Spatial distribution characteristics and driving factors of soil thickness in low-hilly areas: A case study of Oroqen Autonomous Banner
-
摘要:
土壤厚度是土壤的一个重要特性，能直接反映土壤的发育程度，与土壤肥力密切相关，是鉴别土壤肥力的重要指标。以内蒙古鄂伦春自治旗为研究区，选取与土壤厚度密切相关的10项指标，基于SPSS 22.0软件对数据进行主成分分析，利用ArcGIS10.7和地理探测器(GeoDetector)，研究低山丘陵区低成本、可快速获取、高精度的土壤厚度数字制图方法，并对土壤厚度空间变异驱动因子进行分析。结果显示: 鄂伦春自治旗土壤厚度空间分布规律整体表现为西北薄、东南厚，混淆矩阵精度验证结果显示总精度为74.32%，卡帕系数为0.744，表明鄂伦春自治旗土壤厚度数字制图结果跟实际高度一致; 单因子探测结果显示土壤类型、成土母质驱动因子对当地土壤厚度空间分布变异性有较强的解释力; 交互因子探测结果显示地形湿度指数∩径流强度系数的q值(0.58)大于地形湿度指数+径流强度系数的q值(0.47)，呈现非线性增强，其余因子间均表现出双因子增强，表明多因子交互作用对当地土壤厚度空间分布变异性的影响要大于单因子产生的影响。研究成果可为当地农业可持续发展、退耕还林、种植适宜性、国土空间规划提供科学依据。
Abstract:Soil thickness is a fundamental soil characteristic that directly reflects soil development, and it is closely related to soil fertility. It is also an important indicator to identify soil fertility. Taking Oroqen Autonomous Banner of Inner Mongolia as the study case, the authors in this paper selected 10 indicators closely related to soil thickness. The principal component analysis of these data were conducted by SPSS 22.0 software, and soil thickness digital mapping. method with the characteristic of low cost, rapid acquirability and high precision was probed by ArcGIS10.7 and GeoDetector. Besides, driving factors of the spatial variation of soil thickness was analyzed. The study reveals that soil thickness in Oroqen Autonomous Banner is distributed thinly in the northwest and thickly in the southeast, and the accuracy verification results of the confusion matrix indicates a total accuracy of 74.32% and the kappa coefficient of 0.744, indicating a high level of agreement with the actual situation. The single-factor detection results show that the soil type and the driving factor of soil-forming matrix significantly influence the spatial distribution variability of local soil thickness. The results of the interacting factor detection show that the q-value (0.58) of the terrain humidity index ∩ runoff intensity coefficient is larger than the q-value (0.47) of the terrain humidity index + runoff intensity coefficient, indicating a non-linearly enhancement. And the other factors show two-factor enhancement. This suggests that the effect of multifactor interaction on the local spatial distribution of soil thickness is greater than that of a single factor. This study could provide scientific basis for the sustainable development of local agriculture, returning ploughland to forests, planting suitability, and spatial planning of the national territory.
