Spatial distribution and potential risk assessment of thallium in surface soils from urban area of Nanchang City
-
摘要:
铊元素是一种毒性极强却鲜受关注的污染物质，对环境与健康具有潜在威胁。文章以南昌市城区表层土壤为研究对象，系统分析了铊元素的含量状况以及分布特征，并采用单因子指数法、潜在生态风险指数法和健康风险评估法等方法对其进行风险评估。结果表明：①南昌市城区表层土壤的铊元素含量为0.11～0.92 mg/kg，平均含量为0.62 mg/kg，低于江西省土壤背景值，但高于中国表层土壤铊元素的平均含量；②赣江东岸地区（老城区）表层土壤的铊元素平均含量略高于西岸地区，赣江沿岸地区土壤的铊元素含量相对较高，且具有向东西两侧呈轻微下降的趋势；③单因子指数法、潜在生态风险法和健康风险评估法显示，南昌市土壤中铊元素污染风险和健康风险较低，但红谷滩区、东湖区等地区的个别点位存在一定的健康风险，应加强对相关地区的铊污染监测工作。
Abstract:As a kind of highly toxic pollutant substance, thallium has received little attention. This study used the single factor index, potential ecological risk method, and health risk assessment to conduct a thorough risk evaluation and examine the distribution and content of thallium (Tl) in the surface soil of Nanchang’s inner city area. The results show that: ①The average Tl concentration in Nanchang City’s surface soil is 0.62 mg/kg, with a range of 0.11 to 0.92 mg/kg. This is greater than the average Tl level in China’s surface soil but lower than the background value of Jiangxi Province’s soil; ②The old town region on the eastern bank of the Gan River has somewhat higher Tl concentration than those in the western bank’s surface soil, and soils closer to the Gan River exhibit significantly higher Tl concentration, which gradually decreases toward the east and the west; ③According to the risk assessment techniques adopted, there are typically few health and pollution problems associated with thallium in Nanchang’s soil. However, places like Donghu District and Honggutan District have been linked to specific health hazards. As a result, it is imperative to improve the thallium pollution monitoring in these risky regions.
-
Key words:
- Nanchang City /
- surface soil /
- thallium /
- potential ecological risks /
- health risk assessment
-
-
表 1 土壤单元素Cf和Er等级划分（Hakanson, 1980; 何茂粉和张成丽, 2019）
Table 1. Grading of single element Cf and Er in soil（Hakanson, 1980; He and Zhang, 2019）
评价范围 污染程度 评价范围 风险程度 Cf＜1 没有污染 Er＜40 轻微生态风险 1≤Cf＜3 轻度污染 40≤Er＜80 中等生态风险 3≤Cf＜6 较高污染 80≤Er＜120 较高生态风险 Cf≥6 高污染 120≤Er＜320 高生态风险 − − Er≥320 极高生态风险
下载: 导出CSV
表 2 非致癌风险健康评价暴露参数（US EPA, 2002）
Table 2. Exposure parameters for assessing non-carcinogenic health risk（US EPA, 2002）
参数 单位 含义 取值（成人） 取值（儿童） $ \mathrm{\mathit{C}}_{\mathrm{s}\mathrm{o}\mathrm{i}\mathrm{l}} $ mg/kg 土壤中元素的实测含量 — — $ \mathrm{I}\mathrm{n}\mathrm{g}\mathrm{R} $ mg/d 土壤摄入率 100 200 EFing=EFinh=EFderm d/a 暴露频率 350 350 EDing=EDinh=EDderm a 暴露持续时间 24 6 BW kg 平均体重 60 15 AT h 平均暴露时间 365×24 365×24 CF kg/mg 转换系数 1×10-6 1×10-6 InhR m3/d 呼吸速率 20 7.6 PEF m3/kg 颗粒物排放因子 1.36×109 1.36×109 SA cm2 皮肤暴露面积 5700 200 AF mg/cm2 皮肤黏着度 0.07 0.2 ABS 无量纲 皮肤吸收因子 0.001 0.001 RfDing mg/(kg/d) 污染元素的参考剂量 8.00×10-5 8.00×10-5 RfDinh mg/(kg/d) 污染元素的参考剂量 8.00×10-5 8.00×10-5 RfDderm mg/(kg/d) 污染元素的参考剂量 8.00×10-5 8.00×10-5
