Progress and prospective analysis of natural hydrogen investigation research in Shangyi-Zhangbei area
-
摘要:
在全球能源转型背景下，天然氢已成为新能源领域的研究热点，许多国家陆续开展了针对天然氢的调查工作。结合前人的研究成果，将已发现有H2逸出显示的张北盆地作为天然氢研究重点区域，选择在尚义—张北地区开展地质、土壤气体地球化学、重力及大地电磁测深调查研究工作。结果表明: 尚义—张北地区土壤的H2异常围绕胡家洼—马驹沟呈周边高、中间低的环形分布特征，部分采样点土壤H2浓度超过5 000×10-6; 氢同位素δD为-567‰~-461‰，表明H2主要为幔源成因。依据重力和大地电磁测深结果，推断出12条隐伏断裂和3个沉积凹陷，并解译了盆地基底埋深和构造格架。断裂是连接深部氢源的有利通道，早白垩世和古近纪—新近纪的沉积组合具备储气潜力，泥岩和致密块状玄武岩流起到了圈闭盖层的作用。通过综合分析，划定H2逸出较少且被玄武岩流覆盖的沉积凹陷区域作为天然氢勘查有利区，面积约590 km2。研究可为尚义—张北地区天然氢的进一步勘探提供依据。
Abstract:Under the background of the global energy transition, natural hydrogen has emerged as a research hotspot in the field of new energy, and many countries have successively launched investigations into natural hydrogen. On the basis of previous research findings, Zhangbei Basin, with the presence of H2 escape, is designated as a key area for natural hydrogen research. Then, geological, soil gas geochemical, gravity, and magnetotelluric sounding investigations were carried out in Shangyi-Zhangbei area. The results reveal that soil H2 anomaly in Shangyi-Zhangbei area exhibits a ring-shaped distribution pattern with high values in the periphery and low values in the center around Hujiawa-Majugou. H2 concentration in some sampling points exceeds 5, 000×10-6. Hydrogen isotope analysis (δD values ranging from -567‰ to -461‰) indicates that H2 is predominantly of mantle-derived origin. Twelve hidden faults and 3 sedimentary depressions have been identified according to gravity and magnetotelluric sounding results, and the basement depth and tectonic framework of the basin have been interpreted. It is considered that faults are favorable channels connecting deep hydrogen sources. The sedimentary assemblages of the Cretaceous and the Paleogene-Neogene have the potential for gas storage. Mudstones and dense massive basalt flows play the role of trap caprocks. The sedimentary sag areas with less H2 escape and covered by basalt flows were delimited as favorable areas for further exploration of natural hydrogen, after comprehensive analysis, with an area of approximately 590 km2. This study could provide basis for further exploration of natural hydrogen in Shangyi-Zhangbei area.
-
-
表 1 土壤H2浓度统计参数特征
Table 1. Characteristics of statistical parameters of H2 concentration in soil
H2浓度/10-6 极值比 变异系数 最大值 最小值 平均值 中位数 背景值 标准差 异常下限 1 000 1 200 84 5 266 220 1 000 1.33
下载: 导出CSV
表 2 凹陷区土壤H2浓度统计参数特征
Table 2. Statistical characteristics of soil H2 concentration in the depression area
位置 H2浓度/10-6 总样本数/个 最大值 最小值 平均值 中位数 下四分位数 上四分位数 标准离差 胡家洼凹陷 967 1 142 74 34 180 179 113 马驹沟凹陷 1 000 1 186 84 30 219 250 248 凹陷区外 1 000 1 210 86 33 262 276 1 156
下载: 导出CSV
-
[1] Guélard J, Beaumont V, Rouchon V, et al. Natural H2 in Kansas: Deep or shallow origin?[J]. Geochemistry, Geophysics, Geosystems, 2017, 18(5): 1841-1865. doi: 10.1002/2016GC006544
[2] Prinzhofer A, Cissé C S T, Diallo A B. Discovery of a large accumulation of natural hydrogen in Bourakebougou (Mali)[J]. International Journal of Hydrogen Energy, 2018, 43(42): 19315-19326. doi: 10.1016/j.ijhydene.2018.08.193
[3] Prinzhofer A, Moretti I, Françolin J, et al. Natural hydrogen continuous emission from sedimentary basins: The example of a Brazilian H2-emitting structure[J]. International Journal of Hydrogen Energy, 2019, 44(12): 5676-5685. doi: 10.1016/j.ijhydene.2019.01.119
[4] Lefeuvre N, Truche L, Donzé F V, et al. Native H2 exploration in the Western Pyrenean foothills[J]. Geochemistry, Geophysics, Geosystems, 2021, 22(8): e2021GC009917. doi: 10.1029/2021GC009917
[5] Frery E, Langhi L, Maison M, et al. Natural hydrogen seeps identified in the North Perth Basin, Western Australia[J]. International Journal of Hydrogen Energy, 2021, 46(61): 31158-31173. doi: 10.1016/j.ijhydene.2021.07.023
[6] Ramirez A C, Penagos F G, Rodriguez G, et al. Natural H2 emissions in colombian ophiolites: First findings[J]. Geosciences, 2023, 13(12): 358. doi: 10.3390/geosciences13120358
[7] Zgonnik V, Beaumont V, Deville E, et al. Evidence for natural molecular hydrogen seepage associated with Carolina bays (surficial, ovoid depressions on the Atlantic Coastal Plain, Province of the USA)[J]. Progress in Earth and Planetary Science, 2015, 2: 31. doi: 10.1186/s40645-015-0062-5
[8] Hand E. Hidden hydrogen[J]. Science, 2023, 379(6633): 630-636. doi: 10.1126/science.adh1477
[9] Cha J, Lee J Y. A review on occurrence, mechanism and distribution of natural hydrogen as a promising energy source[J]. Journal of the geological society of Korea, 2023, 59(3): 513-526. doi: 10.14770/jgsk.2023.034
[10] Rystad Energy. The white gold rush and the pursuit of natural hydrogen[EB/OL]. (2024-03-13).
