Application of comprehensive geophysical prospecting in polymetallic ores exploration in Xiaoshan area of Henan Province
-
摘要:
河南崤山地区位于豫西金钼铝土矿铅锌多金属成矿带，具有优越的成矿地质条件，但由于第四系和植被覆盖严重，难以开展传统地质填图和化探工作。采用高精度磁法、激电中梯和激电测深综合物探方法，结合钻探验证，查明崤山地区小妹河一带隐伏岩体、地层及构造分布，圈定多金属找矿有利靶区。研究结果表明: 燕山期花岗岩与太华群的接触带是多金属矿成矿的有利部位，而高磁异常+ 高阻高极化组合是识别隐伏花岗岩体的重要标志，花岗岩与安山岩的电性突变带(高阻-低阻过渡区)可能对应热液蚀变或多金属矿化体，高极化异常区与多金属矿化密切相关。综合物探方法为崤山地区的金矿勘查提供了高效、低成本的技术手段，研究成果对该区未来的找矿工作具有指导意义。
Abstract:Xiaoshan area in Henan Province is located in the gold-molybdenum-bauxite lead-zinc polymetallic mineralization belt in the western Henan, with superior geological conditions for mineralization. However, due to the severe Quaternary system and vegetation coverage, it is difficult to carry out traditional geological mapping and geochemical exploration work. By using comprehensive geophysical prospecting method of high-precision magnetic method, induced polarization midale gradient and induced polarization sounding, and combined with drilling verification, the authors identified the distribution of concealed rock masses, strata and structures in Xiaomeihe area of Xiaoshan, and delineated favorable target areas for polymetallic prospecting. The results show that the contact zone between Yanshanian granites and Taihua Group is a favorable location for polymetallic mineralization. The combination of high magnetic anomalies and high resistance and high polarization is an important indicator for identifying concealed granites. The electrical property mutation zone (high resistance-low resistance transition zone) between granites and andesites may correspond to hydrothermal alteration or polymetallic mineralized bodies. The high polarization anomaly zone is closely related to polymetallic mineralization. The comprehensive geophysical prospecting method provides efficient and low-cost technical means for gold exploration in Xiaoshan area. This research could provide references for future mineral exploration in this area.
-
-
表 1 研究区岩石物性参数
Table 1. Physical property parameters of rocks in the study area
岩石类别 视极化率/4π·10-6SI 电阻率/Ω·m 极化率/% 最小值 最大值 平均值 最小值 最大值 平均值 最小值 最大值 平均值 斜长角闪片岩 75 1 048 358 65 907 328 0.63 1.06 0.79 片麻状花岗岩 508 3 351 2 260 563 1 847 1 118 0.91 2.04 1.39 花岗斑岩 65 4 510 1 407 928 4 165 2 161 0.47 1.71 1.3 杏仁状安山岩 16 307 114 340 1 358 639 0.54 0.98 0.77 构造蚀变岩 - - - 32 264 118 1.57 3.55 2.24 注: “-”为无数据。
下载: 导出CSV
表 2 异常分区及异常体推测解释
Table 2. Explanation of anomaly zoning and anomaly body speculation
磁异常区域 特性 异常值/nT 异常面积/km2 异常体推测 C-01 磁力高 120~500 1.2 花岗斑岩 C-02 磁力高 160~600 0.2 片麻状花岗岩或花岗斑岩 C-03 磁力高 160~800 1.0 片麻状花岗岩或花岗斑岩 C-04 磁力高 120~900 1.0 斜长角闪岩 C-05 无磁异常 0~80 2.8 地表对应的第四系和安山岩
下载: 导出CSV
表 3 断裂构造推断解释
Table 3. Inference and explanation of fault structure
断裂编号 走向 长度/km 级别 F1 NNE向 1.0 一般断裂 F2 NNW向 1.1 一般断裂 F3 NNW向 1.1 一般断裂 F4 NWW向 0.5 一般断裂 F5 NWW向 0.8 一般断裂 F6 NEE向 1.2 一般断裂 F7 NNW向 3.0 较大断裂 F8 NWW向 0.9 一般断裂 F9 NEE向 0.6 一般断裂 F10 NWW向 0.9 一般断裂 F11 NNE向 1.2 一般断裂 F12 NNE向 0.8 一般断裂 F13 NNE向 0.8 一般断裂 F14 NNW向 1.4 一般断裂 F15 NNE向 1.5 较大断裂 F16 NNW向 0.9 一般断裂 F17 NWW向 0.7 一般断裂
下载: 导出CSV
-
[1] 李肖龙. 豫西熊耳山地区金矿成矿作用与找矿模型研究[D]. 北京: 中国地质大学(北京), 2021.
