Susceptibility assessment of mountain landslide based on feature indicator screening and negative sample optimization
-
摘要:
滑坡易发性评价是开展灾害监测预警工作的基础，如何科学、合理地筛选特征指标并优化评价样本仍是当前棘手且易被忽略的问题。以湖南省龙山县为例，基于斜坡单元提取高程、坡度、坡向等15项特征指标，经主成分分析(principal component analysis, PCA)、相关性分析与共线性诊断筛选优质指标，提出一种优化负样本(optimize negative samples, ONS)的方法构建评价样本，然后使用确定性系数-随机森林(certainty factor-random forest, CF-RF) 模型进行滑坡易发性制图，并根据受试者工作特征(receiver operating characteristic, ROC)曲线与合理性分析检验预测结果准确性。研究表明: ONS-CF-RF模型能显著提升模型评价精度，其受试者ROC曲线下面积(area under curve, AUC)较CF-RF模型AUC提升了10.64%; 研究区滑坡高、极高易发区较集中于研究区西北角人类聚集区，低易发区分布于受人类活动影响较小的高海拔山区。研究成果可为龙山县滑坡灾害防治提供科学指导，也可为同类型区域滑坡易发性分区提供参考依据。
Abstract:Landslide susceptibility assessment is the basis of disaster monitoring and early warning. How to scientifically and reasonably screen feature indicators and optimize assessment samples is still a difficult and easily ignored problem. The authors took Longshan County of Hunan Province as an example, and screened high-quality indicators by principal component analysis (PCA), correlation analysis and collinearity diagnosis, based on 15 feature indicators such as elevation, slope and slope direction. An optimize negative samples (ONS) method was proposed to construct assessment samples, and then certainty factor-random forest (CF-RF) model was used to map landslide susceptibility. The accuracy of prediction results was tested according to receiver operating characteristic (ROC) curve and rationality analysis. The results show that ONS-CF-RF model can significantly enhance the accuracy of model assessment. The area under curve (AUC) of this model has increased by 10.64% compared to the AUC of CF-RF model. The high landslide prone area is concentrated in human gathering area in the northwest corner of the study area, while the low landslide prone area is distributed in the high-altitude mountainous area which is less affected by human activities. The research results could provide scientific guidance for the prevention and control of landslide disaster in Longshan County, and could also provide references for the landslide prone zoning in the same type of region.
-
-
表 1 资料数据详细来源
Table 1. Detailed sources of data
序号 数据名称 来源 类型 备注 1 历史滑坡灾害点 湘西州1∶5万地质灾害详查 Excel表格 截至2017年，历史滑坡和潜在滑坡共计221处 2 地质图 湖南省自然资源事务中心 jpg图片 纸质扫描存档，比例尺为1∶200 000 3 行政区划 http://datav.aliyun.com 矢量 更新于2021年5月 4 地层年代与断层 http://dcc.ngac.org.cn 矢量 5 河网与路网 https://www.resdc.cn 矢量 6 土地利用 https://gtdc.mnr.gov.cn 栅格 湖南省土地利用图，比例尺为1∶1 200 000 7 DEM 91卫图 栅格 ALOS DEM，分辨率为12.5 m
下载: 导出CSV
表 2 成分信息量分析
Table 2. Ingredient information analysis
主成分 特征根 特征根 方差解释率/% 累积方差解释率/% PC01 4.216 46.848 46.848 PC02 1.393 15.475 62.323 PC03 1.085 12.055 74.379 PC04 0.979 10.879 85.258 PC05 0.711 7.904 93.161 PC06 0.368 4.091 97.252 PC07 0.182 2.021 99.273 PC08 0.046 0.516 99.789 PC09 0.019 0.211 100