-
Key words:
- principal component analysis /
- soil thickness /
- Oroqen Autonomous Banner /
- geodetector /
- low-hilly area
-
-
表 1 主成分特征值及方差贡献率
Table 1. Principal component eigenvalues and variance contribution rates
主成分 初始特征值 提取载荷平方和 特征值 方差贡献率/% 累计贡献率/% 特征值 方差贡献率/% 累计贡献率/% F1 3.341 33.411 33.411 3.341 33.411 33.411 F2 3.155 31.550 64.960 3.155 31.550 64.960 F3 1.035 10.354 75.314 1.035 10.354 75.314 F4 0.680 6.799 82.113 — — — F5 0.669 6.695 88.808 — — — F6 0.580 5.803 94.611 — — — F7 0.381 3.815 98.426 — — — F8 0.157 1.574 100.000 — — — 注: “—”表示无数值。
下载: 导出CSV
表 2 鄂伦春自治旗土壤厚度空间分布因子探测器q值统计
Table 2. Statistics of q value for soil thickness spatial distribution factor detectors in Oroqen Autonomous Banner
驱动因子 平面曲率 剖面曲率 地形湿度指数 径流强度系数 土壤类型 成土母质 海拔 坡度 土地利用类型 植被覆盖度 q值 0.29 0.26 0.20 0.27 0.75 0.72 0.50 0.53 0.44 0.16
下载: 导出CSV
表 3 交互因子对鄂伦春自治旗土壤厚度的影响
Table 3. Influence of interaction factors on the soil thickness in Oroqen Autonomous Banner
交互因子 q 交互因子 q 交互因子 q 土地利用∩海拔 0.64 剖面曲率∩成土母质 0.77 植被覆盖度∩径流强度系数 0.54 土地利用∩径流强度系数 0.53 剖面曲率∩土壤类型 0.80 植被覆盖度∩平面曲率 0.38 土地利用∩平面曲率 0.54 土壤类型∩海拔 0.82 植被覆盖度∩坡度 0.40 土地利用∩坡度 0.66 土壤类型∩径流强度系数 0.80 植被覆盖度∩地形湿度指数 0.59 土地利用∩地形湿度指数 0.50 土壤类型∩平面曲率 0.82 地形湿度指数∩海拔 0.32 土地利用∩植被覆盖度 0.48 土壤类型∩坡度 0.87 地形湿度指数∩径流强度系数 0.58 土地利用∩成土母质 0.79 土壤类型∩地形湿度指数 0.78 地形湿度指数∩平面曲率 0.55 土地利用∩土壤类型 0.80 土壤类型∩植被覆盖度 0.77 地形湿度指数∩坡度 0.39 土地利用∩剖面曲率 0.53 土壤类型∩成土母质 0.81 坡度∩海拔 0.56 剖面曲率∩海拔 0.59 成土母质∩海拔 0.84 坡度∩径流强度系数 0.71 剖面曲率∩径流强度系数 0.39 成土母质∩径流强度系数 0.77 坡度∩平面曲率 0.56 剖面曲率∩平面曲率 0.48 成土母质∩平面曲率 0.79 平面曲率∩海拔 0.58 剖面曲率∩坡度 0.57 成土母质∩坡度 0.83 平面曲率∩径流强度系数 0.65 剖面曲率∩地形湿度指数 0.36 成土母质∩地形湿度指数 0.75 径流强度系数∩海拔 0.41 剖面曲率∩植被覆盖度 0.37 成土母质∩植被覆盖度 0.76 径流强度系数∩海拔 0.62 注：“∩”表示两个因子间的交互作用。
下载: 导出CSV
表 4 鄂伦春自治旗土壤厚度分级结果混淆矩阵
Table 4. Confusion matrix of soil thickness classification results in Oroqen Autonomous Banner
混淆矩阵 土壤厚度分级/cm 精度/% 一级(0, 28] 二级(28, 47] 三级(47, 64] 四级(64, 85] 五级(85, 115] 六级(115, 140] 七级(140, 160] 八级(>160) 总计 土壤厚度实测数据分级/cm 一级(0, 28] 11 5 0 1 1 0 0 0 18 61.11 二级(28, 47] 0 22 4 1 1 1 0 0 29 75.86 三级(47, 64] 0 0 12 2 1 2 0 0 17 70.59 四级(64, 85] 0 0 0 19 1 2 1 1 24 79.17 五级(85, 115] 0 0 1 0 15 0 2 2 20 75.00 六级(115, 140] 0 0 0 0 1 17 5 0 23 73.91 七级(140, 160] 0 0 0 1 0 1 4 0 6 66.67 八级(>160) 0 0 0 0 1 0 3 19 23 82.61 总计 11 27 17 24 21 23 15 22 160 74.38
下载: 导出CSV
-
[1] 曾宪勤, 刘宝元, 刘瑛娜, 等. 2008. 北方石质山区坡面土壤厚度分布特征——以北京市密云县为例[J]. 地理研究, 2008, 27(6): 1281-1289. doi: 10.3321/j.issn:1000-0585.2008.06.007
Zeng X Q, Liu B Y, Liu Y N, et al. Soil depth distribution characteristics on the lithoidal mountainous slope of northern China: A case study of Miyun County, Beijing[J]. Geographical Research, 2008, 27(6): 1281-1289. doi: 10.3321/j.issn:1000-0585.2008.06.007
[2] 李润奎, 彭明, 河野泰之, 等. 基于分层策略和模糊推理的北方石质山区土壤厚度制图——以滦平县虎什哈流域为例[J]. 地理研究, 2013, 32(5): 965-973.