下载: 导出CSV
表 3 南昌市城区表层土壤铊元素含量统计结果
Table 3. Statistics of thallium content of surface soils in Nanchang City
地区 样品数/个 最小值 最大值 平均值 标准差 变异系数 超过背景值样品个数（比例） 整个研究区 100 0.11 0.92 0.62 0.21 0.19 18(18%) 研究区东部（赣江东岸） 45 0.36 0.92 0.65 0.10 0.15 10(22%) 研究区西部（赣江西岸） 55 0.11 0.86 0.59 0.13 0.22 8(14%) 青云谱区 6 0.36 0.92 0.63 0.19 0.30 1(16%) 新建区 33 0.11 0.76 0.53 0.11 0.20 1 (3%) 西湖区 13 0.50 0.74 0.63 0.06 0.10 1(7%) 东湖区 9 0.54 0.81 0.65 0.09 0.13 2(22%) 红谷滩区 22 0.50 0.86 0.66 0.11 0.17 7(31%) 青山湖区 17 0.43 0.84 0.65 0.09 0.14 6(35%) 备注：含量单位为mg/kg。
下载: 导出CSV
表 4 南昌市表层土壤中铊元素成人/儿童ADD与HQ统计数据（平均值）
Table 4. Statistics（average value）of adult/child ADD and HQ of thallium of surface soils from Nanchang City
成人口 成人呼吸 成人皮肤 儿童口 儿童呼吸 儿童皮肤 ADD 4.71×10−6 7.30×10−10 3.96×10−9 7.94×10−6 5.84×10−9 2.22×10−8 HQ 1.22×10−2 9.12×10−6 4.95×10−5 9.92×10−2 7.30×10−5 2.78×10−4
下载: 导出CSV
-
[1] AGENCY FOR TOXIC SUBSTANCES AND DISEASE REGISTRY. 1992. Toxicological profile for thallium[M]. Atlanta: Agency for Toxic Substances and Disease Registry.
[2] CHANG J N, QU J G. 2005. Heavy metal pollution in water body: ecological effects and biological monitoring[J]. Sichuan Environment,24(4):29-33 (in Chinese with English abstract).
[3] CHENG X D, SUN J W, JIA X, SHANG L N, ZHANG L, SUN Y K. 2022. Pollution and source apportionment of heavy metals in the farmland soils of the gold mining area in Tantou Basin, western Henan metallogenic belt[J]. East China Geology,43(3):313-323(in Chinese with English abstract).
[4] CHENG Y S, WANG D P, HUANG K X, ZHOU Y, ZENG D X, LI X Y, ZHANG Z W. 2024. Research status and development trend of causes of thallium pollution in surface water and soil environment[J]. The Chinese Journal of Nonferrous Metals,34(6):2043-2058 (in Chinese with English abstract).
[5] DENG K. 2021. Study on the spatial and temporal evolution characteristics of urban morphology-water system relationship in Nanchang city and its affecting factors[D]. Wuhan: Huazhong University of Science and Technology (in Chinese with English abstract).
[6] DUAN W X, SONG Y B, ZHOU Q. 2019. Research progress on adverse impacts of thallium on ecological environment and human health[J]. Journal of Environmental and Occupational Medicine,36(9):884-890 (in Chinese with English abstract).
[7] FERGUSSON J E. 1990. The heavy elements: chemistry, environmental impact, and health effects[M]. New York: Pergamon Press, 614.
