Clay minerals and detrital minerals in clay fraction from the Changjiang River estuary and inner continental shelf of the East China Sea and their provenance indication
-
摘要:
黏土矿物以及黏土粒级碎屑矿物颗粒细小、搬运距离远，是进行长江口及浙闽内陆架泥质区多物源示踪的良好指标。本研究利用改进的黏土矿物XRD（X射线衍射分析）预处理方法，制作了供多面XRD衍射分析的方形样品，实现了部分黏土矿物种的鉴定，结合黏土粒级中碎屑矿物鉴定，探讨了长江口及内陆架沉积物来源。研究表明：长江口及内陆架表层沉积物中的黏土矿物种属包括伊利石（含2M1、2M2两个多型）、高岭石、珍珠陶土、斜绿泥石以及弹性绿泥石，非黏土矿物主要有石英、钾长石、斜长石、白云石、铁白云石、方解石以及硬石膏。依据黏土矿物、黏土粒级碎屑矿物空间分布差异把长江口及东海内陆架划分为两个物源区：长江口及内陆架北部物源区、内陆架南部物源区，前者受废黄河物质影响，后者受浙闽中小河流物质影响。本研究表明来自苏北废黄河的沉积物不仅跨过了长江冲淡水进入长江水下三角洲，而且一直向南达到浙闽泥质区的北部。
Abstract:Clay minerals and detrital minerals in clay fraction can be transported long distance due to small sizes, making them good indicators for multi-provenance tracing in the muddy areas of the Changjiang (Yangtze) River estuary and its adjacent areas. Based on an improved clay mineral XRD pretreatment method, the main clay mineral species and detrital minerals in clay fraction were specified. The distributions of clay minerals and non-clay minerals in the areas, and the sources and sinks of sediment in the Changjiang River estuary and the inner continental shelf were explored. The results show that the types of clay minerals in the surface sediments in the Changjiang River estuary and inner continental shelf included illite (containing 2M1 and 2M2), kaolinite, nacrite, clinochlore, and cronstedtite, whereas non-clay minerals in clay fraction included mainly quartz, potassium feldspar, plagioclase, dolomite, iron dolomite, calcite, and anhydrite. Based on the spatial distribution differences of clay minerals and non-clay minerals, the study areas could be divided into two provenance areas: the first is the northern area covering the Changjiang River estuary and the northern part of the inner continental shelf; and the second is the southern area covering the southern part of the inner continental shelf. Provenances in the former area are dominated by Changjiang River originated materials, with a few from the abandoned Huanghe (Yellow) River delta; while the latter are also dominated by Changjiang River originated materials, but with a certain amount of material from regional small-medium–sized rivers in Zhejiang and Fujian provinces. These results reveal that sediments from the abandoned Huanghe River delta in the northern Jiangsu coastal zone could transport cross the Changjiang River estuary and reach the northern part of the inner continental shelf.
-
-
表 1 各站位饱和片中黏土矿物种的统计结果
Table 1. Statistics of clay mineral species in ethylene glycol saturated specimens of each station
黏土矿物 站位 S00-1 03-11 SF-1 SF-2 S01-1 SF-3 S03-1 S04-1 SF-4 S05-1 蒙皂石族 少 少 少 少 少 少 少 少 少 少 伊利石族 2M2伊利石 较多 较多 较多 较多 较多 较多 较多 较多 较多 较多 2M1伊利石 多 多 多 多 多 多 多 多 多 多 高岭石族 高岭石 较多 少 较多 少 较多 较多 较多 少 少 少 珍珠陶土 少 较多 较多 较多 较多 较多 较多 较多 较多 较多 绿泥石族 斜绿泥石 较多 较多 较多 较多 较多 较多 较多 较多 较多 较多 弹性绿泥石 少 少 少
下载: 导出CSV
表 2 各站位黏土粒级非黏土矿物统计
Table 2. Statistics of other minerals in clay fraction at each station
% 矿物 S00-1 03-11 SF-1 SF-2 S01-1 SF-3 S03-1 S04-1 SF-4 S05-1 硬石膏 21.8 0.0 0.0 10.2 9.9 12.0 0.0 0.0 0.0 0.0 石英 5.8 2.3 7.6 2.1 2.6 2.8 2.2 5.4 3.7 2.8 钾长石 12.8 1.3 2.5 1.2 4.0 1.7 2.2 2.6 4.0 0.0 斜长石 13.9 3.8 5.9 3.1 7.1 6.2 3.3 10.9 10.9 6.0 方解石 8.4 2.4 11.0 7.7 9.4 8.9 7.5 15.3 13.9 10.8 铁白云石 0.0 0.0 2.5 0.0 0.0 0.0 2.3 2.2 7.5 4.2 白云石 0.0 1.8 2.6 1.7 2.1 0.0 2.5 3.2 4.5 0.0
下载: 导出CSV
-
[1] 范德江, 杨作升, 毛登, 等. 长江与黄河沉积物中粘土矿物及地化成分的组成[J]. 海洋地质与第四纪地质, 2001, 21(4):7-12
FAN Dejiang, YANG Zuosheng, MAO Deng, et al. Clay minerals and geochemistry of the sediments from the Yangtze and Yellow Rivers[J]. Marine Geology & Quaternary Geology, 2001, 21(4):7-12.]
