The model of compound traps development and controlling factors of hydrocarbon enrichment in Kongqueting area of the Xihu Sag
-
摘要:
随着勘探程度不断加深，东海西湖凹陷保俶斜坡带全面进入了断层-岩性复合油气藏勘探阶段，位于保俶斜坡中北部的孔雀亭地区是复合油气藏有利发育区。通过对孔雀亭地区复合圈闭发育的构造沉积背景、断裂-古地貌的控砂作用以及分带、分层系油气成藏富集规律研究，明确了孔雀亭地区复合圈闭形成条件、发育模式及油气富集差异控制因素。认为孔雀亭地区西高东低的地貌背景、西部古隆起上发育的多条“U”型及“V”型沟谷，NE向断裂坡折及NW挠曲坡折共同控制了多条水系的平面发育特征及砂体展布，与NE向断层匹配形成了典型的断层-岩性复合圈闭，成为孔雀亭地区重要的勘探领域，取得了断层-岩性圈闭勘探突破。孔雀亭地区不同区带油气富集程度不同，圈闭与有效烃源岩距离、砂体规模、储层物性、断层封堵性等要素的匹配程度控制各带油气富集程度。中低带相对近源，断层未断至浅层，保存条件好，受断坡及挠曲坡折共控，为规模砂体卸载区，物性较好，油气相对最为富集，具有良好的勘探潜力。
Abstract:With the advancement of exploration degree, the western slope belt of the Xihu Sag in the East China Sea has fully entered the stage of fault-lithologic compound reservoir exploration. The Kongqueting area, located in the north-central part of the western slope belt, is a favorable area for compound reservoirs. We specified the formation conditions, the development patterns, and the controlling factors of differential enrichment of hydrocarbon in compound reservoir of the study area by studying on the structure and sedimentary settings, the controlling effect of faults and paleogeomorphology on sand distribution, and hydrocarbon accumulation and enrichment rule in different zones and formations. In geomorphology, it was high in the west and low in the east in the study area. It developed multiple U- and V-shaped valleys on the ancient uplifts in the west of the study area, the ancestral rivers and the sand distribution were controlled by the north-east faulted slope-break and the north-west flexural slope-break. The north-west sand bodies matches the north-east faults, and formed the fault-lithological compound traps, which has become an important field for exploration and expansion of reserves in the study area, and achieved a breakthrough in fault-lithological reservoir exploration. The degree of hydrocarbon enrichment is different in Konqueting area, and is controlled by the distance between trap and source, the size of sand body, the fault plugging capacity, and their combinations. The middle and low Kongqueting area has the highest degree of hydrocarbon enrichment and the best expansion potential because of the proximity to source rock, the best storage condition, the large sand body, and the good reservoir properties.
-
Key words:
- compound traps /
- development pattern /
- differential enrichment /
- Xihu Sag
-
-
表 1 孔雀亭地区砂体有效通道空间系数
Table 1. Spatial coefficient of effective channel of the sand body in Kongqueting area
构造带 井号 通道系数/% E3h上 E3h下 E2p上 E2p中 E2p下 E2b 孔雀亭 W1 0 0 4.10 13.26 43.81 N/A L1 12.09 0 43.30 1.42 91.95 32.00 W2 0 0 19.07 34.92 14.15 0 W3 3.25 8.33 0 2.65 4.84 38.00 W5 0 0.90 11.08 46.33 28.21 N/A W4 5.03 5.36 53.06 62.86 N/A N/A D1 80.54 86.19 88.86 61.38 N/A N/A
下载: 导出CSV
-
[1] 吴峰, 任培罡, 谈明轩, 等. 东海西湖凹陷孔雀亭地区平湖组沉积相演变及其主控因素分析[J]. 海洋地质与第四纪地质, 2022, 42(2):119-130
WU Feng, REN Peigang, TAN Mingxuan, et al. Facies evolution and its controlling factors of the Pinghu formation in the Kongqueting area of Xihu depression, the East China Sea [J]. Marine Geology & Quaternary Geology, 2022, 42(2): 119-130.