[8] GAO B, SUN K, REN M Z, LIANG X R, PENG P A, SHENG G Y, FU J M. 2008. Ecological risk assessment of thallium pollution in the surface sediment of Beijiang River[J]. Ecology and Environment,17(2):528-532 (in Chinese with English abstract).
[9] HAKANSON L. 1980. An ecological risk index for aquatic pollution control. a sedimentological approach[J]. Water Research,14(8):975-1001. doi: 10.1016/0043-1354(80)90143-8
[10] HE L B, SUN W Q, XIAO T F. 2005. Distribution and occurring forms of thallium and its potential damage to the environments[J]. Acta Mineralogica Sinica,25(3):230-236 (in Chinese with English abstract).
[11] HE M F, ZHANG C L. 2019. Thallium content analysis in Xinmi Mine area and its environmental risk assessment[J]. Nonferrous Metal Materials and Engineering,40(5):32-37 (in Chinese with English abstract).
[12] HEIM M, WAPPELHORST O, MARKERT B. 2002. Thallium in terrestrial environments-occurrence and effects[J]. Ecotoxicology,11(5):369-377. doi: 10.1023/A:1020513523462
[13] HUANG Y, CHEN G G, LI X P. 2020.Discussion on the relationship between Wuyishan tea quality and geochemistry background characteristics[J]. East China Geology, 41(2): 166-176(in Chinese with English abstract).
[14] HOU Q Y, YANG Z F, YU T, XIA X Q, CHENG H X, ZHOU G H. 2020. Soil geochemical dataset of China[M]. Beijing: Geology Press (in Chinese).
[15] JIA Z M. 2020. Characteristics, source apportionment, and ecological health risk assessment of soil heavy metals contamination in Northwest Chongqing[D]. Chongqing: Southwest University (in Chinese with English abstract).
[16] LI R Z, PAN C R, CHEN J, JIANG Y M, DING G Z. 2012. Heavy metal contamination and health risk assessment for urban topsoil and dust in Tongling city[J]. China Environmental Science,32(12):2261-2270 (in Chinese with English abstract).
[17] LI H F, ZHU J R, FU J. 2007. The toxicity of thallium and its harm to human health[J]. Chinese Journal of Public Health Management, 23(1): 77-79 (in Chinese).
[18] LIU J Y. 2006. Application of element and lead isotope tracing to the migration of thallium in soil from Yunfu pyrite mine[D]. Guangzhou: Graduate School of the Chinese Academy of Sciences, Guangzhou Institute of Geochemistry (in Chinese with English abstract).
[19] LIU F T, WANG X Q, CHI Q H. 2021. Spatial variation and health risk assessment of thallium in floodplain soil in “Three Rivers” regions of southwest China[J]. China Environmental Science,41(4):1765-1777 (in Chinese with English abstract).
[20] LIU Y X, WANG Q, ZHUANG W, YUAN Y L, YUAN Y N, JIAO K Q, WANG M T, CHEN Q. 2018. Calculation of thallium’s toxicity coefficient in the evaluation of potential ecological risk index: a case study[J]. Chemosphere,194:562-569. doi: 10.1016/j.chemosphere.2017.12.002
[21] LIU Q, XIANG L H, CHENG Y, WU C, FANG T. 2021. Distribution characteristics and risk assessment of the heavy metals in agricultural land along the Yangtze River in the eastern suburbs of Nanjing city[J]. East China Geology,42(1):37-45 (in Chinese with English abstract).
[22] LIU S G, ZHANG T L, WANG X X, PAN J J. 2010. Heavy metal pollution characteristics of topsoil in suburban areas—a case study of Nanchang city[J]. Chinese Journal of Soil Science,41(2):463-466 (in Chinese with English abstract).
[23] LU Q Q. 2018. Graphite furnace atomic absorption spectrometry for determination of thallium in lead and zinc melted industry waste water[J]. Hunan Nonferrous Metals,34(1):75-77,80 (in Chinese with English abstract).