Li X L. Study on Mineralization and Prospecting Models of Gold Deposits in the Xiong'ershan, Western Henan Province[D]. Beijing: China University of Geosciences (Beijing), 2021.
[2] 刘文毅. 崤山—熊耳山地区金多金属矿床大数据分析与勘查靶区优选研究[D]. 长沙: 中南大学, 2022.
Liu W Y. Optimization of Exploration Targets and Big Data Analysis for gold Polymetallic Deposits in Xiaoshan-Xiongershan Area[D]. Changsha: Central South University, 2022.
[3] 王春永, 郭方方, 李军旗, 等. 豫西崤山矿集区薄脉型金银矿床地质特征及找矿远景[J]. 矿产勘查, 2021, 12(2): 221-228.
Wang C Y, Guo F F, Li J Q, et al. Geological characteristics and prospecting prospect of the thin vein type Au-Ag deposits in Xiaoshan ore-concentrated area, western Henan Province[J]. Mineral Exploration, 2021, 12(2): 221-228.
[4] 王晋定, 王大钊, 詹小飞, 等. 小秦岭金成矿区南矿带构造控矿规律和矿床定位样式[J]. 大地构造与成矿学, 2018, 42(6): 1064-1077.
Wang J D, Wang D Z, Zhan X F, et al. Structural controls on mineralization and distribution of orebodies in the southern ore belt of the Xiaoqinling District[J]. Geotectonica et Metallogenia, 2018, 42(6): 1064-1077.
[5] 王素琴, 梁天佑. 崤山地区东南部燕山期花岗岩对热液型银多金属矿床的控制作用研究[J]. 矿产勘查, 2022, 13(7): 873-886.
Wang S Q, Liang T Y. Research on controlling factors of Yanshanian granite on hydrothermal silver polymetallic deposits in southeastern Xiaoshan area[J]. Mineral Exploration, 2022, 13(7): 873-886.
[6] 张家嘉, 张顺林, 汪青松, 等. 综合物探方法在覆盖区找矿中的应用——以皖东五河金矿整装勘查为例[J]. 中国地质调查, 2020, 7(6): 109-115. doi: 10.19388/j.zgdzdc.2020.06.14
Zhang J J, Zhang S L, Wang Q S, et al. Application of comprehensive geophysical prospecting method in ore prospecting in coverage area: A case study of integrated survey area of Wuhe Gold Mine in Eastern Anhui[J]. Geological Survey of China, 2020, 7(6): 109-115. doi: 10.19388/j.zgdzdc.2020.06.14
[7] 邓经永. 综合物探方法在安徽明光市西张郢地区金矿找矿中的应用[J]. 中国地质调查, 2019, 6(3): 92-98. doi: 10.19388/j.zgdzdc.2019.03.13
Deng J Y. Application of comprehensive geophysical methods in gold deposits prospecting in Xizhangying area of Mingguang City in Anhui Province[J]. Geological Survey of China, 2019, 6(3): 92-98. doi: 10.19388/j.zgdzdc.2019.03.13
[8] 张落毅, 王西荣, 王学武, 等. 物化探在金寨县西岭冲铅锌多金属矿中的应用[J]. 中国地质调查, 2023, 10(3): 34-40. doi: 10.19388/j.zgdzdc.2023.03.04
Zhang L Y, Wang X R, Wang X W, et al. Application of geophysical and geochemical exploration methods in Xilingchong Pb-Zn polymetallic deposit of Jinzhai County[J]. Geological Survey of China, 2023, 10(3): 34-40. doi: 10.19388/j.zgdzdc.2023.03.04
[9] 陈炳锦. 地面高精度磁法在陕南西乡地区磁铁矿勘查中的应用[J]. 物探与化探, 2014, 38(6): 1129-1133.