[2] 范德江, 杨作升, 王文正. 长江、黄河沉积物中碳酸盐组成及差异[J]. 自然科学进展, 2002, 12(1):60-64
FAN Dejiang, YANG Zuosheng, WANG Wenzheng. Carbonate composition and differences in sediments of the Yangtze and Yellow Rivers[J]. Progress in Natural Science, 2002, 12(1):60-64.]
[3] 朱凤冠, 李秀珠, 高水土. 东海大陆架沉积物中粘土矿物的研究[J]. 东海海洋, 1988, 6(1):40-51
ZHU Fengguan, LI Xiuzhu, GAO Shuitu. Research of clay minerals of sediments on the continential shelf of the East China Sea[J]. Donghai Marine Science, 1988, 6(1):40-51.]
[4] 杨作升. 黄河、长江、珠江沉积物中粘土的矿物组合、化学特征及其与物源区气候环境的关系[J]. 海洋与湖沼, 1988, 19(4):336-346
YANG Zuosheng. Mineralogical assemblages and chemical characteristics of clays from sediments of the Huanghe, Changjiang, Zhujiang Rivers and their relationship to the climate environment in their sediment source areas[J]. Oceanologia et Limnologia Sinica, 1988, 19(4):336-346.]
[5] 安郁辉, 刘健, 张军强, 等. 淮河与长江和黄河沉积物的物源识别指标比较研究[J]. 第四纪研究, 2020, 40(3):837-850
AN Yuhui, LIU Jian, ZHANG Junqiang, et al. Comparative researches on the provenance indicators of Huaihe River, Yangtze River and Yellow River sediments[J]. Quaternary Sciences, 2020, 40(3):837-850.]
[6] 李安春, 张凯棣. 东海内陆架泥质沉积体研究进展[J]. 海洋与湖沼, 2020, 51(4):705-727 doi: 10.11693/hyhz20200500145
LI Anchun, ZHANG Kaidi. Research progress of mud wedge in the inner continental shelf of the East China Sea[J]. Oceanologia et Limnologia Sinica, 2020, 51(4):705-727.] doi: 10.11693/hyhz20200500145
[7] 王昆山, 王国庆, 蔡善武, 等. 长江水下三角洲沉积物的重矿物分布及组合[J]. 海洋地质与第四纪地质, 2007, 27(1):7-12
WANG Kunshan, WANG Guoqing, CAI Shanwu, et al. Heavy mineral characteristics of surface sediments in the subaqueous Yangtze River delta[J]. Marine Geology & Quaternary Geology, 2007, 27(1):7-12.]
[8] 张凯棣, 李安春, 董江, 等. 东海表层沉积物碎屑矿物组合分布特征及其物源环境指示[J]. 沉积学报, 2016, 34(5):902-911
ZHANG Kaidi, LI Anchun, DONG Jiang, et al. Detrital mineral distributions in surface sediments of the East China Sea: implications for sediment provenance and sedimentary environment[J]. Acta Sedimentologica Sinica, 2016, 34(5):902-911.]