[24] Lü B G. 2013. Ecological system health evaluation of urban wetlands in Nanchang city[D]. Nanchang: Nanchang University (in Chinese with English abstract).
[25] MA J J, HAN Z C. 2017. Status and progress of treating thallium-containing wastewater[J]. Environment and Sustainable Development,42(5):65-67 (in Chinese with English abstract).
[26] MA J H, HAN C X, JIANG Y L. 2020. Some problems in the application of potential ecological risk index[J]. Geographical Research,39(6):1233-1241 (in Chinese with English abstract).
[27] QIE H M, WEN B Y, WANG J Q, ZHOU Q Q, LIU B Q. 2017.Safety evaluation of heavy metal contents in selenium-rich soil in the Zishan area,Ganzhou, Jiangxi Province[J]. East China Geology, 38(3): 234-240(in Chinese with English abstract).
[28] TANG C H, FENG C H, MA Y L. 2005. Study on current situation of heavy metal contamination in soils of Nanchang city proper[C]//JIANGSU GEOLOGICAL SOCIETY. Earth Science and Social Sustainable Development——Collection of Papers from the 2005 East China Six Provinces and One City Geoscience and Technology Forum. Wuhan: China University of Geosciences Press, 5 (in Chinese).
[29] TANG Z M, ZHANG X D, ZHANG M, ZHOU M, TIAN F J, WANG S X, MA Q S, WANG C, ZHANG J, NIU X N, ZONG L L, HUANG D L. 2023.Geochemical characteristics of soil elements in Xin’an River Basin: constraints from rock formation types[J]. East China Geology, 44(2): 172-185(in Chinese with English abstract).
[30] TAO C J, LI M H, MA M H, ZHANG X R, DU G Q, LIANG H X. 2023. Ecological risk assessment of heavy metals in soil-rice in a typical selenium-rich area of southern Anhui Province[J]. East China Geology,44(2):160-171(in Chinese with English abstract).
[31] TIAN L. 2009. Geochemical characteristics of thallium in South China[D]. Beijing: China University of Geosciences (Beijing) (in Chinese with English abstract).
[32] US EPA. 2002. Supplemental guidance for developing soil screening levels for superfund sites[R]. Washington: Office of Emergency and Remedial Response, U. S. Environmental Protection Agency.
[33] WANG C, ZENG X Y, YU Z Q, SHENG G Y, FU J M. 2013. Distribution and risk assessment of thallium and other metals in sediments from Hengyang Section of Xiangjiang River[J]. Asian Journal of Ecotoxicology,8(1):16-22 (in Chinese with English abstract).
[34] WU J Y. 2023. Research on the typical heavy metals control in situ and biological environment improvement in mercury thallium mine waste[D]. Guiyang: Guizhou University (in Chinese with English abstract).
[35] XIA J, HU J L, LI K, ZHAO W Q, LIU F, ZHANG K, CHENG S B, CUI S, LIU B. 2020. Analysis of thallium anomaly in groundwater around Liantang Town, Hezhou, Guangxi[J]. South China Geology,36(3):263-269 (in Chinese with English abstract).
[36] YU F, WANG W, YU Y, WANG D H, LIU S B, GAO J Q, LÜ B T, LIU L J. 2021.Distribution Characteristics and Ecological Risk Assessment of Heavy Metals in Soils from Jiulong Li-Be Mining Area, Western Sichuan Province, China[J]. Rock and Mineral Analysis, 40(3): 408-424(in Chinese with English abstract).
[37] ZHAO F Q. 2021. Mineralogical constraint on thallium mobility and transformation under supergenic conditions in Lanmuchang mercury-thallium mine, Xingren, Guizhou province, China[D]. Guiyang: Guizhou University (in Chinese with English abstract).