Chen B J. The application of ground high-precision magnetic survey to the exploration of magnetite deposits in Xixiang area of southern Shaanxi Province[J]. Geophysical & Geochemical Exploration, 2014, 38(6): 1129-1133.
[10] 赖月荣, 韩磊, 杨树生. 高精度磁测在阿勒泰冰碛物覆盖区地质填图中的应用[J]. 物探与化探, 2014, 38(6): 1181-1185.
Lai Y R, Han L, Yang S S. The effects of applying high precision magnetic survey to geological mapping in Altay glacial till covering area[J]. Geophysical & Geochemical Exploration, 2014, 38(6): 1181-1185.
[11] 柳建新, 李庆华, 曾宥元, 等. 地面高精度磁法在塞拉利昂洛琴铁矿区的应用[J]. 物探与化探, 2014, 38(4): 649-653.
Liu J X, Li Q H, Zeng Y Y, et al. The application of the ground high-precision magnetic method to the Roten iron ore district in Sierra Leone[J]. Geophysical & Geochemical Exploration, 2014, 38(4): 649-653.
[12] 毕炳坤, 常云真, 施强, 等. 综合物探在崤山东部浅覆盖区勘查银多金属矿床中的应用[J]. 物探与化探, 2019, 43(5): 976-985.
Bi B K, Chang Y Z, Shi Q, et al. The application of geophysical exploration to prospecting for silver-lead-zinc deposits in shallow cover areas of eastern Xiaoshan[J]. Geophysical & Geochemical Exploration, 2019, 43(5): 976-985.
[13] 徐文超, 王通, 常云真, 等. 河南省崤山地区典型金矿床的成矿流体特征及其对进一步找矿工作的启示[J]. 矿产与地质, 2016, 30(1): 1-11.
Xu W C, Wang T, Chang Y Z, et al. Characteristics of the ore-forming fluid of typical gold deposits in Xiaoshan area of Henan and their enlightenment to further prospecting works[J]. Mineral Resources and Geology, 2016, 30(1): 1-11.
[14] 宋立强, 王春永, 宋仲科, 等. 崤山矿集区金多金属矿成矿模式与成矿预测[J]. 矿产勘查, 2015, 6(6): 715-724.
Song L Q, Wang C Y, Song Z K, et al. Metallogenic model and metallogenic prognosis of Xiaoshan gold polymetallic ore concentration area[J]. Mineral Exploration, 2015, 6(6): 715-724.
[15] 范海洋. 河南省崤山东部银多金属矿床成矿作用[D]. 北京: 中国地质科学院, 2018.
Fan H Y. Mineralization of Ag-Polymetallic Ore Deposits in the Eastern Xiaoshan, Henan Province[D]. Beijing: Chinese Academy of Geological Sciences, 2018.
[16] 李照义, 李中明, 张宇, 等. 河南省金矿成矿规律及成矿系列[J/OL]. 矿产勘查, 1-23[2025-07-15].
https://link.cnki.net/urlid/11.5875.TD.20250517.1030.002 .Li Z Y, Li Z M, Zhang Y, et al. The metallogenic regularity and metallogenic series of gold deposits in Henan Province[J/OL]. Mineral Exploration, 1-23[2025-07-15].
https://link.cnki.net/urlid/11.5875.TD.20250517.1030.002 .[17] 中华人民共和国地质矿产部. DZ/T 0071—93地面高精度磁测技术规程[S]. 北京: 地质出版社, 1996: 1-8.
Ministry of Geology and Mineral Resources of the PRC. DZ/T 0071—93 Technical Regulations for Ground High-Precision Magnetic Measurement[S]. Beijing: Geological Publishing House, 1996: 1-8.
-