Li R K, Peng M, Kono Y, et al. Soil depth mapping in lithoidal mountainous areausing stratified strategy and fuzzy logic: A case study in Hushiha watershed, North China[J]. Geographical Research, 2013, 32(5): 965-973.
[3] 刘创民, 李昌哲, 史敏华, 等. 多元统计分析在森林土壤肥力类型分辨中的应用[J]. 生态学报, 1996, 16(4): 444-447.
Liu C M, Li C Z, Shi M H, et al. Multivariate statistical analysis techniques applicated in differentiation of soil fertility[J]. Acta Ecologica Sinica, 1996, 16(4): 444-447.
[4] 李润奎, 朱阿兴, Augello P C, 等. SWAT模型对高精度土壤信息的敏感性研究[J]. 地球信息科学, 2007, 9(3): 72-78, 90.
Li R K, Zhu A X, Augello P C, et al. Sensitivity of SWAT model to detailed soil information[J]. Journal of Geo-information Science, 2007, 9(3): 72-78, 90.
[5] Kuriakose S L, Devkota S, Rossiter D G, et al. Prediction of soil depth using environmental variables in an anthropogenic landscape, a case study in the western Ghats of Kerala, India[J]. CATENA, 2009, 79(1): 27-38 doi: 10.1016/j.catena.2009.05.005
[6] 王志强, 刘宝元, 海春兴. 土壤厚度对天然草地植被盖度和生物量的影响[J]. 水土保持学报, 2007, 21(4): 164-167.
Wang Z Q, Liu B Y, Hai C X. Effects of soil depth on vegetation cover and above ground biomass in east part of inner Mongo\|lia[J]. Journal of Soil and Water Conservation, 2007, 21(4): 164-167.
[7] 王绍强, 朱松丽, 周成虎. 中国土壤土层厚度的空间变异性特征[J]. 地理研究, 2001, 20(2): 161-169.
Wang S Q, Zhu S L, Zhou C H. Characteristics of spatial variability of soil thickness in China[J]. Geographical Research, 2001, 20(2): 161-169.
[8] 王改粉, 赵玉国, 杨金玲, 等. 流域尺度土壤厚度的模糊聚类与预测制图研究[J]. 土壤, 2011, 43(5): 835-841.
Wang G F, Zhao Y G, Yang J L, et al. Prediction and mapping of soil depth at a watershed scale with fuzzy-c-means clustering method[J]. Soils, 2011, 43(5): 835-841.
[9] 王德彩, 叶希琛, 张雅梅, 等. 利用数字土壤制图技术评价桉树林土壤肥力[J]. 土壤通报, 2021, 52(1): 139-147.
Wang D C, Ye X C, Zhang Y M, et al. Evaluation of soil fertility under eucalyptus plantation using digital soil mapping[J]. Chinese Journal of Soil Science, 2021, 52(1): 139-147.
[10] 朱阿兴, 杨琳, 樊乃卿, 等. 数字土壤制图研究综述与展望[J]. 地理科学进展, 2018, 37(1): 66-78.
Zhu A X, Yang L, Fan N Q, et al. The review and outlook of digital soil mapping[J]. Progress in Geography, 2018, 37(1): 66-78.
[11] 王军, 傅伯杰, 邱扬, 等. 黄土高原小流域土壤养分的空间异质性[J]. 生态学报, 2002, 22(8): 1173-1178.
Wang J, Fu B J, Qiu Y, et al. Spatial heterogeneity of soil nutrients in a small catchment of the loess Plateau[J]. Acta Ecologica Sinica, 2002, 22(8): 1173-1178.
[12] 王强, 吴炳方, 朱亮. 土壤厚度研究进展[J]. 安徽农业科学, 2012, 40(9): 5273-5277, 5287.
Wang Q, Wu B F, Zhu L. Review of soil depth[J]. Journal of Anhui Agricultural Sciences, 2012, 40(9): 5273-5277, 5287.
[13] Dietrich W E, Reiss R, Hsu M L, et al. A process-based model for colluvial soil depth and shallow landsliding using digital elevation data[J]. Hydrological Processes, 1995, 9(3/4): 383-400.