[38] ZHAO H Q, CHANG R Q, JIN Q, WU Y H, WANG X F, MA H C, LI M Y, FU H C. 2023. Spatial analysis and risk assessment of soil heavy metal pollution in the Xishimen iron mining area of Hebei province[J]. Rock and Mineral Analysis,42(2):371-382 (in Chinese with English abstract).
[39] ZHAO W Z, XIE X, ZHANG B B, ZHANG J T, HE T. 2024. Application of deep eutectic solvent extraction in eco-geological sample analysis[J]. East China Geology,45(1):78-87(in Chinese with English abstract).
[40] ZHOU C S, ZOU S Z, LI L J, SHEN H Y. 2015. Comparison of evaluation methods for soil heavy metals contamination[J]. Earth and Environment,43(6):709-713 (in Chinese with English abstract).
[41] 常晋娜, 瞿建国. 2005. 水体重金属污染的生态效应及生物监测[J]. 四川环境,24(4):29-33.
[42] 程贤达, 孙建伟, 贾煦, 商连南, 张龙, 孙亚柯. 2022. 豫西成矿带潭头盆地金矿区农田土壤重金属污染及来源解析[J]. 华东地质,43(3):313-323.
[43] 成永生, 王丹平, 黄宽心, 周瑶, 曾德兴, 李向阳, 张泽文. 2024. 表生水土环境铊污染成因研究现状与发展趋势[J]. 中国有色金属学报,34(6):2043-2058.
[44] 邓康. 2021. 南昌城水关系时空演变特征及其影响因素研究[D]. 武汉: 华中科技大学.
[45] 段维霞, 宋云波, 周取. 2019. 铊对生态环境和人体健康危害的研究进展[J]. 环境与职业医学,36(9):884-890.
[46] 高博, 孙可, 任明忠, 梁细荣, 彭平安, 盛国英, 傅家谟. 2008. 北江表层沉积物中铊污染的生态风险[J]. 生态环境,17(2):528-532.
[47] 何立斌, 孙伟清, 肖唐付. 2005. 铊的分布、存在形式与环境危害[J]. 矿物学报,25(3):230-236.
[48] 何茂粉, 张成丽. 2019. 新密市矿区铊含量分析及其环境风险评价[J]. 有色金属材料与工程,40(5):32-37.
[49] 侯青叶, 杨忠芳, 余涛, 夏学齐, 成杭新, 周国华. 2020. 中国土壤地球化学参数[M]. 北京: 地质出版社.
[50] 黄炎, 陈国光, 李雪平. 2020. 武夷山茶叶品质与土壤地球化学背景特征关系探讨[J]. 华东地质,41(2):166-176. doi: 10.16788/j.hddz.32-1865/P.2020.02.008
[51] 贾中民. 2020. 渝西北土壤重金属污染特征、源解析与生态健康风险评价[D]. 重庆: 西南大学.
[52] 李如忠, 潘成荣, 陈婧, 姜艳敏, 丁贵珍. 2012. 铜陵市区表土与灰尘重金属污染健康风险评估[J]. 中国环境科学,32(12):2261-2270.
[53] 李汉帆, 朱建如, 付洁. 2007. 铊的毒性及对人体的危害[J]. 中国公共卫生管理,23(1):77-79.
[54] 刘敬勇. 2006. 云浮硫铁矿区土壤中铊迁移行为的元素—铅同位素示踪研究[D]. 广州: 中国科学院研究生院(广州地球化学研究所).
[55] 刘福田, 王学求, 迟清华. 2021. 中国西南“三江”流域区土壤铊空间分布及健康风险评估[J]. 中国环境科学,41(4):1765-1777.
[56] 刘强, 项立辉, 程瑜, 吴灿, 方涛. 2021. 南京东郊沿江地区农用地土壤重金属分布特征及风险性评价[J]. 华东地质,42(1):37-45.
