A1 B1 C1 D1 E1 F1 G1 H1 H2 H3 H1 H2 H3 H1 H2 H3 H1 H2 H3 H1 H2 H3 H1 H2 H3 H1 H2 H3 地层厚度/m 173 110 135 195.5 126.7 143.5 143.5 152.6 193 257 131 185 267 254 255 254 271 265 188.5 280.5 256 砂岩厚度（粉砂及以上）/m 25 27.5 56.5 64.5 30.54 66 30.5 12 84 87 40 139 71 120.5 98 90 65 179 48 84.5 191.5 砂岩百分含量/% 14 25 42 33 24 46 21 8 43 34 31 75 27 47 38 35 24 68 25 30 75 泥岩厚度/m 140.5 62 61.5 128 128 72.5 93.5 107.5 88 168 81 37 150 107 122 129 143 75 130.5 171.5 58.5 泥岩百分含量/% 81 56 46 65 60 51 65 70 46 65 62 20 56 42 48 51 53 28 69 61 23
下载: 导出CSV
表 3 中央背斜带典型构造油气藏参数
Table 3. Statistical table of carbon isotope value of natural gas and source rock in central anticlinal belt
构造名称 圈闭面积/km2 圈闭幅度/m 气水界面深度/m 综合解释结论 含气面积/km2 气柱高度/m 充满度/% 气水关系 气藏类型 B 32.0 140 −2781 气层 11.42 50 35.7 层状底水 构造气藏 C 23.6 50 − 水层 − − − − − D 12.4 20 − 含气水层 − − − − − F 42.65 232 −3812.2 气层 42.65 232 100 层状边水 构造气藏
下载: 导出CSV
-
[1] 朱立新, 宋在超. 东海西湖凹陷原型盆地构造格架与演化分析[J]. 海洋石油, 2016, 36(1):1-6
ZHU Lixin, SONG Zaichao. Analysis of tectonic framework and evolution of prototype basin in Xihu Sag of the East China Sea [J]. Offshore Oil, 2016, 36(1): 1-6.
[2] 何将启, 杨风丽. 东海西湖凹陷新生代盆地原型分析[J]. 海洋石油, 2003, 23(S1):13-20
HE Jiangqi, YANG Fengli. Prototype basin analysis in Cenozoic for Xihu Sag, East China Sea [J]. Offshore Oil, 2003, 23(S1): 13-20.
[3] 郑求根, 周祖翼, 蔡立国, 等. 东海陆架盆地中新生代构造背景及演化[J]. 石油与天然气地质, 2005, 26(2):197-201
ZHENG Qiugen, ZHOU Zuyi, CAI Liguo, et al. Meso-Cenozoic tectonic setting and evolution of East China Sea shelf basin [J]. Oil & Gas Geology, 2005, 26(2): 197-201.
[4] 胡明毅, 柯岭, 梁建设. 西湖凹陷花港组沉积相特征及相模式[J]. 石油天然气学报, 2010, 32(5):1-5
HU Mingyi, KE Ling, LIANG Jianshe. The characteristics and pattern of sedimentary facies of Huagang formation in Xihu Depression [J]. Journal of Oil and Gas Technology, 2010, 32(5): 1-5.
[5] 谢月芳, 陈敏娟, 王坚勇. 东海西湖凹陷浙东中央背斜带中南部油气成藏规律与晚期剪切断层的关系探讨[J]. 海洋石油, 2002, 22(2):8-13
XIE Yuefang, CHEN Minjuan, WANG Jianyong. Pattern of oil and gas accumulation in the South and Middle Part of Zhedong Central anticline area [J]. Offshore Oil, 2002, 22(2): 8-13.
[6] 熊斌辉, 张喜林, 张锦伟, 等. 西湖凹陷油气成藏的主控因素[J]. 海洋石油, 2008, 28(2):14-24
XIONG Binhui, ZHANG Xilin, ZHANG Jinwei, et al. The key factor controlling hydrocarbon accumulation in Xihu Depression [J]. Offshore Oil, 2008, 28(2): 14-24.
[7] 钟韬, 李键, 曹冰, 等. 西湖凹陷花港组储层致密化及其与油气成藏的关系[J]. 海洋地质前沿, 2018, 34(1):20-27
ZHONG Tao, LI Jian, CAO Bing, et al. Densification timing of reservoir and its bearing on hydrocarbon accumulation in the Huagang formation of Xihu Sag [J]. Marine Geology Frontiers, 2018, 34(1): 20-27.
[8] 魏恒飞, 陈践发, 陈晓东, 等. 西湖凹陷平湖组滨海型煤系烃源岩发育环境及其控制因素[J]. 中国地质, 2013, 40(2):487-497
WEI Hengfei, CHEN Jianfa, CHEN Xiaodong, et al. The controlling factors and sedimentary environment for developing coastal coal-bearing source rock of Pinghu Formation in Xihu Depression [J]. Geology in China, 2013, 40(2): 487-497.
[9] 李昆, 周兴海, 吴嘉鹏, 等. 西湖凹陷中下始新统宝石组沉积相研究[J]. 海洋石油, 2017, 37(1):16-20
LI Kun, ZHOU Xinghai, WU Jiapeng, et al. Sedimentary facies of middle-lower Eocene Baoshi formation in Xihu Sag, East China Sea shelf basin [J]. Offshore Oil, 2017, 37(1): 16-20.
[10] 吴嘉鹏, 万丽芬, 张兰, 等. 西湖凹陷平湖组岩相类型及沉积相分析[J]. 岩性油气藏, 2017, 29(1):27-34
WU Jiapeng, WAN Lifen, ZHANG Lan, et al. Lithofacies types and sedimentary facies of Pinghu formation in Xihu Depression [J]. Lithologic Reservoirs, 2017, 29(1): 27-34.