[2] 李峻颉, 蒋一鸣, 侯国伟, 等. 坡折带对油气圈闭发育的约束效应: 以平湖斜坡带孔雀亭区平湖组为例[J]. 海洋地质与第四纪地质, 2021, 41(3):141-150
LI Junjie, JIANG Yiming, HOU Guowei, et al. Constraints of slope break belt on oil and gas trapping: An example from the Pinghu formation in the Kongqueting area of Pinghu slope [J]. Marine Geology & Quaternary Geology, 2021, 41(3): 141-150.
[3] 李朝阳, 魏琳, 刁慧, 等. 西湖凹陷孔雀亭构造平湖组油气来源及充注特征[J]. 石油科学通报, 2021, 6(2):196-208 doi: 10.3969/j.issn.2096-1693.2021.02.016
LI Chaoyang, WEI Lin, DIAO Hui, et al. Hydrocarbon source and charging characteristics of the Pinghu formation in the Kongqueting structure, Xihu depression [J]. Petroleum Science Bulletin, 2021, 6(2): 196-208. doi: 10.3969/j.issn.2096-1693.2021.02.016
[4] 周荔青, 江东辉, 张尚虎, 等. 东海西湖凹陷大中型油气田形成条件及勘探方向[J]. 石油实验地质, 2020, 42(5):803-812 doi: 10.11781/sysydz202005803
ZHOU Liqing, JIANG Donghui, ZHANG Shanghu, et al. Formation conditions and exploration direction of large and medium oil and gas reservoirs in Xihu sag, East China Sea [J]. Petroleum Geology & Experiment, 2020, 42(5): 803-812. doi: 10.11781/sysydz202005803
[5] 许红, 马惠福, 蒲庆南, 等. 东海陆架盆地新生代地层特征及其含油气性[J]. 海洋地质动态, 2003, 19(4):22-25 doi: 10.3969/j.issn.1009-2722.2003.04.006
XU Hong, MA Huifu, PU Qingnan, et al. Cenozoic sedimentary sequence stratigraphy of the East China Sea shelf basins [J]. Marine Geology Letters, 2003, 19(4): 22-25. doi: 10.3969/j.issn.1009-2722.2003.04.006
[6] 周心怀, 蒋一鸣, 唐贤君. 西湖凹陷成盆背景、原型盆地演化及勘探启示[J]. 中国海上油气, 2019, 31(3):1-10
ZHOU Xinhuai, JIANG Yiming, TANG Xianjun. Tectonic setting, prototype basin evolution and exploration enlightenment of Xihu sag in East China Sea basin [J]. China Offshore Oil and Gas, 2019, 31(3): 1-10.
[7] 余朝丰, 陈建文, 杜远生, 等. 东海西湖凹陷平湖组层序地层划分[J]. 海洋地质与第四纪地质, 2007, 27(5):85-90 doi: 10.16562/j.cnki.0256-1492.2007.05.012
YU Chaofeng, CHEN Jianwen, DU Yuansheng, et al. Division of sequence stratigraphy of Pinghu formation in Xihu sag in East China Sea [J]. Marine Geology & Quaternary Geology, 2007, 27(5): 85-90. doi: 10.16562/j.cnki.0256-1492.2007.05.012
[8] 唐贤君, 蒋一鸣, 张建培, 等. 东海盆地西湖凹陷平北区断陷层断裂特征及其对圈闭的控制[J]. 海洋地质前沿, 2019, 35(8):34-43
TANG Xianjun, JIANG Yiming, ZHANG Jianpei, et al. Fault characteristic and its control on traps of fault structural layer in the northern Pinghu slope belt, Xihu sag, East China Sea shelf basin [J]. Marine Geology Frontiers, 2019, 35(8): 34-43.
[9] 单超, 叶加仁, 曹强, 等. 西湖凹陷孔雀亭气田成藏主控因素[J]. 海洋地质与第四纪地质, 2015, 35(1):135-144
SHAN Chao, YE Jiaren, CAO Qiang, et al. Controlling factors for gas accumulation in Kongqueting gas field of Xihu sag [J]. Marine Geology & Quaternary Geology, 2015, 35(1): 135-144.