https://www.rystadenergy.com/news/white-gold-rush-pursuit-natural-hydrogen .[11] 李玉宏, 魏仙样, 卢进才, 等. 内蒙古自治区商都盆地新生界氢气成因[J]. 天然气工业, 2007, 27(9): 28-30.
Li Y H, Wei X Y, Lu J C, et al. Origin of Cenozoic hydrogen in Shangdu basin, Inner Mongolia Autonomous Region[J]. Natural Gas Industry, 2007, 27(9): 28-30.
[12] 万燕鸣. 全球天然氢的勘探、应用与发展[J]. 中国能源, 2020, 42(9): 33-37.
Wan Y M. Global exploration, application and prospect of natural hydrogen[J]. Energy of China, 2020, 42(9): 33-37.
[13] 田黔宁, 张炜, 王海华, 等. 能源转型背景下不可忽视的新能源: 天然氢[J]. 中国地质调查, 2022, 9(1): 1-15. doi: 10.19388/j.zgdzdc.2022.01.01
Tian Q N, Zhang W, Wang H H, et al. Non-negligible new energy in the energy transition context: Natural hydrogen[J]. Geological Survey of China, 2022, 9(1): 1-15. doi: 10.19388/j.zgdzdc.2022.01.01
[14] 张振利, 魏文通, 刘增校, 等. 河北省、北京市、天津市区域地质志[R]. 石家庄: 河北省区域地质矿产调查研究所, 河北地质大学, 河北省地球物理勘查院, 2013.
Zhang Z L, Wei W T, Liu Z J, et al. Regional Geology of Hebei, Beijing, and Tianjin[R]. Shijiazhuang: Hebei Institute of Regional Geo\|logy and Mineral Resources Survey, Hebei GEO University, 2013.
[15] 郭金城, 张振利, 张计东, 等. 张家口幅K50C004001 1: 25万区域地质调查报告[R]. 北京: 全国地质资料馆, 2008.
Guo J C, Zhang Z L, Zhang J D, et al. Geological survey report of the Zhangjiakou Sheet (K50C004001), 1: 250, 000[R]. Beijing: National Geological Data Museum, 2008.
[16] 易明初, 李晓. 燕山地区喜马拉雅运动及现今地壳稳定性研究[M]. 北京: 地震出版社, 1991.
Yi M C, Li X. Himalayan Movement in Yanshan Area and Present Crust Stability[M]. Beijing: Seismological Press, 1991.
[17] 胡玲, 宋鸿林. "内蒙地轴"南缘断裂带的活动时代及结构分析[J]. 中国地质, 2002, 29(4): 369-373.
Hu L, Song H L. Ages of activities of the southern "Inner Mongolian axis" marginal fault belt and an analysis of its structure[J]. Geology in China, 2002, 29(4): 369-373.
[18] 夏国礼. 坝上张北盆地成热的可能性探讨[J]. 河北地质矿产信息, 2004(2): 28-31.
Xia G L. Discussion on the possibility of maturity in the Zhangbei Basin on the Bashang Plateau[J]. Hebei Geology and Mineral Information, 2004(2): 28-31.
[19] 魏仙样, 卢进才, 李玉宏, 等. 商都坳陷浅层CO2气藏成因与典型气藏分析[J]. 西安石油大学学报: 自然科学版, 2010, 25(3): 27-32.
Wei X Y, Lu J C, Li Y H, et al. Origin of shallow carbon dioxide gas reservoir in Shangdu Depression and the analysis of typical gas reservoir[J]. Journal of Xi'an Shiyou University (Natural Science Edition), 2010, 25(3): 27-32.