[11] 李上卿, 李纯洁. 东海西湖凹陷油气资源分布及勘探潜力分析[J]. 石油实验地质, 2003, 25(6):721-728
LI Shangqing, LI Chunjie. Analysis on the petroleum resource distribution and exploration potential of the Xihu Depression, the East China Sea [J]. Petroleum Geology & Experiment, 2003, 25(6): 721-728.
[12] 叶加仁, 顾惠荣, 贾健宜. 东海西湖凹陷油气地质条件及其勘探潜力[J]. 海洋地质与第四纪地质, 2008, 28(4):111-116
YE Jiaren, GU Huirong, JIA Jianyi. Petroleum geological condition and exploration potential of Xihu Depression, East China Sea [J]. Marine Geology & Quaternary Geology, 2008, 28(4): 111-116.
[13] 朱扬明, 周洁, 顾圣啸, 等. 西湖凹陷始新统平湖组煤系烃源岩分子地球化学特征[J]. 石油学报, 2012, 33(1):32-39
ZHU Yangming, ZHOU Jie, GU Shengxiao, et al. Molecular geochemistry of Eocene Pinghu Formation coal-bearing source rocks in the Xihu Depression, East China Sea Shelf Basin [J]. Acta Petrolei Sinica, 2012, 33(1): 32-39.
[14] 叶加仁, 顾惠荣. 东海西湖凹陷浙东中央背斜带烃源岩生排烃史研究[J]. 海洋地质与第四纪地质, 2001, 21(3):75-80
YE Jiaren, GU Huirong. A study on hydrocarbon generation history and expulsion history of source rock in the Zhedong central anticline belt, Xihu Depression [J]. Marine Geology & Quaternary Geology, 2001, 21(3): 75-80.
[15] 周瑾. 西湖凹陷中央背斜带两种热体制下烃源岩的热演化[J]. 中国海上油气(地质), 2003, 17(1):64-68
ZHOU Jin. Thermal evolution of source rocks under two thermal systems in the central anticlinal zone in Xihu Sag, East China Sea Basin [J]. China Offshore Oil and Gas (Geology), 2003, 17(1): 64-68.
[16] Prinzhofer A, Girard J P, Buschaert S, et al. Chemical and isotopic characterization of hydrocarbon gas traces in porewater of very low permeability rocks: The example of the Callovo-Oxfordian argillites of the eastern part of the Paris Basin [J]. Chemical Geology, 2009, 260(3-4): 269-277. doi: 10.1016/j.chemgeo.2008.12.021
[17] 曹倩, 徐旭辉, 曾广东, 等. 东海盆地西湖凹陷天然气及原油地化特征分析[J]. 石油实验地质, 2015, 37(5):627-632
CAO Qian, XU Xuhui, ZENG Guangdong, et al. Geochemical characteristics of natural gases and crude oils in the Xihu Sag of East China Sea Basin [J]. Petroleum Geology & Experiment, 2015, 37(5): 627-632.
[18] 苏奥, 陈红汉, 王存武, 等. 东海盆地西湖凹陷油气成因及成熟度判别[J]. 石油勘探与开发, 2013, 40(5):521-527
SU Ao, CHEN Honghan, WANG Cunwu, et al. Genesis and maturity identification of oil and gas in the Xihu Sag, East China Sea Basin [J]. Petroleum exploration and Development, 2013, 40(5): 521-527.
[19] 蒋海军, 胡明毅, 胡忠贵, 等. 西湖凹陷古近系沉积环境分析-以微体古生物化石为主要依据[J]. 岩性油气藏, 2011, 23(1):74-78
JIANG Haijun, HU Mingyi, HU Zhonggui, et al. Sedimentary environment of Paleogene in Xihu Sag: Microfossil as the main foundation [J]. Lithologic Reservoirs, 2011, 23(1): 74-78.
[20] 董春梅, 赵仲祥, 张宪国, 等. 西湖凹陷中北部花港组物源及沉积相分析[J]. 东北石油大学学报, 2018, 42(5):25-34, 72
DONG Chunmei, ZHAO Zhongxiang, ZHANG Xianguo, et al. Analysis of provenance and sedimentary facies of Huagang formation in the north central of Xihu Sag [J]. Journal of Northeast Petroleum University, 2018, 42(5): 25-34, 72.
[21] 蔡佳, 祁鹏, 宋双. 东海盆地西湖凹陷花港组下段沉积相分析[J]. 海洋地质与第四纪地质, 2017, 37(2):56-65
CAI Jia, QI Peng, SONG Shuang. Sedimentary facies of the Lower Huagang formation in Xihu Depression of Donghai Basin [J]. Marine Geology & Quaternary Geology, 2017, 37(2): 56-65.
[22] 蒋一鸣, 何新建, 张绍亮. 东海陆架盆地“反转-改造”构造迁移演化特征——以西湖凹陷边缘构造为例[J]. 长江大学学报: 自科版, 2016, 13(26):1-7
JIANG Yiming, HE Xinjian, ZHANG Shaoliang. The characteristics of “Inverse-transform” tectonic migration evolution of the East China Sea Shelf Basin-By taking the marginal structure of Xihu Sag for example [J]. Journal of Yangtze University: Natural Science Edition, 2016, 13(26): 1-7.
[23] 徐发, 张建培, 张田, 等. 西湖凹陷输导体系特征及其对油气成藏的控制作用[J]. 海洋地质前沿, 2012, 28(7):24-29
XU Fa, ZHANG Jianpei, ZHANG Tian, et al. Features of migration system in Xihu Sag and its control on hydrocarbon accumulation [J]. Marine Geology Frontiers, 2012, 28(7): 24-29.
-