下载: 导出CSV
表 3 各指标VIF值
Table 3. VIF value for each indicator
地质时期 森林类型 距主道路距离 建设用地占比 距地表水源距离 距断层距离 主成分PC01 主成分PC04 地质时期 1.066 1.068 1.071 1.051 1.068 1.068 1.055 森林类型 1.070 1.075 1.070 1.072 1.073 1.027 1.072 距主道路距离 1.154 1.157 1.158 1.109 1.158 1.084 1.138 建设用地占比 1.005 1.000 1.005 1.005 1.005 1.005 1.005 距地表水源距离 1.133 1.151 1.106 1.155 1.155 1.151 1.109 距断层距离 1.014 1.016 1.018 1.018 1.018 1.014 1.011 PC01 1.163 1.114 1.091 1.166 1.162 1.162 1.129 PC04 1.134 1.148 1.132 1.152 1.107 1.145 1.115
下载: 导出CSV
表 4 研究区特征指标分级信息
Table 4. Classification information of feature indicator in the study area
类型 评价指标 分区标准 CF值 类型 评价指标 分区标准 CF值 离散型 森林类型 非林地 -0.567 1 连续型 距断层距离 ＜300 m 0.400 4 竹林地 0.408 3 [300, 600) m 0.159 2 灌木林地 -0.038 2 [600, 900) m -0.017 4 乔木林地 0.013 7 [900, 1 200) m -0.475 1 其他林地 -0.105 8 [1 200, 1 500) m -0.551 6 地层与地貌 奥陶系 0.050 2 [1 500, 1 800) m -0.136 1 志留系 0.378 7 [1 800, 2 100) m -0.440 2 泥盆系 -1.000 0 ≥2 100 m 0.075 8 二叠系 -0.792 5 PC01 ＜-26 -0.087 5 三叠系 -0.767 6 [-26, -24) -0.120 1 第四纪 0.859 5 [-24, -22) 0.374 6 白垩系 0.664 8 [-22, -20) 0.126 5 寒武系 -0.532 8 [-20, -18) 0.253 8 河流积水区 0.662 9 [-18, -16) 0.195 9 连续型 距主道路距离 ＜250 m 0.525 2 [-16, -14) 0.167 7 [250, 750) m -0.070 5 [-14, -12) -0.140 0 [750, 1 250) m 0.103 1 [-12, -10) -0.398 7 [1 250, 1 750) m -0.292 3 [-10, -8) -0.610 1 [1 750, 2 250) m -0.331 2 [-8, -6) -0.749 5 [2 250, 2 750) m -0.682 4 ≥-6 -0.716 0 ≥2 750 m -0.311 6 PC04 ＜-40 -0.655 7 建设用地占比 ＜2% -0.754 5 [-40, -20) -0.511 5 [2, 12)% 0.689 8 [-20, 0) 0.008 7 [12, 22)% 0.851 2 [0, 20) 0.123 6 [22, 32)% 0.874 7 [20, 40) 0.204 2 [32, 42)% 0.968 2 [40, 60) -0.425 6 [42, 52)% 0.743 3 [60, 80) 0.278 9 ≥52% 0.489 5 [80, 100) 0.005 5 距地表水源距离 ＜200 m 0.527 7 [100, 120) 0.214 1 [200, 450) m -0.015 2 [120, 140) -0.167 2 [450, 700) m 0.089 3 [140, 160) 0.275 7 [700, 950) m -0.086 2 [160, 180) -0.213 2 [950, 1 200) m -0.313 3 [180, 200) 0.585 0 [1 200, 1 450) m -0.601 8 ≥200 0.078 6 [1 450, 1 700) m -0.815 2 ≥1 700 m -0.877 3
下载: 导出CSV
表 5 研究区模型结果对比分析
Table 5. Comparative analysis of the model results in the study area
分区 CF-RF模型 区域面积/km2 滑坡数量/个 滑坡面积/104 m2 FR值 低易发区 751.348 3 2 1.664 0 0.037 8 中易发区 1 000.134 1 17 38.123 0 0.241 5 高易发区 837.074 2 43 22.800 5 0.730 0 极高易发区 495.120 9 155 143.907 7 4.448 7 低易发区 1 086.163 4 8 8.619 0 0.104 7 中易发区 1 060.840 2 23 37.142 0 0.308 1 高易发区 491.194 4 37 21.626 5 1.070 4 极高易发区 445.479 5 149 139.107 7 4.753 0
下载: 导出CSV
表 6 ONS-CF-RF模型统计分析
Table 6. Statistical analysis of ONS-CF-RF model
分区 分区面积/km2 分区面积占比/% 滑坡数量/个 滑坡密度/(个· 10 000 m-2) 低易发区 1 168.1 37.88 8 0.68 中易发区 1 057.3 34.29 23 2.18 高易发区 467.2 15.15 37 7.92 极高易发区 391.0 12.68 149 38.10
下载: 导出CSV
-