[57] 刘绍贵, 张桃林, 王兴祥, 潘剑君. 2010. 南昌市城郊表层土壤重金属污染特征研究[J]. 土壤通报,41(2):463-466.
[58] 鲁青庆. 2018. 石墨炉原子吸收法测定有色冶炼环境水样中痕量铊[J]. 湖南有色金属,34(1):75-77,80.
[59] 吕保贵. 2013. 南昌城市湿地生态系统健康评价[D]. 南昌: 南昌大学.
[60] 马军军, 韩正昌. 2017. 含铊污染废水处理技术的现状及研究[J]. 环境与可持续发展,42(5):65-67.
[61] 马建华, 韩昌序, 姜玉玲. 2020. 潜在生态风险指数法应用中的一些问题[J]. 地理研究,39(6):1233-1241.
[62] 郄海满, 文帮勇, 王继强, 周强强, 刘冰权. 2017. 江西赣州梓山地区富硒土壤重金属元素安全性评价[J]. 华东地质,38(3):234-240. doi: 10.16788/j.hddz.32-1865/P.2017.03.010
[63] 唐春花, 冯昌和, 马逸麟. 2005. 南昌城区土壤重金属污染现状研究[C]//江苏省地质学会. 地球科学与社会可持续发展——2005年华东六省一市地学科技论坛论文集. 武汉: 中国地质大学出版社, 5.
[64] 唐志敏, 张晓东, 张明, 周墨, 田福金, 王尚晓, 马青山, 王冲, 张洁, 牛晓楠, 宗乐丽, 黄丁伶.2023. 新安江流域土壤元素地球化学特征:来自岩石建造类型的约束[J]. 华东地质, 44(2): 172-185.
[65] 陶春军, 李明辉, 马明海, 张笑蓉, 杜国强, 梁红霞. 2023. 皖南某典型富硒区土壤-水稻重金属生态风险评估[J]. 华东地质,44(2):160-171. doi: 10.16788/j.hddz.32-1865/P.2023.02.005
[66] 田雷. 2009. 中国南方地区铊地球化学特征[D]. 北京: 中国地质大学(北京).
[67] 王晨, 曾祥英, 于志强, 盛国英, 傅家谟. 2013. 湘江衡阳段沉积物中铊等重金属的污染特征及其生态风险评估[J]. 生态毒理学报,8(1):16-22.
[68] 伍建业. 2023. 汞铊矿废弃物中典型重金属的原位固持及生境改良研究[D]. 贵阳: 贵州大学.
[69] 夏杰, 胡俊良, 李堃, 赵武强, 刘飞, 张鲲, 程顺波, 崔森, 刘冰. 2020. 广西贺州莲塘镇周边地下水铊异常浅析[J]. 华南地质与矿产,36(3):263-269.
[70] 于沨, 王伟, 于扬, 王登红, 刘善宝, 高娟琴, 吕秉廷, 刘丽君.2021. 川西九龙地区锂铍矿区土壤重金属分布特征及生态风险评价[J]. 岩矿测试, 40(3): 408-424.
[71] 赵凤其. 2021. 贵州兴仁滥木厂汞铊矿区表生条件下铊迁移转化的矿物学机制[D]. 贵阳: 贵州大学.
[72] 赵恒谦, 常仁强, 金倩, 吴艳花, 王雪飞, 马会春, 李美钰, 付含聪. 2023. 河北西石门铁矿区土壤重金属污染空间分析及风险评价[J]. 岩矿测试,42(2):371-382.
[73] 赵文志, 谢旭, 张兵兵, 张锦涛, 何添. 2024. 深共晶溶剂在生态地质样品分析中的应用研究[J]. 华东地质,45(1):78-87. doi: 10.16788/j.hddz.32-1865/P.2024.01.006
[74] 周长松, 邹胜章, 李录娟, 申豪勇. 2015. 几种土壤重金属污染评价方法的对比[J]. 地球与环境,43(6):709-713.
-