[9] 徐方建, 李安春, 李铁刚, 等. 中全新世以来东海内陆架泥质沉积物来源[J]. 中国石油大学学报:自然科学版, 2011, 35(1):1-6,12
XU Fangjian, LI Anchun, LI Tiegang, et al. Provenance of mud sediments in the inner shelf of East China Sea since mid-Holocene[J]. Journal of China University of Petroleum, 2011, 35(1):1-6,12.]
[10] Liu J, Saito Y, Kong X H, et al. Sedimentary record of environmental evolution off the Yangtze River estuary, East China Sea, during the last ~13, 000 years, with special reference to the influence of the Yellow River on the Yangtze River delta during the last 600 years[J]. Quaternary Science Reviews, 2010, 29(17-18):2424-2438. doi: 10.1016/j.quascirev.2010.06.016
[11] 李佩玉. X射线鉴定绿泥石方法及其意义[J]. 中国地质科学院南京地质矿产研究所所刊, 1987, 8(4):14-23
LI Peiyu. Discussion on some problems of chlorite in X-ray diffraction[J]. Bulletin Nanjing Institute of Geology and Mineral Resources Chinese Academy of Geological Sciences, 1987, 8(4):14-23.]
[12] 国家能源局. SY/T 5163-2010 沉积岩中黏土矿物和常见非黏土矿物X衍射分析方法[S]. 北京: 石油工业出版社, 2010: 1-37
National Energy Administration. SY/T 5163-2010 Analysis method for clay minerals and ordinary non-clay minerals in sedimentary rocks by the X-ray diffraction[S]. Beijing: Petroleum Industry Press, 2010: 1-37.]
[13] 张乃娴, 傅景春. 用X射线衍射仪定量分析粘土矿物的实验研究[J]. 石油勘探与开发, 1980(6):12-19,33
ZHANG Naixian, FU Jingchun. Experimental study on quantitative analysis of clay minerals by X-ray diffractometer[J]. Petroleum Exploration and Development, 1980(6):12-19,33.]
[14] Huff W D. X-ray diffraction and the identification and analysis of clay minerals[J]. Clays and Clay Minerals, 1990, 38(4):448. doi: 10.1346/CCMN.1990.0380416
[15] 陈丽蓉, 申顺喜, 徐文强, 等. 中国海的碎屑矿物组合及其分布模式的探讨[J]. 沉积学报, 1986, 4(3):87-96
CHEN Lirong, SHEN Shunxi, XU Wenqiang, et al. An approach to the detrital assemblages and their distribution patterns in the sediments of the China sea[J]. Acta Sedimentologica Sinica, 1986, 4(3):87-96.]
[16] 肖尚斌, 李安春, 陈木宏, 等. 近8 ka东亚冬季风变化的东海内陆架泥质沉积记录[J]. 地球科学-中国地质大学学报, 2005, 30(5):573-581
XIAO Shangbin, LI Anchun, CHEN Muhong, et al. Recent 8 ka mud records of the East Asian Winter monsoon from the inner shelf of the East China Sea[J]. Earth Science-Journal of China University of Geosciences, 2005, 30(5):573-581.]
[17] 郭志刚, 杨作升, 范德江, 等. 长江口泥质区的季节性沉积效应[J]. 地理学报, 2003, 58(4):591-597
GUO Zhigang, YANG Zuosheng, FAN Dejiang, et al. Seasonal sedimentary effect on the Changjiang estuary mud area[J]. Acta Geographica Sinica, 2003, 58(4):591-597.]
[18] 杨灿. 浙闽泥质区沉积物相关物源和粒径特征分析[D]. 厦门大学硕士学位论文, 2019
YANG Can. Recent changes in detrital supply and organic matter burial inferred from elemental and isotopic geochemistry of date short sediment cores from the Changjiang distal mud belt, East China sea[D]. Master Dissertation of Xiamen University, 2019.]