[14] Minasny B, McBratney A B. A rudimentary mechanistic model for soil production and landscape development[J]. Geoderma, 1999, 90(1/2): 3-21.
[15] 易湘生, 李国胜, 尹衍雨, 等. 土壤厚度的空间插值方法比较——以青海三江源地区为例[J]. 地理研究, 2012, 31(10): 1793-1805.
Yi X S, Li G S, Yin Y Y, et al. Comparison on soil depth prediction among different spatial interpolation methods: A case study in the Three-River Headwaters Region of Qinghai Province[J]. Geographical Research, 2012, 31(10): 1793-1805.
[16] Jenny H. Factors of Soil Formation: A System of Quantitative Pedology[M]. New York: Dover Publications, Inc., 1994.
[17] 张振华. 耦合植被物候与SoLIM的新疆绿洲土壤盐渍化数字制图[D]. 乌鲁木齐: 新疆大学, 2020.
Zhang Z H. Soil Salinization Digital Mapping Coupled with Vegetation Phenology and Soil Land Inference Model in the Oasis of Xinjiang[D]. Urumqi: Xinjiang University, 2020.
[18] 杨琳, 朱阿兴, 李宝林, 等. 应用模糊c均值聚类获取土壤制图所需土壤-环境关系知识的方法研究[J]. 土壤学报, 2007, 44(5): 784-791.
Yang L, Zhu A X, Li B L, et al. Extraction of Knowledge about Soil-Environment relationship for soil mapping using Fuzzy c-Means (FCM) clustering[J]. Acta Pedologica Sinica, 2007, 44(5): 784-791.
[19] 何婷, 赵春兰, 李屹, 等. 基于FCM聚类的模糊综合评价方法[J]. 陕西师范大学学报: 自然科学版, 2023, 51(1): 111-119.
He T, Zhao C L, Li Y, et al. Research on fuzzy comprehensive evaluation method based on FCM clustering[J]. Journal of Shaanxi Normal University (Natural Science Edition), 2023, 51(1): 111-119.
[20] 戴亮亮, 罗敏玄, 张涛, 等. 基于主成分分析法的低山丘陵区土壤厚度快速评定方法与实践——以河南省罗山县为例[J]. 华南地质, 2021, 37(04): 377-386.
Dai L L, Luo M X, Zhang T, et al. Method and practice of rapid evaluation of soil thickness in low mountain and hilly area based on principal component analysis: Taking Luoshan county, Henan Province as an example[J]. South China Geology, 2021, 37(4): 377-386.
[21] 邰苏日嘎拉, 王永亮, 陈国栋, 等. 基于SRP模型的内蒙古鄂伦春地区生态脆弱性评价[J]. 中国地质, 2024, 51(1): 234-247.
Tai S R G L, Wang Y L, Chen G D, et al. Ecological vulnerability assessment of Oroqen region in the Inner Mongolia based on SRP model[J]. Geology in China, 2024, 51(1): 234-247.
[22] 田丰收, 刘新平, 原伟鹏. 新疆和田地区耕地面源污染生态风险评价[J]. 干旱区地理, 2019, 42(2): 295-304.
Tian F S, Liu X P, Yuan W P. Ecological risk assessment of farmland non-point source pollution in Hotan Prefecture, Xinjiang[J]. Arid Land Geography, 2019, 42(2): 295-304.
[23] 马骏. 三峡库区重庆段生态脆弱性动态评价[D]. 重庆: 西南大学, 2014.
Ma J. Dynamic Evaluation of Ecological Vulnerability in the Three Gorges Reservoir Region in Chongqing Section, China[D]. Chongqing: Southwest University. 2014.
[24] 田福金, 马青山, 张明, 等. 基于主成分分析和熵权法的新安江流域水质评价[J]. 中国地质, 2023, 50(2): 495-505.
Tian F J, Ma Q S, Zhang M, et al. Evaluation of water quality in Xin'anjiang River basin based on principal component analysis and entropy weight method[J]. Geology in China, 2023, 50(2): 495-505.
[25] 徐梦婷, 王强, 郝艳宾, 等. 基于主成分分析的核桃品种油用性状综合评价[J]. 食品工业科技, 2024, 45(2): 235-242.