[10] 胡望水, 蔡峰, 胡芳, 等. 东海西湖凹陷平湖斜坡带裂陷期变换构造特征及其演化规律[J]. 石油天然气学报:江汉石油学院学报, 2010, 32(3):7-12
HU Wangshui, CAI Feng, HU Fang, et al. The characteristics of tectonic transform evolutional rules of chasmic cycles in Pinghu slope of Xihu depression of East China Sea [J]. Journal of Oil and Gas Technology (Journal of Jianghan Petroleum Institute), 2010, 32(3): 7-12.
[11] 李敏, 陈永进, 姜文斌. 西湖凹陷平湖组岩性油气藏形成条件[J]. 油气地质与采收率, 2012, 19(2):23-25 doi: 10.3969/j.issn.1009-9603.2012.02.007
LI Min, CHEN Yongjin, JIANG Wenbin. Hydrocarbon accumulation conditions for lithologic reservoirs in Pinghu formation, Xihu depression [J]. Petroleum Geology and Recovery Efficiency, 2012, 19(2): 23-25. doi: 10.3969/j.issn.1009-9603.2012.02.007
[12] 吴嘉鹏, 张兰, 万丽芬, 等. 西湖凹陷平湖组物源分析[J]. 中国石油勘探, 2017, 22(2):50-57 doi: 10.3969/j.issn.1672-7703.2017.02.006
WU Jiapeng, ZHANG Lan, WAN Lifen, et al. Provenance analysis of Pinghu formation in Xihu sag [J]. China Petroleum Exploration, 2017, 22(2): 50-57. doi: 10.3969/j.issn.1672-7703.2017.02.006
[13] 吴嘉鹏, 万丽芬, 张兰, 等. 西湖凹陷平湖组岩相类型及沉积相分析[J]. 岩性油气藏, 2017, 29(1):27-34 doi: 10.3969/j.issn.1673-8926.2017.01.004
WU Jiapeng, WAN Lifen, ZHANG Lan, et al. Lithofacies types and sedimentary facies of Pinghu formation in Xihu depression [J]. Lithologic Reservoirs, 2017, 29(1): 27-34. doi: 10.3969/j.issn.1673-8926.2017.01.004
[14] 蒋一鸣, 邵龙义, 李帅, 等. 西湖凹陷平湖构造带平湖组沉积体系及层序地层研究[J]. 现代地质, 2020, 34(1):141-153 doi: 10.19657/j.geoscience.1000-8527.2020.002
JIANG Yiming, SHAO Longyi, LI Shuai, et al. Deposition system and stratigraphy of Pinghu formation in Pinghu tectonic belt, Xihu sag [J]. Geoscience, 2020, 34(1): 141-153. doi: 10.19657/j.geoscience.1000-8527.2020.002
[15] 周祥林, 高伟中, 张建培, 等. 东海西湖凹陷平北断裂特征及其对油气成藏的控制[J]. 上海国土资源, 2021(4):54-57
HOU Xianglin, GAO Weizhong, ZHANG Jianpei, et al. Characteristics of the large braided river depositional system of the Oligocene Huagang Formation in the Xihu sag [J]. Shanghai Land & Resources, 2021(4): 54-57.
[16] 邹德江. 断陷湖盆控砂机制研究与有利勘探方向优选: 以冀中坳陷深县凹陷为例[D]. 中国地质大学(北京)博士学位论文, 2009.
ZOU Dejiang. Controlling mechanism on sandbody and favorable prospecting directions in fault lacustrine basin, take Shenxian sag, Jizhong depression, Bohaiwan basin for an example[D]. Doctor Dissertation of China University of Geosciences, 2009.