[20] 卢进才, 魏仙样, 曹萱铎, 等. 内蒙古商都地区CO2气藏地质条件研究[J]. 西北地质, 2002, 35(4): 122-134.
Lu J C, Wei X Y, Cao X D, et al. Research on CO2 gas pool-geological conditions in Shangdu area, Inner Mongolia[J]. Northwestern Geology, 2002, 35(4): 122-134.
[21] 卢进才, 李玉宏, 魏仙样, 等. 内蒙古商都地区二氧化碳(CO2)气藏勘查报告[R]. 西安: 西安地质矿产研究所, 2009: 18-39.
Lu J C, Li Y H, Wei X Y, et al. Investigation Report on CO2 Gas Reservoirs in the Shangdu Area, Inner Mongolia[R]. Xi'an: Xi'an Institute of Geology and Mineral Resources, 2009: 18-39.
[22] 河北省地矿局第三地质大队. 河北省张北县公会一带煤矿详查地质报告[R]. 2012: 81-105.
The Third Geological Brigade of Hebei Geological and Mineral Bureau. Geological Report on Detailed Prospecting of Coal Resources in the Gonghui Area, Zhangbei County, Hebei Province[R]. 2012: 81-105.
[23] 杜俐, 沈光银, 林银山. 华北地台北缘火山岩型铀钼矿床找矿模型研究[J]. 地质找矿论丛, 2012, 27(4): 458-462.
Du L, Shen G Y, Lin Y S. Prospecting model research of volcanics- hosted U-Mo deposits at north margin of the North China platform[J]. Contributions to Geology and Mineral Resources Research, 2012, 27(4): 458-462.
[24] 许洪才, 申宗义, 李新华, 等. 河北省沽源地区矿产成矿规律与找矿方向[J]. 地质调查与研究, 2016, 39(4): 260-272.
Xu H C, Shen Z Y, Li X H, et al. Metallogenic regularity and prospect of the Guyuan area, Hebei Province[J]. Geological Survey and Research, 2016, 39(4): 260-272.
[25] 王建青, 刘高杰, 董帅, 等. 河北省沽源县张麻井铀钼矿"三位一体"找矿预测地质模型[J]. 地质通报, 2023, 42(6): 931-940.
Wang J Q, Liu G J, Dong S, et al. The "trinity" prospecting prediction geological model of the Zhangmajing uranium molybdenum deposit in Guyuan county, Hebei Province[J]. Geological Bulletin of China, 2023, 42(6): 931-940.
[26] 董杰, 宫进忠, 赵琪. 河北省区域岩石物性调查成果报告[R]. 北京: 全国地质资料馆, 1994.
Dong J, Gong J Z, Zhao Q. Regional Rock Physical-property Survey Report of Hebei Province[R]. Beijing: National Geological Data Museum, 1994.
[27] 万卫, 陈振亚, 程志中, 等. CO2气体测量方法在低山丘陵区隐伏矿勘查的试验研究[J]. 物探与化探, 2019, 43(1): 70-76.
Wan W, Chen Z Y, Cheng Z Z, et al. Pilot study of CO2 gas measurement method for mineral exploration in hilly areas[J]. Geophysical and Geochemical Exploration, 2019, 43(1): 70-76.
[28] Moretti I, Prinzhofer A, Françolin J, et al. Long-term monitoring of natural hydrogen superficial emissions in a brazilian cratonic environment. sporadic large pulses versus daily periodic emissions[J]. International Journal of Hydrogen Energy, 2021, 46(5): 3615-3628.
[29] Milkov A V. Molecular hydrogen in surface and subsurface natural gases: abundance, origins and ideas for deliberate exploration[J]. Earth-Science Reviews, 2022, 230: 104063.
[30] 张亚东, 刘俊长, 龚红蕾, 等. 河北省矿产资源潜力评价重力资料应用研究[M]. 武汉: 中国地质大学出版社, 2017: 23-26.
Zhang Y D, Liu J C, Gong H L, et al. Application Research on Gravity Data in the Potential Evaluation of Mineral Resources in Hebei Province[M]. Hubei: China University of Geosciences Press, 2017: 23-26.
[31] 袁炳强, 张化安, 许延浪, 等. 集宁盆地商都坳陷重磁力场与石油地质特征[C]//2008年重磁数据处理解释应用研讨会. 杭州: 浙江大学, 中国地质大学, 2008: 76-81.
Yuan B Q, Zhang H A, Xu Y L, et al. The gravity-magnetic field and petroleum geological characteristics of Shangdu Depression in Jining Basin[C]//Symposium on the Processing, Interpretation and Application of Gravity-magnetic Data. Hangzhou: Zhejiang University, China University of Geosciences, 2008: 76-81.
-