Xu M T, Wang Q, Hao Y B, et al. Comprehensive evaluation of oil-use traits of walnut varieties based on principal component analysis[J]. Science and Technology of Food Industry, 2024, 45(5): 235-242.
[26] 张晓磊, 杨源祯, 阎琨, 等. 广西珍珠湾红树林湿地沉积物重金属分布及评价[J]. 中国地质调查, 2022, 9(5): 104-110. doi: 10.19388/j.zgdzdc.2022.05.12
Zhang X L, Yang Y Z, Yan K, et al. Distribution and evaluation of heavy metals in sediments of Zhenzhu Bay mangrove wetland in Guangxi[J]. Geological Survey of China, 2022, 9(5): 104-110. doi: 10.19388/j.zgdzdc.2022.05.12
[27] 刘潇, 薛莹, 纪毓鹏, 等. 基于主成分分析法的黄河口及其邻近水域水质评价[J]. 中国环境科学, 2015, 35(10): 3187-3192.
Liu X, Xue Y, Ji Y P, et al. An assessment of water quality in the Yellow River estuary and its adjacent waters based on principal component analysis[J]. China Environmental Science, 2015, 35(10): 3187-3192.
[28] 傅德印. 主成分分析中的统计检验问题[J]. 统计教育, 2007(9): 4-7.
Fu D Y. Statistical testing problems in principal component analysis[J]. Statistical Education, 2007(9): 4-7.
[29] 黄美菱, 黄露滴, 龙飞利. 基于主成分分析法的西安市生态环境评价[J]. 环境与发展, 2017, 29(8): 57, 59.
Huang M L, Huang L D, Long F L. Evaluation of ecological environment in Xi'an Based on principal component analysis[J]. Environment and Development, 2017, 29(8): 57, 59.
[30] 王钰, 胡宝清. 西江流域生态脆弱性时空分异及其驱动机制研究[J]. 地球信息科学学报, 2018, 20(7): 947-956.
Wang Y, Hu B Q. Spatial and temporal differentiation of ecological vulnerability of Xijiang river in Guangxi and its driving mechanism[J]. Journal of Geo-information Science, 2018, 20(7): 947-956.
[31] 王劲峰, 徐成东. 地理探测器: 原理与展望[J]. 地理学报, 2017, 72(1): 116-134.
Wang J F, Xu C D. Geodetector: Principle and prospective[J]. Acta Geographica Sinica, 2017, 72(1): 116-134.
[32] 叶妍君, 齐清文, 姜莉莉, 等. 基于地理探测器的黑龙江垦区农场粮食产量影响因素分析[J]. 地理研究, 2018, 37(1): 171-182.
Ye Y J, Qi Q W, Jiang L L, et al. Impact factors of grain output from farms in Heilongjiang reclamation area based on geographical detector[J]. Geographical Research, 2018, 37(1): 171-182.
[33] 阎琨, 杨源祯, 李伟. 广西钦州典型农业区表层土壤Se含量分布特征及影响因素[J]. 中国地质调查, 2023, 10(6): 69-76. doi: 10.19388/j.zgdzdc.2023.06.08
Yan K, Yang Y Z, Li W. Distribution characteristics and influencing factors of surface soil selenium content in typical agricultural areas of Qinzhou in Guangxi[J]. Geological survey of China, 2023, 10(6): 69-76. doi: 10.19388/j.zgdzdc.2023.06.08
[34] 田智慧, 尹传鑫, 王晓蕾. 鄱阳湖流域生态环境动态评估及驱动因子分析[J]. 环境科学, 2023, 44(2): 816-827.
Tian Z H, Yin C X, Wang X L. Dynamic monitoring and driving factors analysis of ecological environment Qualityin Poyang lake basin[J]. Environmental Science, 2023, 44(2): 816-827.
[35] 芦园园, 张甘霖, 赵玉国, 等. 复杂景观环境下土壤厚度分布规则提取与制图[J]. 农业工程学报, 2014, 30(18): 132-141.
Lu Y Y, Zhang G L, Zhao Y G, et al. Extracting and mapping of soil depth distribution rules in complex landscape environment[J]. Transactions of the Chinese Society of Agricultural Engineering, 2014, 30(18): 132-141.
-