[17] 康海亮, 林畅松, 刘晓, 等. 南堡凹陷北部东营组同沉积断裂对沉积体系及岩性圈闭的控制作用[J]. 现代地质, 2016, 30(2):286-293 doi: 10.3969/j.issn.1000-8527.2016.02.004
KANG Hailiang, LIN Changsong, LIU Xiao, et al. Syndepositional fault control on types and distribution of depositional system and lithologic trap of Dongying formation in the north of Nanpu sag [J]. Geoscience, 2016, 30(2): 286-293. doi: 10.3969/j.issn.1000-8527.2016.02.004
[18] 贾承造, 赵文智, 邹才能, 等. 岩性地层油气藏地质理论与勘探技术[J]. 石油勘探与开发, 2007, 34(3):257-272 doi: 10.3321/j.issn:1000-0747.2007.03.001
JIA Chengzao, ZHAO Wenzhi, ZOU Caineng, et al. Geological theory and exploration technology for lithostratigraphic hydrocarbon reservoirs [J]. Petroleum Exploration and Development, 2007, 34(3): 257-272. doi: 10.3321/j.issn:1000-0747.2007.03.001
[19] 陆俊泽, 叶加仁, 黄胜兵, 等. 西湖凹陷平北地区烃源岩特征及生排烃史[J]. 海洋石油, 2009, 29(4):38-43 doi: 10.3969/j.issn.1008-2336.2009.04.038
LU Junze, YE Jiaren, HUANG Shengbing, et al. Characteristics and hydrocarbon generation-expulsion histories of source rocks of Pingbei area in Xihu depression [J]. Offshore Oil, 2009, 29(4): 38-43. doi: 10.3969/j.issn.1008-2336.2009.04.038
[20] 丁飞, 刘金水, 蒋一鸣, 等. 东海陆架盆地西湖凹陷孔雀亭区油气来源及运移方向[J]. 海洋地质与第四纪地质, 2021, 41(2):156-165 doi: 10.16562/j.cnki.0256-1492.2020090801
DING Fei, LIU Jinshui, JIANG Yiming, et al. Source and migration direction of oil and gas in Kongqueting area, Xihu sag, East China Sea shelf basin [J]. Marine Geology & Quaternary Geology, 2021, 41(2): 156-165. doi: 10.16562/j.cnki.0256-1492.2020090801
[21] 陶士振, 邹才能. 东海盆地西湖凹陷天然气成藏及分布规律[J]. 石油勘探与开发, 2005, 32(4):103-110 doi: 10.3321/j.issn:1000-0747.2005.04.017
TAO Shizhen, ZOU Caineng. Accumulation and distribution of natural gases in Xihu sag, East China Sea basin [J]. Petroleum Exploration & Development, 2005, 32(4): 103-110. doi: 10.3321/j.issn:1000-0747.2005.04.017
[22] 赵兰全. 西湖凹陷平湖地区油气源分析及其对成藏的影响[J]. 油气地质与采收率, 2011, 18(1):26-29 doi: 10.3969/j.issn.1009-9603.2011.01.008
ZHAO Lanquan. Analysis on hydrocarbon source and influence on reservoir formation, Pinghu area, Xihu depression [J]. Petroleum Geology and Recovery Efficiency, 2011, 18(1): 26-29. doi: 10.3969/j.issn.1009-9603.2011.01.008
[23] 苏奥, 陈红汉, 马玉华, 等. 东海盆地西湖凹陷孔雀亭气区气侵条件及主控因素[J]. 天然气地球科学, 2015, 26(2):292-300
SU Ao, CHEN Honghan, MA Yuhua,et al. Characteristics and main controlling factors of gas invasion in Kongqueting gas area, Xihu sag, East China Sea Basin [J]. Natural Gas Geoscience, 2015, 26(2): 292-300.
[24] 胡芬, 叶加仁, 刘俊海. 东海西湖凹陷平湖构造带油气运聚特征[J]. 海洋地质与第四纪地质, 2003, 23(1):95-102 doi: 10.16562/j.cnki.0256-1492.2003.01.015
HU Fen, YE Jiaren, LIU Junhai. Characteristics of oil and gas migration and accumulation in the Pinghu structural belt, Xihu depression, East China Sea [J]. Marine Geology & Quaternary Geology, 2003, 23(1): 95-102. doi: 10.16562/j.cnki.0256-1492.2003.01.015
[25] 李明诚. 油气运移基础理论与油气勘探[J]. 地球科学—中国地质大学学报, 2004, 29(4):379-383
LI Mingcheng. Basic principles of migration and hydrocarbon exploration [J]. Earth Scienceh Journal of China University of Geosciences, 2004, 29(4): 379-383.
-