[19] 丁大林, 张训华, 于俊杰, 等. 浙闽泥质区全新世物源和古气候演化研究进展[J]. 吉林大学学报:地球科学版, 2019, 49(1):178-195
DING Dalin, ZHANG Xunhua, YU Junjie, et al. Progress in sedimentary sources and palaeoclimate evolution in Zhejiang-Fujian mud area in Holocene[J]. Journal of Jilin University:Earth Science Edition, 2019, 49(1):178-195.]
[20] Liu J P, Xu K H, Li A C, et al. Flux and fate of Yangtze River sediment delivered to the East China Sea[J]. Geomorphology, 2007, 85(3-4):208-224. doi: 10.1016/j.geomorph.2006.03.023
[21] Yang Z, Wang H, Saito Y, et al. Dam impacts on the Changjiang (Yangtze) River sediment discharge to the sea: the past 55 years and after the Three Gorges Dam[J]. Water Resources Research, 2006, 42(4):W04407.
[22] 石学法, 刘升发, 乔淑卿, 等. 东海闽浙沿岸泥质区沉积特征与古环境记录[J]. 海洋地质与第四纪地质, 2010, 30(4): 19-30
SHI Xuefa, LIU Shengfa, QIAO Shuqing, et al. Depositional featu res ang palaeoenvironmental records of the mud deposits in Min-Zhe coastal mud area, East China Sea[J]. Marine Geology & Quaternary Geology, 2010, 30(4): 19-30.]
[23] 董江. 末次盛冰期以来东海内陆架沉积物来源及环境记录[D]. 中国科学院大学(中国科学院海洋研究所)博士学位论文, 2018
DONG Jiang. Sediment provenance and environmental records on the inner shelf of the East China Sea since the Last Glaciation Maximum[D]. Doctor Dissertation of Institute of Oceanography, Chinese Academy of Sciences, 2018.]
[24] 肖尚斌. 东海内陆架泥质沉积的古环境记录[D]. 中国科学院研究生院(海洋研究所)博士学位论文, 2004
XIAO Shangbin. Record on paleoenvironmental from mud in the inner shelf of the East China Sea[D]. Doctor Dissertation of Graduate School of Chinese Academy of Sciences (Institute of Oceanography), 2004.]
[25] 杨守业, 印萍. 自然环境变化与人类活动影响下的中小河流沉积物源汇过程[J]. 海洋地质与第四纪地质, 2018, 38(1):1-10
YANG Shouye, YIN Ping. Sediment source-to-sink processes of small mountainous rivers under the impacts of natural environmental changes and human activities[J]. Marine Geology & Quaternary Geology, 2018, 38(1):1-10.]
[26] 王亮, 范德江, 李巍然, 等. 东海内陆架泥质区百年来黏土矿物组成变化及其环境意义[J]. 海洋学报, 2015, 37(5):87-100
WANG Liang, FAN Dejiang, LI Weiran, et al. The variation of clay minerals contents on the inner shelf of the East China Sea in the last one hundred years and its environmental implication[J]. Haiyang Xuebao, 2015, 37(5):87-100.]
[27] 周晓静, 李安春, 万世明, 等. 东海陆架表层沉积物粘土矿物组成分布特征及来源[J]. 海洋与湖沼, 2010, 41(5):667-675 doi: 10.11693/hyhz201005002002
ZHOU Xiaojing, LI Anchun, WAN Shiming, et al. Clay minerals in surfacial sediments of the East China sea shelf: distribution and provenance[J]. Oceanologia et Limnologia Sinica, 2010, 41(5):667-675.] doi: 10.11693/hyhz201005002002
[28] 肖尚斌, 李安春, 刘卫国, 等. 闽浙沿岸泥质沉积的物源分析[J]. 自然科学进展, 2009, 19(2):185-191 doi: 10.3321/j.issn:1002-008X.2009.02.009
XIAO Shangbin, LI Anchun, LIU Weiguo, et al. Source analysis of muddy sediments along the Fujian Zhejiang coast[J]. Progress in Natural Science, 2009, 19(2):185-191.] doi: 10.3321/j.issn:1002-008X.2009.02.009
[29] Doeke E. Intertidal Deposits: River Mouths, Tidal Flats, and Coastal Lagoons[M]. London: CRC Press: 2019.
[30] Liu J P, Li A C, Xu K H, et al. Sedimentary features of the Yangtze River-derived along-shelf clinoform deposit in the East China Sea[J]. Continental Shelf Research, 2006, 26(17-18):2141-2156. doi: 10.1016/j.csr.2006.07.013
[31] 孙效功, 方明, 黄伟. 黄、东海陆架区悬浮体输运的时空变化规律[J]. 海洋与湖沼, 2000, 31(6):581-587 doi: 10.11693/hyhz200006001001
SUN Xiaogong, FANG Ming, HUANG Wei. Spatial and temporal variations in suspended particulate matter transport on the Yellow and East China Sea shelf[J]. Oceanologia et Limnologia Sinica, 2000, 31(6):581-587.] doi: 10.11693/hyhz200006001001
[32] 杨作升, 郭志刚, 王兆祥, 等. 黄东海陆架悬浮体向其东部深海区输送的宏观格局[J]. 海洋学报, 1992, 14(2):81-90
YANG Zuosheng, GUO Zhigang, WANG Zhaoxiang, et al. Macroscopic pattern of transport of suspended bodies from the Yellow Sea and East China Sea shelf to the eastern deep-sea region[J]. Acta Oceanologica Sinica, 1992, 14(2):81-90.]
[33] Hao Y C, Guo Z G, Fan D J. High-resolution sedimentary record of lead in the coastal mud of the East China Sea in the past one hundred and fifty years[J]. Chinese Journal of Geochemistry, 2006, 25(S1):13.
[34] 秦蕴珊. 东海地质[M]. 北京: 科学出版社, 1987: 1-286
QIN Yunshan. Geology of the East China Sea[M]. Beijing: Science Press, 1987: 1-286.]
[35] Qiao S Q, Shi X F, Wang G Q, et al. Sediment accumulation and budget in the Bohai Sea, Yellow Sea and East China Sea[J]. Marine Geology, 2017, 390:270-281. doi: 10.1016/j.margeo.2017.06.004
[36] 赵德博, 万世明, 沈兴艳, 等. 海洋沉积物中黏土矿物的两种提取方法的对比[J]. 海洋地质与第四纪地质, 2015, 35(5):173-181
ZHAO Debo, WAN Shiming, SHEN Xingyan, et al. A discussion on methodology to extract clay minerals from marine sediments[J]. Marine Geology & Quaternary Geology, 2015, 35(5):173-181.]
[37] 南京大学地质学矿物岩石学教研室. 粉晶X射线物相分析[M]. 北京: 地质出版社, 1980
Teaching and Research Office of Geology, Mineral and Petrology at Nanjing University. Powder X-Ray Phase Analysis one Thousand Nine Hundred and Seventy-Eight[M]. Beijing: Geology Press, 1980.]
[38] Biscaye P E. Mineralogy and sedimentation of recent deep-sea clay in the Atlantic Ocean and adjacent seas and oceans[J]. GSA Bulletin, 1965, 76(7):803-832. doi: 10.1130/0016-7606(1965)76[803:MASORD]2.0.CO;2
[39] Levinson A A. Studies in the mica group: polymorphism among illites and hydrous micas[J]. American Mineralogist, 1955, 40(1-2):41-49.
[40] 张国藩. 4.7ka以来东海内陆架泥质区南部沉积学特征及物源环境指示意义[D]. 中国地质大学(北京)硕士学位论文, 2018
ZHANG Guofan. The characteristics and provenances of sediments in the inner shelf of the East China Sea: constrains on the index of paleoenvironment scince 4.7ka[D]. Master Dissertation of China University of Geosciences (Beijing), 2018.]
[41] 张杰. 东海内陆架泥质区S05-2孔沉积物4.9 ka以来沉积特征、物源指示及气候响应[D]. 中国地质大学(北京)硕士学位论文, 2019
ZHANG Jie. Sedimentary characteristics, provenance indication and climate response of Core S05-2 sediments in the mud area of inner shelf in the East China Sea since 4.9 Ka[D]. Master Dissertation of China University of Geosciences (Beijing), 2019.]
-
